MERCEDES-BENZ B-CLASS HATCHBACK 2008 Owners Manual

Service products and capacities
298
Capacities The following values indicate the total cooling system capacities.
B 150
Manual trans- mission B 150
BlueEFFICIENCY B 150
AUTOTRONIC* B 170
Manual trans- mission B 170
BlueEFFICIENCY B 170
AUTOTRONIC* Coolant
6.3 l 6.3 l 6.5 l 6.3 l 6.3 l 6.6 l
Amount of antifreeze/corrosion inhibitor required for antifreeze protection
Down to
–37 †(approx.
50%)
3.2 l 3.2 l 3.25 l 3.2 l 3.2 l 3.0 l
Down to
–45 †(approx.
55%)
3.5 l 3.5 l 3.6 l 3.5 l 3.5 l 3.65 l
B 200 B 200
TURBO B 180 CDI B 200 CDI
Coolant
6.6 l 8.5 l 8.0 l 9.7 lTechnical data
* optional
245_AKB; 2; 7, en-GB
wdomann,
Version: 2.11.4 2008-10-17T11:22:31+02:00 - Seite 298Dateiname: 6515_1640_02_buchblock.pdf; preflight

Service products and capacities
299Amount of antifreeze/corrosion inhibitor required for antifreeze protection
Down to
–37 †(approx.
50%)
3.0 l 4.25 l 4.0 l 4.85 l
Down to
–45 †(approx.
55%) 3.65 l 4.7 l 4.4 l 5.35 l
Brake fluid
Over a period of time, the brake fluid absorbs
moisture from the air; this lowers its boiling
point. G
Risk of accident
If the boiling point of the brake fluid is too
low, vapour pockets may form in the brake
system when the brakes are applied hard
(e.g. when driving downhill). This would
impair braking efficiency.
Have the brake fluid renewed every two
years with a brake fluid that has been
approved by Mercedes-Benz and have this
confirmed in the Service Booklet. i
There is usually a notice in the engine
compartment to remind you when the next
brake fluid change is due. Windscreen washer system
G
Risk of fire
Windscreen washer concentrate is highly
flammable. Fire, naked flames and smoking
are prohibited when windscreen washer
concentrate is being handled.
The washer fluid reservoir holds approxi-
mately 6.4 litres.
The headlamp cleaning system* and the
windscreen washer system are both supplied
from the washer fluid reservoir. Further information on windshield washer
fluid and the mixing ratio can be found on
(Y
page 175). Technical data
* optional
245_AKB; 2; 7, en-GB
wdomann,
Version: 2.11.4
2008-10-17T11:22:31+02:00 - Seite 299 ZDateiname: 6515_1640_02_buchblock.pdf; preflight

300245_AKB; 2; 7, en-GB
wdomann ,V ersion: 2.11.4
2008-10-17T11:22:31+02:00 - Seite 300 Dateiname: 6515_1640_02_buchblock.pdf; preflight
