3. After about 15 minutes, drive thevehicle at a speed of at least 25 km/h
(16 mph) for 10 minutes and the tire
pressure sensor ID s ignal code will be
registered automatically.
NOTE
If the vehicle is driven within about 15
minutes of changing tires, the tire pressure
monitoring system warning light will flash
because the sensor ID signal code would
not have been registered. If this happens,
park the vehicle fo r about 15 minutes,
after which the sensor ID signal code will
register upon driving the vehicle for 10
minutes.
Replacing tires and wheels
CAUTION
 When replacing/repairing the tires or
wheels or both, have the work done by
an Authorized Mazda Dealer, or the tire
pressure sensors may be damaged.
 The wheels equipped on your Mazda are
specially designed for installation of the
tire pressure sensors. Do not use
non-genuine wheels, otherwise it may
not be possible to install the tire pressure
sensors.
Be sure to have the tire pressure sensors
installed whenever tires or wheels are
replaced.
When having a tire or wheel or both
replaced, the following types of tire
pressure sensor installations are possible.
•The tire pressure sensor is removed
from the old wheel and installed to the
new one.
•The same tire pressu re sensor is used
with the same wheel. Only the tire is
replaced.
•A new tire pressure sen sor is installed to
a new wheel.
NOTE
•The tire pressure sensor ID signal code
must be registered when a new tire
pressure sensor is purchased. For
purchase of a tire pressure sensor and
registration of the tire pressure sensor
ID signal code, consult an Authorized
Mazda Dealer.
•When reinstalling a previously removed
tire pressure sensor to a wheel, replace
the grommet (seal between valve body/
sensor and wheel) for the tire pressure
sensor.
When Driving
Tire Pressure Monitoring System
4-163
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

â–¼Displayable Range on the Screen
The images on the screen may be different from the actual condi
tions.

(Screen display) Garnish
Bumper
(Actual view)
Object
Obstruction detection
indication in parking
sensor system
Some models
NOTE
•The displayable range varies depending on the vehicle and road conditions.
•The displayable range is limited. Objects under the bumper or around the bumper ends
cannot be displayed.
•The distance appearing in the displayed image is different from the actual distance
because the rear view parking camera is equipped with a specific lens.
•Some optionally installed vehicle accessories may be picked up by the camera. Do not
install any optional part s that can interfere with the camera view, such as illuminating
parts or parts made of reflective material.
•It may be difficult to see the display under the following conditions, however, it does not
indicate a malfunction.
•In darkened areas.
•When the temperature around the lens is high/low.
•When the camera is wet such as on a rainy day or during periods of high humidity.
•When foreign material such as mud is stuck around the camera.
•When the camera lens reflects sunlight or headlight beams.
•Image display may be delayed if the temperature around the camera is low.
When Driving
Rear View Monitor
4-166
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Parking Sensor System*
The parking sensor system uses ultrasonic sensors to detect obstructions around the vehicle
while parking the vehicle in a g arage or during parallel parking when the vehicle is driven at
a speed of about 10 km/h (6 mph) or less. The system is equippe d with an assist device to
notify the driver of the approxima te distance from the vehicle to the surrounding obstruction
using a beep sound and obstruction detection indication.

Rear corner sensor
Front corner sensor
Rear sensor
Front sensorSome models.
WA R N I N G
Do not rely completely on the parking sensor system and be sure to confirm the safety around
your vehicle visually when driving.
This system can assist the driver in opera ting the vehicle in the forward and backward
directions while parking. The detection ranges of the sensors are limited, therefore, driving the
vehicle while relying only on the system may cause an accident. Always confirm the safety
around your vehicle visually when driving.
NOTE
•Do not install any accessories within the detection ranges of the sensors. It may affect the
system operation.
•Depending on the type of obstruction and th e surrounding conditions, the detection range
of a sensor may narrow, or the sensors may not be able to detect obstructions.
•The system may not operate norma lly under the following conditions:
•Mud, ice, or snow is adhering to the sensor area (Returns to normal operation when
removed).
•The sensor area is frozen (Returns to normal operation when the ice is thawed).
•The sensor is covered by a hand.
•The sensor is excessively shocked.
When Driving
Parking Sensor System
4-172*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

