Break-In Period
No special break-in is necessary, but a few
precautions in the first 1,000 km (600
miles) may add to the performance,
economy, and life of the vehicle.
•Do not race the engine.
•Do not maintain one constant speed,
either slow or fast, for a long period of
time.
•Do not drive constantly at full-throttle or
high engine rpm for e xtended periods of
time.
•Avoid unnecessary hard stops.
•Avoid full-throttle starts.
•Do not tow a trailer.
Saving Fuel and Protection of the Environment
How you operate your Mazda determines
how far it will travel on a tank of fuel. Use
these suggestions to help save fuel and
reduce CO
2.
•Avoid long warm-ups. Once the engine
runs smoothly, begin driving.
•Avoid fast starts.
•Drive at lower speeds.
•Anticipate when to apply the brakes
(avoid sudden braking).
•Follow the maintenance schedule (page
6-4) and have an Authorized Mazda
Dealer perform inspections and
servicing.
•Use the air conditioner only when
necessary.
•Slow down on rough roads.
•Keep the tires properly inflated.
•Do not carry unnecessary weight.
•Do not rest your foot on the brake pedal
while driving.
•Keep the wheels in correct alignment.
•Keep windows closed at high speeds.
•Slow down when driving in crosswinds
and headwinds.
WA R N I N G
Never stop the engine when going down a
hill:
Stopping the engine when going down a
hill is dangerous. This causes the loss of
power steering and power brake control,
and may cause damage to the drivetrain.
Any loss of steering or braking control
could cause an accident.
Before Driving
Driving Tips
3-48
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Descending a hill
Shift into a lower gear and use engine compression as a braking effect.
WA R N I N G
Always use lower gears to reduce speed:
Holding the brake pedal down too long or too frequently is dangerous as it could cause the
brakes to overheat and lose power, resulting in loss of control and a serious accident. Use
lower gears to help reduce speed. Pull off the road and allow brakes to cool down whenever
braking performance feels reduced.
Overheated engine
The extra weight of the trailer may strain the engine on hot days and on long or steep
upgrades.
If the temperature gauge indicates overheating, turn off the ai r conditioner, drive safely to
the side of the road, park off the right-of-way and wait for en gine to cool. Refer to
Overheating on page 7-25.
Parking
Always make sure the tires of the trailer and the tow vehicle a re blocked while parked.
Apply the parking brake firmly and put the transaxle in P.
Avoid parking on an incline, but if you must, follow these instructions:
1. Depress and hold down the brake pedal.
2. Have a helper put wheel blocks against the downhill side of a ll vehicle and trailer tires.
3. Then release the brake pedal slowly until the blocks bear the load.
•If the grade is downhill, turn the steering wheel so that the front of the front tires face
the curb.
•If it is uphill, face the rear of the front tires against the curb.
4. Firmly apply t he parking brake.
5. Shift the transaxle into P, and stop the engine.
To restart after parking on an incline:
1. With the transaxle in P, start the engine. (Be sure to depres s and hold the brake pedal.)
2. Shift into gear.
3. Release the parking brake (also the foot brake) and pull away from the wheel blocks.
Stop; apply the parking brake and shift into P.
4. Have a helper retrieve the wheel blocks.
Before Driving
To w i n g
3-62
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

i-ACTIV AWD................................. 4-81i-ACTIV AWD Operation
*.........4-81
Power Steering................................. 4-83 Power Steering............................4-83
i-ACTIVSENSE............................... 4-84 i-ACTIVSENSE
*........................4-84
Adaptive Front Lighting System
(AFS)
*........................................ 4-87
High Beam Control System
(HBC)
*........................................4-88
Blind Spot Monitoring (BSM)
*.........
.................................................... 4-91
Traffic Sign Recognition System
(TSR)
*........................................ 4-97
Distance Recognition Support
System (DRSS)
*....................... 4-104
Rear Cross Traffic Alert (RCTA)
*.....
.................................................. 4-107
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function)
*................4-110
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS)
*.................................. 4-123
Advanced Smart City Brake Support
(Advanced SCBS)
*...................4-134
Smart City Brake Support
(SCBS)
*.................................... 4-138
Smart Brake Support (SBS)
*.... 4-142
Forward Sensing Camera (FSC)
*......
.................................................. 4-145
Radar Sensor (Front)
*.............. 4-150
Radar Sensors (Rear)
*.............. 4-153
Cruise Control............................... 4-155 Cruise Control
*.........................4-155
Tire Pressure Monitoring
System.............................................4-160 Tire Pressure Monitoring System
*.....
.................................................. 4-160
Rear View Monitor....................... 4-164 Rear View Monitor
*................. 4-164
Parking Sensor System................. 4-172 Parking Sensor System
*........... 4-172
4-2*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

