129 Navigation
Destination input

Turn the right-hand rotary/push-button
v to highlight the name of the inter-
section.

Press the right-hand rotary/push-
button v to confirm the selection.
The selection menu “Destination Entry”
will appear, indicating the intersection.

Press the right-hand rotary/push-
button v longer than 2 seconds to cal-
culate the route (
page 141).Adding a house number
Depending on the data stored on the navi-
gation CD, you can add a house number to
the destination address.
In order to do so, the menu field “House
no.” must be shown in black in the selec-
tion menu “Destination Entry”.

Turn the right-hand rotary/push-button
v to highlight 2 and press to confirm.
An input menu will appear.

Turn the right-hand rotary/push-button
v to highlight the desired numbers
one after the other and press to con-
firm.
The numbers will appear in the input
line.

Press the right-hand rotary/push-
button v longer than 2 seconds.
A list will appear.
iThe previous/next page can be display-
ed as described for the city list
(page 125).
P82.85-9172-31

130 NavigationDestination input
Turn the right-hand rotary/push-button
v to highlight the desired block and
press to confirm.
The selection menu “Destination Entry”
will appear.

Press the right-hand rotary/push-
button v longer than 2 seconds to cal-
culate the route (
page 141).Selecting a city center
You can activate the list “Center Entry” in
the main address menu (
page 123) or af-
ter selecting a city (
page 126).

Turn the right-hand rotary/push-button
v to highlight “Center” and press to
confirm.
The list “Center Entry” will appear.

Turn the right-hand rotary/push-button
v to highlight the desired entry and
press to confirm.
The selection menu “Destination Entry”
will appear.

Press the right-hand rotary/push-
button v longer than 2 seconds to cal-
culate the route (
page 141).
iThe house numbers usually appear on
the list in blocks, e.g.
1-5 odd numbers
42-50 even numbers
1-50 mixed numbers

131 Navigation
Destination input
Activating the map from the main des-
tination input menu“Destination via Map” menu
Setting the map center
1To the previous destination
2To the current vehicle location
3Activate the “City/Suburb Entry” input
menu and select the corresponding
city center after input
4Activate the coordinate destination in-
put menu
Turn the right-hand rotary/push-button
v to highlight “Destination via Map...”
(Destn via Map) in the main destination
input menu and press to confirm.
The selection menu “Destination via
Map” will appear.

Turn the right-hand rotary/push-button
v to highlight 1, 2, 3 or 4 and press to
confirm.
1 and 2 The map with the crosshairs
will appear
3 The “City/Suburb Entry”
menu will appear
(
page 124)

Enter the city in the input menu and
confirm it.
Then, the map with the crosshairs
will appear. The crosshairs are cen-
tered on the city center.
4 The coordinate destination input
menu will appear (
page 135).
Selecting a destination via the map

134 NavigationDestination inputZooming in for more detailed map
Press +.
or

Turn the right-hand rotary/push-button
v to the left.
A filled arrow for the new scale 11 and
a square 12 appear.
Press the right-hand rotary/push-button
v to calculate the map with the new sca-
le.Zooming out for less detailed map

Press ,.
or

Turn the right-hand rotary/push-button
v to the right.
The new scale will appear.

Press the right-hand rotary/push-
button v to calculate the map with the
new scale.
This will take place automatically after
6 seconds.Confirming destination and calculating
route
The crosshairs highlight the desired desti-
nation

Press the right-hand rotary/push-
button v longer than 2 seconds.

Then calculate the route (
page 141).

135 Navigation
Destination input
Destination entry via coordinates
You can enter a destination if the corres-
ponding coordinates are known.“Coordinate Destination” menu
Turn the right-hand rotary/push-button
v to highlight “Coordinate Destinati-
on...” in the Destination via Map menu
(page 131) and press to confirm.
The “Coordinate Destination” input
menu will appear.Activating the adjustment mode

Press the right-hand rotary/push-
button v.
The entry will appear in red.
Altering the setting

Turn the right-hand rotary/push-button
v.
or

Enter cordinates with the number keys.
Store the new setting and move the mar-
king to the next entry

Press the right-hand rotary/push-
button v.
The entry will appear in black.

