Page 34 of 225
33 At a glance
Operating COMAND
Switching to the list without predictive
speller
If other entries for a town exist, or the
name exists more than once in the system,
then
B is highlighted in the speller.
Press n.
You can switch to the list at any point while
entering characters.
Slide qmr repeatedly until the list ap-
pears without the speller.
or
Select B and press n.
COMAND will complete your entry if
the name is unambiguous. In this case
it is not necessary to switch to the list,
the Enter Destination menu will appear.
Selecting a list entry
Town list for navigation
1+ symbol for additional options
To select a town: Rotate ymz or slide
qmr.
To confirm selection: Press n.
A town with the 1 symbol exists more
than once in the selected country. Con-
firming this type of town will result in a
further selection. The
+ symbol then
switches to
/.
Switching to radio mode and request-
ing the station list
Initial situation:
You would like to switch, for example, from
the phone function to radio mode and re-
quest the station list from there.
i In this guide, the path to a menu item is
shown as an action in italics.
“Audio” K “Audio” K “Radio” K “Radio”
K “Station List”
i Depending on the initial situation, this se-
quence of actions may be shorter.
If radio mode was active last, it is sufficient to se-
lect “Audio”
K““Radio””K “Station List”.
The individual steps for the above example
are described below.
Operating example
Page 36 of 225
35 At a glance
Basic functions of COMAND
i The COMAND components can be found on
(
page 14). Operating examples can be found
on (
page 31).
i For many operating functions you can also
use the buttons on the multifunction steering
wheel, e.g. for volume setting the æ, ç
buttons, (
page 23).
Press the rotary/push button x.
or
Press the display cover button
The cover opens up and the
COMAND display folds out. A warning
message appears. COMAND opens the
last active menu.
i When COMAND is switched off, playback of
the current audio or video source is also
switched off.
To switch on/off: Press V.
The sound from the active audio or
video source is switched on or off.
i When the sound is switched off, the symbol
X appears in the status line.
If you change the audio or video source or alter
the volume, the sound is automatically switched
on again.
i Announcements from the navigation system
can still be heard with the sound switched off.
Switching navigation announcements
on/off
Press V during the announcement.
i The navigation announcements are
switched on again after restarting route guid-
ance or after switching COMAND off/on using
x.
To set: Turn the rotary/push button
x.
The volume of the selected audio or
video source changes.
Volume of navigation announcements
You can set the volume for navigation an-
nouncements independently of the volume
for the active audio or video source.
During a navigation announcement:
Turn the rotary/push button x.
Setting volume for phone calls
The volume for hands-free operation can
be set during an active phone call.
Turn the rotary/push button x.
Basic functions of COMAND
Switching COMAND on/off
Mute
Setting the volume
Page 38 of 225
37 At a glance
Basic functions of COMAND
To save setting: Press n.
The setting is stored and the menu is
exited.
To exit menu without changes: Press
the Back button
í.
Your vehicle is equipped with the harman/
kardon LOGIC7
® Surround Sound system.
You can select between “
LOGIC7®On” and
“
LOGIC7®Off”.
harman/kardon LOGIC7
® Surround Sound
is available for the following operating
modes:
Radio (FM only)
SatRadio*
CD audio
DVD audio (MLP, DTS, PCM and Dolby
Digital audio formats)
MP3 (including PCMCIA memory card)
Aux
DVD video (PCM, DTS and Dolby Digital
audio formats)
i As some DVDs contain both stereo and also
multi-channel audio formats, it may be neces-
sary to set the audio format (
page 66).
i The “LOGIC7®On” function of the harman/
kardon LOGIC7® Surround Sound system per-
mits the playback of discrete 5.1 and stereo re-
cordings with an optimal surround sound
platform for each passenger. Music and films on
CD or audio and video DVDs with high-resolution
surround formats, such as MLP, DTS or Dolby
Digital, are played with optimum sound.
The LOGIC7
® distributes the 5.1 surround infor-
mation over the 12-channel system architecture
to provide the optimum sound in all seats. This
produces the sound characteristics as intended
by the sound engineer during the original record-
ing.
harman/kardon LOGIC7
® converts all two-chan-
nel stereo sound sources into multi-channel sur-
round sound. The surround information stored
during the original recording is read out using
LOGIC7
® and likewise distributed over the
12 channels. No effects are created during the
process, anything that was always on the record-
ing is just made audible again.
