AUTO lights
Display message ............................ 225
see Lights
Automatic headlamp mode .............. 108
Automatic transmission Automatic drive program ...............146
Changing gear ............................... 144
Display message ............................ 236
Driving tips .................................... 144
Emergency running mode ..............149
Kickdown ....................................... 144
Manual drive program ....................147
Problem (malfunction) ...................149
Program selector button ................144
Pulling away ................................... 139
Releasing the parking lock
manually ........................................ 149
Selector lever ................................ 142
Shift ranges ................................... 146
Starting the engine ........................139
Steering wheel paddle shifters ......145
Transmission position display ........143
Transmission positions ..................143
Automatic transmission
emergency mode ............................... 149
B
Back support see Lumbar support
Backup lamp
Changing bulbs .............................. 116
Display message ............................ 224
Bag hook ............................................ 258
BAS (Brake Assist System) ................. 59
Basic settings see Settings
BAS PLUS (Brake Assist System
PLUS) .................................................... 60
Battery (SmartKey) Checking .......................................... 74
Important safety notes ....................74
Replacing ......................................... 74
Battery (vehicle)
Charging ........................................ 300
Display message ............................ 227
Important safety notes ..................298
Jump starting ................................. 301
Belt
see Seat belts
Blind Spot Assist
Activating/deactivating .................205
Notes/function .............................. 183
see Active Blind Spot Assist
Brake Assist System
see BAS (Brake Assist System)
Brake fluid
Display message ............................ 217
Notes ............................................. 350
Brake fluid level ................................ 282
Brake lamps Changing bulbs .............................. 116
Display message ............................ 223
Brakes
ABS .................................................. 59
BAS .................................................. 59
BAS PLUS ........................................ 60
Brake fluid (notes) .........................350
Display message ............................ 214
Driving tips .................................... 156
High-performance brake system ....158
Important safety notes ..................156
Maintenance .................................. 157
Parking brake ................................ 154
Warning lamp ................................. 241
Breakdown
see Flat tire
see Towing away/tow-starting
Bulbs
see Changing bulbs
C
California Important notice for retail
customers and lessees ....................22
Calling up a malfunction
see Display messages
Capacities
see Technical data
Car
see Vehicle
Index5

CareCarpets .......................................... 289
Car wash ........................................ 284
Display ........................................... 288
Exterior lights ................................ 287
Gear or selector lever ....................288
Matte finish ................................... 285
Notes ............................................. 283
Paint .............................................. 285
Plastic trim .................................... 288
Power washer ................................ 284
Rear view camera .......................... 287
Roof lining ...................................... 289
Seat belt ........................................ 289
Seat cover ..................................... 288
Sensors ......................................... 287
Steering wheel ............................... 288
Tail pipes ....................................... 287
Trim pieces .................................... 288
Washing by hand ........................... 284
Wheels ........................................... 285
Windows ........................................ 286
Wiper blades .................................. 286
Wooden trim .................................. 288
Cargo tie down rings ......................... 258
Car wash (care) ................................. 284
CD player/CD changer (on-board
computer) .......................................... 202
Cell phone see Mobile phone
Center console ..................................... 32
Central locking Automatic locking (on-board
computer) ...................................... 208
Locking/unlocking (SmartKey) ........70
Changing bulbs
Brake lamps ................................... 116
Cornering light function .................115
High-beam headlamps ...................115
Important safety notes ..................113
Low-beam headlamps ....................114
Overview of bulb types ..................114
Parking lamps ................................ 115
Reversing lamps ............................ 116
Standing lamps (front) ...................115
Child-proof locks
Important safety notes ....................57
Rear doors ....................................... 57Children
In the vehicle ................................... 53
Restraint systems ............................ 53
Child seat
LATCH-type (ISOFIX) child seat
anchors ............................................ 55
Special seat belt retractor ...............55
Top Tether ....................................... 56
Cigarette lighter ................................ 262
Climate control Automatic climate control (3-
zone) .............................................. 125
Controlling automatically ...............127
Cooling with air dehumidification ..126
Defrosting the windows .................130
Defrosting the windshield ..............129
Dual-zone automatic climate
control ........................................... 123
Important safety notes ..................122
Indicator lamp ................................ 127
Maximum cooling .......................... 130
Notes on using automatic climate
control ................................... 124, 126
Overview of systems ......................122
Problems with cooling with air
dehumidification ............................ 127
Problem with the rear window
defroster ........................................ 130
Rear control panel .........................125
Refrigerant ..................................... 350
Setting the air distribution .............128
Setting the airflow .........................129
Setting the air vents ......................131
Setting the climate mode (AIR
FLOW) ............................................ 127
Setting the temperature ................128
Switching air-recirculation mode
on/off ............................................ 130
Switching on/off ........................... 126
Switching residual heat on/off ......131
Switching the rear window
heating on/off ............................... 130
Switching the ZONE function on/
off .................................................. 129
Cockpit
Overview .......................................... 28
see Instrument cluster 6Index

