MAZDA MODEL CX-50 2023 Owners Manual

▼Dimensions
Item
Vehicle specification
Overall length 4,720 mm (185.8 in)
Overall width 1,920 mm (75.6 in)
Overall height Without roof rail
and roof antenna
17 inch wheel ve-
hicle
1,604 mm (63.2 in)
20 inch wheel ve-
hicle 1,613 mm (63.5 in)
With roof rail or
roof antenna 17 inch wheel ve-
hicle
1,613 mm (63.5 in)
20 inch wheel ve-
hicle 1,622 mm (63.9 in)
Front tread 17 inch wheel vehicle
1,658 mm (65.3 in)
20 inch wheel vehicle 1,648 mm (64.9 in)
Rear tread 17 inch wheel vehicle
1,662 mm (65.5 in)
20 inch wheel vehicle 1,652 mm (65.1 in)
Wheelbase 2,815 mm (110.8 in)
▼Weights
U.S.A. and Canada
SKYACTIV-G 2.5
Item Weight
FWD AWD
GVWR (Gross Vehicle Weight Rating) 2,074 kg (4,572 lbs) 2,199kg (4,848 lbs)
GAWR (Gross Axle Weight
Rating) Front 1,090 kg (2,403 lbs) 1,133 kg (2,498 lbs)
Rear 996 kg (2,196 lbs) 1,079 kg (2,379 lbs)
SKYACTIV-G 2.5T
Item
Weight
GVWR (Gross Vehicle Weight Rating) 2,243 kg (4,945 lbs)
GAWR (Gross Axle Weight
Rating) Front
1,182 kg (2,606 lbs)
Rear 1,073 kg (2,366 lbs)
Specifications
Specifications
9-6
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

Mexico
SKYACTIV-G 2.5
Item Weight
FWD AWD
GVW (Gross Vehicle
Weigh t ) Total
2,109 kg (4,650 lbs) 2,272 kg (5,009 lbs)
Front 1,095 kg (2,414 lbs) 1,186 kg (2,615 lbs)
Rear 1,014 kg (2,235 lbs) 1,086 kg (2,394 lbs)
GAW (Permissible axle load) Front
1,118 kg (2,465 lbs) 1,209 kg (2,665 lbs)
Rear 1,066 kg (2,350 lbs) 1,138 kg (2,509 lbs)
SKYACTIV-G 2.5T
Item Weight
GVW (Gross Vehicle
Weigh t ) Total
2,272 kg (5,009 lbs)
Front 1,186 kg (2,615 lbs)
Rear 1,085 kg (2,392 lbs)
GAW (Permissible axle load) Front
1,209 kg (2,665 lbs)
Rear 1,138 kg (2,509 lbs)
▼Light Bulbs
Exterior light/Interior light
All the light bulbs are the LED type.
The LED bulb cannot be replaced. Consult an Authorized Mazda Dealer when the
replacement is necessary.
▼Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type
originally fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for
tire size and inflation pressure.
Refer to Tire Pressure Label on page 9-2.Refer to Tire Inflation Pressure on page 6-31.
Specifications
Specifications
9-7
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

Standard tire
(U.S.A. and Canada)
Tire sizeInflation pressure
Front Rear
225/65R17 102H 250 kPa (36 psi)250 kPa (36 psi)
245/45R20 99V 240 kPa (35 psi)240 kPa (35 psi)
(Mexico)
Tire size Inflation pressure
Front Rear
225/65R17 102H 250 kPa (2.5 bar, 36 psi) 250 kPa (2.5 bar, 36 psi)
245/45R20 99V 240 kPa (2.4bar, 35 psi) 240 kPa (2.4bar, 35 psi)
Temporary spare tire
(U.S.A. and Canada)
Tire size Inflation pressure
T155/90D17 101M 420 kPa (60 psi)
(Mexico)
Tire sizeInflation pressure
185/80R17 99M 320 kPa (3.2 bar, 46 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108―147 N·m (12―14 kgf·m, 80―108 ft·lbf)
▼Fuses
Refer to Fuses on page 6-35.
Specifications
Specifications
9-8
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18

