Steering Lock

0 - The electronic key can be withdrawn in this position only. The steering is locked with the electronic key removed
from the steering lock. The electronic key an be removed only with the selector lever in position "P" and the foot off
the brake pedal. After removing the electronic key or with the electronic key in steering lock position 0, the
selector lever is locked in position "P".
1 - Steering is unlocked. (If necessary, move steering wheel slightly to allow the electronic key to be turned clockwise
to position 1.) Most electrical consumers can be operated. For detailed information see respective subjects.
2 - Driving position.
3 - Starting position.

Refer to Index for Starting and turning off the engine.


Warning !
When leaving the vehicle always remove the electronic key from the steering lock, and lock the vehicle.
Do not leave children unattended in the vehicle, or with access to an unlocked vehicle.
Unsupervised use of vehicle equipment may cause serious personal injury.


Important !
If the electronic key is left in the steering lock position 0 for an extended period of time, it can no longer be turned
in the lock. In this case, remove electronic key from steering lock and reinsert.

Notes:
A warning sounds when the driver's door is opened with the electronic key in steering lock position 1 or 0. With the
engine at idle speed, the charging rate of the alternator (output) is limited. It is therefore recommended to turn off
unnecessary electrical consumers while driving in stop-and-go traffic. This precaution helps to avoid draining of the
battery. Unnecessary strain on the battery and charging system may be minimized by turning off the following power
consumers, for example: Heated seats, rear window defroster. In addition, the automatic climate air volume control
should be set to the lowest position. The steering lock can only be unlocked with the vehicle battery properly
connected.

Caution !
To prevent accelerated battery discharge and a possible dead battery, always remove the electronic key from the
steering lock. Do not leave the electronic key in steering lock position 0.

Layout of Poly-V-belt Drive

The engine is equipped with two poly-V-belts.
For dimensions of the poly-V-belts, see Technical Data in Index.






C 230 Kompressor
Routing, Belt I


1. Crankshaft
2. Air conditioner compressor
3. Power steering pump
4. Coolant pump
5. Idler pulley


C 230 Kompressor
Routing, Belt II


6. Generator (alternator)
7. Idler pulley
8. Idler pulley
9. Supercharger


C 230 Kompressor
Routings combined, Belts I and II

Spare Parts Service


C 280, C 43 AMG
1. Automatic belt tensioner
2. Crankshaft:
3. Air conditioner compressor
4. Generator (alternator)
5. Idler pulley
6. Power steering pump
7. Coolant pump, fan


For dimensions of the poly-V-belt, see Technical Data in Index.


Spare Parts Service

All authorized Mercedes-Benz dealers maintain a stock of original spare parts required for maintenance and repair
work. In addition, strategically located parts distribution centers provide quick and reliable parts service. More than
300,000 different spare parts, for other Mercedes-Benz models, are available.
Mercedes-Benz original spare parts are subjected to the most stringent quality inspections. Each part has been
specifically developed, manufactured or selected for and adapted to Mercedes-Benz vehicles. Therefore, Mercedes-
Benz original spare parts should be installed.

Important !
The use of non-genuine parts and accessories not authorized by Mercedes-Benz could damage the vehicle or
compromise its durability or safety.

Technical Data C 230 KOMPRESSOR
Model C 230 KOMMPRESSOR
(202 024)1 Rims - Tires (except Sport Package)
Engine 111 Rims (light
alloy rims)

7J x 15 H 2
Mode of operation 4-stroke engine,
gasoline injection
Wheel offset 1.46 in (37 mm)
No. of cylinders 4

All season
tires:;
Radial-ply tires
205/60R 15 91 H
Bore 3.58 in (90.90 mm) Winter tires;
Radial-ply tires
205/60 R 15 91 T M+S
Stroke 3.48 in (88.40 mm) C 230 KOMMPRESSOR - Canada only (ikl.spare wheel)
Total piston displacemen 140.8 cu.in. (2295 cm3)

Rims (steel
rims)
Wheel offset

61/2J x 15 H 2
1.46 in (37 mm)

Compression ratio 8.8:1

All
season;Radial-
ply tires
Winter
tires;Radial-ply
tires

195/65 R 15 91 H
S

Output acc. to SAE J
1349
185 hp/5300 rpm
(136 kW/5300 rpm)
Rims All season Tires ( Sport Package)
Maximum torque acc.
to SAE J 1349
200 ft.lb./2500 rpm
(270 Nm/2500rpm)

Rims (light
alloy rims)
Wheel offset

7J x 16 H 2
1.46 in (37 mm)

Maximum engine speed 5800 rpm

All season
tires:
Radial-ply tires205/55 R 16 91 H
Firing order 1-3-4-2 Electrical System
tPoly-V-belt routing I 1875 mm Generator
(alternator)

14 V/90 A
Poly-V-belt routing II 1339 mm Starter motor 12 V/1.7KW
Weights See certification tag Battery 12 V/100 Ah
Roof load max.
Trunk load max.

