MAZDA MODEL MX-5 2005 Owners Manual (in English)

Black plate (141,1)
lWhen driving over uneven surfaces,
the sound may jump.
lThe CD player/changer has been
designed to play CDs bearing the
identification logo as shown. No other
discs can be played.
lBe sure never to touch the signal
surface when handling the CDs. Pick
up a CD by grasping the outer edge or
the edge of the hole and the outer edge.
lDo not stick paper or tape on the CD.
Avoid scratching the reverse side (the
side without a label).
lDust, finger smudges, and dirt can
decrease the amount of light reflected
from the signal surface, thus affecting
sound quality. If the CD should
become soiled, gently wipe it with a
soft cloth from the center of the CD to
the edge.
lDo not use record sprays, antistatic
agents, or household spray cleaners.
Volatile chemicals such as benzine and
thinner can also damage the surface of
the CD and must not be used. Anything
that can damage, warp, or fog plastic
should never be used to clean CDs.
lCDs, like traditional audio records, are
made of plastic. To avoid warping,
keep the CDs in their cases and do not
store them where they will be exposed
to direct sunlight.
lThe CD player/changer ejects the CD if
the CD is inserted upside down. Also
dirty and/or defective CDs may be
ejected.
l8 cm (3 in) CDs and CD accessories
(e.g. 8 cm disc adapter) cannot be used
in the CD player/changer.
lDo not insert cleaning discs in the CD
player/changer.
lDo not insert any disc with a peel-off
or seal on it.
Interior Comfort
Audio System
6-15
MX-5 Miata_8T72-EA-04G_Edition1 Page141
Wednesday, June 9 2004 3:5 PM
Form No.8T72-EA-04G

Black plate (142,1)
6-16
Interior Comfort
Audio System
MX-5 Miata_8T72-EA-04G_Edition1 Page142
Wednesday, June 9 2004 3:5 PM
Form No.8T72-EA-04G

Black plate (143,1)
Types of the Audio Set
Audio Set (Type A) ................................................................................................ page 6-19
Audio Set (Type B) ................................................................................................ page 6-43
(Some countries.)
Interior Comfort
Audio System
6-17
MX-5 Miata_8T72-EA-04G_Edition1 Page143
Wednesday, June 9 2004 3:5 PM
Form No.8T72-EA-04G

Black plate (144,1)
6-18
Interior Comfort
Audio System
MX-5 Miata_8T72-EA-04G_Edition1 Page144
Wednesday, June 9 2004 3:5 PM
Form No.8T72-EA-04G

Black plate (145,1)
Audio Set (Type A)í
CD Player In-dash CD Changer
Cassette Tape Player Mini Disc (MD) Player Illustration is of a representative audio unit.
Power/Volume/Sound Controls .............................................................................. page 6-20
Clock ...................................................................................................................... page6-24
Operating the Radio ............................................................................................... page 6-26
Operating the Cassette Tape Player ........................................................................ page 6-28
Operating the Mini Disc (MD) Player .................................................................... page 6-32
Operating the Compact Disc (CD) Player .............................................................. page 6-36
Operating the In-Dash CD Changer ....................................................................... page 6-38
Error Indications ..................................................................................................... page 6-41
Interior Comfort
Audio System
6-19íSome models. MX-5 Miata_8T72-EA-04G_Edition1 Page145
Wednesday, June 9 2004 3:5 PM
Form No.8T72-EA-04G

Black plate (146,1)
qPower/Volume/Sound Controls
Display
Audio control dial Power/Volume dial
Power ON/OFF
Turn the ignition switch to the ACC or
ON position.
Press the power/volume dial to turn the
audio system on.
Press the power/volume dial again to turn
the audio system off.
NOTE
To prevent the battery from being
discharged, do not leave the audio
system on for a long period of time
when the engine is not running.
Volume adjustment
To adjust the volume, turn the power/
volume dial.Turn the power/volume dial to the right to
increase volume, to the left to decrease it.
Audio sound adjustment
1. Press the audio control dial to select the
function. The selected function will be
indicated.
6-20
Interior Comfort
Audio System
MX-5 Miata_8T72-EA-04G_Edition1 Page146
Wednesday, June 9 2004 3:5 PM
Form No.8T72-EA-04G