•The vehicle is excessively tilted.
•Under extremely hot or cold weather conditions.
•The vehicle is driven on bumps, inclines, gravel, or grass covered roads.
•Anything which generates ultrasound is near the vehicle, such as another vehicle's
horn, the engine sound of a motorcycle, the air brake sound of a large-sized vehicle, or
another vehicle's sensors.
•The vehicle is driven in heavy rain or in road conditions causing water-splash.
•A commercially-available fender pole or an antenna for a radio transmitter is installed
to the vehicle.
•The vehicle is moving towards a tall or square curbstone.
•An obstruction is too close to the sensor.
•Obstructions under the bumper may not be detected. Obstructions that are lower than the
bumper or thin which may have been initially detected but are no longer detected as the
vehicle approaches more closely.
•The following types of obstructions may not be detected:
•Thin objects such as wire or rope
•Things which absorb sonic waves easily such as cotton or snow
•Angular shaped objects
•Very tall objects, and those which are wide at the top
•Small, short objects
•Always have the system inspected at an Authorized Mazda Dealer if any shock is applied
to the bumpers, even in a minor accident. If the sensors are deviated, they cannot detect
obstructions.
•(With front sensor and front corner sensor)
The system may have a malfunction if the beep does not operate or the indicator light
does not illuminate when the park assist sensors switch is turned on. Consult an
Authorized Mazda Dealer.
•(Without front sensor an d front corner sensor)
The system may have a malfunction if the be ep does not operate. Consult an Authorized
Mazda Dealer.
•(With front sensor and front corner sensor)
The system may have a malfunction if the beep sound which indicates a system
malfunction is heard and the i ndicator light flashes. Consult an Authorized Mazda Dealer.
•The beeper which indicates a system malf unction may not be heard if the ambient
temperature is extremely cold, or mud, ice, or snow adheres to the sensor area. Remove
any foreign material from the sensor area.
•When installing a trailer hitch, consult an Authorized Mazda Dealer.
When Driving
Parking Sensor System
4-173
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

â–¼Sensor Detection Range
The sensors detect obstruction
s within the following range.

Front sensor detection range
Front corner sensor detection range Rear sensor detection range
Rear corner sensor detection range
B
A
D
C A: About 55 cm (About 21.7 in)
B: About 55 cm (About 21.7 in)
C: About 100 cm (About 39.3 in)
D: About 150 cm (About 59.0 in)
â–¼
Park Assist Sensor System Operation
With front sensor and front corner sensor
The switch can be activated when the ignition is switched ON, t
he selector lever is in any
position except reverse (R), and the vehicle speed is about 10 km/h (6 mph) or less.
When the parking sensor switch is pressed, a beep sound is hear d, the obstruction detection
indication is displayed in the a udio screen, and the indicator light in the switch illuminates.

Indicator light
When Driving
Parking Sensor System
4-174
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

NOTE
•If the system is cancelled, it will not restore automatically even when the vehicle speed is
decreased to 10 km/h (6 mph) or less.
•When the ignition is switched OFF, the system status before it was turned off is
maintained. For example, if the ignition is switched OFF while the parking sensor is
activated, the system will be activated when the ignition is switched ON the next time.
Sensor detection condition
The system can be used when the ignition is switched ON and the Park Assist Sensor
Switch has been turned on.
The sensors detect obstructions under the following conditions:
Sensor Condition
Front Sensor The selector lever is in any po
sition except reverse (R), and the vehicle speed is
about 10 km/h (6 mph) or less.
Front Corner Sensor The vehicle speed is about 10 km/h (6 mph) o r less.
Rear Sensor The selector lever is in reverse (R).
Rear Corner Sensor The selector lever is in rever
se (R), and the vehicle speed is about 10 km/h (6 mph)
or less.
The system is cancelled under the following conditions:
•The parking sensor switch is pressed while the parking sensor i s in operation.
•The vehicle speed is 10 km/h (6 mph) or more. (Except rear sens or)
Without front sensor and front corner sensor
When the ignition is switched ON and the selector lever is shifted to the reverse (R), the
beep sound activates and the system is enabled for use.
The sensors detect obstructions under the following conditions:
Sensor Condition
Rear Sensor The selector lever is in reverse (R).
Rear Corner Sensor The selector lever is in rever
se (R), and the vehicle speed is about 10 km/h (6 mph)
or less.
When Driving
Parking Sensor System
4-175
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

