69 Audio
Music Register
Start the reording
Rotate ymz or slide omp until “Start”
is highlighted.
Press n.
In the display information about
source, destination and progress of the
recording is shown.
i The Disc menu re-appears automatically af-
ter a sucessful recording.
To stop the recording: Rotate ymz or
slide omp until “Cancel” is highlighted.
Press n.
The Disc menu re-appears.This function can be used to delete all the
music files in the Music Register.
Select “Music Register” K “Delete All
Music Files”.
A prompt appears. “No” is highlighted.
Do not delete: Press n.
The Music Register menu appears.
To delete: Select “Yes”.
A corresponding message appears.
Select “Music Register” K “Memory In-
fo”.
A window appears containing informa-
tion on:
Memory capacity
Available memory
Occupied memory
Content (folders, tracks)You can view the content of the Music Reg-
ister, change folder/track names and de-
lete individual folders/tracks.
Select “Folder” in the submenu.
1Back folder symbol
2Music file symbol
3Current folder
or
Press n if the display/selection win-
dow is highlighted.
A similar list appears that also shows
the content of the music register.
Deleting all music files
Requesting memory space informa-
tion
Folder functions

70 Audio
Music Register
To switch to the next folder up: Se-
lect theQsymbol.
The display changes to the next folder
up.
Changing folder/track name
Select “Folder”.
To select a folder/track: Rotate ymz
or slide qmr.
Select “Options” K “Change”.
Enter a name for the folder/track in the
input line.
To save change: Select B.
Deleting folder/track
Select “Folder”.
To select a folder/track: Rotate ymz
or slide qmr.
Select “Options” K “Delete”.
A prompt appears. “No” is highlighted.
Do not delete: Press n.
To delete: Select “Yes” and press n.
A message appears.The following options are available:
“Normal Track Sequence”
You will hear the tracks in the normal
sequence (e. g. track 1, 2, 3 etc.).
“Random Tracks”
The tracks are played in random order.
“Random Folder”
The tracks of the currently active folder
and any subfolders are heard in ran-
dom order.
To select an option: Switch to Music
Register (

page 67).
Select “Music Register” in the sub-
menu.
The Options list appears. A dotRindi-
cates the activated option.
Select an option.
The option is activated. A correspond-
ing display will appear in the display/
selection window for all options except
“Normal Track Sequence”.
i The option “Normal Track Sequence” is au-
tomatically activated if you change the medium
which is currently being played or if you select
another medium. An activated option remains
active after COMAND is switched on or off.Playback options

74 Video
DVD video
If the vehicle is travelling faster than ap-
proximately 3 MPH, the picture will switch
off automatically in DVD video mode.
The following message will then appear in
the display: “In order not to distract you
from the traffic situation, the picture is fad-
ed out while the vehicle is in motion.”.
As soon as the speed falls below approxi-
mately 3 MPH, the picture switches back
on again.
i When playing copied discs, problems may
occur with the playback.
A wide variety of disc-writing software and writ-
ers are available. Due to this variety we cannot
guarantee that the system will be able to play
discs that you have written/copied yourself
! Do not attach stickers or labels of any kind
to discs. They may come loose and damage
COMAND. Labels may also cause the disc to
bend, which may result in reading errors and
problems with disc recognition.
! COMAND has been designed for discs meet-
ing the requirements of standard EN 60908.
Therefore, only discs with a maximum thickness
of 1.3 mm can be used.
If a thicker disc is inserted, e. g. one which stores
data on both sides, (DVD on one side, audio data
on the other side), this cannot be ejected and
COMAND will be damaged.
Do not use 8 cm diameter discs, not even with an
adapter.
Only use round, 12 cm diameter discs.

Only touch the discs at the edges.

Handle discs with care in order to pre-
vent malfunctions during playback.

Avoid scratching, leaving fingerprints
and dust on the discs.

Clean the discs occasionally with a
commercially available cleaning cloth.
Always wipe in a straight line from the
inside outwards, never in a circular mo-
tion.

The discs must only be labelled using
pens specially designed for this pur-
pose.
DVD video
Safety instructions
G Warning
COMAND is classified as a Class 1 laser
product. You must not open the casing.
There is a risk of exposure to invisible laser
laser radiation if you open the casing, or if
the casing is faulty or damaged.
COMAND does not contain any parts that
you are able to maintain yourself. For safety
reasons, all maintenance work must be car-
ried out by qualified technicians.
G Warning
Only carry out the following when the vehi-
cle is stationary:

Inserting a disc

Ejecting a disc
There is a risk of accident by being distract-
ed from road and traffic conditions if you
load a CD/DVD while the vehicle is in mo-
tion.
Automatic picture switch-off
Notes on storage media
Notes on the care of discs

75 Video
DVD video

After use, replace the discs into the
sleeve.