F
Filler cap see Fuel filler flap
First-aid kit ......................................... 292
Flat tire Changing a wheel/mounting the
spare wheel ................................... 293
MOExtended run-flat system .........297
Preparing the vehicle .....................293
Raising the vehicle .........................295
Floormat ............................................. 276
Frequencies Garage door opener .......................275
Front fog lamps ................................. 108
Display message ............................ 223
Switching on/off ........................... 108
Front windshield
see Windshield
Fuel
Additives ........................................ 348
Consumption statistics ..................199
Displaying the current
consumption .................................. 199
Displaying the range ......................199
Driving tips .................................... 155
Flexible fuel vehicles ......................347
Fuel gauge ....................................... 29
Important safety notes ..................347
Premium-grade unleaded gasoline . 347
Problem (malfunction) ...................153
Refueling ........................................ 150
Specifications ................................ 348
Tank content/reserve fuel .............346
Fuel filler flap
Emergency release ........................151
Opening/closing ............................ 151
Fuel level
Calling up the range (on-board
computer) ...................................... 199
Fuel tank
Capacity ........................................ 346
Problem (malfunction) ...................153
Fuse allocation chart (vehicle tool
kit) ...................................................... 292
Fuses Allocation chart ............................. 305
Before changing ............................. 305Dashboard fuse box .......................305
Fuse box in the engine
compartment ................................. 306
Fuse box in the trunk .....................306
Important safety notes ..................305
G
Garage door opener Clearing the memory .....................274
Frequencies ................................... 275
Notes ............................................. 270
Opening/closing the garage door ..273
Programming (button in the rear-
view mirror) ................................... 271
Gasoline ............................................. 150
Gear indicator (on-board
computer) .......................................... 210
Gear or selector lever (cleaning
guidelines) ......................................... 288
Genuine Mercedes-Benz parts ......... 342
Glove box ........................................... 254
H
Handbrake see Parking brake
Hazard warning lamps ...................... 109
Headlamp cleaning system Notes ............................................. 351
Headlamps
Adding fluid to cleaning system .....281
Cleaning system (function) ............109
Fogging up ..................................... 112
see Automatic headlamp mode
Head restraints
Adjusting ......................................... 95
Adjusting (electrically) .....................96
Adjusting (manually) ........................95
Adjusting (rear) ................................ 96
Installing/removing (rear) ................97
Luxury .............................................. 96
see NECK-PRO head restraints
see NECK-PRO head restraints/
NECK-PRO luxury head restraints
Heating
see Climate control
10Index

High-beam headlampsChanging bulbs .............................. 115
Display message ............................ 223
Switching Adaptive Highbeam
Assist on/off ................................. 110
Switching on/off ........................... 109
Hill start assist .................................. 140
HOLD function Display message ............................ 228
Function/notes ............................. 172
Hood
Closing ........................................... 279
Display message ............................ 237
Opening ......................................... 278
Hydroplaning ..................................... 158
I
Ignition lock see Key positions
Immobilizer .......................................... 66
Indicator lamps see Warning and indicator lamps
Indicators
see Turn signals
Instrument cluster
Overview .......................................... 29
Settings ......................................... 206
Warning and indicator lamps ...........30
Instrument cluster lighting ................ 29
Instrument lighting see Instrument cluster lighting
Interior lighting ................................. 112
Automatic control ..........................112
Delayed switch-off (on-board
computer) ...................................... 208
Emergency lighting ........................113
Manual control ............................... 113
Overview ........................................ 112
Reading lamp ................................. 112
J
Jack Storage location ............................ 292
Using ............................................. 295
Jump starting (engine) ...................... 301
K
Key see SmartKey
KEYLESS-GO
Convenience closing feature ............85
Display message ............................ 238
Locking ............................................ 71
Start/Stop button .......................... 137
Starting the engine ........................139
Unlocking ......................................... 71
Key positions
KEYLESS-GO .................................. 137
SmartKey ....................................... 137
Kickdown
Driving tips .................................... 144
Manual drive program ....................148
Knee bag .............................................. 40
L
Lamps see Warning and indicator lamps
Lane-change assistant
see Blind Spot Assist
Lane detection (automatic)
see Lane Keeping Assist
Lane Keeping Assist
Activating/deactivating .................205
Display message ............................ 229
Function/information ....................185
Lane Tracking package ..................... 183
Lap time (RACETIMER) ...................... 211
LATCH-type (ISOFIX) child seat
anchors ................................................ 55
Lighting see Lights
Lights
Activating/deactivating the
interior lighting delayed switch-off . 208
Active light function .......................110
Automatic headlamp mode ............108
Cornering light function .................110
Display message ............................ 222
Driving abroad ............................... 106
Fog lamps ...................................... 108
Hazard warning lamps ...................109
High beam flasher .......................... 109
Index11

