MAZDA MODEL MX-5 MIATA 2003 Owners Manual

9-13
Customer Information and Reporting Safety Defects
Uniform Tire Quality Grading System (UTQGS)
Form No. 8R09-EA-02G
These grades will be added to the sidewalls of passenger vehicle tires over the next several
years according to a schedule established by the NHTSA and the tire manufacturers.
The grade of tires available as standard or optional equipment on Mazda vehicle may vary
with respect to grade.
ALL PASSENGER VEHICLE TIRES MUST CONFORM TO THESE GRADES AND
TO ALL OTHER FEDERAL TIRE-SAFETY REQUIREMENTS.

Uniform Tire Quality Grading
Quality grades can be found where applicable on the tire sidewall between tread shoulder
and maximum section width.
For example:
Treadwear 200 Traction AA Temperature A
The temperature grade for this tire is established for a tire that is properly inflated
and not overloaded. Excessive speed, underinflation, or excessive loading, either
separately or in combination, can cause heat buildup and possible tire failure.
WARNING
UTQGS MARK (example)
TREADWEAR 200 TRACTION AA
TEMPERATURE A
J07R_8R09_EA_02G_Edition4.book Page 13 Monday, February 3, 2003 1:16 PM

9-14
Customer Information and Reporting Safety Defects
Form No. 8R09-EA-02G
Reporting Safety Defects
Reporting Safety Defects
NOTE
If you live in the U.S.A., all correspondence to Mazda Motor Corporation should be
forwarded to:
Mazda North American Operations
7755, Irvine Center Drive
Irvine, California 92618-2922
P.O. Box 19734
Irvine, CA 92623-9734
Customer Assistance Center or toll free at 1 (800) 222-5500
If you live outside of the U.S.A., please contact the nearest Mazda Distributor shown
(page 9-7) in this booklet.
J07R_8R09_EA_02G_Edition4.book Page 14 Monday, February 3, 2003 1:16 PM

9-15
Customer Information and Reporting Safety Defects
Form No. 8R09-EA-02G
Service Publications
Factory-authorized Mazda service publications are available for owners who wish to do
some of their own maintenance and repair.
When requesting any of our publications through an Authorized Mazda Dealer, refer to the
chart below.
If they don’t have what you need in stock, they can order it for you.

WORKSHOP MANUAL:
Covers recommended maintenance and repair procedures of the drive train, body and
chassis.

WIRING DIAGRAM:
Provides electrical schematics as well as component location for the entire electrical
system.

OW N E R
’S MANUAL:
This booklet contains information regarding the proper care and operation of your vehicle.
This is not a technician ’s manual.
Service Publications
PUBLICATION ORDER NUMBER PUBLICATION DESCRIPTION
9999-95-042B-03 2003 WORKSHOP MANUAL (English)
9999-95-026G-03 2003 WIRING DIAGRAM (English)
9999-95-031C-03 (U.S.A. only) 2003 OWNER’S MANUAL
9999-EC-031C-03 (Canada only) 2003 OWNER’S MANUAL
J07R_8R09_EA_02G_Edition4.book Page 15 Monday, February 3, 2003 1:16 PM

9-16
Form No. 8R09-EA-02G
J07R_8R09_EA_02G_Edition4.book Page 16 Monday, February 3, 2003 1:16 PM

10-1
Form No. 8R09-EA-02G
10Specifications
Technical information about your Mazda.
Identification Numbers ............................................................. 10- 2
Vehicle Information Labels ................................................... 10- 2
Specifications ............................................................................. 10- 4
Specifications ........................................................................ 10- 4
J07R_8R09_EA_02G_Edition4.book Page 1 Monday, February 3, 2003 1:16 PM

10-2
Form No. 8R09-EA-02G
Identification Numbers

Vehicle Identification Number
The vehicle identification number legally
identifies your vehicle. The number is on
a plate attached to the left top side of the
dashboard. This plate can easily be seen
through the windshield.

