ï‚·The same tire pressure sensor is used
with the same wheel. Only the tire is
replaced.
ï‚·A new tire pressure sensor is installed to
a new wheel.
NOTE
ï‚·The tire pressure sensor ID signal code
must be registered when a new tire
pressure sensor is purchased. For
purchase of a tire pressure sensor and
registration of the tire pressure sensor
ID signal code, consult an Authorized
Mazda Dealer.
ï‚·When reinstalling a previously removed
tire pressure sensor to a wheel, replace
the grommet (seal between valve body/
sensor and wheel) for the tire pressure
sensor.
When Driving
Tire Pressure Monitoring System
4-220
CX-9_8HT8-EA-19I_Edition2_old2019-9-24 13:14:55

â–¼Displayable Range on the Screen
The images on the screen may be different from the actual conditions.

(Screen display)
Garnish
Bumper
(Actual view)
Object
Obstruction detection
indication in parking
sensor system
Some models
NOTE
ï‚·The displayable range varies depending on the vehicle and road conditions.
ï‚·The displayable range is limited. Objects under the bumper or around the bumper ends
cannot be displayed.
ï‚·The distance appearing in the displayed image is different from the actual distance
because the rear view parking camera is equipped with a specific lens.
ï‚·Some optionally installed vehicle accessories may be picked up by the camera. Do not
install any optional parts that can interfere with the camera view, such as illuminating
parts or parts made of reflective material.
ï‚·It may be difficult to see the display under the following conditions, however, it does not
indicate a malfunction.
ï‚·In darkened areas.
ï‚·When the temperature around the lens is high/low.
ï‚·When the camera is wet such as on a rainy day or during periods of high humidity.
ï‚·When foreign material such as mud is stuck around the camera.
ï‚·When the camera lens reflects sunlight or headlight beams.
ï‚·Image display may be delayed if the temperature around the camera is low.
When Driving
Rear View Monitor
4-223
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

Parking Sensor System*
The parking sensors use ultrasonic sensors which detect obstructions around the vehicle
when the vehicle is driven at low speeds, such as during garage or parallel parking, and a
buzzer sound and detection indicator notify the driver of the approximate distance from the
vehicle to the surrounding obstruction.

Rear corner sensor
Front corner sensor
Rear sensor
Front sensorSome models.
WA R N I N G
Do not rely completely on the parking sensor system and be sure to confirm the safety around
your vehicle visually when driving:
This system can assist the driver in operat ing the vehicle in the forward and backward
directions while parking. The detection ranges of the sensors are limited, therefore, driving the
vehicle while relying only on the system may cause an accident. Always confirm the safety
around your vehicle visually when driving.
NOTE
ï‚·Do not install any accessories within the detection ranges of the sensors. It may affect the
system operation.
ï‚·Depending on the type of obstruction and the surrounding conditions, the detection range
of a sensor may narrow, or the sensors may not be able to detect obstructions.
ï‚·The system may not operate normally under the following conditions:
ï‚·Mud, ice, or snow is adhering to the sensor area (Returns to normal operation when
removed).
ï‚·The sensor area is frozen (Returns to normal operation when the ice is thawed).
ï‚·The sensor is covered by a hand.
ï‚·The sensor is excessively shocked.
ï‚·The vehicle is excessively tilted.
ï‚·Under extremely hot or cold weather conditions.
When Driving
Parking Sensor System
*Some models.4-229
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

