3. Turn the screw counterclockwise andremove it, and then partially peel back
the mudguard.

4. Turn the socket and bulb assemblycounterclockwise and remove it.
5. Disconnect the bulb from the socket.
6. Install the new bulb in the reverseorder of the removal procedure.
Front side-marker lights
1. Make sure the ignition is switched off,and the headlight switch is off.
2. If you are changing the right bulb, start the engine, turn the steering wheel all
the way to the right, and turn off
engine. If you are changing the left
bulb, turn the steering wheel to the left.
3. Pull the center of each plastic retainer and remove the retainers, and then
partially peel back the mudguard.

Removal
Installation
4. Turn the socket and bulb assemblycounterclockwise and remove it.
5. Disconnect the bulb from the socket.
6. Install the new bulb in the reverseorder of the removal procedure.
Maintenance and Care
Owner Maintenance
6-41
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

Front turn signal lights
1. Make sure the ignition is switched off,and the headlight switch is off.
2. If you are changing the right bulb, start the engine, turn the steering wheel all
the way to the right, and turn off
engine. If you are changing the left
bulb, turn the steering wheel to the left.
3. Pull the center of each plastic retainer
and remove the retainers, and then
partially peel back the mudguard.

Removal
Installation
4. Disconnect the connector from the unit by pressing the tab on the connector
with your finger and pulling the
connector rearward.

5. Turn the socket and bulb assemblycounterclockwise and remove it.
6. Disconnect the bulb from the socket.

7. Install the new bulb in the reverseorder of the removal procedure.
Side turn signal lights
1. Make sure the ignition is switched off, and the headligh t switch is off.
2. If you are changing the right bulb, start the engine, turn the steering wheel all
the way to the right, and turn off
engine. If you are changing the left
bulb, turn the steering wheel to the left.
Maintenance and Care
Owner Maintenance
6-42
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

3. Pull the center of each plastic retainerand remove the retainers, and then
partially peel back the mudguard.

Removal
Installation
4. Remove the unit by pressing the tab onthe unit with your finger and pulling
the unit forward.

5. Detach the electrical connector from
the unit by pulling it to the rear.

6. Install the new side turn signal unit inthe reverse order of the removal
procedure.
Rear turn signal lights
1. Make sure the ignition is switched off, and the headlight switch is off.
2. Pull the center of each plastic retainer
and remove the retainers and the trunk
end trim.

Removal
Installation
Maintenance and Care
Owner Maintenance
6-43
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

3. Disconnect the connector from the unitby pressing the tab on the connector
with your finger and pulling the
connector downward.

4. Pull the center of each plastic retainer
and remove the retainers, and then
partially peel back the trunk side trim.

Removal
Installation
5. To provide a hole fo r inserting a finger
to remove the rear combination lamp
unit later in the procedure, pinch the
top and bottom of the grommet shown
in the figure and press it out of the hole
in the direction of t he rear combination
lamp unit.

Grommet
Rear combination lamp
unit

Grommet
Body
Maintenance and Care
Owner Maintenance
6-44
MX-5_8GV5-EA-18E_Edition3
2018-7-17 15:48:16

6. Apply protective tape as shown in thefigure. Otherwise, the rear combination
lamp unit will contact the body and
may scratch or damage it.
Always apply three layers of protective
tape to the area indicated in the figure.

Protective tape
Rear combination
lamp unit
Area specifically in need
of protection
CAUTION
 Do not use tape with strong adhesive
strength. Otherwise, the vehicle paint
may peel off.
 Always apply three layers of
protective tape to the area indicated
in the
figure. Otherwise, the body
may become scratched or damaged
when pulling out the rear
combination lamp unit.
7. Remove the screw and nut.
8. To remove the rear combination lampunit, insert your finger from inside the
trunk and into the hole from which the
grommet was removed in Step 5, and
while holding the lamp lens (round
part) of the rear combination lamp with
your hand, press the rear combination
lamp unit until the hook detaches from
the clip.