Protect the discs from heat and direct
sunlight.
Some DVDs may not comply with the
NTSC or PAL TV playback standards.
Sound, picture and other playback prob-
lems may occur when you play such DVDs.
As standard, COMAND can play video
DVDs which meet the following criteria:

Region code 1 or region code 0 (no re-
gion code)
i With a video DVD having another region
code, a corresponding message will be dis-
played.

PAL or NTSC TV standard
Information on this can usually be found ei-
ther on the DVD itself or on the DVD
sleeve.
i The factory setting for COMAND is region
code 1. An authorized Mercedes-Benz Center
can change this setting. This will enable you to
play video DVDs with other region codes, provid-
ed that they have been made to the PAL or NTSC
TV standard.
It may be the case that some functions or
actions may not be possible at certain
times, or may not be possible in general,
depending on the DVD.
When you activate such functions or ac-
tions, this is indicated by the 7 symbol in
the display.
Proceed as described in the “Loading
CDs and DVDs” section (
page 54).
Proceed as described in the “Ejecting
CDs and DVDs” section (
page 57).
DVD playback conditions
Functional restrictions
Loading DVDs
Ejecting DVDs

77 Video
DVD video
From the control unit
Load DVD video (page 55).
COMAND loads the inserted medium
and starts playing it.
or
Press the function button y.
i Pressing the function button switches di-
rectly to the disc mode selected last (CD audio,
DVD audio, MP3 CD or DVD video). COMAND
then accesses all discs in the DVD changer.
If necessary select “Changer” and in
the media list select (
page 78) a DVD
video I.
From the COMAND controller
Select “Video” in the main function
menu.
To display: Slide qmr.
To hide: Slide qmr.
or
Wait apprx. eight seconds.
Control menu displayed
1Disc type
2Current track
3Current scene
4Elapsed track time
5Displays menu system
To display: Press n.
To hide: Slide qm and select “Full
Screen”.
Menu system displayed
1DVD-Video menu
2Pause function
3Stop function
4Media selection
5Sound settings
Switching to DVD videoDisplaying/hiding control menuDisplaying/hiding menu system

78 Video
DVD video
Slide and hold omp until the desired
point is reached.
or
Press and hold G or H on the
control unit until the desired point is
reached.
The control menu will appear.
In DVD video mode, if necessary dis-
play the menu system (
page 77).
Select “Changer”.
The media list appears. The dotRindi-
cates the medium currently playing.
Media list
1Symbol for DVD video
2DVD Video currently playing
To select DVD video I: Rotate ymz
or slide qmr.
Press n.
COMAND switches the medium.
i If you select a CD-/DVD-audio or MP3 me-
dium, the system switches to the corresponding
audio mode (
page 60).
Further information on the media list can be
found on (
page 62).
In DVD video mode, if necessary dis-
play the menu system (
page 77).
To interrupt playback: Select h.
The g display changes to T.
To resume playback: Select T.
Playback will then continue at the point
at which it was interrupted. The menu
system is hidden.
To stop playback: Press h again
when playback is stopped.
or
Select h twice in immediate succes-
sion during playback.
The option selector remains at T.
To restart playback: Select T.
Playback will start from the beginning.
The menu system is hidden.
Fast forward/reverse
Selecting DVD media
Stop function

79 Video
DVD video
In DVD video mode, if necessary dis-
play the menu system (
page 77).
To activate playback pause:
Select g.
The g display changes to T.
To resume playback: Select T.
To skip forwards or backwards: Ro-
tate ymz or slide omp.
or
Press G or H on the control unit.
The control menu appears for approx.
eight seconds (
page 77).
i The function is only available if the DVD is di-
vided into several films/tracks.
In DVD video mode, if necessary dis-
play the menu system (
page 77).
Select “DVD-Video” K “DVD Func-
tions”.
A menu appears.
DVD function menu
Rotate ymz or slide qmr until “Title
Selection” is selected.
To open selection list: Press n.
Select a film/track.Adjusting the brightness, contrast or
color
In DVD video mode, if necessary dis-
play the menu system (
page 77).
Select “DVD-Video” K “Brightness” or
“Contrast” or “ Color”.
To change setting: Rotate ymz or
slide qmr until the desired setting is
reached.
To save setting: Press n.
Switching picture format
In DVD video mode, if necessary dis-
play the menu system (
page 77).
Select “DVD-Video”.
The DVD-Video menu appears. F in
front of the menu items “16:9 Optimi-
zed”, “4:3” or “Widescreen” indicates
the format currently selected.
To switch the format: Rotate ymz or
slide qmr until the desired format is
selected.
To save setting: Press n.
Pause function
Selecting a scene/chapter
Selecting a film/trackPicture settings