Moreover, harman/kardon LOGIC7
® draws the
audible sound source away from the individual
loudspeakers, thus creating a natural 360°
sound platform for each passenger.
i By selecting “LOGIC7® Off”, the playback
of all playable formats is performed as on the ex-
isting medium. Due to the spatial conditions in
the vehicle, optimal sound is not possible in all
seats.
i Discs supporting the above-mentioned au-
dio formats display the following logos
Dolby Digital
DTS
MLP
Surround sound
Page 41 of 225
40 Audio
Radio
i Information on the COMAND control system
and how to operate it can be found on
(
page 14) and (page 31).
i For many operating functions you can also
use the buttons on the multifunction steering
wheel, e.g. the (, &, $ or % but-
tons, for selecting a station or a menu or scroll-
ing through lists (
page 23).
From the COMAND control unit
Press the X function button.
i Press the button repeatedly to switch wave-
band in the sequence FM, AM, WB (
page 42)
and SatRadio* mode (
page 45). Pressing
again will switch back to FM radio mode.
From the COMAND controller
From another main function
Select “Audio” K “Audio” K “FM / AM
Radio” in the display.
i If radio mode was active last, you only need
to select “Audio”.
Within the audio function
Select “Audio” K “FM / AM Radio”.The radio display appears. The last se-
lected station in the last selected wave-
band is heard.
Display with Audio menu
1Main function line
2Audio menu
3Current audio mode
i You can switch to the various audio modes
in the audio menu:
FM / AM radio mode
SatRadio* mode (page 45)
CD-/DVD audio/MP3 mode (“Disc” and
“Memory Card” are described together in
this guide), (
page 60)
Music Register (page 67)
Aux mode (page 71)Radio display
1Display/selection window with station
or frequency
2Memory preset number
3Name or frequency of selected station
4Sound settings
5WB (Weather band)
6AM radio
7FM radio
8Stored station list
9Radio functions
Radio
Switching to the radio
Page 47 of 225
46 Audio
Satellite radio*
Subscribing to satellite radio
To switch to satellite radio operation:
From another main function
Select “Audio” K “Audio” K
“SatRadio”.
i If radio mode was active last, you only need
to select “Audio”.
Within the audio function
Select “Audio” K “SatRadio”.
The Satellite radio main menu will ap-
pear and displays the
Weather chan-
nel. You cannnot select any other
station.
Select “SatRadio” (from the submenu)
K “Service”.
The Service information display will ap-
pear.
Service information display
1Phone number of the provider,
(SIRIUS) or “Call Service Provider”
2SIRIUS ID of your satellite receiver
Contact satellite radio service provider
at the telephone number displayed in
the screen.
i It is also possible to activate the satellite
service online. To do so please visit SIRIUS Sat-
ellite Radio’s website at www.sirius.com (USA)
or www.siriuscanada.com (Canada)
After the connection is made:
Follow the instructions given by the op-
erator.
The activation process may take up to
10 minutes. If it is successful, you will
see the display with the message
“Acquiring Signal...” (
page 47) fol-
lowed by the Satellite radio main menu
(
page 47).
i If a subscription is not included with system
purchase, credit card information is required to
activate your account.
If a satellite receiver is not installed or not prop-
erly installed:
The message “Device Unavailable” will appear.
Subscribing
Page 53 of 225
52 Audio
CD audio/DVD audio and MP3
Permissible storage media
CD-R and CD-RW
DVD+R and DVD+RW
DVD-R and DVD-RW
PCMCIA memory card (page 57)
Permissible file systems
ISO9660/Joliet for CD storage media
UDF for DVDs
FAT16 or FAT32 for PCMCIA memory
card with storage medium
Multisession CDs
On multisession CDs, the content of the
first session determines how COMAND
handles the CD.
If the first session, for example, contains
data in audio CD format and the second
session contains MP3 tracks, COMAND
handles the CD as a conventional audio
CD. This means that the MP3 tracks can-
not be accessed.Similarly, if the first session contains MP3
tracks and the second session contains
d a t a i n a u d i o C D f ormat, COMAND handles
the CD as an MP3 CD. Only the MP3 tracks
can be accessed.
