fuse box MERCEDES-BENZ C CLASS COUPE 2005 Owners Manual

Contents
Uniform Tire Quality Grading
Standards (U.S. vehicles) ............. 320
Tire ply material ........................... 322
Tire and loading terminology ........ 323
Rotating tires ............................... 326
Winter driving .................................... 328 Winter tires .................................. 328
Block heater (Canada only) .......... 329
Snow chains................................. 329
Maintenance...................................... 330 Clearing the maintenance
service indicator........................... 331
Maintenance service term
exceeded ..................................... 331
Calling up the maintenance
service indicator........................... 331
Resetting the maintenance
service indicator........................... 332
Vehicle care ....................................... 333 Cleaning and care of the vehicle .. 333
Practical hints .................................. 339
What to do if … ................................... 340 Lamps in instrument cluster ......... 340
Lamp in center console................. 345
Vehicle status messages in the
multifunction display..................... 347
Where will I find ...? ............................ 373 First aid kit.................................... 373
Vehicle tool kit .............................. 373
Spare wheel .................................. 375
Unlocking/locking in an emergency... 377 Unlocking the vehicle.................... 377
Locking the vehicle ....................... 379
Fuel filler flap ................................ 379
Manually unlocking the gear
selector lever ................................ 380
Opening/closing in an emergency ..... 381 Panorama roof with power
tilt/sliding panel* ......................... 381
Replacing SmartKey batteries ............ 382 SmartKey ...................................... 383
Replacing bulbs .................................. 384 Bulbs ............................................. 384
Replacing bulbs for front lamps .... 386
Replacing bulbs for rear lamps ..... 390 Replacing wiper blades ...................... 393
Removing ...................................... 393
Installing ....................................... 393
Flat tire............................................... 394 Preparing the vehicle .................... 394
Mounting the spare wheel ............ 394
Battery ............................................... 401 Disconnecting the battery ............ 402
Removing the battery ................... 402
Charging and reinstalling battery .. 402
Reconnecting the battery ............. 403
Jump starting...................................... 404
Towing the vehicle.............................. 406 Installing towing eye bolt .............. 409
Fuses.................................................. 410 Aids for changing fuses ................ 410
Main fuse box in passenger
compartment ................................ 411
Fuse box in engine compartment . 411
Fuse box in trunk .......................... 412

290 OperationAt the gas stationCheck regularly and before a long trip1 Coolant level
2 Brake fluid (fuse box cover removed)
3 Windshield washer and headlamp
cleaning system* Brake fluid
Remove fuse box cover before checking
brake fluid (
page 410).
Engine oil level
For more information on engine oil, see
“Engine oil” (page 292).
Opening hood, see (
page 291). Coolant
For normal replenishing, use water (pota-
ble water quality). For more information on
coolant, see “Coolant level” (
page 296)
Vehicle lighting
Check function and cleanliness. For infor-
mation on replacing light bulbs, see “Re-
placing bulbs” (
page 384).
Exterior lamp switch, see (
page 110).
Tire inflation pressure
For information on tire inflation pressure,
see “Checking tire inflation pressure”
(
page 311).
Windshield washer and headlamp
cleaning system*
For more information on filling up the
washer reservoir, see “Windshield washer
system and headlamp cleaning system*”
(page 299).
!If you find that the brake fluid in the
brake fluid reservoir has fallen to the
minimum mark or below, have the
brake system checked for brake pad
thickness and leaks immediately. Noti-
fy an authorized Mercedes-Benz Center
immediately. Do not add brake fluid as
this will not solve the problem. For
more information, see “Practical Hints”
(page 341).

410 Practical hintsFusesThe electrical fuses in your vehicle serve to
stop the supply of electricity to a device
that is malfunctioning. This helps to
prevent damage to the other vehicle
electronics.
The following aids are available to help you
change fuses.

Fuse chart


Spare fuses


Fuse extractorThe electrical fuses are located in different
fuse boxes.