Black plate (147,1)
2. Turn the audio control dial to adjust the
selected functions as follows:
BOSE Sound System-equipped model
*1
*1 *2
*1Depending on the mode selected, the
indication changes.
*2BAL function is available only for the
front speakers.
Indication Turn Left Turn Right
Select mode Select mode
Decrease bass Increase bass
Decrease
trebleIncrease
treble
Shift the sound
to the frontShift the sound
to the rear
(front speakers
only)Shift the sound
to the leftShift the sound
to the right
OFF ON
Standard audio-equipped model
*1
*2
*1If your vehicle is not equipped with rear
speakers, adjust the power/volume dial so
the level is even.
*2Depending on the mode selected, the
indication changes.
Indication Turn Left Turn Right
Decrease bass Increase bass
Decrease
mid-rangeIncrease
mid-range
Decrease
trebleIncrease
treble
Shift the sound
to the frontShift the sound
to the rear
Shift the sound
to the leftShift the sound
to the right
OFF ON
NOTE
About 5 seconds after selecting any
mode, the volume function will be
automatically selected. To reset bass,
mid-range, treble, fade and balance,
press the audio control dial for 2
seconds. The unit will beep and
“CLEAR”will be displayed.
Interior Comfort
Audio System
6-21
MX-5 Miata_8T72-EA-04G_Edition1 Page147
Wednesday, June 9 2004 3:5 PM
Form No.8T72-EA-04G

Black plate (148,1)
Automatic Level Control (ALC)
(BOSE Sound System-equipped model)
The automatic level control is a feature
that automatically adjusts audio volume
and sound quality according to the vehicle
speed.
The volume increases in accordance with
the increase in vehicle speed, and
decreases as vehicle speed decreases.
The following 7 modes are available.
Select the desired mode according to use.
Mode UseVolume
change
ALC does
not operate.No change
Use when
the
convertible
top is
closed.
Three levels
are
available.Minimum
Medium
Maximum
Use when
the
convertible
top is open.
Three levels
are
available.Minimum
Medium
Maximum
Turn the audio control dial to select the
desired mode. The selected mode will be
indicated.
BEEP setting
The beep-sound when operating the audio
system can be set on or off.
6-22
Interior Comfort
Audio System
MX-5 Miata_8T72-EA-04G_Edition1 Page148
Wednesday, June 9 2004 3:5 PM
Form No.8T72-EA-04G

Black plate (149,1)
Interior Comfort
Audio System
6-23
MX-5 Miata_8T72-EA-04G_Edition1 Page149
Wednesday, June 9 2004 3:5 PM
Form No.8T72-EA-04G

Black plate (150,1)
qClock
Display Clock button
Hour set
button
Minute set
button
Setting the time
The clock can be set at any time when the
ignition switch is in the ACC or ON
position.
1. To adjust the time, press the clock
button (
) for about 2 seconds
until a beep is heard.
The clock's current time will flash.
NOTE
To select 12-hour or 24-hour clock
time, turn the audio control dial while
the clock display is flashing. After
selecting the desired display, press the
audio control dial to return to the
flashing clock display.2. To advance the hours, press the hour
set button (
). To advance the
minutes, press the minute set button
(
) while the time is flashing.
3. Press the clock button (
) again
to start the clock.
Exact hour adjustment
1. To set the exact hour, press the clock
button (
) for about 2 seconds
until a beep is heard.
The clock's current time will flash.
2. Press the clock button (
) again
and the time will be adjusted as
follows:
(Example)
12:01―12:29→12:00
12:30―12:59→1:00
6-24
Interior Comfort
Audio System
MX-5 Miata_8T72-EA-04G_Edition1 Page150
Wednesday, June 9 2004 3:5 PM
Form No.8T72-EA-04G
