MAZDA MODEL CX-7 2009 Navigation Manual (in English)

11
Before Use
Ifnecessary
Rear View
Monitor
MEMO
'<C)%FSSO4EKI8YIWHE]1EVGL%1

12
RoutingAddress
Book
Getting started
Activation
Insert the map disc into the unit to start the Mobile Navigation System.
Note
l
The map disc cannot be inserted or ejected while the ignition switch is in the OFF position.
l Remember that the battery can run down if the ignition switch is kept in the ACC or ON
position for a long time while the engine not running.
nMap Disc
l Refer to “Handling and Care of Map Discs” to know how to handle a map
disc ( page 60).
1
Insert the map disc
with the printed side
facing up.Note
lThe main unit is located under the front passenger
seat.
l Condensation may form on the optical lens or the
map disc inside the unit when the temperature in
the vehicle increases in a short time such as when
heating the car on a cold day. This condensation
may cause malfunctions. If so, unload the map disc
and do not operate the unit for approximately 1
hour. Wipe the condensation off the map disc with a
soft cloth.
If the unit does not operate correctly after 1 hour,
consult an Authorized Mazda Dealer.
Note
lWhen the ignition switch is in the ACC or ON
position, the screen changes as follows to activate
the navigation system.
l The screen (audio or navigation) that was displayed
prior to the engine being turned off is displayed.
Before the navigation screen is displayed, the
CAUTION screen will be displayed.
Cautions
(CAUTION) screen
'<C)%FSSO4EKI8YIWHE]1EVGL%1

13
Getting started
Ifnecessary
Rear View
Monitor
lThe Current Position screen appears.
Note
lYou can select the language by selecting the on-screen button. You can also
change the selected language using Language Selection. ( page 20)
l The CAUTION screen remains on the display unless you select the on-screen
button.
If the mobile telephone is programmed to the hands-free unit for use with the Bluetooth
hands-free telephone, the Bluetooth hands-free information is displayed on the screen
momentarily. While this information is displayed, the on-screen button cannot be
selected. Select the on-screen button after the display is cleared.
Select the on-screen button lightly with your finger.
Colors for unavailable buttons will be pale.
2
Read the CAUTION
carefully, and select
the on-screen
button.
Removing the Map Disc
1
With the ignition switch in the ACC position, remove the cover.
2
Press (EJECT).
On-screen Buttons
Most functions are inhibited while the
vehicle is in motion.
Please read the handbook for operation
instructions.
Always obey traffic regulations.
Caution
Scre Scre
Br
Do not get your hand or fingers caught in
moving parts or in the disc slot. This can
cause injuries. Children are inquisitive, try
to install or remove the map disc without
infants looking on.
Caution
'<C)%FSSO4EKI8YIWHE]1EVGL%1

14
RoutingAddress
Book
Getting started
Menu
Menu appears when pressing . MENU
Destination Entry and Route Search ( page 30)
Address Book ( page 46)
Cancel Guidance ( page 41)
Route Options ( page 42)
Volume ( page 52)
Set Clock ( page 15)
Navigation Set Up ( page 16)
'<C)%FSSO4EKI8YIWHE]1EVGL%1

15
Getting started
Ifnecessary
Rear View
Monitor
Set Clock
The current time is set using this function. Since time notification is provided by a GPS
satellite.
Before Steps select MENU
Open the [SET CLOCK] screen
Select if you prefer 24-hour display;
for 12-hour display.
Select to move the setting ahead by one hour,
and similarly, select to move it back by one
hour.
How to exit .
Note
Minutes and seconds are adjusted by the GPS, however, it is necessary to
adjust hours under the following conditions:
lDriving across different time zones
l Daylight saving time start and end
'<C)%FSSO4EKI8YIWHE]1EVGL%1

16
RoutingAddress
Book
Getting started
Navigation Set Up
l
You can alter the map display conditions, the route guidance conditions and show the
system information.
nStop your vehicle before the following operations. Do not change the settings and destination locations while driving. Minimize the time
spent viewing the monitor screen and listening to the voice guidance while driving.
Operating the system will distract the driver from looking ahead of the vehicle and may
cause an accident.
Always stop the vehicle in a safe location and put the parking brake on before operating
the system.
Before Stepsselect
Warning
MENU
Open
[NAVIGATION SET UP] ( page 17)
( page 19)
( page 20)
( page 21)
( page 22)
( page 24)
'<C)%FSSO4EKI8YIWHE]1EVGL%1

17
Getting started
Ifnecessary
Rear View
Monitor
Navigation Set Up
Before Steps
select
select
User Setting
MENU
Open the
[USER SETTINGS]
screen
nMap Color
Select a screen color from to options.
nMap Mode
lAuto : The display will automatically switch between Day
and Night illumination mode when the headlights are
turned off and on respectively.
lDay :The display will be presented in Day illumination mode
regardless of whether the headlights are on or off.
lNight : The display will be presented in Night illumination mode regardless of whether the headlights are on or off.
nDistance
Select the distance unit from or .
nAverage Speed
Set the average speed for each road to be driven.
(This function sets the standard speed (average vehicle speed
for each route) used for calculating the estimated arrival time
when calculating the route time.)
: Average speed setting:Changes back to default
nRoad Restriction Warnings
The display of warnings during route guidance when passing
through areas with traffic restrictions can be turned on or off.
'<C)%FSSO4EKI8YIWHE]1EVGL%1

18
RoutingAddress
Book
Getting started
Navigation Set Up
Before Steps
select
select

User Setting
MENU
Open the
[USER SETTINGS]
screen
nArrival Time
The time which is displayed until reaching the destination or a
way point can be set as an estimated arrival time or the
remaining time.
Select to display the estimated arrival time, or to
display the remaining time.
nKeyboard Layout
The layout of input keys can be selected as or .
nClock
Allows selection of whether clock is to be displayed.
When the time display setting is switched on in the "USER
SETTINGS" screen on the navigation screen, the time will be
displayed on the navigation, SETTINGS, SOUND, LOAD/
EJECT, and DISPLAY MODE screens.
Even if the display of the clock on the navigation is not set, the
clock on the information display remains displayed.
nBeep
Allows selection of whether beep will sound.
'<C)%FSSO4EKI8YIWHE]1EVGL%1

19
Getting started
Ifnecessary
Rear View
Monitor
Navigation Set Up
This function allows you set the categories on the area displayed when the (Point of Interest)
menu is selected on the map. Quick POI enables you store up to six different kinds of
categories which you use most regularly.
1 select
2 Select
Quick POI Selection
MENU
Open the [QUICK POI SELECTION] screen
Select the button for Quick POI storage.
Note
lSelect the category to be changed
: This button allows you to restore the factory
settings.
Select a category.
Once selected, subcategories will be displayed.
: Subcategories from all of the individual categories will be
displayed together.
Select the subcategories to be displayed on the
map.
Repeat the above steps to add further POI markers displayed on the menu.
'<C)%FSSO4EKI8YIWHE]1EVGL%1

20
RoutingAddress
Book
Getting started
Navigation Set Up
You can change the language of the menu and the voice guidance.
Before Steps
select
select

Language
MENU
Open the [LANGUAGE] screen
Select your preferred language from the list.