▼Warning Indication/Warning Lights
These lights turn on or flash to notify the user of the system
operation status or a system
malfunction.
Signal Warning Page
Brake System Warning Indication/Warning Light*1*27-30
ABS Warning Light*1
Electronic Brake
Force Distribu- tion System
Wa r n i n g 7-30
ABS warning 7-33
Charging System Warning Indication/Warning Light*17-30
Engine Oil Warning Light*17-30
(Red) High Engine Coolant Temperature Warning Indication/Warning Ligh
t
*17-30
Power Steering Malfunction Indication/Malfunction Indicator Light*17-30
Master Warning Indication/Warning Light*17-33
Electric Parking Brake (EPB) Warning Indication/Warning Light 7-33
*Engine Oil Level Warning Indication 7-33
Check Engine Light*17-33
Automatic Transaxle Warning Indication/Warning Light*17-33
When Driving
Instrument Cluster and Display
4-32*Some models.
CX-9_8GC3-EA-17G_Edition1
2017-5-29 10:13:38

Driving Tips
WA R N I N G
Do not let the vehicle move in a direction
opposite to the direction selected by the
selector lever:
Do not let the vehicle move backward with
the selector lever in a forward position, or
do not let the vehicle move forward with
the selector lever in the reverse position.
Otherwise, the engine may stop, causing
the loss of the power brake and power
steering functions, and make it difficult to
control the vehicle which could result in an
accident.
Passing
For extra power when passing another
vehicle or climbing steep grades, depress
the accelerator fully. The transaxle will
shift to a lower gear, depending on vehicle
speed.
NOTE
•The accelerator pedal may initially feel
heavy as it is being depressed, then feel
lighter as it is depressed further. This
change in pedal force aids the engine
control system in determining how much
the accelerator pedal has been
depressed for performing kickdown, and
functions to control whether or not
kickdown should be performed.
•While the selector lever is in the M
position and the TCS is turned off,
manual shift mode does not switch to
automatic shift mode even if the
accelerator pedal is completely
depressed. Operate the selector lever.
Climbing steep gra des from a stop
To climb a steep grade from a stopped
position:
1. Depress the brake pedal.
2. Shift to D or M1, depending on the load weight and grade steepness.
3. Release the brake pedal while gradually accelerating.
Descending steep grades
When descending a steep grade, shift to
lower gears, depending on load weight and
grade steepness. Descend slowly, using the
brakes only occasionally to prevent them
from overheating.
When Driving
Automatic Transaxle
4-48
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Power Steering
•Power steering is only operable when
the engine is running. If the engine is off
or if the power steering system is
inoperable, you can still steer, but it
requires more physical effort.
If the steering feels stiffer than usual
during normal driving or the steering
vibrates, consult an Authorized Mazda
Dealer.
•The warning indication/warning light
notifies the driver of system
abnormalities and operation conditions.
In addition, the buzzer may also activate
depending on the system abnormality or
operation condition.
Refer to Warning Indication/Warning
Lights on page 4-32.
Refer to Power Steering Warning
Buzzer on page 7-50.
CAUTION
Never hold the steering wheel to the
extreme left or right for more than 5
seconds with the engine running. This
could damage the power steering system.
When Driving
Power Steering
4-83
CX-9_8GC3-EA-17G_Edition12017-5-29 10:13:38

