Contents
Manual transmission ......................... 157Shifting into reverse ..................... 158
Automatic transmission* ................... 159 One-touch gearshifting................. 160
Gear ranges ................................. 161
Gear selector lever position ......... 162
Automatic shift program .............. 164
Driving tips ................................... 165
Emergency operation
(Limp Home Mode) ...................... 166
Good visibility .................................... 167 Headlamp cleaning system* ........ 167
Rear view mirrors ......................... 167
Sun visors .................................... 169
Rear window defroster ................. 170
Climate control .................................. 172 Deactivating the climate control
system ......................................... 175
Setting the temperature ............... 175
Adjusting air distribution and
volume ......................................... 176
Defrosting .................................... 177
Air recirculation mode.................. 177
Air conditioning ............................ 179
Rear passenger compartment
adjustable air vents...................... 180 Automatic climate control* ................ 182
Deactivating the automatic
climate control system ................. 185
Setting the temperature................ 185
Adjusting air distribution............... 186
Adjusting air volume ..................... 187
Defrosting ..................................... 188
Maximum cooling MAXCOOL ........ 188
Air recirculation mode .................. 189
Charcoal filter ............................... 191
Air conditioning............................. 192
Residual heat and ventilation
(available on automatic climate
control panel design A only).......... 193
Rear passenger compartment
adjustable air vents....................... 194 Audio system...................................... 195
Audio and telephone, operation .... 195
Operating safety ........................... 195
Operating and display elements ... 196
Button and soft key operation ...... 198
Operation...................................... 198
Radio operation ............................ 203
Introduction to satellite radio*
(USA only) ..................................... 208
CD mode....................................... 213
GSM network phones ................... 220
TDMA or CDMA network phones .. 227
Emergency calls “911” ................. 234
Power windows .................................. 237 Opening and closing the windows 237
Synchronizing power windows ...... 240

ContentsTechnical data.................................. 413
Parts service ...................................... 414
Warranty coverage ............................. 415 Loss of Service and Warranty
Information Booklet...................... 415
Identification labels............................ 416
Layout of poly-V-belt drive ................. 417 C 230 Kompressor ....................... 417
C 320 ........................................... 417
Engine ................................................ 418
Rims and Tires ................................... 419 Same size tires ............................. 420
Mixed size tires ............................ 421
Spare wheel ................................. 422
Electrical system................................ 423
Main Dimensions ............................... 424
Weights .............................................. 425 Fuels, coolants, lubricants, etc. ......... 426
Capacities .................................... 426
Engine oils.................................... 428
Engine oil additives ...................... 428
Air conditioning refrigerant .......... 428
Brake fluid .................................... 428
Premium unleaded gasoline ......... 429
Fuel requirements ........................ 429
Gasoline additives ........................ 430
Flexible Fuel Vehicles ................... 431
Coolants....................................... 432
Windshield washer system and
headlamp cleaning system ........... 435
Technical terms ............................... 437Index................................................. 443

11
Introduction
Operator’s Manual
Important notice for California
retail buyers and lessees of Mercedes-Benz automobiles
Under California law you may be entitled to
a replacement of your vehicle or a refund
of the purchase price or lease price, if
Mercedes-Benz USA, LLC and / or its
authorized repair or service facilities fail to
fix one or more substantial defects or mal-
functions in the vehicle that are covered by
its express warranty after a reasonable
number of repair attempts. During the pe-
riod of 18 months from original delivery of
the vehicle or the accumulation of
18 000 miles (approximately 29 000 km)
on the odometer of the vehicle, whichever
occurs first, a reasonable number of repair
attempts is presumed for a retail buyer or
lessee if one or more of the following
occurs:
(1) the same substantial defect or mal-
function results in a condition that is
likely to cause death or serious bodily
injury if the vehicle is driven, that de-
fect or malfunction has been subject to
repair two or more times, and you have
directly notified Mercedes-Benz USA,
LLC in writing of the need for its repair,
(2) the same substantial defect or mal- function of a less serious nature than
category (1) has been subject to repair
four or more times and you have direct-
ly notified us in writing of the need for
its repair, or (3) the vehicle is out of service by reason
of repair of the same or different sub-
stantial defects or malfunctions for a
cumulative total of more than
30 calendar days.
Written notification should be sent to us,
not a dealer, at Mercedes-Benz USA, LLC,
Customer Assistance Center,
One Mercedes Drive, Montvale,
NJ 07645-0350.

