Do not use the front bumper to push other vehicles or obstructions such as when pulling
out of a parking space. Otherwise, the radar sensor (front) could be hit and its position
deviated.
 Do not remove, disassemble, or mo dify the radar sensor (front).
 For repairs, replacement or paint work ar ound the radar sensor (front), consult an
Authorized Mazda Dealer.
 Do not modify the suspension. If the suspensi on are modified, the vehicle's posture could
change and the radar sensor (front) may not be able to correctly detect a vehicle ahead or
an obstruction.
NOTE
•Under the following conditions, the radar sensor (front) may not be able to detect vehicles
ahead or obstructions correctly and each system may not operate normally.
•The rear surface of a vehicle ahead does not reflect radio waves effectively, such as an
unloaded trailer or an automobile with a loading platform covered by a soft top,
vehicles with a hard plastic tailgate, and round-shaped vehicles.
•Vehicles ahead with low vehicle height and thus less area for reflecting radio waves.
•Visibility is reduced due to a vehicle ahead casting off water, snow, or sand from its tires
and onto your windshield.
•The luggage compartment is loaded with heavy objects or the rear passenger seats are
occupied.
•Ice, snow, or soiling is on the front surface of the front emblem.
•During inclement weather such as rain, snow, or sand storms.
•When driving near facilities or objects emitting strong radio waves.
•Under the following conditions, the radar sensor (front) may not be able to detect vehicles
ahead or obstructions.
•The beginning and end of a curve.
•Roads with continuous curves.
•Narrow lane roads due to road construction or lane closures.
•The vehicle ahead enters the radar sensor's blind spot.
•The vehicle ahead is running abnormally due to accident or vehicle damage.
•Roads with repeated up and down slopes
•Driving on poor roads or unpaved roads.
•The distance between your vehicle and the vehicle ahead is extremely short.
•A vehicle suddenly comes close such as by cutting into the lane.
•To prevent incorrect operation of the system, use tires of the same specified size,
manufacturer, brand, and tread pattern on all four wheels. In addition, do not use tires
with significantly different wear patterns or tire pressures on the same vehicle (Including
the temporary spare tire).
•If the battery power is weak, the system may not operate correctly.
When Driving
i-ACTIVSENSE
4-151
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

▼Control Switches
Rear switch
Press the rear switch to operate the rear air
conditioner.
The indicator illuminates to indicate that
the rear air conditioner is operating.
AUTO switch
By pressing the AUTO switch the
following functions will be automatically
controlled in accord
ance with the set
temperature:
•Airflow temperature
•Amount of airflow
•Selection of airflow mode
OFF switch
Pressing the OFF sw itch shuts off the
climate control system.
Temperature control switch
This switch controls temperature. Press
for hot and for cold.
Fan control switch
The fan has five speeds. The selected
speed will be displayed.
Mode selector switch
The desired airflow mode can be selected.
Refer to Selecting the Airflow Mode on
page 5-13.
▼ Operation of Automatic Air
Conditioner
Operation from front seats
1. Turn the front air conditioner on.
2. Press the rear switch. The rear air
conditioner operates.
3. Selection of the airflow mode, airflow
amount and temperature will be
automatically controlled to the same
temperature setting as the front air
conditioner for the driver's side.
NOTE
•If the AUTO switch is pressed while
the front A/C switch is off, the rear
air conditioner operates only to
circulate air.
•Setting the temperature to the
maximum high or low will not
provide the desired temperature at a
faster rate.
•When selecting heat, the system will
restrict airflow until it has warmed
to prevent cold air from blowing out
of the vents.
•When the rear air conditioner is
controlled to the same temperature
setting as the front air conditioner
for the driver's side, “SYNC” is
displayed on the rear screen.
Operation from rear seats
1. Turn the front air conditioner on.
2. Press the AUTO switch. The selection of the airflow mode and airflow
amount will be automatically
controlled.
3. Use the temperature control switch to
set the desired temperature.
Interior Features
Climate Control System
5-15
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Sunshade (Rear DoorWindow)
*
The sunshades are equipped to the
windows on both sides of the second-row
seats.

Hold the tab and pull the sunshade upward
and hook the slots.
Ta b
Hook
Sunshade
To return the sunshade to its original
position, unhook the sunshade and retract
it slowly.
CAUTION
Securely hook the sunshade. Otherwise,
the sunshade may retract suddenly
resulting in injury such as fingers get
pinched.
 Use the sunshades only when the
windows are fully closed. Using a
sunshade while a window is open could
cause is to unhook and
flap around
inside the cabin where it can hit
someone sitting near the window,
resulting in injury.
Interior Features
Interior Equipment
5-104*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38