â–¼Obstruction Detection Indication
The position of a sensor which has detected an obstruction is i
ndicated. The gauge
illuminates in different areas d epending on the distance to an obstruction detected by the
sensor.
As the vehicle approaches closer to an obstruction, the zone in the gauge closer to the
vehicle illuminates.

Front left corner
sensor gauge Front right corner
sensor gauge
Rear right corner
sensor gauge
Rear left corner
sensor gauge Front sensor gauge
Rear sensor gauge Some models.
NOTE
The detection indicator can switch between display and non-display.
Refer to Personalization Features on page 9-11.
When Driving
Parking Sensor System
4-176
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

System problem notification
If any of the problems indicated in the table occurs, the driver is notified of the problem
depending on the type of system as shown.
Detection Indicator
Solution
With front sensor
and front corner sensor Without front sen-
sor and front corner sensor
Disconnection
The system may have a malfunction. Have
the vehicle inspected at an Authorized Maz-
da Dealer as soon as possible.
System malfunc- tion
The system may have a malfunction. Have
the vehicle inspected at an Authorized Maz-
da Dealer as soon as possible.
Frost/soiling
Foreign matter may b e on the sensor area
corresponding to the obstruction detection
indication shown. If the system does not re-
cover, have the vehicle inspected at an Au-
thorized Mazda Dealer.
When Driving
Parking Sensor System
4-177
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

â–¼Parking Sensor Warning Beep
The beeper sounds as follows while the system is operating.
Front Sensor
*, Rear Sensor
Distance Detec-
tion area Distance between vehicle and obstruction
Beeper sound*1Front Sensor*Rear Sensor
Farthest distance Approx. 100―60 cm (39.3―23.6
in)
Approx. 150―60 cm (59.0―23.6in)
Slow intermittent
sound
Far distance Approx. 60―45 cm (23.6―17.7
in)
Approx. 60―45 cm (23.6―17.7in)
Medium intermit-
tent sound
Middle distance Approx. 45―35 cm (17.7―13.7
in)
Approx. 45―35 cm (17.7―13.7in)
Fast intermittent
sound
Close distance Within approx. 35 cm (13.7 in)
Within approx. 35 cm (13.7 in)
Continuous sound
*1 The rate at which the interm
ittent sound beeps increases as the vehicle approaches the obstruction.
When Driving
Parking Sensor System
4-178*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Front Corner Sensor*, Rear Corner Sensor
Distance Detection areaDistance between vehicle and obstruction
Beeper sound*1Front*/Rear Corner Sensor
Far distance Approx. 55―38 cm (21.7―15.0 in)
Medium intermittent sound
Middle distance Approx. 38―25 cm (15.0―9.8 in)
Fast intermittent sound
Close distance Within approx. 25 cm (9.8 in)
Continuous sound
*1 The rate at which the intermitte
nt sound beeps increases as the vehicle approaches the obstruction.
NOTE
If an obstruction is detected in a zone for 6 seconds or more, the beep sound is stopped
(except for the close-distance zone). If the same obstruction is detected in another zone, the
corresponding beep sound is heard.
When Driving
Parking Sensor System
*Some models.4-179
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38