220 lb(100 kg)
220 lb(100 kg)

Spark plugs
Electrode gap
Tightening
torque

Bosch F 7 KTCR
0.039 in (1,0 mm)
15-22ft.lb. (20-30 Mm)

Spare Wheel Main Dimensions
Rim (light alloy rim)
Wheel offset 7 J x 16 H 2
1.46 in (37 mm) Overall vehicle
length 178.2 in (4526 mm)
All season tire:
Radial-ply tire 205/55 R 16 91 H Overall vehicle
width 67.8 in (1723mm)
Overall height 56.1 in (1424 mm)
Spare Wheel ( exept Canada model with steel rims) Wheel base 105.9 in (2690 mm)
Rim (light alloy rim)
Wheel offset 7 J x 15 H 2
1.46 in (37 mm) Track, front 59.0 in (1499 mm)
All season tire:
Radial-ply tire 205/55 R 16 91 H Track, rear 57.6 in (1464mm)

1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz
dealer for the correspon-ding data of ali specialbodies and special equipment,

Technical Data C 280
Model C 280 (202 029)1 Rims - Tires (except Sport Package)
Engine 112 Rims (light
alloy rims)7J x 15 H 2
Mode of operation 4-stroke engine,
gasoline injection Wheel
offset 1.46 in (37 mm)
No. of cylinders 6

All season
tires;
Radial-ply
tires
205/60R 15 91 H
Bore 3.54 in (89.90 mm)

Winter
tires;
Radial-ply
tires
205/60 R 15 91 T M+S
Stroke 2.89 in (73.50 mm) Weights See certification tag
Total piston displacemen 170.8 cu.in. (2799cm3) Roof load
max. 220 lb(100 kg)
Compression ratio 10.1 Trunk load
max. 220 lb(100 kg)
Output acc. to SAE J
1349 194 hp/5800 rpm
(145 kW/5800 rpm) Rims All season Tires ( Sport Package)
Maximum torque acc.
to SAE J 1349 195 ft.lb./3000 rpm
(265 Nm/3000rpm)

Rims (light
alloy rims)
Wheel
offset
7J x 16 H 2
1.46 in (37 mm)
Maximum engine speed 6000 rpm

tires:
Radial-ply
tires 205/55 R 16 91 H
Firing order 1-4-3-6-2-5 Electrical System
tPoly-V-belt 2390 mm Generator
(alternator)14 V/90 A
Starter
motor 12 V/1.7KW
Spare Wheel Battery 12 V/100 Ah
Rim (light alloy rim)
Wheel offset

7 J x 15 H 2
1.46 in (37 mm)

Spark
plugs

Electrode
gap
Tightening
torque Bosch F 8 DPER
Beru 14 FGH 8 DPUR X 20.03 in (1,0 mm)
15-22ft.lb. (20-30 Mm)
All season tire:
Radial-ply tire 205/55 R 16 91 H Main Dimensions


Overall
vehicle
length 178.4 in (4526 mm)


Overall
vehicle
width 67.8 in (1723mm)
Overall
height 56.1 in (1424 mm)
Wheel
base 105.9 in (2690 mm)
Track,
front 59.0 in (1499 mm)
Track, rear57.6 in (1464mm)

1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz dealer
for the correspon-ding data of ali specialbodies and special equipment,

Technical Data C 43 AMG
Model C 43 AMG (202 033)1 Rims and All season Tires
Engine 113

Rims2
Front axle
AMG light
alloy rims
Wheel
offset


71/2J x 17 H 2
1.38 in (35 mm)
Mode of operation 4-stroke engine,
gasoline injection

Rear axle
AMG light
alloy rims
Wheel
offset
81/2J x 17 H 2
1.18 in (30 mm)
No. of cylinders 8

All season
tires:
Radial-ply
tires
Front axle
Rear axe

225/45 ZR 173
245/40 ZR 173
Bore 3.54 in 89.90 mm)

Rims and
Winter
Tires
Stroke 3.31 in (84.00 mm)

Rims2
AMG light alloy rims 71/2J x 17 H 2
Wheel offset 1.38 in (35 mm)
Radial-ply tires
or
215/45 R 17 H M + S
225/45 R 17 H M + S 3
Spare Wheel
Rims2
AMG light alloy rims 71/2J x 17 H 2
Wheel offset 1.38 in (35 mm)
All season tire:
Radial-ply tire

225/45 ZR 173
Electrical System
Total piston displacement 260.0 cu.in. (4265 cm3) Generator
(alternator)14 V/150 A
Compression ratio 10:1 Starter
motor
12 V/1.7KW
Output acc. to SAE J
1349
302 hp/5850 rpm
(225 kW/5850 rpm) Battery 12 V/100 Ah
Maximum torque acc.
to SAE J 1349

302ft.lb./3250 rpm
(410 Nm/3250rpm)

Spark
plugs
Electrode
gap
Tightening
torque
Bosch F 8 DPER
Beru 14 FGH 8 DPUR X 2
0.039 in (1,0 mm)
15-22ft.lb. (20-30 Mm)
Maximum engine speed 6300 rpm Main Dimensions
Firing order 1-5-4-2-6-3-7-8

Overall
vehicle
length
177.4 in (4507 mm)
Poly-V-belt 2390 mm

Overall
vehicle
width 67.7 in (1720mm)
Overall
height
56.1 in (1424 mm)
Wheel
base 105.9 in (2690 mm)
Track,
front
59.9 in (1497 mm)