10Index
10-1
CX-50_8KB8-EA-22A_Edition2_new2022-1-6 14:55:18

Index
A
Accessory Socket....................... 5-41
Active Driving Display................4-35
Adaptive Front Lighting System
(AFS)........................................ 4-93
Add-On Non-Genuine Parts and
Accessories............................... 8-16
Advanced KeyAdvanced keyless entry
system................................... 3-9
Operational range................ 3-10
Advanced Keyless Entry System..... 3-9
Antilock Brake System (ABS).......4-78
Assist Grips............................... 5-48
AUTOHOLD.............................. 4-73
AUTOHOLD Warning Beep........ 7-39
Automatic Transmission Active Adaptive Shift (AAS)... 4-40
Automatic transmission
controls................................4-37
Direct mode.........................4-47
Driving tips.......................... 4-48
Manual shift mode............... 4-41
Shift-lock system...................4-38
Transmission ranges.............. 4-39
B
Battery...................................... 6-27Maintenance........................ 6-28
Replacement........................ 6-28
Specifications......................... 9-4
Battery Runs Out....................... 7-11
Jump-starting....................... 7-11
Blind Spot Assist......................4-141
Blind Spot Monitoring (BSM)..... 4-99
Canceling operation of Blind Spot
Monitoring (BSM)...............4-103
Blind Spot Monitoring (BSM) Warning
Beep.........................................7-39
Body Lubrication....................... 6-22
Bottle Holder............................ 5-48
Brakes
Brake assist.......................... 4-72
Brake override system........... 4-72
Electric Parking Brake (EPB)....4-68
Foot brake............................4-67
Pad wear indicator................4-72
Parking brake....................... 4-68
Warning light........................4-72
Brake Override System............... 4-72
Brake Override Warning Beep.....7-38
Break-In Period......................... 3-46
C
Capacities...................................9-5
Cell Phones.............................. 8-17
Center Console......................... 5-50
Child Restraint Categories of child-restraint
systems................................ 2-36
Child-restraint precautions.... 2-31
Child-restraint system
installation........................... 2-36
Child-restraint system suitability
for various seat positions
table.................................... 2-38
Installing child-restraint
systems................................ 2-41
ISOFIX child-restraint systems
(Mexico).............................. 2-47
LATCH child-restraint systems
(Except Mexico)................... 2-47
Climate Control System Fully automatic type..............5-10
Manual type...........................5-6
Operating tips........................ 5-2
Vent operation....................... 5-3
Collision warning...................... 7-40
Coming Home Light.................. 4-52
10-2
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

Index
Cruise Control........................ 4-198Cruise control switch.......... 4-198
Cruise standby indication (white)/
cruise set indication (green) ..........
......................................... 4-198
Cup Holder.............................. 5-47
Customer Assistance (Canada)..... 8-6
Customer Assistance (Mexico)..... 8-9
Customer Assistance (Puerto
Rico).......................................... 8-8
Customer Assistance (U.S.A.)....... 8-2
Cylinder Deactivation................ 4-10
D
Daytime Running Lights............. 4-53
Defogger.................................. 4-59 Mirror.................................. 4-60
Rear window........................ 4-59
Dimensions.................................9-6
Display..................................... 4-18
Distance & Speed Alert (DSA).. 4-110 Indication on display...........4-111
Door Locks............................... 3-11
Door-ajar Warning Beep............ 7-40
Driver Attention Alert (DAA).... 4-111
Driving In Flooded Area............. 3-51
Driving on Uneven Road............ 3-52
Driving Position Memory........... 2-10
Driving Tips...............................3-46 Automatic transmission......... 4-48
Break-in period.................... 3-46
Driving in flooded area......... 3-51
Driving on uneven road.........3-52
Floor mat............................. 3-48
Hazardous driving.................3-47
Overloading......................... 3-51
Rocking the vehicle...............3-49
Saving fuel and protection of the
environment.........................3-46
Turbocharged vehicles (SKYACTIV-
G 2.5T)................................ 3-52
Winter driving...................... 3-49
Dynamic Stability Control
(DSC)....................................... 4-81 TCS/DSC indicator light........4-81
E
Electric Parking Brake (EPB)........ 4-68
Electric Parking Brake (EPB) Warning
Beep.........................................7-39
Emergency Lane Keeping (ELK) ..........
.............................................. 4-141Blind Spot Assist................. 4-141
Road Keep Assist................ 4-144
Emergency Starting Push-starting........................ 7-14
Starting a flooded engine...... 7-14
Emergency Towing Tiedown hooks..................... 7-18
Towing description............... 7-17
Emission Control System............ 3-28
Engine Coolant............................... 6-19
Engine compartment
overview.............................. 6-14
Exhaust gas.......................... 3-28
Hood release....................... 6-12
Oil....................................... 6-16
Starting.................................. 4-5
Essential Information................... 6-2
Event Data Recorder.................. 8-18
Excessive Speed Warning........... 7-40
Exterior Care............................. 6-43 Aluminum wheel
maintenance........................ 6-48
Bright-metal maintenance..... 6-47
Maintaining the finish........... 6-44
Plastic part maintenance....... 6-48
10-3
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

