odometer MAZDA MODEL CX-9 2022 Owners Manual

▼Multi-information Display (Type A)
INFO switchMulti-information Display (Type A)
Dashboard illumination knob
The multi-information display indi
cates the following information.
Speedometer
Odometer
Trip meter
Outside temperature
Distance-to-empty
Average fuel economy
Current fuel economy
Maintenance Monitor
Blind Spot Monitoring (BSM) Display
Distance Recognition Support System (DRSS) Display
Mazda Radar Cruise Control with Stop & Go function (MRCC with S top & Go function)
System Display
Lane-keep Assist System (LAS) & Lane Departure Warning System ( LDWS) Display
Cruise Control Display
Compass Display
Door-Ajar/Liftgate-Ajar Warning Indication
Message Display
When Driving
Instrument Cluster and Display
4-13
CX-9_8KH5-EA-21K_Edition2_old 2021-9-16 14:11:22

The screen content changes each time the dashboard illumination knob is pressed and held.
Gauge indication
Display off Numerical indication Press and hold
dashboard illumination
knob
Press and hold dashboard
illumination knob
Press and hold dashboard
illumination knob
▼
Odometer, Trip Meter and Trip
Meter Selector
The odometer is constantly displayed on
the screen when the ignition is switched
ON, and the TRIP A or TRIP B screen can
When Driving
Instrument Cluster and Display
4-15
CX-9_8KH5-EA-21K_Edition2_old
2021-9-16 14:11:22

be displayed by operating the INFO
switch.

INFO switch
Press the INFO switch
Trip Meter A
display
Trip Meter B
display
Odometer
The odometer records the total distance
the vehicle has been driven.
Trip meter
The driving distance for a specified
interval is indicated. Two types (TRIP A,
TRIP B) of interval distance and the
average fuel economy for each can be
measured.

For instance, trip me
ter A can record the
distance from the point of origin, and trip
meter B can record the distance from
where the fuel tank is filled.

When trip meter A is selected, TRIP A
will be displayed. Wh en trip meter B is
selected, TRIP B will be displayed.

The trip meter and average fuel economy
can be reset by pressi ng the INFO switch
for 1.5 seconds or more while in each
mode.
NOTE
Only the trip meters record tenths of
kilometers (miles).
The trip record will be erased when:
The power supply is interrupted
(blown fuse or the battery is
disconnected).
The vehicle is driven over 9999.9 km
(mile).
▼ Engine Coolant Temperature Gauge
Displays the engine coolant temperature.
The blue range of the gauge indicates that
the engine coolant temperature is low, and
the red range of the gauge indicates that
the engine coolant temperature is high and
overheating.

When Driving
Instrument Cluster and Display
4-16
CX-9_8KH5-EA-21K_Edition2_old
2021-9-16 14:11:22

▼Multi-information Display (Type B)
INFO switchMulti-information Display (Type B)
The multi-information display in
dicates the following information.
Odometer
Trip meter
Engine coolant temperature gauge
Fuel gauge
Outside temperature
Distance-to-empty
Average fuel economy
Current fuel economy
Maintenance Monitor
Blind Spot Monitoring (BSM) Display
Distance Recognition Support System (DRSS) Display
Mazda Radar Cruise Control with S top & Go function (MRCC with Stop & Go function)
System Display
Lane-keep Assist System (LAS) & Lane Departure Warning System ( LDWS) Display
Cruise Control Display
Compass Display
Message Display
When Driving
Instrument Cluster and Display
4-30
CX-9_8KH5-EA-21K_Edition2_old 2021-9-16 14:11:22

The screen content changes each time the INFO switch is pressed.
Press the INFO switch
Press the INFO switch
Press the INFO switch Press the INFO switch
Press the INFO switch Press the INFO switch
Current Fuel Economy,
Trip Meter A, Average
Fuel Economy, Outside
Temperature,
Odometer, Fuel Gauge
Current Fuel Economy,
Trip Meter B, Average
Fuel Economy, Outside
Temperature,
Odometer, Fuel Gauge
Engine Coolant
Temperature Gauge,
Maintenance Monitor,
Outside Temperature,
Odometer, Fuel Gauge i-ACTIVSENSE display,
Outside Temperature,
Odometer, Fuel Gauge Warning message,
Outside Temperature,
Odometer, Fuel Gauge
*1
*1: Displayed only when a warning occurs. Engine Coolant
Temperature Gauge,
Compass,
Distance-to-empty,
Outside Temperature,
Odometer, Fuel Gauge
▼
Odometer, Trip Meter and Trip
Meter Selector
The odometer is constantly displayed on
the screen when the ignition is switched
ON, and the TRIP A or TRIP B screen can
When Driving
Instrument Cluster and Display
4-31
CX-9_8KH5-EA-21K_Edition2_old
2021-9-16 14:11:22

be displayed by operating the INFO
switch.