Motor Vehicle Safety Standard
Label

Chassis Number

Vehicle Emission Control
Information Label

Tire Pressure Label
Vehicle Information Labels
J07R_8R09_EA_02G_Edition4.book Page 2 Monday, February 3, 2003 1:16 PM

10-3
Identification Numbers
Form No. 8R09-EA-02G

Engine Number
Front
J07R_8R09_EA_02G_Edition4.book Page 3 Monday, February 3, 2003 1:16 PM

10-4
Form No. 8R09-EA-02G
Specifications

Engine

Electrical System

Lubricant Quality
*Refer to the recommended SAE viscosity numbers on page 8-13 .
Specifications
Item
Model
Type DOHC-16V in-line, 4-cylinder
Bore ×Stroke 83×85mm (3.3 ×3.4 in)
Displacement 1,840 ml (1,840 cc, 112.2 cu in)
Compression ratio 10.0:1
Item Model
Battery Maintenance-free, 12V-32AH/5HR
Alternator 12V-80 A
Starter 12V-1.0 kW
Spark-plug number NGK
BKR5E11, BKR6E11
DENSO K16PR-U11, K20PR-U11
Spark-plug gap 1.0—1.1 mm (0.040 —0.043 in)
Lubricant Classification
API Service ILSAC
Engine oil
*
SG (Energy Conserving II) —
SH (Energy Conserving II) GF-I SJ GF-II
SL GF-III
Lubricant Classification
Manual transmission oil Any temperature
API Service GL-4 or GL-5
SAE 75W-90
Above 10 °C (50 °F) API Service GL-4 or GL-5
SAE 80W-90
Automatic transmission fluid ATF M-III or equivalent (e.g. Dexron ® III)
Rear differential oil API Service GL-5
SAE 90
Power steering fluid ATF M-III or equivalent (e.g. Dexron ® III)
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
J07R_8R09_EA_02G_Edition4.book Page 4 Monday, February 3, 2003 1:16 PM

10-5
Specifications
Form No. 8R09-EA-02G

Capacities
(Approximate Quantities)
Check oil and fluid levels with dipsticks or reservoir gauges.

Dimensions
*With license plate holder

We i g h t s

Air Conditioner
Item Unit
L US qt Imp qt
Engine oil With oil filter
3.84.0 3.3
Without oil filter 3.63.8 3.2
Coolant 6.06.3 5.3
Manual transmission oil 5-Speed transmission 2.0
2.11.8
6-Speed transmission 1.8 1.91.6
Automatic transmission fluid 6.77.1 5.9
Rear differential oil 1.01.1 0.9
Fuel tank 48 12.7 (US gal) 10.6 (Imp gal)
Item mm (in)
Overall length 3,945 (155.3), 3,963 (156.0)
*
Overall width 1,678 (66.1)
Overall height 1,228 (48.4)
Front tread 1,415 (55.7)
Rear tread 1,440 (56.7)
Wheelbase 2,265 (89.2)
Item Weight
GVWR (Gross Vehicle Weight Rating) 1,335 kg (2,943 lb)
GAWR (Gross Axle Weight Rating) Front
685 kg (1,510 lb)
Rear 670 kg (1,477 lb)
Gas complies with SAE J639 Maximum operating charge
HFC134a (R134a) 0.4 kg (14.1 oz)
J07R_8R09_EA_02G_Edition4.book Page 5 Monday, February 3, 2003 1:16 PM

10-6
Specifications
Form No. 8R09-EA-02G

Light Bulbs

Tires
Check the tire pressure label for tire size and inflation pressure. Refer to Tire Inflation
Pressure on page 8-28.
Standard tire
Temporary spare tire

Fuses
Refer to the fuse rating on page 8-37
Light bulb
Wattage
Headlights High beam (HB3)
60
Low beam (HB4) 51
Front turn signal/Parking lights 27/8
Fog lights 55
Side-marker lights 3.8
Rear turn signal lights 21
Brake lights/Taillights 21/5
High-mount brake lights 21
Reverse lights 21
License plate lights/Trunk lights 5
Overhead light 8
Tire size Inflation pressure
Front Rear
195/50 R15 82V 180 kPa (1.8 kgf/cm
2, 26 psi)180 kPa (1.8 kgf/cm2, 26 psi)
205/45 R16 83W
Tire size Inflation pressure
T115/70 D14 88M 420 kPa (4.2 kgf/cm
2, 60 psi)
T105/70 D15 85M 420 kPa (4.2 kgf/cm2, 60 psi)