Main fuse box in passenger compart-
ment (
page 411)


Fuse box in engine compartment
(page 411)


Fuse box in trunk (
page 412)
Aids for changing fuses
Fuse chart
The fuse chart is found in the main fuse
box in the passenger compartment
(page 411). The amperages of the fuses
are also given there.
Spare fuses
Spare fuses are found in the vehicle tool kit
in the spare wheel well (
page 373).
Fuse extractor
The fuse extractor is found in the fuse box
cover in the trunk (
page 412).
Warning!
G
Only use fuses approved for Mercedes-Benz
with the specified amperage for the system
in question. Otherwise, a short circuit could
result and cause a fire.
!Only install fuses that have been tested
and approved by Mercedes-Benz and
that have the specified amperage
rating.
Otherwise, electrical parts or systems
could be damaged.
Never attempt to repair or bridge a
blown fuse. Have the cause determined
and remedied by an authorized
Mercedes-Benz Center.

411
Practical hintsFuses
Main fuse box in passenger compartment
1 Main fuse box cover
Opening fuse box
Open the driver’s door

Pull cover 1 open with a screw driver
or similar tool (see arrow).

Remove cover 1 rearward.
Closing fuse box

Attach cover 1 in the front.

Fold cover 1 in until it engages.
Fuse box in engine compartment
The fuse box is located in the engine
compartment on the driver’s side.
1 Cover
2 Screws
3 Retainer
Removing cover
Twist screws 2 90° counterclock-
wise.

Lift the rear of cover 1.

Slide out retainer 3 and remove
cover 1 by pulling towards front. Opening fuse box
4 Fuse box cover
5 Clamps

With a dry cloth, remove any moisture
from the fuse box.

Release clamps 5.

Remove fuse box cover 4.
Closing fuse box

Make sure the sealing rubber is proper-
ly positioned.

Press fuse box cover 4 down and
secure with clamps 5.

412 Practical hintsFusesInstalling cover
Insert cover1 sideways into
retainer 3.

Twist screws 2 90° clockwise.
Fuse box in trunk
The fuse box is located in the trunk behind
the left hand trim panel.
1 Handles
2 Trim panel
Opening
Turn handles 1 clockwise.

Remove trim panel 2. 3
Fuse extractor
4 Fuse box cover
5 Fuse box

Remove fuse box cover 4.
Closing

Insert fuse box cover 4.

Insert trim panel 2.

Turn handles 1 counterclockwise.

450 IndexDownhill drivingCruise control 248
Downshifting Automatic transmission* 160
Manual transmission 158
Drinking and driving 277
Driving Aquaplaning 281
General instructions 44, 277
In winter 283
Problems 55
Safety systems 81
Through standing water 284
Driving abroad 284
Driving instructions 277
Driving off 279
Driving safety systems ABS 81
BAS 82
ESP 83
Driving systems 247 Cruise control 247
Driving safety systems 81 E
Easy-entry/exit feature* 100
Activating 148
Electrical fuses 410
Electrical outlet 260
Electrical system Technical data 423
Electronic Stability Program see ESP 438
Emergency call system* 262
Emergency calls "911" 234
Initiating an emergency call 264
With Tele Aid* 263
Emergency operation (Limp Home Mode) 166
Emergency operations Closing panorama roof with power tilt/sliding panel* 381
Locking the vehicle 379
Opening panorama roof with power tilt/sliding panel* 381
Releasing trunk lid from inside 96
Remote door unlock 268
Unlocking the Trunk lid 378
Unlocking the vehicle 377 Emergency tensioning device see
ETD 438
Emission control 286
Emission control label 416
Ending A call (telephone*) 154
Engine Compartment 291
Starting with automatic transmission* 49
Starting with manual transmission 48
Starting with the SmartKey 48, 49
Technical data 418
Turning off with the key 58
Engine cleaning 335
Engine compartment 291 Fuse box in 411
Hood 291
Engine malfunction indicator lamp 25, 342
Engine number 438