Subsequently repeat operating se-
quence and enter coordinates comple-
tely.Changing between western (W) and eas-
tern (E) longitude

Press u repeatedly.
Changing between northern (N) and
southern (S) latitude

Press t repeatedly.iAdjustment range

Longitude (W - West or E - East)
0-179° 0-59 min
0-59 s 0.1-0.9 s


Latitude (N - North or S - South)
0-89° 0-59 min
0-59 s 0.1-0.9 s

136 NavigationDestination inputConfirming coordinate destination
Press the right-hand rotary/push-
button v longer than 2 seconds.
The above display appears.Starting the adjustment mode

Turn the right-hand rotary/push-button
v to highlight “OK” and press to con-
firm.
Store the coordinate destination in the
destination memory with a name

Turn the right-hand rotary/push-button
v to highlight “Save” and press to
confirm.
This will activate the destination me-
mory (
page 175).Activate the map with crosshairs

Turn the right-hand rotary/push-button
v to highlight “Map” and press to con-
firm.
This will activate the map
(page 132).
P82.85-9180-31

137 Navigation
Destination input
This function allows you to select Points of
Interest such as gas stations, parking faci-
lities or shopping centers.“Points of Interest” selection menuSelect a Point of Interest
1Around the current area of vehicle loca-
tion
2Around the previous destination area
3In the surrounding area of another city
4As regional destination, e.g. airport

Turn the right-hand rotary/push-button
v to highlight “Special destinations”
in the main destination input menu and
press to confirm.
The selection menu “Point of Interest”
will appear.

Turn the right-hand rotary/push-button
v to highlight 1 to 4 and press to con-
firm.
1, 2, 4 A Category list will appear
3 The input menu “City/Area”
will appear (
page 139)Around the current area of vehicle loca-
tion or previous destination area
Category list5Display previous page, if :
6Display next page, if ;
Entering Points of Interest
P82.85-9182-31
56

138 NavigationDestination input
Turn the right-hand rotary/push-button
v to highlight 1 or 2 and press to con-
firm.
The list “Select Category” will appear.

Turn the right-hand rotary/push-button
v to highlight the desired category
and press to confirm.
A corresponding list will appear.
7Point of Interest entry with distance to
destination in miles (as the crow flies)
8Symbol for long entry
9Complete entry in a windowDisplay the entry in full in a window 9

Press u.

Press u again to remove 9.
Selecting the desired destination

Turn the right-hand rotary/push-button
v to highlight the entry in the selec-
tion list and press to confirm.

Then calculate the route (
page 141).
iNot all Points of Interest may be listed
on the CD.
P82.85-9183-31
7
8
9

139 Navigation
Destination input
In the surrounding area of another city“City/Area” input menu
Turn the right-hand rotary/push-button
v to highlight “Select City...” in the
Points of Interest menu and press to
confirm.
The input menu “City/Area” will ap-
pear.

Select the city and activate the city list
(page 125).

Turn the right-hand rotary/push-button
v to highlight the desired destination
in the city list and press to confirm.
The list “Select Category” will appear.

Turn the right-hand rotary/push-button
v to highlight the desired category
and press to confirm.
A corresponding list will appear.

Select the desired destination.

Then calculate the route (
page 141).Regional destinations

Turn the right-hand rotary/push-button
v to highlight “Regional...” in the
Points of Interest menu and press to
confirm.
The list “Select Category” will appear.
P82.85-9184-31
iIf several options of a city/suburb are
available, another menu will appear
where you must make and confirm your
desired selection.iNot all Points of Interest may be listed
on the CD.
iNot all Points of Interest may be listed
on the CD.
P82.85-9187-31

140 NavigationDestination input
Turn the right-hand rotary/push-button
v to highlight highlight the desired ca-
tegory and press to confirm.
An input menu, e.g. “Airport” will ap-
pear.

Select an entry (
page 124) and then
activate the list.Activating the list

Press the right-hand rotary/push-
button v longer than 2 seconds.
or

Turn the right-hand rotary/push-button
v to highlight “List” and press to con-
firm.
The list will appear.

Turn the right-hand rotary/push-button
v to highlight the desired entry and
press to confirm.

Then calculate the route (
page 141).
P82.85-9189-31