Press the INFO switchINFO switch
Odometer,
Trip meter A
Odometer,
Trip meter B
Odometer
The odometer records the total distance
the vehicle has been driven.
Trip meter
The driving distance for a specified
interval is indicated. Two types (TRIP A,
TRIP B) of interval distance and the
average fuel economy for each can be
measured.

For instance, trip me ter A can record the
distance from the point of origin, and trip
meter B can record the distance from
where the fuel tank is filled.

When trip meter A is selected, TRIP A
will be displayed. Wh en trip meter B is
selected, TRIP B will be displayed.

The trip meter and average fuel economy
can be reset by pressi ng the INFO switch
for 1.5 seconds or more while in each
mode.
NOTE
Only the trip meters record tenths of
kilometers (miles).
The trip record will be erased when:
The power supply is interrupted
(blown fuse or the battery is
disconnected).
The vehicle is driven over 9999.9 km
(mile).
▼ Engine Coolant Temperature Gauge
Displays the engine coolant temperature.
The blue range of the gauge indicates that
the engine coolant temperature is low, and
the red range of the gauge indicates that
the engine coolant temperature is high and
overheating.

When Driving
Instrument Cluster and Display
4-32
CX-9_8KH5-EA-21K_Edition2_old
2021-9-16 14:11:22

approximate date and mileage at the time any problem(s) were first brought to the
attention of Mazda or one of our dealers, and a statement of the relief you are seeking.
5. BBB AUTO LINE staff may try to help resolve your dispute thro ugh mediation. If
mediation is not successful, or if you do not wish to participate in mediation, claims
within the program's jurisdictio n may be presented to an arbitrator at an informal
hearing. The arbitrator's decision should ordinarily be issued within 40 days from the
time your complaint is filed; there may be a delay of 7 days if you did not first contact
Mazda about your problem, or a delay of up to 30 days if the ar bitrator requests an
inspection/report by an impartial technical expert or further i nvestigation and report by
BBB AUTO LINE.
6. You are required to use BBB AUTO LINE before asserting in cou rt any rights or
remedies conferred by California Civil Code Section 1793.22. Yo u are also required to
use BBB AUTO LINE before exercising rights or seeking remedies created by Title I of
the Magnuson-Moss Warranty Act, 15 U.S.C. sec. 2301 et seq. If you choose to seek
redress by pursuing rights and remedies not created by Californ ia Civil Code Section
1793.22 or Title I of the Magnuson-Moss Warranty Act, resort to BBB AUTO LINE is
not required by those statutes.
7. California Civil Code Section 1793.2 (d) requires that, if Ma zda or its representative is
unable to repair a new motor vehicle to conform to the vehicle' s applicable express
warranty after a reasonable number of attempts, Mazda may be re quired to replace or
repurchase the vehicle. Califor nia Civil Code Section 1793.22 ( b) creates a presumption
that Mazda has had a reasonable number of attempts to conform t he vehicle to its
applicable express warranties if, within 18 months from deliver y to the buyer or 18,000
miles on the vehicle's odometer, whichever occurs first, one or more of the following
occurs:
The same nonconformity [a failure to conform to the written warranty that
substantially impairs the use, value or safety of the vehicle] results in a condition that
is likely to cause death or serious bodily injury if the vehicl e is driven AND the
nonconformity has been subject to repair two or more times by M azda or its agents
AND the buyer or lessee has directly notified Mazda of the need fo r the repair of the
nonconformity; OR
The same nonconformity has been subject to repair 4 or more times by Mazda or its
agents AND the buyer has notified Mazda of the need for the repair of the
nonconformity; OR
The vehicle is out of service by reason of repair of nonconformities by Mazda or its
agents for a cumulative total of more than 30 calendar days aft er delivery of the
vehicle to the buyer.