452 IndexFSS see Flexible Service System (Canada vehicles)
Fuel 289 Additives 430
Cruising range 432
E85 (Ethanol fuel) 432
Fuel reserve warning lamp 344
Gasoline additives 430
Premium unleaded gasoline 289, 427, 429
Requirements 429
Reserve warning 25
Switching (Flexible fuel vehicle) 431
Technical data 426
Fuel additives 430
Fuel cap Message in display 365
Fuel consumption statistics After start 151
Since last reset 151
Fuel filler flap 288 Locking 288
Opening in an emergency 379
Unlocking 288 Fuel tank
Capacity 427
Filler flap 288
Fuels, coolants, lubricants etc. Capacities 426
Functions (control system) 124, 127 Resetting 135
Fuse box 411 In trunk 412
Fuse chart 410
Fuse extractor 410, 412
Fuses 410 Aid for changing 410
Fuse box in engine compartment 411
Fuse box in passenger compartment 411
Fuse box in trunk 412
Fuse chart 410
Fuse extractor 410, 412 G
Garage door opener* 29, 269
Gasoline
Gasoline additives 430
Gasoline see Fuel 289
GAWR 323
Gear range 438 Automatic transmission* 161
Limiting 161
Shifting into optimal 161
Gear range limit Canceling 161
Gear selector lever 25, 159 Cleaning 337
Position (Automatic transmission*) 25, 159, 162
Global Locking 92
Unlocking 92
Global Positioning System (GPS) 439
Glove box 23, 254 Closing 254
Opening 254
Good visibility 167
GPS 439
Gross Axle Weight Rating see GAWR

459
Index
Parts see Parts service 414
Parts service 414
Passenger compartment 284
Fuse box in 411
Interior lighting 117
Interior rear view mirror 42
Parcel net in front passenger footwell 257
Passenger safety see Occupant safety
Pedals 277
Performance In cold weather 431
In hot weather 432
Phone book* Loading 154
Quick search 155
Phone number* Dialing 154
Redialing 156
Plastic and rubber parts Cleaning 338
Playing CDs 216
Poly-V-belt drive 440 Layout 417 Positions (Memory function*)
Recalling from memory 108
Storing into memory 108
Potential problems associated with under- inflated and overinflated tires 312
Power assistance 277
Power seat* Adjusting backrest tilt 38
Adjusting head restraint height 38
Adjusting seat cushion tilt 38
Adjusting seat height 38
Memory function* 107
Removing/installing front head restraints 103
Seat fore and aft adjustment 38
Power train 440
Power washer 334
Power windows 237 Side windows 237
Synchronizing 240
Practical hints First aid kit 373
Fuses 410
Lamp in center console 345
Lamps in instrument cluster 340
Spare wheel 375 Spare wheel bolts 376
Symbol messages 357
Text messages 349
Towing the vehicle 406
Vehicle jack 374
Vehicle status messages in the
display 347
Vehicle tool kit 373
Premium unleaded gasoline 429
Problems While driving 55
Production options weight 324
Program mode selector switch 440 Automatic transmission* 164
PSI 325
Q
Quick search Phone book* 155
R
Radio Selecting stations 130
Radio operation 203
Radio transmitters Control and operation 284

466 IndexTracking servicesFor stolen vehicle 269
Traction 164, 325
Transmission gear selector lever Unlocking manually 380
Transmission see Automatic transmission* 296
Tread 325
Tread depth 302
Tread depth (tires) 328
Treadwear indicators 325
Trim panel Opening 412
Trip computer 151
Trip odometer Resetting 121
Trunk Closing the lid 95
Fuse box 412 Trunk lid
Closing 95
Emergency release 96
Message in display 372
Opening from inside vehicle 95
Turn signal lamps Replacing bulbs 385
Turn signals 52 Additional in mirrors 385
Cleaning lenses 335
Front bulbs 385, 388, 389
Rear bulbs 385, 391
Turning off Engine 58
U
Uniform Tire Quality Grading Standards 326
Units Setting speedometer units 137
Setting temperature units 137 Unlocking 32, 90
Centrally from inside 98
Driver’s door in an emergency 377
Fuel filler flap 288
Global 92
In an emergency 377
Selective settings 92
Transmission gear selector lever manually 380
Trunk lid in an emergency 378
Vehicle in an emergency 268
With the SmartKey 32
Upgrade signals Tele Aid* 267
Uphill driving Cruise control 248
Upholstery Cleaning 338
Upshifting 160