ï‚·The vehicle is driven on bumps, inclines, gravel, or grass covered roads.
ï‚·Anything which generates ultrasound is near the vehicle, such as another vehicle's
horn, the engine sound of a motorcycle, the air brake sound of a large-sized vehicle, or
another vehicle's sensors.
ï‚·The vehicle is driven in heavy rain or in road conditions causing water-splash.
ï‚·A commercially-available fender pole or an antenna for a radio transmitter is installed
to the vehicle.
ï‚·The vehicle is moving towards a tall or square curbstone.
ï‚·An obstruction is too close to the sensor.
ï‚·Obstructions under the bumper may not be detected. Obstructions that are lower than the
bumper or thin which may have been initially detected may no longer be detected as the
vehicle approaches more closely to the obstruction.
ï‚·The following types of obstructions may not be detected:
ï‚·Thin objects such as wire or rope
ï‚·Things which absorb sonic waves easily such as cotton or snow
ï‚·Angular shaped objects
ï‚·Very tall objects, and those which are wide at the top
ï‚·Small, short objects
ï‚·Always have the system inspected at an Authorized Mazda Dealer if any shock is applied
to the bumpers, even in a minor accident. If the sensors are deviated, they cannot detect
obstructions.
ï‚·(With front sensor and front corner sensor)
The system may have a malfunction if the b eep does not operate or the indicator light
does not illuminate when the park assist sensors switch is turned on. Consult an
Authorized Mazda Dealer.
ï‚·(Without front sensor and front corner sensor)
The system may have a malfunction if the beep does not operate. Consult an Authorized
Mazda Dealer.
ï‚·(With front sensor and front corner sensor)
The system may have a malfunction if the beep sound which indicates a system
malfunction is heard and the indicator light flashes. Consult an Authorized Mazda Dealer.
ï‚·The beeper which indicates a system malfunction may not be heard if the ambient
temperature is extremely cold, or mud, ice, or snow adheres to the sensor area. Remove
any foreign material from the sensor area.
ï‚·When installing a trailer hitch, c onsult an Authorized Mazda Dealer.
When Driving
Parking Sensor System
4-230
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

â–¼Sensor Detection Range
The sensors detect obstructions
within the following range.

Front sensor detection range
Front corner sensor detection range Rear sensor detection range
Rear corner sensor detection range
B
A
D
C A: About 55 cm (About 21.7 in)
B: About 55 cm (About 21.7 in)
C: About 100 cm (About 39.3 in)
D: About 150 cm (About 59.0 in)
Viewing distance display
Display
Distance between vehicle and obstruction
Without 360° view monitor With 360° viewmonitor Front Sensor
*/Front
Corner Sensor*Rear Sensor/Rear Corner Sensor
Without front sen-
sor and front cor- ner sensor With front sensor
and front corner sensor
Green
Front sensor:
Approx. 100 ―60 cm
(39.3 ―23.6 in) Rear sensor:
Approx. 150 ―60 cm
(59.0 ―23.6 in)
When Driving
Parking Sensor System
*Some models.4-231
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

DisplayDistance between vehicle and obstruction
Without 360° view monitor With 360° viewmonitor Front Sensor
*/Front
Corner Sensor*Rear Sensor/Rear Corner Sensor
Without front sen-
sor and front cor- ner sensor With front sensor
and front corner sensor
Yellow
Front sensor:
Approx. 60 ―45 cm
(23.6― 17.7 in)
Front corner sensor: Approx. 55 ―38 cm
(21.7― 15.0 in) Rear sensor:
Approx. 60 ―45 cm
(23.6― 17.7 in)
Rear corner sensor:
Approx. 55 ―38 cm
(21.7― 15.0 in)
Amber
Front sensor:
Approx. 45 ―35 cm
(17.7― 13.7 in)
Front corner sensor: Approx. 38 ―25 cm
(15.0― 9.8 in) Rear sensor:
Approx. 45 ―35 cm
(17.7― 13.7 in)
Rear corner sensor:
Approx. 38 ―25 cm
(15.0― 9.8 in)
Red
Front sensor:
Within approx. 35 cm (13.7 in)
Front corner sensor:
Within approx. 25 cm (9.8 in) Rear sensor:
Within approx. 35 cm (13.7 in)
Rear corner sensor:
Within approx. 25 cm (9.8 in)
When Driving
Parking Sensor System
4-232*Some models.
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

â–¼Park Assist Sensor System Operation
With front sensor and front corner sensor
The switch can be activated when the ignition is switched ON, the selector lever is in any
position except reverse (R), and the vehicle
speed is about 10 km/h (6 mph) or less.
When the parking sensor switch is pressed, a beep sound is heard, the obstruction detection
indication is displayed in the audio screen, and the indicator light in the switch illuminates.