File structure of storage medium
When creating an MP3 storage medium,
you can organize MP3 tracks into folders.
A folder can also contain additional fold-
ers. A storage medium may have a maxi-
mum of 255 folders in total. A maximum of
255 tracks and 255 folders are permissible
per folder. A maximum of 4000 tracks in
total are permissible per storage medium.
Track names and folder names
When creating an MP3 storage medium,
you can assign names to the MP3 tracks
and to the folders.
COMAND uses these names in MP3 mode
for the corresponding display. Empty fold-
ers or folders containing data other than
MP3 tracks will not be displayed by
COMAND.
If MP3 files are stored in the root directory
itself, the root directory also counts as a
folder. COMAND will then display the root
directory name as a folder name.
CD audio/DVD audio and MP3
Safety instructions
G Warning
COMAND is classified as a Class 1 laser
product. You must not open the casing.
There is a risk of exposure to invisible laser
laser radiation if you open the casing, or if
the casing is faulty or damaged.
COMAND does not contain any parts that
you are able to maintain yourself. For safety
reasons, all maintenance work must be car-
ried out by qualified technicians.
G Warning
Only carry out the following when the vehi-
cle is stationary:
Inserting a disc
Ejecting a disc
There is a risk of accident by being distract-
ed from road and traffic conditions if you
load a CD/DVD while the vehicle is in mo-
tion.
Notes on MP3 mode
Page 55 of 225
54 Audio
CD audio/DVD audio and MP3
i Discs with copy protection do not comply
with the CD audio standard and in some cases
cannot be played by COMAND.
When playing copied discs, problems may occur
with the playback.
A wide variety of discs, disc writing software and
writers are available. Due to this variety we can-
not guarantee that the system will be able to play
discs that you have written/copied yourself.
There may be playback problems with user-
burned CDs with a storage capacity of more than
700 MB. These CDs do not meet current valid
standards.
i When playing a DVD audio, it may be the
case with numerous albums that the last track
does not contain any music and COMAND
switches to the next track. This is due to the pro-
duction method and does not imply a fault with
the unit.
! Do not attach stickers or labels of any kind
to discs. They may come loose and damage
COMAND.
COMAND has been designed for discs meeting
the requirements of standard EN 60908. There-
fore, only discs with a maximum thickness of
1.3 mm can be used.
If a thicker disc is inserted, e.g. one which stores data on both sides, (DVD on one side, audio data
on the other side), this cannot be ejected and
COMAND will be damaged.
Do not use 8 cm diameter discs, not even with an
adapter. Only use round, 12 cm diameter discs.
i COMAND can play audio CDs with the high-
resolution surround format.
Only touch the discs at the edges.
Handle discs with care in order to pre-
vent malfunctions during playback.
Avoid scratching, leaving fingerprints
and dust on the discs.
Clean the discs occasionally with a
commercially available cleaning cloth.
Always wipe in a straight line from the
inside outwards, never in a circular mo-
tion.
The discs must only be labelled using
pens specially designed for this pur-
pose.
After use, put the discs back into the
box.
Protect the discs from heat and direct
sunlight.
i If the CD/DVD is printed on one side, this
side must face upwards when loaded. If neither
side is printed, the side to be played must face
downwards.
The system may not be able to play copy-protect-
ed CDs/DVDs.
Notes on CD/DVD discs
Notes on the care of
CD/DVD discs
Loading CDs and DVDs
G Warning
Only insert a CD or DVD when the vehicle is
stationary. There is a risk of accident by be-
ing distracted from road and traffic condi-
tions if you load a CD/DVD while the vehicle
is in motion.
Bear in mind that at a speed of just 30 mph
(appr. 50 km/h), your vehicle is covering a
distance of 44 feet (appr. 14 m) every
second.
Page 72 of 225
71 Audio
Audio Aux
An external audio source (AUX) can be
connected to COMAND via the 1/8" jack
1 located inside the glovebox.
From another main function
Select “Audio” K “Audio” K “Aux” in
the Audio menu (
page 40).
i If Audio Aux mode was active last, you only
need to select “
Audio”.
