MERCEDES-BENZ C-Class 2005 W203 Comand Manual

49 Audio
CD operation
Playback locations for audio CDs are:
the CD drive in the COMAND

the CD changer*.
CD drive
CD changer*

In the Audio menu (
page 34), press
the
CD
or the
CD
soft key.
CD changer* main menu1CD number or name of the CD currently
playing
2Track number or name of the track
currently playing
3CD - CD changer*
CD - CD drive
Actual track number/max. track
number on CD and elapsed playback
time
4Symbol for inserted CD
Switching to CD operationiThe CD drive is located behind of the
display unit (
page 46).
iThe CD changer* can accomodate up
to 6 audio CDs. The CD changer* is
located in the glove box.
If a CD changer* is connected to the
COMAND, the
CD
soft key is
available.
iThe
Magaz.
soft key is only assigned
when the CD changer* is active.
If the CD changer* has already read the
magazine, the Magazine menu will
appear (
page 52) when you press the
Magaz.
soft key.
Otherwise the message
Magazine
scan Please wait
will appear first.

50 AudioCD operationCD drive
Activate the Audio menu (
page 34).

Press the
CD
soft key
.
The CD main menu is displayed.
If no audio CD has been inserted, the
message
No CD inserted
will
appear.

Load an audio CD into the CD drive
(page 45).
CD main menu
CD changer*
Activate the Audio menu (
page 34).

Press the
CD
soft key
.
The CD changer* main menu will
appear. The CD last played is played
back.
CD changer* main menu

If the last played CD is not available, the
next available audio CD is played back.
No CD in the magazine:
The message
Magazine empty
will
appear.

Load audio CDs into the CD changer*
(page 48).
Switching on
iThe name of the CD and the name of
the track played are displayed if the
information is available.iThe
CD
soft key is available if a CD
changer* is connected to the
COMAND.
iThe name of the CD and the name of
the track played are displayed if the
information is available.

51 Audio
CD operation
You can select a CD:
in the CD list (
page 51)

with the number keypad (
page 51)

in the magazine menu (
page 52)
In the CD listThe CD list includes all loaded CDs. Only
one list entry is visible at a time.
The entry is displayed above the track
indication. It shows the number of the CD
currently playing.

Push the joystick to H or h to
select another CD from the list.
After the CD is loaded, it is played
back.
or

Do not change the selection.
Playback of the last played CD is
continued.
With the number keypad
Selecting a CD (CD changer* only)iSelection is possible if the
CD changer* has loaded the magazine
(COMAND knows the position of filled
and empty slots) and at least two audio
CDs are loaded.
iThe number keys 1 - 6 can be used
for direct selection.
Keys
1 - 6 magazine slots 1 to 6
of the CD changer*

52 AudioCD operation
Press a number key, e.g. 2 to select
the corresponding CD.
The CD is changed. The selected CD is
played back.
The message
No CD
will
appear if a selected slot is empty.
In the Magazine menu

Press the
Magaz.
soft key.
The Magazine menu is displayed. If the
magazine has not been read in, the
message
Magazine scan
Please wait
is displayed first.

Push the joystick to g or G to
select a CD.

Press E.
or

Press one of the number keys 1 to
6.
The CD is changed. The message Loading CD
will appear.You can select a track:

with g or h (
page 52)

with the joystick (
page 53)

with the number keypad (
page 53)

with CD track scan (
page 53)
With g or h

Activate the main CD menu
(page 49).
Next track

Press h.
The next track is played.
iThe name of the CD instead of e.g.
CD1

is displayed if the information is
available.
Track select

53 Audio
CD operation
Previous track or start of title (if more
than 10 seconds of playing time has
elapsed)
Press g.
Playback begins.
Select any desired track

Press g or h as often as
necessary.
With the joystick

Push the joystick to g or G to play
the next or previous track.With the number keypad

Activate the CD main menu
(page 50).

Press *.
An input line will appear in the CD main
menu.
1Number of tracks on CD corresponds
with the valid number range
2Input line
E.g.: Track 14.

Press 1 and 4 in short succession.

After entering the track number, wait
approximately 3 seconds.
The selected track is played. The CD
main menu is displayed.
CD track scan
The tracks on a CD can be scanned one
after the other for 8 seconds each. The
function will switch off automatically when
the starting track is reached. You can also
manually stop the scan function.iEntries higher than the number of
tracks available on the CD are not
possible.

54 AudioCD operationActivating
Press the
Scan
soft key.
Scan will begin.Ending the function
Scan search is running.

Press the
Scan
soft key.
or

Press E.
Playback will resume with the desired
track.Fast forward

Press h longer than 2 seconds and
keep it pressed.
Fast reverse

Press g longer than 2 seconds and
keep it pressed.
Ending the function

Release h or g.
Playback will resume.
iWhen you start the scan function, the
playback mode
Normal
sequence

(
page 57) is automatically activated.
Fast forward/reverse

55 Audio
CD operation
On
Press J during playback.
The CD operation is muted and theß
symbol is displayed in the status bar.
The soft keys on the left side are
greyed out in some submenus.
Off

Press J again.
Playback will resume.
The ß disappears from the status bar.
The soft keys on the left side are
selectable again.The following options are available:

Normal sequence (
page 57)

Track mix (
page 57)

CD mix (
page 57)

Repeat track (
page 57)

Repeat CD (
page 57)
Muting
iCOMAND will also deactivate muting if
you
press A to select another audio
source

change the volume

press either g or h.
Playback modeiIf the CD changer* is connected, the
playback modes
Repeat CD
and
CD mix
are available additionally.

56 AudioCD operationActivating playback mode
E.g.:
Mode
Repeat
track


Press the
Setting
soft key.
The setting menu will appear.
CD changer* setting menu

Push the joystick to g or G to
select the playback mode
Repeat
track
.

Press E.
The mode is activated. The CD
changer* main menu will then appear. REPEAT TRACK
will appear in the
status bar.
iThe playback mode
Normal
sequence

is not displayed in the status bar.

57 Audio
CD operation
Explanation of the playback modes
Normal sequenceTracks are played in ascending order
(e.g. 1, 2, 3 and so on). If just one CD is
inserted, the first track is played when
the last one is over.
If more than one CD is available, the
first track of the next CD is played
when the last track of the current CD is
over. The CDs are changed in normal
order.

Track mixTracks are played in random order. If
more than one CD is available, the next
available CD is played when the current
CD is over. The CDs are changed in
normal order.

CD mix
(CD changer* only)
At least 4 tracks of any CD are played
in random order. Then follows the next
available CD. The CDs are changed in
random order.

Repeat track The system repeats the current track
until you switch the function off.

Repeat CD
(CD changer* only)
The system repeats the current CD
until you switch the function off.

58 AudioAUX operation

AUX operation
Open the Audio menu (
page 34).

Press the
AUX
soft key.
The AUX menu is displayed. The exter-
nal audio source is played back if it is
connected and switched to playback.At the COMAND, you can set the following
for the AUX operation:

Volume (
page 27)

Balance control and fader (
page 29)

Bass and treble control (
page 30)

Sound functions* (
page 30)
iAn external audio source can be con-
nected to the COMAND.
For further information please contact
an authorized Mercedes-Benz Center.
iFor instructions on how to operate the
external audio source, please see the
operation manual of the device con-
nected.