Index
F
FlasherHazard warning.................... 4-61
Headlights............................4-49
Flat Tire Changing a flat tire................. 7-5
Mounting the spare tire.......... 7-9
Removing a flat tire................ 7-6
Floor Mat................................. 3-48
Fluids Brake/Clutch........................6-20
Classification.......................... 9-4
Washer................................ 6-21
Foot Brake................................ 4-67
Forward Sensing Camera (FSC) ..........
.............................................. 4-189
Front Camera/Side Cameras/Rear
Camera.................................. 4-197
Front Radar Sensor.................. 4-193
Fuel Filler lid and cap...................3-29
Requirements....................... 3-27
Tank capacity......................... 9-5
Fuses........................................ 6-35 Panel description.................. 6-38
Replacement........................ 6-35
G
Gauges..................................... 4-18
Glove Compartment..................5-50
H
Hazardous Driving.....................3-47
Hazard Warning Flasher............. 4-61
HeadlightsComing home light...............4-52
Flashing................................4-52
High-low beam.................... 4-52
Leaving home light............... 4-52
Leveling................................4-53
Head Restraint.......................... 2-15
High Beam Control System
(HBC)....................................... 4-93 High Beam Control System (HBC)
indicator light (green)........... 4-94
Hill Launch Assist (HLA)............. 4-77
HomeLink Wireless Control
System...................................... 4-62
Hood Release........................... 6-12
Horn........................................ 4-61
I
If a Warning Light Turns On or
Flashes......................................7-20
If the Active Driving Display Does Not
Operate.................................... 7-42
Ignition Not Switched Off (STOP)
Warning Beep........................... 7-37
Ignition Switch............................ 4-4
Illuminated Entry System............ 5-40
Immobilizer System................... 3-42
Inspecting Brake/Clutch Fluid
Level.........................................6-20
Inspecting Coolan t Level............ 6-19
Inspecting Engine Oil Level.........6-18
Inspecting Washer Fluid Level..... 6-21
Instrument Cluster..................... 4-18 Average fuel economy...........4-26
Compass display.................. 4-27
Current fuel economy........... 4-26
Dashboard illumination........ 4-24
Distance-to-empty................4-25
Engine coolant temperature
gauge...................................4-22
Fuel gauge........................... 4-23
Indication/indicator lights..... 4-31
i-ACTIVSENSE display........... 4-27
Mazda intelligent Drive Select
(Mi-Drive) Display................ 4-26
10-4
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

Index
Message Display................... 4-28
Message indicated on multi-
information display............... 7-32
Multi-information display...... 4-20
Odometer............................ 4-22
Outside temperature
display................................. 4-25
Speedometer....................... 4-18
Tachometer.......................... 4-19
Trip meter............................ 4-22
Warning indication/warning
lights....................................4-29
Interior Care............................. 6-49 Active driving display
maintenance........................ 6-51
Cleaning the floor mats......... 6-52
Cleaning the window
interiors............................... 6-52
Instrument panel top (Soft pad)
maintenance........................ 6-51
Leather upholstery
maintenance........................ 6-50
Panel maintenance............... 6-51
Plastic part maintenance....... 6-50
Seat belt maintenance.......... 6-49
Upholstery maintenance....... 6-50
Vinyl upholstery
maintenance........................ 6-50
Interior Lights............................ 5-39 Luggage compartment light... 5-39
Map lights............................5-39
Overhead lights.................... 5-39
i-ACTIVSENSE........................... 4-89 Active safety technology........ 4-89
Adaptive Front Lighting System
(AFS)................................... 4-93
Blind Spot Monitoring
(BSM).................................. 4-99
Camera and sensors............. 4-89
Distance & Speed Alert
(DSA)................................ 4-110Driver Attention Alert
(DAA)................................ 4-111
Emergency Lane Keeping
(ELK).................................. 4-141
Forward Sensing Camera
(FSC)................................. 4-189
Front camera/side cameras/rear
camera...............................4-197
Front radar sensor...............4-193
High Beam Control System
(HBC).................................. 4-93
i-ACTIVSENSE OFF Switch..... 4-92
i-ACTIVSENSE status symbol
(warning/risk avoidance support
system)................................ 4-90
Lane Departure Warning System
(LDWS)................................ 4-95
Lane-keep Assist System
(LAS)..................................4-137
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function)........... 4-117
Pre-crash safety technology... 4-89
Rear Cross Traffic Alert
(RCTA)............................... 4-113
Rear side radar sensor......... 4-195
Smart Brake Support (SBS)...4-148
Tra ffi c Jam Assist (TJA)......... 4-124
Tra ffi c Sign Recognition
System (TSR)...................... 4-104
Ultrasonic sensor................ 4-196
360°view monitor...............4-156
i-ACTIV AWD Operation........... 4-86
i-stop....................................... 4-11 Indicator light (Green).......... 4-16
i-stop OFF switch................. 4-15
Vehicle roll prevention
function............................... 4-15
Warning light (Amber).......... 4-16
i-stop warning beep.................. 7-38
10-5
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