Lane-keep Assist System (LAS) & Lane DepartureWarning System (LDWS)
*
The LAS&LDWS alerts the driver th at the vehicle may be deviating from its lane and it
provides steering assistance to help the driver stay within the vehicle lanes.
The Forward Sensing Camera (FSC) detects the white lines (yello w lines) of the vehicle
lane in which the vehicle is traveling and if the system determ ines that the vehicle may
deviate from its lane, it operates the electric power steering to assist the driver's steering
operation. The system also alerts the driver by activating a la ne departure warning sound,
vibrating the steering wheel, and indicating an alert in the di splay. Use the system when you
drive the vehicle on ro ads with white (yellow) lines such as ex pressways and highways.
Refer to Forward Sensing Camera (FSC) on page 4-145.
Forward Sensing
Camera (FSC)
WA R N I N G
Do not rely completely on the LAS&LDWS:
 The LAS&LDWS is not an automatic driving syst em. In addition, the system is not designed
to compensate for a driver's lack of caution, and over-reliance on the system could lead to
an accident.
 The detection ability of the LAS&LDWS is limite d. Always stay on course using the steering
wheel and drive with care.
Do not use the LAS&LDWS in the following cases:
The system may not operate adequately accordin g to the actual driving conditions, resulting
in an accident.
When Driving
i-ACTIVSENSE
*Some models.4-123
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

•There is a malfunction in the power
steering.
•There is a malfunction in the TCS.
•There is a malfunction in the Forward
Sensing Camera (FSC).
•When the ignition is switched OFF, the
system status before it was turned off is
maintained. For example, if the ignition
is switched OFF with the lane-keep
system operable, the system will be
operable when the ignition is switched
ON the next time.
When the LAS&LDWS is turned off, the
vehicle lane line indication in the
multi-information display and the active
driving display turn off.
When Driving
i-ACTIVSENSE
4-131
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

SignalWarning
(Red)
High Engine Coolant
Temperature Warning
Indication/Warning
Light The light flashes when the engine
coolant temperature is extremely high, and illumi-
nates when the engine coolant temperature increases further.
Handling Procedure
Flashing light
Drive slowly to reduce engine load until you can find a safe pl ace to stop the vehicle
and wait for the engine to cool down.
Illuminated light
This indicates the possibility of overheating. Park the vehicle in a safe place immedi-
ately and stop the engine.
Refer to Overheating on page 7-25.
CAUTION
Do not drive the vehicle with the high engine coolant temperature warning light illumi‐
nated. Otherwise, it could resu lt in damage to the engine.
Power Steering Mal-
function Indication*
The message is displayed if the electric power steering has a m alfunction.
If the message is displayed, st op the vehicle in a safe place a nd do not operate the
steering wheel. There is no problem if the message in the displ ay turns off after a
while. Contact an Authorized Mazda Dealer if the message is dis played continuously.
NOTE
•If the message is displayed, the power steering will not operate normally. In this
case, the steering wheel can still be operat ed, however, the operation may feel heavy
compared to normal, or the steerin g wheel could vibrate when turning.
•Repeatedly jerking the steering wheel left and right while the vehicle is stopped or
moving extremely slowly will cause the power steering system to go into protective
mode which will make the steering feel heavy, but this does not indicate a problem. If
this occurs, park the vehicle safely and wait several minutes for the system to return
to normal.
Power Steering Mal- function Indicator
Light
*
The light illuminates/flashes if the electric power steering ha s a malfunction.
If the light illuminates/flashes, stop the vehicle in a safe pl ace and do not operate the
steering wheel. There is no problem if the light turns off afte r a while. Contact an Au-
thorized Mazda Dealer if the lig ht illuminates/flashes continuously.
NOTE
•If the indicator light illuminates/flashes, the power steering will not operate normal-
ly. If this happens, the steering wheel can still be oper ated, however, the operation
may feel heavy compar ed to normal, or the steering wheel could vibrate when turn-
ing.
•Repeatedly jerking the steering wheel left and right while the vehicle is stopped or
moving extremely slowly will cause the power steering system to go into protective
mode which will make the steering feel heavy, but this does not indicate a problem. If
this occurs, park the vehicle safely and wait several minutes for the system to return
to normal.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-32*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38