Rear combination lamp unit
Hook
Grommet installation
hole
Maintenance and Care
Owner Maintenance
6-45
MX-5_8GV5-EA-18E_Edition3
2018-7-17 15:48:16

9. After the hook is detached, pull out therear combination lamp unit in the
direction of the arrow and remove it.

Grommet installation hole
Clip
Hook Rear combination
lamp unit
CAUTION
Carefully pull out the rear combination
lamp unit when removing it from the
body.
The wiring may become damaged if the
rear combination lamp unit is forcefully
pulled out.
10. Turn the socket and bulb assembly counterclockwise and remove it.
11. Disconnect the bulb from the socket.
12. Install the new bulb in the reverse
order of the removal procedure.
Rear side-marker lights
1. Make sure the ignition is switched off,and the headligh t switch is off.
2. Turn the socket and bulb assembly counterclockwise and remove it.
3. Disconnect the bulb from the socket.
4. Install the new bulb in the reverseorder of the removal procedure.
Maintenance and Care
Owner Maintenance
6-46
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

Reverse lights
1. Make sure the ignition is switched off,and the headlight switch is off.
2. Turn the socket and bulb assembly counterclockwise and remove it.
3. Disconnect the bulb from the socket.
4. Install the new bulb in the reverseorder of the removal procedure.
License plate lights
1. Make sure the ignition is switched off,and the headlight switch is off.
2. Remove the unit by pressing the tab on the unit with your finger and pulling
the unit downward.

3. Turn the socket and bulb assemblycounterclockwise and remove it.
4. Disconnect the bulb from the socket.
5. Install the new bulb in the reverse
order of the removal procedure.
Maintenance and Care
Owner Maintenance
6-47
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

▼Replacing Interior Light Bulbs
Overhead light
1. Wrap a small flathead screwdriver with
a soft cloth to prevent damage to the
lens, and then remove the lens by
carefully prying on th e edge of the lens
with the flathead screwdriver.
2. Disconnect the bulb by pulling it out.

3. Install the new bulb in the reverseorder of the removal procedure.
Trunk light
1. Wrap a small flathead screwdriver witha soft cloth to prev ent damage to the
lens, and then remove the lens by
carefully prying on the edge of the lens
with the flathead screwdriver.

2. Disconnect the connector from the unit.
3. Disconnect the bulb by pulling it out.
4. Install the new bulb in the reverseorder of the removal procedure.
Maintenance and Care
Owner Maintenance
6-48
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

Fuses
Your vehicle's electrical system is
protected by fuses.

If any lights, accessories, or controls do
not work, inspect the appropriate circuit
protector. If a fuse has blown, the inside
element will be melted.

If the same fuse blows again, avoid using
that system and consult an Authorized
Mazda Dealer as soon as possible.
▼ Fuse Replacement
Replacing the fuses on
the vehicle's left
side
If the electrical system does not work, first
inspect the fuses on the vehicle's left side.

1. Make sure the ignition is switched off,
and other switches are off.
2. Open the fuse panel cover.
3. Pull the fuse straight out with the fuse puller provided on the fuse block
located in the engine compartment.
4. Inspect the fuse and replace it if it isblown.
Normal Blown
5. Insert a new fuse of the same
amperage rating, and make sure it fits
tightly. If it does not fit tightly, have an
expert install it. We recommend an
Authorized Mazda Dealer.
If you have no spare fuses, borrow one
of the same rating from a circuit not
essential to vehicle operation, such as
the AUDIO or OUTLET circuit.
CAUTION
Always replace a fuse with a genuine
Mazda fuse or equivalent of the same
rating. Otherwise you may damage the
electric system.
6. Reinstall the cover and make sure that it is securely installed.
Maintenance and Care
Owner Maintenance
6-49
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

Replacing the fuses under the hood
If the headlights or other electrical
components do not work and the fuses in
the cabin are normal, inspect the fuse
block under the hood. If a fuse is blown, it
must be replaced. Follow these steps:

1. Make sure the ignition is switched off,and other switches are off.
2. Remove the fuse block cover.
NOTE
If the lock is forcefully opened, the fuse
block cover may come in contact with
the frame when it is removed and
become scratched.
When removing the cover, remove it
slowly according to the following
procedure.
1. Disengage the rear lock by pressing down on the front tab with
your fingers.
2. Remove the front tab while slightly
lifting the front of the cover.
3. Remove the cover while lifting itand sliding it to the rear.
3. If any fuse but the MAIN fuse isblown, replace it with a new one of the
same amperage rating .
Normal
Blown
WARNING
Do not replace the main fuse by
yourself. Have an Authorized Mazda
Dealer perform the replacement:
Replacing the fuse by yourself is
dangerous because the MAIN fuse is a
high current fuse. Incorrect
replacement could cause an electrical
shock or a short circuit resulting in a
fire.
4. Reinstall the cover and make sure that it is securely installed.