Index
J
Jack............................................ 7-3
Jump-Starting............................ 7-11
K
Keyless Entry System.................... 3-4
Keys........................................... 3-2Key suspend function..............3-8
Transmitter............................. 3-5
Key Left-in-luggage Compartment
Warning beep (With the advanced
keyless function)....................... 7-38
Key Left-in-vehicle Warning Beep
(With the advanced keyless
function)...................................7-38
Key Removed from Vehicle Warning
Beep.........................................7-37
Key Suspend Function................. 3-8
L
Label Information Chassis number...................... 9-2
Engine number....................... 9-3
Motor vehicle safety standard
label...................................... 9-2
Tire pressure label.................. 9-2
Vehicle emission control
information label.................... 9-2
Vehicle identification
number..................................9-2
Lane Departure Warning System
(LDWS).....................................4-95
Lane-change Signals.................. 4-54
Lane-keep Assist System (LAS) ...........
.............................................. 4-137
Lane/Road Departure Warning
Beep.........................................7-39
Leaving Home Light................... 4-52
Liftgate..................................... 3-19
When liftgate cannot be
opened................................ 7-41
Liftgate Door-lock Switch Inoperable
Warning Beep........................... 7-37
Lights-on Reminder................... 7-36
Light Bulbs Replacement........................ 6-34
Specifications ......................... 9-7
Lubricant Quality......................... 9-4
Luggage Compartment.............. 5-50 Cargo sub-compartment....... 5-50
Luggage Compartment Light...... 5-39
M
Maintenance Information............................ 6-2
Scheduled (Canada)............... 6-6
Scheduled (Mexico)................6-8
Scheduled (U.S.A. and Puerto
Rico)......................................6-4
Map Lights................................ 5-39
Mazda Connect........................ 5-15 Appendix............................. 5-28
Connected Service................5-36
Mazda Connect Basic
Operations........................... 5-19
Mazda intelligent Drive Select (Mi-
Drive) (AWD)............................4-83
Mazda intelligent Drive Select (Mi-
Drive) (FWD)............................ 4-82
Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop
& Go function)........................4-117 Close proximity warning...... 4-119
Display indication............... 4-118
Setting the system...............4-120
Stop hold control............... 4-123
10-6
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

Index
Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop
& Go function) System
Warnings.................................. 7-40
Message Indicated on Multi-
information Display................... 7-32
Meters...................................... 4-18
MirrorsOutside mirrors.................... 3-32
Rearview mirror.................... 3-34
Mirror Defogger........................ 4-60
Multi-information Display.......... 4-20
O
Outside Mirrors.........................3-32
Overhead Console.................... 5-49
Overhead Lights........................ 5-39
Overheating.............................. 7-15
Overloading.............................. 3-51
Owner Maintenance Closing the hood..................6-13
Engine compartment
overview.............................. 6-14
Key battery replacement........6-29
Opening the hood................ 6-12
Owner maintenance
precautions.......................... 6-11
P
Panorama sunroof..................... 3-39
Parking Brake............................ 4-68
Parking Sensor System............. 4-215
Power Liftgate........................... 3-22
Power Liftgate Warning Beep...... 7-38
Power Steering.......................... 4-88
Power Windows........................ 3-36
R
Rearview Mirror........................ 3-34
Rear Coat Hooks....................... 5-49
Rear Cross Tra ffi c Alert (RCTA) ...........
.............................................. 4-113
Rear Cross Traffic Alert (RCTA)
Warning Beep........................... 7-39
Rear Door Child Safety Locks..... 3-18
Rear Side Radar Sensor............ 4-195
Rear View Monitor.................. 4-206 Displayable range on the
screen................................ 4-208
Rear view monitor
operation........................... 4-210
Rear view parking camera
location............................. 4-207
Switching to the rear view monitor
display............................... 4-208
Variance between actual road
conditions and displayed
image................................ 4-213
Viewing the display.............4-209
Rear Window Defogger............. 4-59
Rear Window Washer................ 4-58
Rear Window Wiper.................. 4-58
Recommended Oil.................... 6-16
Recording of Vehicle Data..........8-19
Recreational Towing.................. 3-61
Registering Your Vehicle in A Foreign
Country.................................... 8-15
Replacement Fuse..................................... 6-35
Key battery........................... 6-29
Light bulbs........................... 6-34
Tires.....................................6-32
Wheel.................................. 6-34
Wiper.................................. 6-22
Road Keep Assist.....................4-144
Rocking the Vehicle................... 3-49
S
Safety Defects, Reporting
(Canada).................................. 8-13
10-7
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18