174 Controls in detailClimate controlThe climate control is operational when-
ever the engine is running. You can oper-
ate the climate control system in either the
automatic or manual mode. The system
cools or heats the interior depending on
the selected interior temperature and the
current outside temperature.Nearly all dust particles, pollutants and
odors are filtered out before outside air en-
ters the passenger compartment through
the air distribution system.
The air conditioning will not engage (no
cooling) if the mode
AC
OFF
is activated or
mode A/C is deactivated (page 179).
Warning!
G
When operating the climate control, the air
that enters the passenger compartment
through the air vents in the footwell can be
very hot or very cold (depending on the set
temperature). This may cause burns or frost-
bite on unprotected skin in the immediate
area of the air vents. Always keep sufficient
distance between unprotected parts of the
body and the footwell air vents. If necessary,
change the air flow using the air distribution
controls to direct the air away from the foot-
well air vents (
page 176).
Warning!
G
Follow the recommended settings for heat-
ing and cooling given on the following pag-
es. Otherwise the windows could fog up,
impairing visibility and endangering you and
others.
iSevere conditions (e.g. strong air
pollution) may require replacement of
the filter before its scheduled interval.
A clogged filter will reduce the air
volume to the interior.
If the vehicle interior is hot, ventilate
the interior before driving off, see
“Opening (Summer opening feature)”
(page 240).
Keep the air intake grille in front of the
windshield free of snow and debris.
Do not obstruct air flow by placing
objects on the air flow-through exhaust
slots below the rear window.

175
Controls in detail
Climate control
Deactivating the climate control system
Deactivating
Set air volume control
1 (
page 173)
to position 0.
Reactivating

Set air volume control 1 (
page 173)
to any speed.
Setting the temperature
Use temperature controls 2 and 3
(page 173) to separately adjust the air
temperature on each side of the passenger
compartment. You should raise or lower
the temperature setting in small incre-
ments, preferably starting at 72°F (22°C). Increasing

Turn temperature control
2 or 3
slightly to the right.
The climate control system will corre-
spondingly adjust the interior air tem-
perature.
Decreasing

Turn temperature control 2 or 3
slightly counterclockwise.
The climate control system will corre-
spondingly adjust the interior air tem-
perature.
iWhen the air conditioning is switched
off, the outside air supply and circula-
tion are also switched off. Only choose
this setting for a short time. Otherwise
the windows could fog up.
iWhen operating the climate control
system in automatic mode, you will
only rarely need to adjust the tempera-
ture, air volume and air distribution.

177
Controls in detail
Climate control
Defrosting
Activating
Press button
P or0
(page 173).
The indicator lamp on the button
comes on.
The air conditioning switches automatical-
ly to the following functions:


maximum blowing and heating
power


air flows onto the windshield and
the front side windows


the air recirculation mode is
switched off Deactivating

Press button
P or0
(page 173).
The indicator lamp on the button goes
out. Defrosting is turned off.
Air recirculation mode
Switch to air recirculation mode to prevent
unpleasant odors from entering the vehicle
from the outside. This setting cuts off the
intake of outside air and recirculates the
air in the passenger compartment. Activating

Press button
, (
page 173).
The indicator lamp on the button
comes on.
iThese settings should only be selected
for a short time.
Warning!
G
When the outside temperature is
below 41°F (5°C), only switch to air
recirculation mode for short periods to
prevent window fogging.
Window fogging may impair visibility and
endanger you and others.
iIf you keep button , pressed the
side windows and panorama roof with
power tilt/sliding panel* will close.Warning!
G
Never operate the side windows and the
panorama roof with power tilt/sliding pan-
el* if there is the possibility of anyone being
harmed by the closing procedure.
Vehicles without panorama roof with power
tilt/sliding panel*:
In the event that the procedure causes
potential danger, the opening and closing of
the side windows can be immediately halted
by pressing or pulling the respective window
switch.