80 Video
DVD video
i The DVD menu is the menu stored on the
DVD itself. Its structure differs from one DVD to
another and enables specific actions or settings
to be performed.
Opening the DVD menu
In DVD video mode, if necessary dis-
play the menu system (
page 77).
Select “DVD-Video” K “DVD Func-
tions”
K “Menu”.
The DVD menu appears.
Selecting menu items from the DVD
menu
Slide qmr or omp.
To select: Press n.
The selection menu appears.
i Menu items that cannot be selected are
grayed out.
To confirm selection: Select “Select”.
COMAND will perform the action or dis-
plays a submenu represented by the
menu item selected in the DVD menu.
If necessary select from further options
in the same way.
COMAND then switches back to the
DVD menu.
i Depending on the DVD, it is possible the
menu item “Play” either has no function or no
function in certain parts of the DVD menu. This
is indicated by the 7 symbol on the display.
or
In DVD video mode, if necessary dis-
play the control menu (
page 77).
Select “Menu” K“DVD-Video” K “DVD
Functions”
Select a directional arrow to navigate
the DVD menu.
DVD menu
DVD menu

81 Video
DVD video
Stopping film or skipping to the
beginning/end of a scene
Select any menu item from the DVD
menu.
The selection menu appears.
To stop a film: Select the menu item
“Stop”.
To skip to the end of the scene: Se-
lect the menu item r.
To skip to the beginning of the
scene: Select the menu item p.
i Depending on the DVD, it is possible the
menu items p and r either have no func-
tion or no function in certain parts of the DVD
menu. This is indicated by the 7 symbol on the
display.
Switching to the next DVD menu up
Press the í button.
or
Select the corresponding menu item
from the DVD menu.
or
Select any menu item from the DVD
menu.
In the selection menu select the menu
item “Go Up”.
i Depending on the DVD, it is possible the
menu item “Go Up” either has no function or no
function in certain parts of the DVD menu. This is
indicated by the 7 symbol on the display.
Back to movie
Press the í button repeatedly until
the film is shown.
or
Select the corresponding menu item
from the DVD menu.
or
Select any menu item from the DVD
menu.
In the selection menu select the menu
item “Back (to movie)”.
i Depending on the DVD, it is possible the
menu item “Back (to movie)” either has no func-
tion or no function in certain parts of the DVD
menu.
i The function is not available for all DVDs. If
it is available, you can set the DVD menu lan-
guage, the audio language or the audio format.
The number of settings is determined by the DVD
content. The settings may also be possible in the
DVD menu (
page 80).
In DVD video mode, if necessary dis-
play the menu system (
page 77).
Select “DVD-Video” K “DVD Func-
tions”.
Select “Audio Language”.
A selection menu will appear after a
short time. The dotRin front of an en-
try indicates the currently selected lan-
guage.
To change setting: Rotate ymz or
slide qmr until the desired setting is
reached.
To save setting: Press n.
To exit menu without changes: Slide
omp.
Setting language

88 Telephone
Activating the mobile phone
COMAND’s Bluetooth® device name is
“MB Bluetooth”.
In the phone submenu select “Phone”
K “Phone List” K “Update” K
“Options”
K “External Authorization”.
Start Bluetooth® search procedure on
the mobile phone (
mobile phone op-
erating guide).
Select COMAND (“MB Bluetooth”) from
the device list on your mobile phone.
When prompted to do so, enter the
passcode on the mobile phone and on
COMAND.
Displaying details on a mobile phone
In the phone submenu select “Phone”
K “Phone List”.
Select the mobile phone from the list.
Select “Options” K “Details”.
The details screen for the device is dis-
played.
To close details screen: Rotate ymz,
slide qmr or omp or press n.Deregistering (de-authorizing) a mobile
phone
In the phone submenu select “Phone”
K “Phone List”.
Select the authorized mobile phone.
Select “Options” K “De-Authorize”.
You will be asked whether the device
should really be de-authorized.
Select “Yes” or “No”.
If you select “Yes”, the authorization of
the device is withdrawn.
i If the authorization of a device, which had
been authorized in the past, has been withdrawn
and it is no longer found in the search, the device
list no longer includes this device.
Activating another mobile phone
If you have authorized several mobile
phones, you can switch between the indi-
vidual mobile phones.
When you authorize a new mobile phone, it
is activated automatically. Only one mobile
phone is active at a time.
Select “Phone” K “Phone List”.
Select the mobile phone from the list.
Press n.
The selected mobile phone is activated
if the selected mobile is within recep-
tion range and its Bluetooth
® function
is switched on. Any previously activat-
ed phone is deactivated.
Receiving business cards
You can import business cards (vCards)
into the address book from external Blue-
tooth
® devices. Please note the following:

Bluetooth® must be activated
(
page 169)
i If the “Bluetooth” function on the
COMAND is switched off, the message “Blue-
tooth not activated in system settings.” appears.