NOTICE TO Mazda AS REQUIRED ABOVE SHALL BE SENT TO THE
FOLLOWING ADDRESS:
Mazda North American Operations
Customer Information and Reporting Safety Defects
Customer Assistance
8-5
CX-9_8KH5-EA-21K_Edition2_old 2021-9-16 14:11:22

Customer Assistance (Canada)
▼Satisfaction Review Process
Your complete and permanent satisfaction is of primary concern
to Mazda. All Authorized
Mazda Dealers have both the knowledge and tools to keep your Ma zda in top condition. In
our experience, any questions, pro blems, or complaints regarding the operation of your
Mazda or any other general service transactions are most effect ively resolved by your
dealer. If the cause of your dissatisfaction cannot adequately be addressed by normal
dealership procedures, we recommend that you take the following steps:
▼STEP 1: Contact the Mazda Dealer
Discuss the matter with a member of dealership management. If t
he Service Manager has
already reviewed your concerns, contact the owner of the dealership or its General Manager.
▼STEP 2: Contact the
Mazda Regional Office
If you feel that you still requ ire assistance, ask the dealer S ervice Manager to arrange for
you to meet the local Mazda Service Representative. If more exp edient, contact Mazda
Canada Inc. Regional Office nearest you for such arrangements. Regional Office address
and phone numbers are shown (page 8-9).
▼ STEP 3: Contact the Mazda Cu
stomer Relations Department
If still not substantially satisfied, contact the Customer Rela tions Department, Mazda
Canada Inc., 55 Vogell Road, Richmond Hill, Ontario, L4B 3K5 Ca nada TEL: 1 (800)
263-4680.
Provide the Department wit h the following information:

1. Your name, address and telephone number
2. Year and model of vehicle
3. Vehicle Identification Number ( VIN). Refer to the Vehicle Identification Number on
page 9-2 for the location of the VIN.
4. Purchase date
5. Present odometer reading
6. Your dealer's name and location
7. The nature of your problem and/or cause of dissatisfaction

The Department, in cooperation wi th the local Mazda Service Representative, will review
the case to determine if everyth ing possible has been done to ensure your satisfaction.

Please recognize that the resolution of service problems in mos t cases requires the use of
your Mazda dealer's service facilities, personnel and equipment . We urge you to follow the
above three steps in sequenc e for most effective results.
Customer Information and Reporting Safety Defects
Customer Assistance
8-7
CX-9_8KH5-EA-21K_Edition2_old 2021-9-16 14:11:22

Index
Fuel Gauge.................................. 4-17
Indication/Indicator Lights.......... 4-25
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS) Display..........................4-20
Maintenance Monitor.................. 4-20
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) Display.......4-21
Message Display..........................4-21
Multi-information Display (Type
A)................................................. 4-13
Odometer..................................... 4-15
Outside Temperature Display...... 4-18
Speedometer................................ 4-12
Speed Unit Selector..................... 4-18
Tachometer.................................. 4-12
Trip Meter....................................4-15
Warning Indication/Warning
Lights........................................... 4-23
Instrument Cluster (Type B)............. 4-29 Average Fuel Economy............... 4-35
Blind Spot Monitoring (BSM)
Display......................................... 4-36
Compass Display......................... 4-37
Cruise Control Set Vehicle Speed
Display......................................... 4-37
Current Fuel Econo my................ 4-36
Dashboard Illumina tion............... 4-34
Distance Recognition Support System
(DRSS) Display........................... 4-37
Distance-to-empty....................... 4-35
Engine Coolant Temperature
Gauge........................................... 4-32
Fuel Gauge.................................. 4-33
Indication/Indicator Lights.......... 4-41
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS) Display..........................4-36
Maintenance Monitor.................. 4-36Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) D isplay.......4-37
Multi-information Display (Type
B)................................................. 4-30
Odometer..................................... 4-31
Outside Temperature Display...... 4-35
Speedometer................................ 4-29
Tachometer.................................. 4-29
Trip Meter....................................4-31
Warning Indication/Warning
Lights........................................... 4-39
Warning (Display Indication)...... 4-37
Interior Care...................................... 6-58 Active driving display
maintenance................................. 6-60
Cleaning the floor mats............... 6-60
Cleaning the window interiors.....6-60
Instrument panel top
maintenance................................. 6-59
Leather upholstery
maintenance................................. 6-59
Panel maintenance....................... 6-59
Plastic part maintenance.............. 6-59
Seat belt maintenance..................6-58
Upholstery maintenan ce.............. 6-58
Vinyl upholstery maintenance..... 6-58
Interior Lights................................... 5-56
Luggage compartment light.........5-56
Map lights....................................5-56
Overhead lights............................5-56
i-ACTIVSENSE.............................. 4-102 Active safety technology........... 4-102
Adaptive Front Lighting System
(AFS)......................................... 4-105
Advanced Smart City Brake Support
(Advanced SCBS)..................... 4-157
Blind Spot Monitoring (BSM) ............
................................................... 4-109
Camera and sensors................... 4-103
10-5
CX-9_8KH5-EA-21K_Edition2_old 2021-9-16 14:11:22
