change language MAZDA MODEL CX-9 2020 Owners Manual (in English)

Home screen
IconFunction
Applications
Information such as average fuel economy, maintenance, and warnings can be verified.
Depending on the grade an d specification, the screen display may differ.
Entertainment
Operates audio such as the radio. The audi o source most recently used is displayed. An
audio source which cannot be used at that time is skipped and the previous audio source is
displayed.
To change the audio source, select the
icon displayed at th e bottom of the screen.
Communication
Bluetooth® related functions are available.
Navigation
Navigation screen is displayed (vehicles with navigation system).
If the SD card for the navigation system is no t inserted, the compass indicating the direc-
tion in which the vehicle is moving is displayed.
The compass may not indicate the correct bearin g when the vehicle is stopped or traveling
at a slow speed.
Settings
Overall setting menu (Such as display, sound, Bluetooth® and Language).
Depending on the grade an d specification, the screen display may differ.
Interior Features
Audio Set
5-24
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

4. Select .
5. Select
.
6. Select
.
▼ Changing PIN code
PIN code (4 digits) can be changed.
1. Select the
icon on the home screen
to display the Settings screen.
2. Select the
tab.
3. Select
.
4. Select
.
5. Select
.
6. Input the new PIN code to be set.
7. Select
.
Available Language
The Bluetooth® Hands-Free System
applies to the following languages:
English
Spanish
French
Refer to Settings on page 5-78.
Interior Features
Audio Set
5-54
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

3. Select the unread message displayed inbold.
4. The details of the message are
displayed and replying to the message,
making a call, or playback can be
performed.
Changing accoun t for displaying
(E-mail only)
1. Select
.
2. Select the account which you would
like to display. Only the messages for
the selected account are displayed in
the inbox.
Editing preset messages
1. Select the
icon on the home screen
to display the Communication screen.
2. Select
.
3. Select
.
4. Select the preset message which you would like to edit. The keyboard
screen is displayed.
5. When the message is input and
is
selected, the message is stored as a
preset message.
NOTE
Select the icon to change the
language.
Select the icon to switch between
capitalized and lower-case characters.
Select the icon to return to the
previous screen without storing the edit.
Interior Features
Audio Set
5-73
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

Ta bI t e m F u n c t i o n
Devices Bluetooth
Refer to Bluetooth
® Preparation on page 5-52.
Android Auto An Android Auto™ mode connection can be
set on or off when connecting an Android™
Smartphone.
The setting takes effect directly after switching
on/off.
Displays in gray and cannot be selected if an
Android™ Smartphone
is not connected.
Apple CarPlay An Apple CarPlay™ connection can be set on
or off when connecting an iPhone
®.
For the setting to take effect, it is necessary to
connect the iPhone
® again.
Displays in gray and cannot be selected if an
iPhone
® is not connected.
System Tool Tips Turns button explanations ON/OFF.
VR Examples
When this function is ON and the talk button
of the audio remote control switch is pressed,
voice command examples are displayed. When
the function is OFF, they are not displayed.
Language Changes the language.
Temperature Changes the setting between Fahrenheit and
Celsius.
Distance Changes the setting between miles and kilome-
ters.
Music Database Update Used to update Gracenote
®. Gracenote® is
used with USB Audio and Bluetooth® Audio,
and provides:
1. Supplemental music information (Such as song name, artist name)
2. Voice recognition assistance for Play Ar- tist and Play Album
Gracenote
® can be downloaded from the Maz-
da Handsfree Website.
Refer to Gracenote
® Database on page 5-40.
Restore All Factory Settings Memory and settings are
initialized to the fac-
tory settings.
The initialization launches by selecting the
button.
About Agreements and
Disclaimers
Verify the disclaimer and agree.
Version Information Can verify the current audio unit OS version
and Gracenote
® Database version.
Interior Features
Audio Set
5-79
CX-9_8HT8-EA-19I_Edition2_old
2019-9-24 13:14:55

ItemFeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Auto-light con-
trol (page 4-68) Timing by which lights turn on Medium High/
Med. High/ Medium/
Med. Low/ Low A
―
High Beam Con-
trol System
(HBC) (page
4-118) Operational/non-operational
*1On On/Off A
―
Adaptive Front
Lighting System
(AFS) (page
4-117)Operational/non-operational
*1On On/Off A
―
Lights-on re-
minder*8 (page
7-47) Warning beep volume High High/Low/Off A
―
Coming home
light (page 4-71)Time until headlights turn off 30 seconds 120 seconds/
90 seconds/
60 seconds/
30 seconds/ Off A
―
Leaving home
light (page 4-71) Operational/non-operational On On/Off A
―
Turn indicator
(page 4-73)Beep volume High High/Low A
―
Three-flash turn
signal (page
4-74)Operational/non-operational On On/Off A
―
Ambient Light-
ing (page 5-94)Ambient lights brightness*9MediumBright/
Medium/ Dim/
Off
*10
A ―
Rear window
defogger (page
4-78) The operation time for the rear window defog-
ger can be changed.
15 minutes15 minutes/
Continuous
*11――
System
Language Language indicated in display US EnglishDepends on
market
*12A ―
Temperature Temperature unit in dicated in display °F °F/°C A ―
Distance Distance unit indicated in display mi or km mi/km A―
Specifications
Personalization Features
9-13
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55