Indicator light
NOTE
ï‚·If the system is cancelled, it will not restore automatically even when the vehicle speed is
decreased to 10 km/h (6 mph) or less.
ï‚·When the ignition is switched OFF, the system status before it was turned off is
maintained. For example, if the ignition is switched OFF while the parking sensor is
activated, the system will be activated when the ignition is switched ON the next time.
Sensor detection condition
The system can be used when the ignition is switched ON and the Park Assist Sensor
Switch has been turned on.
The sensors detect obstructions under the following conditions:
Sensor Condition
Front Sensor The selector lever is in any position ex
cept reverse (R), and the vehicle speed is
about 10 km/h (6 mph) or less.
Front Corner Sensor The vehicle speed is about 10 km/h (6 mph) or less.
Rear Sensor The selector lever is in reverse (R).
Rear Corner Sensor The selector lever is in reverse (R), and
the vehicle speed is about 10 km/h (6 mph)
or less.
The system is cancelled under the following conditions:
ï‚·The parking sensor switch is pressed while the parking sensor is in operation.
When Driving
Parking Sensor System
4-233
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

ï‚·The vehicle speed is 10 km/h (6 mph) or more. (Except rear sensor)
Without front sensor and front corner sensor
When the ignition is swit ched ON and the selector lever is shifted to the reverse (R), the
beep sound activates and the system is enabled for use.
The sensors detect obstructions under the following conditions:
Sensor Condition
Rear Sensor The selector lever is in reverse (R).
Rear Corner Sensor The selector lever is in reverse (R), and the vehicle speed is ab
out 10 km/h (6 mph)
or less.
â–¼ Obstruction Detection Indication
The position of a sensor which has detected an obstruction is indicated. The gauge
illuminates in different areas depending on the distance to an obstruction detected by the
sensor.
As the vehicle approaches closer to an obstruction, the zone in the gauge closer to the
vehicle illuminates.

With 360° view monitorWithout 360° view monitor
Left front
corner sensor Right front
corner sensor
Rear sensor Rear sensor
Left rear
corner sensor Left front
corner sensor
Left rear
corner sensor
Right rear
corner sensor Right front
corner sensor
Right rear
corner sensor
Front sensor
Front sensor
Some models
NOTE
The detection indicator can switch between display and non-display.
Refer to Personalization Features on page 9-9.
System problem notification
If a problem occurs, the driver is notified of the problem by the following indications.
When Driving
Parking Sensor System
4-234
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

Detection IndicatorSolution
Without 360° view monitor
With 360° view moni-tor
Without front sensor
and front corner sen- sor With front sensor and
front corner sensor
Discon- nection
The system may have a
malfunction. Have the ve-
hicle inspected at an Au-
thorized Mazda Dealer as
soon as possible.
System mal-
function
The system may have a
malfunction. Have the ve-
hicle inspected at an Au-
thorized Mazda Dealer as
soon as possible.
Frost/
soiling
Foreign matter may be on
the sensor area corre-
sponding to the obstruc-
tion detection indication
shown. If the system does
not recover, have the vehi-
cle inspected at an Author-
ized Mazda Dealer.
â–¼ Parking Sensor Warning Beep
The beeper sounds as follows while the system is operating.
When Driving
Parking Sensor System
4-235
CX-9_8HT8-EA-19I_Edition2_old
2019-9-24 13:14:55

Front Sensor*, Rear Sensor
Distance Detec-tion area Distance between vehicle and obstruction
Beeper sound*1Front Sensor*Rear Sensor
Farthest distance Approx. 100
―60 cm (39.3 ―23.6
in)
Approx. 150 ―60 cm (59.0 ―23.6
in)
Slow intermittent
sound
Far distance Approx. 60
―45 cm (23.6 ―17.7
in)
Approx. 60 ―45 cm (23.6 ―17.7
in)
Medium intermit-
tent sound
Middle distance Approx. 45
―35 cm (17.7 ―13.7
in)
Approx. 45 ―35 cm (17.7 ―13.7
in)
Fast intermittent
sound
Close distance Within approx. 35 cm (13.7 in)
Within approx. 35 cm (13.7 in)
Continuous sound
*1 The rate at which the intermittent sound beeps in
creases as the vehicle approaches the obstruction.
Front Corner Sensor*, Rear Corner Sensor
Distance Detection area Distance between vehicle and obstruction
Beeper sound*1Front*/Rear Corner Sensor
Far distance Approx. 55
―38 cm (21.7 ―15.0 in)
Medium intermittent sound
When Driving
Parking Sensor System
4-236*Some models.
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55