178 Controls in detailClimate control
Deactivating
Press button, (
page 173).
The indicator lamp on the button goes
out.
The air recirculation mode is deactivated
automatically:


after five minutes if the outside
temperature is below
approximately 41°F (5°C)


after five minutes if the air conditioning
is turned off


after 30 minutes if the outside
temperature is above
approximately 41°F (5°C)
Vehicles with panorama roof with power
tilt/sliding panel*:
In the event that the procedure causes po-
tential danger, the opening and closing of
the side windows can be immediately halted
by releasing the , button or by pressing
or pulling the respective window switch. The
opening and closing of the panorama roof
with power tilt/sliding panel* can be imme-
diately halted by releasing the , button
or by moving the panorama roof with power
tilt/sliding panel switch in the overhead
control panel in any direction.
iThe air recirculation mode is activated
automatically at high outside tempera-
tures.
The indicator lamp on the , button
is not lit when the air recirculation
mode is automatically switched on.
After approximately 30 minutes, out-
side air is added to the air inside the
vehicle.
If you have turned off the air condi-
tioning (
page 179) or the outside
temperature is below 41°F (5°C), the
air recirculation mode will not switch
on automatically.
iIf you keep button , pressed, the
side windows and panorama roof with
power tilt/sliding panel* will return to
their previous position.


179
Controls in detail
Climate control
At outside temperatures above 79°F
(26°C) the system will not automatically
switch back to outside air. A quantity of
outside air is added after approximately
30 minutes.Air conditioning
The air conditioning is operational while
the engine is running and cools the interior
air to the temperature set by the operator.
Deactivating
It is possible to deactivate the air condi-
tioning (cooling) function of the climate
control system. The air in the vehicle will
then no longer be cooled or dehumidified.
Climate control panel design A

Press button
± (
page 173).
The indicator lamp on the button
comes on.
The cooling function switches off after
a short delay.
Climate control panel design B

Press button 2 (
page 173).
The indicator lamp on the button goes
out.
The cooling function switches off after
a short delay. Activating
Moist air can fog up the windows. You can
dehumidify the air with the air condition-
ing.
Climate control panel design A

Press button
± (
page 173).
The indicator lamp on the button goes
out.
Climate control panel design B

Press button 2 (
page 173).
The indicator lamp on the button
comes on.
The air conditioning uses the
refrigerant R134a. This refrigerant is free
of CFCs which are harmful to the ozone
layer.
iCondensation may drip out from under-
neath the vehicle. This is normal and
not an indication of a malfunction.Warning!
G
If you turn off the cooling function, the vehi-
cle will not be cooled when weather condi-
tions are warm. The windows can fog up
more quickly. As a result, you can no longer
observe traffic situations around you and
could cause an accident.

180 Controls in detailClimate control
Rear passenger compartment adjustable air vents
The air conditioning for the rear passenger
compartment is controlled via the climate
control panel (
page 173).The air vents for the rear passenger
compartment are located in the rear
center console.
1 Left center air vent
2 Thumbwheel for air volume control for
center air vents
3 Right center air vent
!If the air conditioning cannot be turned
on again, this indicates that the air
conditioning is losing refrigerant. The
compressor has turned itself off.
Have the air conditioning checked at
the nearest authorized Mercedes-Benz
Center.
iThe temperature at the center air vents
for the rear passenger
compartment 1 and 3 is the same as
at the dashboard center air vents.

184 Controls in detailAutomatic climate control*The automatic climate control is operation-
al whenever the engine is running. You can
operate the climate control system in ei-
ther the automatic or manual mode. The
system cools or heats the interior depend-
ing on the selected interior temperature
and the current outside temperature.Nearly all dust particles, pollutants and
odors are filtered out before outside air
enters the passenger compartment
through the air distribution system.
The air conditioning will not engage (no
cooling) if the modeAC
OFF
is activated or
mode A/C is deactivated (page 192).
iFeature availability is based on prelimi-
nary information at time of printing.
The automatic climate control may not
be available as optional equipment on
all models.
Warning
G
When operating the automatic climate
control, the air that enters the passenger
compartment through the air vents in the
footwell can be very hot or very cold
(depending on the set temperature). This
may cause burns or frostbite on unprotected
skin in the immediate area of the air vents.
Always keep sufficient distance between
unprotected parts of the body and the foot-
well air vents. If necessary change the air
flow using the air distribution controls to
direct the air away from the footwell air
vents (
page 186).
Warning!
G
Follow the recommended settings for
heating and cooling given on the following
pages. Otherwise the windows could fog up,
impairing visibility and endangering you and
others.iSevere conditions (e.g. strong air
pollution) may require replacement of
the filter before its scheduled interval.
A clogged filter will reduce the air
volume to the interior.
If the vehicle interior is hot, ventilate
the interior before driving off, see
“Opening (Summer opening feature)”
(page 245).
Keep the air intake grille in front of the
windshield free of snow and debris.
Do not obstruct air flow by placing
objects on the air flow-through exhaust
slots below the rear window.