Within the audio function
Select “Audio” K “Aux”.
The Audio Aux menu appears.
The medium in the external audio
source is heard, provided it is connect-
ed and switched to playback.
i Please refer to the relevant operating guide
for operation of the external audio source.
The following settings can be made in Au-
dio Aux mode:
Volume (page 35)
Balance and fader (page 36)
Treble and bass (page 36)
Surround sound (page 38)
i The volume of external audio sources is ex-
tremely variable. It is possible that a device con-
nected as an external audio source will sound
quieter or louder in the vehicle or that the usual
maximum volume cannot be achieved. On cer-
tain devices the volume can be set separately. In
this case, start at a moderate volume and in-
crease it slowly. In this way, you can determine
whether the system is capable of playback with-
out distortion, even at high volume.
Audio Aux
Switching to Audio Aux
GWarning
Due to the different volumes of the external
audio sources, system messages (e.g. navi-
gation announcements) may be much loud-
er. You may need to disable these system
messages or adjust the volume of these
messages manually (
page 35).
Page 75 of 225
74 Video
DVD video
If the vehicle is travelling faster than ap-
proximately 3 MPH, the picture will switch
off automatically in DVD video mode.
The following message will then appear in
the display: “In order not to distract you
from the traffic situation, the picture is fad-
ed out while the vehicle is in motion.”.
As soon as the speed falls below approxi-
mately 3 MPH, the picture switches back
on again.
i When playing copied discs, problems may
occur with the playback.
A wide variety of disc-writing software and writ-
ers are available. Due to this variety we cannot
guarantee that the system will be able to play
discs that you have written/copied yourself
! Do not attach stickers or labels of any kind
to discs. They may come loose and damage
COMAND. Labels may also cause the disc to
bend, which may result in reading errors and
problems with disc recognition.
! COMAND has been designed for discs meet-
ing the requirements of standard EN 60908.
Therefore, only discs with a maximum thickness
of 1.3 mm can be used.
If a thicker disc is inserted, e. g. one which stores
data on both sides, (DVD on one side, audio data
on the other side), this cannot be ejected and
COMAND will be damaged.
Do not use 8 cm diameter discs, not even with an
adapter.
Only use round, 12 cm diameter discs.
Only touch the discs at the edges.
Handle discs with care in order to pre-
vent malfunctions during playback.
Avoid scratching, leaving fingerprints
and dust on the discs.
Clean the discs occasionally with a
commercially available cleaning cloth.
Always wipe in a straight line from the
inside outwards, never in a circular mo-
tion.
The discs must only be labelled using
pens specially designed for this pur-
pose.
DVD video
Safety instructions
G Warning
COMAND is classified as a Class 1 laser
product. You must not open the casing.
There is a risk of exposure to invisible laser
laser radiation if you open the casing, or if
the casing is faulty or damaged.
COMAND does not contain any parts that
you are able to maintain yourself. For safety
reasons, all maintenance work must be car-
ried out by qualified technicians.
G Warning
Only carry out the following when the vehi-
cle is stationary:
Inserting a disc
Ejecting a disc
There is a risk of accident by being distract-
ed from road and traffic conditions if you
load a CD/DVD while the vehicle is in mo-
tion.
Automatic picture switch-off
Notes on storage media
Notes on the care of discs
Page 78 of 225
77 Video
DVD video
From the control unit
Load DVD video (page 55).
COMAND loads the inserted medium
and starts playing it.
or
Press the function button y.
i Pressing the function button switches di-
rectly to the disc mode selected last (CD audio,
DVD audio, MP3 CD or DVD video). COMAND
then accesses all discs in the DVD changer.
If necessary select “Changer” and in
the media list select (
page 78) a DVD
video I.
From the COMAND controller
Select “Video” in the main function
menu.
To display: Slide qmr.
To hide: Slide qmr.
or
Wait apprx. eight seconds.
Control menu displayed
1Disc type
2Current track
3Current scene
4Elapsed track time
5Displays menu system
To display: Press n.
To hide: Slide qm and select “Full
Screen”.
Menu system displayed
1DVD-Video menu
2Pause function
3Stop function
4Media selection
5Sound settings
Switching to DVD videoDisplaying/hiding control menuDisplaying/hiding menu system
