MAZDA MODEL CX-9 2018 Owners Manual (in English)

Interior light
Light bulbCategory
Wattage UNECE*1
Overhead lights (Front)/Map lights
(Front) Bulb type 8 ―
LED type
LED*2―
Map lights (Center) Bulb type 8 ―
LED type
LED
*2―
Overhead light (Rear) Bulb type 10 ―
LED type
LED
*2―
Ambient lights
*LED*2―
Vanity mirror lights
*2―
Luggage compartment light Bulb type 8 ―
LED type
LED
*2―
*1 UNECE stands for United Nations Economic Commission for Europe.*2 LED is the abbreviation for Light Emitting Diode.
â–¼Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally
fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and inflation press
ure.
Refer to Tire Inflation Pressure on page 6-41.
Specifications
Specifications
*Some models.9-9
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Standard tire
(U.S.A. and Canada)
Tire sizeInflation pressure
Front Rear
P255/60R18 107H 230 kPa (34 psi)230 kPa (34 psi)
P255/50R20 104V 230 kPa (34 psi)230 kPa (34 psi)
(Mexico)
Tire size Inflation pressure
Front Rear
P255/50R20 104V 230 kPa (2.3 bar, 33 psi) 230 kPa (2.3 bar, 33 ps i)
Temporary spare tire
(U.S.A. and Canada)
Tire sizeInflation pressure
T155/90D17 101M 420 kPa (60 psi)
(Mexico)
Tire sizeInflation pressure
185/80R17 99M 320 kPa (3.2 bar, 46 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108―147 N·m (12―14 kgf·m, 80―108 ft·lbf)
â–¼ Fuses
Refer to Fuses on page 6-53.
Specifications
Specifications
9-10
CX-9_8GC3-EA-17G_Edition1
2017-5-29 10:13:38

Personalization Features
The following personalization features can be set or changed by the customer or an Author-
ized Mazda Dealer. Consult an Authorized Mazda Dealer for details.
Additionally, some of the persona lization features can be changed by the customer depend-
ing on the feature.
Personalization features and settings which can be changed diff er depending on the market
and specification.
Settings Change Method
Settings can be changed by opera ting the center display screen.
A: Refer to Settings on page 5-76.
B: Refer to Fuel Economy Monitor on page 4-77.
C: Refer to Active Drivi ng Display on page 4-28.
Settings can be changed by op erating the vehicle switches.
D: Refer to Auto Lock/Unlock Function on page 3-18.
E: Refer to Transmitter on page 3-4.
F: Refer to Locking, Unlocking with Request Switch (With the ad vanced keyless function)
on page 3-14.
Settings can be changed by an Authorized Mazda Dealer.
Item FeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Safety
Smart City
Brake Support
(SCBS) (page
4-138) The system can be changed so that Smart City
Brake Support (SCBS) does not operate.
*1On On/Off A ―
Advanced Smart
City Brake Sup-
port (Advanced
SCBS) (page
4-134)
Smart Brake
Support (SBS)
(page 4-142)The system can be changed so that Advanced
Smart City Brake Support (Advanced SCBS)/
Smart Brake Support (SBS) does not operate.
*1On On/Off A ―
The distance at which the collision warning ac-
tivates can be changed.
Mid Near/Mid/Far A ―
The volume of the collision warning can be
changed.
High High/Low/Off A ―
Specifications
Personalization Features
9-11
CX-9_8GC3-EA-17G_Edition1
2017-5-29 10:13:38

ItemFeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Lane-keep As-
sist System
(LAS) & Lane
Departure Warn-
ing System
(LDWS) (page
4-123) The system can be change
d so that the steering
wheel assist does not operate. On On/Off A ―
When the steering
wheel operation assis-
tance is turned onThe sensitivity of the
steering assistance for
the Lane-keep Assist
System (LAS) & Lane
Departure Warning
System (LDWS) can
be changed.
High High/Low A ―
The system can be
changed so that the
lane departure warn-
ing does not activate.
On On/Off A ―
When the steering
wheel operation assis-
tance is turned offThe warning timing in
which the Lane-keep
Assist System (LAS)
& Lane Departure
Warning System
(LDWS) system deter-
mines that the vehicle
may be deviating from
its lane can be
changed.
At At/Before A ―
The sensitivity of the
warning for the
Lane-keep Assist Sys-
tem (LAS) & Lane
Departure Warning
System (LDWS) can
be changed.
Often Often/Rare A ―
The type of Lane-keep Assist System (LAS) &
Lane Departure Warning System (LDWS)
warning can be changed.
Vibration
Vibration/Beep/
Rumble A―
The warning intensity/
volume of the
Lane-keep Assist Sys-
tem (LAS) & Lane De-
parture Warning Sys-
tem (LDWS) system
can be changed. Vibration Low High/Low A ―
Rumble
Low High/Mid/Low A ―
BeepLow High/Low A ―
Specifications
Personalization Features
9-12
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

ItemFeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Blind Spot Mon-
itoring (BSM)
(page 4-91) The system can be changed so that Blind Spot
Monitoring (BSM) does not operate.*1On On/Off A ―
Warning beep volume*2High
High/
Low/ Off A―
Distance Recog-
nition Support
System (DRSS)
(page 4-104) The system can be changed so that Distance
Recognition Support System (DRSS) does not
operate.*1On On/Off A ―
The distance at which the vehicle ahead and
your vehicle indicated in the display flashes in
white can be changed.
Near
Far/Medium/
Near A―
Traffic Sign
Recognition
System (TSR)
*3
(page 4-97) The Traffic Sign Recognition System (TSR)
can be set to inoperable.
*1On On/Off A ―
The warning pattern of the excessive speed
warning can be changed.
OffOff/
Vi s u a l /
Audio & Visual A―
The activation timing for the excessive speed
warning can be changed.00/5/10
A―
Parking sensor
system (page
4-176) Display/non-display On On/Off A ―
Ve h i c l e
Door locks
(page 3-18)Operation condition of auto lock/unlock func-
tion Lock: Driv-
ing, Unlock:
IGN Off Off/
Lock When Driving/
Lock: Driving,
Unlock: IGN Off/
Lock When
Shifting Out Of P/
Lock: Shift
From P, Unlock: In P/
Lock: Driving,
Unlock: In P AD
Specifications
Personalization Features
9-13
CX-9_8GC3-EA-17G_Edition1
2017-5-29 10:13:38

ItemFeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Keyless entry
system (page 3-
3) Method for unlocking door using transmitter
Once: Driv-
er's, Twice: All Doors Once: Driver's,
Twice: AllDoors/
Touch Once: All Doors AE
Time for locking door automatically
60 seconds90 seconds/
60 seconds/
30 seconds A―
Advanced key-
less entry system
(page 3-10) Method for unlocking door using request
switch/transmitter
Once: Driv-
er's, Twice: All Doors Once: Driver's,
Twice: AllDoors/
Touch Once: All Doors A
E,
FTime for locking door automatically 60 seconds90 seconds/
60 seconds/
30 seconds A―
Auto-lock function operation/non-operational Off On/Off A ―
Beep volume when locking/unlocking
MediumHigh/
Medium/ Low/Off A
E,
F
Illuminated en-
try system (page
5-95) Time until interior lights turn off after closing
door
15 seconds60 seconds/
30 seconds/
15 seconds/
7.5 seconds A―
Time until interior lights turn off automatically
when any door is not closed completely
30 minutes60 minutes/
30 minutes/
10 minutes A―
Auto-wiper con-
trol (page 4-55)
Operational/non-operational On or Off
On/Off*4A―
Daytime running
lights (page 4-
53)Operational/non-operational On On/Off ― ―
Auto headlight
off*5 (page 4-49)
Time until headlights
turn off 30 seconds120 seconds/
90 seconds/
60 seconds/
30 seconds/
0 seconds
*6
A―
Specifications
Personalization Features
9-14
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

ItemFeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Auto-light con-
trol (page 4-49) Timing by which lig
hts turn on Medium Light/
Medium Light/ Medium/
Medium Dark/ Dark A―
High Beam Con-
trol System
(HBC) (page
4-88)
Operational/non-operational
*1On On/Off A ―
Adaptive Front
Lighting System
(AFS) (page
4-87)Operational/non-operational
*1On On/Off A ―
Lights-on re-
minder*7 (page
7-47) Warning beep volume High High/Low/Off A ―
Coming home
light (page 4-52)
Time until headlights turn off 30 seconds 120 seconds/
90 seconds/
60 seconds/
30 seconds/ Off A―
Leaving home
light (page 4-52)
Operational/non-operational On On/Off A ―
Turn indicator
(page 4-54)Beep volume High High/Low A ―
Three-flash turn
signal (page
4-55)Operational/non-operational On On/Off A ―
Ambient Light-
ing (page 5-92)
Ambient lights brightness*8MediumBright/
Medium/ Dark/
Off
*9
A―
Rear window
defogger (page
4-59) The operation time for the rear window defog-
ger can be changed.
15 minutes15 minutes/
Continuous
*10――
System
Language Language indicated in display US EnglishDepends on
market
*11A―
Temperature Temperature unit indi cated in display °F or °C °F/°C A ―
Distance Distance unit indicated in display miles or km miles/km A ―
Specifications
Personalization Features
9-15
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

ItemFeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Fuel Economy Monitor (page 4-77)
Ending display On/off Off On/Off B ―
Fuel economy
resetting proce-
dure Linkage/non-linkage with fuel economy reset
and trip meter reset
Off On/Off B ―
Active driving display
(page 4-28)
Display Setting can be changed so that the Active Driv-
ing Display is not displayed.
On On/Off C ―
The display height (up/down position) can be
changed.
013 steps up/
down from ini-
tial setting (total: 27 steps) C―
The method for adjusting the display bright-
ness (automatically/manually) can be changed.
AUTOAUTO/
MANUAL C―
The standard brightness with the automatic
brightness adjustment can be changed. 02 steps up/down
from initial set- ting (total: 5
steps) C―
The standard brightness with the manual
brightness adjustment can be changed.
020 steps up/
down from ini-
tial setting (total: 41 steps) C―
The display angle can be changed.
03steps up/down
from initial set- ting (total:7steps) C―
Navigation guid-
ance
Display/non-display On On/Off C ―
*1 Though these systems can be tur
ned Off, doing so will defeat the purpose of the system and Mazda
recommends that these systems remain On.
*2 Only the volume of the warning beep during Blind Spot Monitori ng (BSM) operation can be changed. The
volume of the warning beep durin g Rear Cross Traffic Alert (RCTA) operation cannot be changed.
*3 This system functions only when t he navigation system is functioning.*4 If the auto-wiper control is set to Off, the wiper lever position is set to in termittent operation.*5 If the setting is changed to O ff, the following operation is performed according to the headlight switch
position:
•At position: Headlights turn off immediately after the ignition i s switched off.•At any position other than : Headlights on/off conditions vary according to the headlight switch
position. Refer to Headlights on page 4-49.
*6 When set to 0 seconds, the lights-on reminder is operable.
Specifications
Personalization Features
9-16
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

*7 The lights-on reminder settings can be changed at anytime, however, the lights-on reminder only operates
when the auto headlight function is set to Off. Refer to Lights-On Reminder on page 7-47.
*8 Change the ambient light illumi nation level with the parking lights or headlights turned on.*9 When set to OFF, the ambient lights remain turned off regardle ss of whether or not the parking lights or
headlights are on or off. Howev er, they will turn on or off in conjunction with the illuminated entry system.
*10 The operation may stop in 15 mi nutes due to the effect of the outside temperature even if the operation time of
the rear window defogger has been changed to Continuous.
*11 Available only in display from the center display.
Specifications
Personalization Features
9-17
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

MEMO
9-18
CX-9_8GC3-EA-17G_Edition12017-5-29 10:13:38
