Ambient Light*
The ambient lights continuously turn on when the ignition is switched ON.
The ambient lights dim when the parking lights or headlights ar e turned on.
Ambient light
NOTE
•The ambient lights turn on or off in conjunction with the illuminated entry system when
the ignition is switched OFF.
•The ambient light illumination level can be ch anged while the parking lights or headlights
are turned on.
Refer to Personalization Features on page 9-11.
Interior Features
Interior Equipment
5-94*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Light Bulbs
Type A (With Adaptive Front Lighting System (AFS))
Type B (Without Adaptive Front Lighting System (AFS))Rear side-marker lights
Rear turn signal lights Brake lights
License plate lights
Headlights (Low/High beam) High-mount brake light
Overhead lights (Front)/
Map lights (Front) Luggage compartment light
Vanity mirror lights
Daytime running lights/
Parking lights Taillights
Ambient lights
Reverse lights
Fog lights
Front turn signal lights
Fog lights
Map lights (Center) Overhead light (Rear)
Rear side-marker lights
Rear turn signal lights Brake lights
License plate lights
Headlights (Low/High beam)/
Daytime running lights High-mount brake light
Overhead lights (Front)/
Map lights (Front) Luggage compartment light
Vanity mirror lights
Reverse lights
Front turn signal lights
Map lights (Center)Overhead light (Rear)
Parking lights/Front
side-marker lights
Front side-marker lights
Some models.
Side turn
signal lights
Side turn
signal lights
Signature wing
illumination
Brake lights/Taillights
Brake lights/Taillights
Ambient lights
Maintenance and Care
Owner Maintenance
6-45
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

CAUTION
When removing the lens or lamp unit using
a flathead screwdriver, make sure that the
flathead screwdriver does not contact the
interior terminal. If the flathead screwdriver
contacts the terminal, a short circuit may
occur.
NOTE
•To replace the bulb, contact an
Authorized Mazda Dealer.
•Use the protective cover and carton for
the replacement bulb to dispose of the
old bulb promptly and out of the reach
of children.
▼Replacing Exterior Light Bulbs
Headlights (type
A), Headlights/
Daytime running lights (type B), Front
turn signal lights (type A), Daytime
running lights/Parking lights (type A),
Front side-marker lights (type A),
Signature wing illumination (type A)*,
Fog lights*, Brake lights, Taillights,
High-mount brake light, Side turn
signal lights, Rear side-marker lights
The LED bulb cannot be replaced as a
single unit because it is an integrated unit.
The LED bulb has to be replaced with the
unit. We recommend an Authorized
Mazda Dealer when the replacement is
necessary.
Front turn signal lights (type B),
Parking lights/Front side-marker lights
(type B)
NOTE
When replacing a bulb for the front turn
signal lights and parking lights/front
side-marker lights, turn the steering wheel
and change the direction in which the tires
are pointed to the position where the bulb
replacement can be done easily.
Turn the steering wheel after starting the
engine and stop the engine after you finish
turning the steering wheel.
1. If you are changing the right bulb, start
the engine, turn the steering wheel all
the way to the right, and turn off
engine. If you are changing the left
bulb, turn the steering wheel to the left,
and turn off engine.
2. Make sure the ignition is switched off, and the headligh t switch is off.
3. Turn the screw counterclockwise and remove it.

Maintenance and Care
Owner Maintenance
6-46*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

3. Pull the fuse straight out with the fuse
puller provided on the fuse block
located in the engine compartment.
4. Inspect the fuse and replace it if it is blown.
Normal Blown
5. Insert a new fuse of the same
amperage rating, and make sure it fits
tightly. If it does not fit tightly, have an
expert install it. We recommend an
Authorized Mazda Dealer.
If you have no spare fuses, borrow one
of the same rating from a circuit not
essential to vehicle operation, such as
the AUDIO or OUTLET circuit.
CAUTION
Always replace a fuse with a genuine
Mazda fuse or equivalent of the same
rating. Otherwise you may damage the
electric system.
6. Reinstall the cover and make sure that it is securely installed.
Replacing the fuse s under the hood
If the headlights or other electrical
components do not work and the fuses in
the cabin are normal, inspect the fuse
block under the hood. If a fuse is blown, it
must be replaced. Follow these steps:

1. Make sure the ignition is switched off, and other switches are off.
2. Remove the fuse block cover.
Maintenance and Care
Owner Maintenance
6-54
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

▼Light Bulbs
Exterior light
With Adaptive Front Li
ghting System (AFS)
Light bulb Category
Wattage UNECE*1 (SAE)
Headlights High beam
LED
*2― (―)
Low beam LED
*2― (―)
Daytime running lights/Parking lights LED
*2― (―)
Front side-marker lights LED
*2― (―)
Front turn signal lights LED
*2― (―)
Fog lights LED
*2― (―)
Signature wing illumination
*LED*2― (―)
Side turn signal lights LED
*2― (―)
High-mount brake light LED
*2― (―)
Rear turn signal lights 21 WY21W (7443NA)
Rear side-marker lights LED
*2― (―)
Brake lights/Taillights LED
*2― (―)
Brake lights LED
*2― (―)
Taillights LED
*2― (―)
Reverse lights 18 W16W (921)
License plate lights 5W5W (―)
*1 UNECE stands for United Nations Economic Commission for Europe.*2 LED is the abbreviation for Light Emitting Diode.

Specifications
Specifications
*Some models.9-7
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Without Adaptive Front Lighting System (AFS)
Light bulbCategory
Wat tage UNECE*1 (SAE)
Headlights High beam
LED
*2― (―)
Low beam LED
*2― (―)
Daytime running lights LED
*2― (―)
Parking lights/Front side-marker lights 5 WY5W (―)
Front turn signal lights 21WY21W (7443NA)
Fog lights
*LED*2― (―)
Side turn signal lights LED
*2― (―)
High-mount brake light LED
*2― (―)
Rear turn signal lights 21 WY21W (7443NA)
Rear side-marker lights LED
*2― (―)
Brake lights/Taillights LED
*2― (―)
Brake lights LED
*2― (―)
Reverse lights 18 W16W (921)
License plate lights 5W5W (―)
*1 UNECE stands for United Nations Economic Commission for Europe.*2 LED is the abbreviation for Light Emitting Diode.

Specifications
Specifications
9-8*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

ItemFeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Keyless entry
system (page 3-
3) Method for unlocking door using transmitter
Once: Driv-
er's, Twice: All Doors Once: Driver's,
Twice: AllDoors/
Touch Once: All Doors AE
Time for locking door automatically
60 seconds90 seconds/
60 seconds/
30 seconds A―
Advanced key-
less entry system
(page 3-10) Method for unlocking door using request
switch/transmitter
Once: Driv-
er's, Twice: All Doors Once: Driver's,
Twice: AllDoors/
Touch Once: All Doors A
E,
FTime for locking door automatically 60 seconds90 seconds/
60 seconds/
30 seconds A―
Auto-lock function operation/non-operational Off On/Off A ―
Beep volume when locking/unlocking
MediumHigh/
Medium/ Low/Off A
E,
F
Illuminated en-
try system (page
5-95) Time until interior lights turn off after closing
door
15 seconds60 seconds/
30 seconds/
15 seconds/
7.5 seconds A―
Time until interior lights turn off automatically
when any door is not closed completely
30 minutes60 minutes/
30 minutes/
10 minutes A―
Auto-wiper con-
trol (page 4-55)
Operational/non-operational On or Off
On/Off*4A―
Daytime running
lights (page 4-
53)Operational/non-operational On On/Off ― ―
Auto headlight
off*5 (page 4-49)
Time until headlights
turn off 30 seconds120 seconds/
90 seconds/
60 seconds/
30 seconds/
0 seconds
*6
A―
Specifications
Personalization Features
9-14
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

ItemFeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Auto-light con-
trol (page 4-49) Timing by which lig
hts turn on Medium Light/
Medium Light/ Medium/
Medium Dark/ Dark A―
High Beam Con-
trol System
(HBC) (page
4-88)
Operational/non-operational
*1On On/Off A ―
Adaptive Front
Lighting System
(AFS) (page
4-87)Operational/non-operational
*1On On/Off A ―
Lights-on re-
minder*7 (page
7-47) Warning beep volume High High/Low/Off A ―
Coming home
light (page 4-52)
Time until headlights turn off 30 seconds 120 seconds/
90 seconds/
60 seconds/
30 seconds/ Off A―
Leaving home
light (page 4-52)
Operational/non-operational On On/Off A ―
Turn indicator
(page 4-54)Beep volume High High/Low A ―
Three-flash turn
signal (page
4-55)Operational/non-operational On On/Off A ―
Ambient Light-
ing (page 5-92)
Ambient lights brightness*8MediumBright/
Medium/ Dark/
Off
*9
A―
Rear window
defogger (page
4-59) The operation time for the rear window defog-
ger can be changed.
15 minutes15 minutes/
Continuous
*10――
System
Language Language indicated in display US EnglishDepends on
market
*11A―
Temperature Temperature unit indi cated in display °F or °C °F/°C A ―
Distance Distance unit indicated in display miles or km miles/km A ―
Specifications
Personalization Features
9-15
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

ItemFeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Fuel Economy Monitor (page 4-77)
Ending display On/off Off On/Off B ―
Fuel economy
resetting proce-
dure Linkage/non-linkage with fuel economy reset
and trip meter reset
Off On/Off B ―
Active driving display
(page 4-28)
Display Setting can be changed so that the Active Driv-
ing Display is not displayed.
On On/Off C ―
The display height (up/down position) can be
changed.
013 steps up/
down from ini-
tial setting (total: 27 steps) C―
The method for adjusting the display bright-
ness (automatically/manually) can be changed.
AUTOAUTO/
MANUAL C―
The standard brightness with the automatic
brightness adjustment can be changed. 02 steps up/down
from initial set- ting (total: 5
steps) C―
The standard brightness with the manual
brightness adjustment can be changed.
020 steps up/
down from ini-
tial setting (total: 41 steps) C―
The display angle can be changed.
03steps up/down
from initial set- ting (total:7steps) C―
Navigation guid-
ance
Display/non-display On On/Off C ―
*1 Though these systems can be tur
ned Off, doing so will defeat the purpose of the system and Mazda
recommends that these systems remain On.
*2 Only the volume of the warning beep during Blind Spot Monitori ng (BSM) operation can be changed. The
volume of the warning beep durin g Rear Cross Traffic Alert (RCTA) operation cannot be changed.
*3 This system functions only when t he navigation system is functioning.*4 If the auto-wiper control is set to Off, the wiper lever position is set to in termittent operation.*5 If the setting is changed to O ff, the following operation is performed according to the headlight switch
position:
•At position: Headlights turn off immediately after the ignition i s switched off.•At any position other than : Headlights on/off conditions vary according to the headlight switch
position. Refer to Headlights on page 4-49.
*6 When set to 0 seconds, the lights-on reminder is operable.
Specifications
Personalization Features
9-16
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

*7 The lights-on reminder settings can be changed at anytime, however, the lights-on reminder only operates
when the auto headlight function is set to Off. Refer to Lights-On Reminder on page 7-47.
*8 Change the ambient light illumi nation level with the parking lights or headlights turned on.*9 When set to OFF, the ambient lights remain turned off regardle ss of whether or not the parking lights or
headlights are on or off. Howev er, they will turn on or off in conjunction with the illuminated entry system.
*10 The operation may stop in 15 mi nutes due to the effect of the outside temperature even if the operation time of
the rear window defogger has been changed to Continuous.
*11 Available only in display from the center display.
Specifications
Personalization Features
9-17
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38