High-beam headlamps ...................109
Light switch ................................... 106
Low-beam headlamps ....................107
Parking lamps ................................ 106
Rear fog lamp ................................ 108
Switching Adaptive Highbeam
Assist on/off ................................. 207
Switching the daytime running
lamps on/off (on-board
computer) ...................................... 207
Switching the daytime running
lamps on/off (switch) ....................107
Switching the exterior lighting
delayed switch-off on/off (on-
board computer) ............................ 207
Switching the surround lighting
on/off (on-board computer) ..........207
Turn signals ................................... 109
see Changing bulbs
see Interior lighting
Light sensor (display message) ....... 225
LIM indicator lamp Cruise control ................................ 160
DISTRONIC PLUS ........................... 164
Loading guidelines ............................ 254
Locking see Central locking
Locking (doors)
Automatic ........................................ 78
Emergency locking ........................... 79
From inside (central locking
button) ............................................. 78
Locking centrally
see Central locking
Locking verification signal (on-
board computer) ............................... 208
Low-beam headlamps Changing bulbs .............................. 114
Display message ............................ 222
Setting for driving abroad
(symmetrical) ................................. 106
Switching on/off ........................... 107
Lumbar support
Adjusting ......................................... 97
Adjusting the 4-way lumbar
support ............................................ 97
Luxury head restraints ....................... 96M
M+S tires ............................................ 312
Maintenance see ASSYST PLUS service interval
display
Malfunction message
see Display messages
Matte finish (cleaning
instructions) ...................................... 285
mbrace Call priority .................................... 268
Display message ............................ 218
Downloading destinations
(COMAND) ..................................... 269
Emergency call .............................. 266
Important safety notes ..................264
Locating a stolen vehicle ...............270
MB info call button ........................268
Remote vehicle locking ..................270
Roadside Assistance button ..........267
Search & Send ............................... 269
Self-test ......................................... 265
System .......................................... 265
Vehicle remote unlocking ..............269
Mechanical key
Function/notes ................................ 73
Locking vehicle ................................ 79
Unlocking the driver's door ..............79
Memory card (audio) ......................... 202
Memory function ............................... 103
Message memory (on-board
computer) .......................................... 213
Messages see Display messages
Mirrors
see Exterior mirrors
see Rear-view mirror
see Vanity mirror
Mobile phone
Menu (on-board computer) ............202
Modifying the programming
(SmartKey) ........................................... 73
MOExtended run-flat system ........... 297
MP3 Operation ....................................... 202
see separate operating instructions 12Index

Warning and indicator lampsFunctionPage:÷ ESP®243M
SPORT handling
mode in AMG vehicles
244
;Distance warning249=ESP ®
OFF243?Brakes (USA only)241ABrakes (Canada only)241BTurn signal109CABS242DSRS245ECheck engine246FunctionPageFTire pressure monitor250GSeat belt239HESP ®
on AMG vehicles243ICoolant247JRear fog lamp108KHigh-beam headlamps109LLow-beam headlamps107MFront fog lamps108NReserve fuel24630Instrument clusterAt a glance

XMake sure that the SmartKey is in position
1 or 2 in the ignition lock.XBriefly press button :.
Both exterior mirrors fold in or out.
i Make sure that the exterior mirrors are
always folded out fully while the vehicle is
in motion, as they may otherwise vibrate.
i If you are driving faster than
9 mph (15 km/h), you can no longer fold in
the exterior mirrors.
Setting the exterior mirrors
This function is only available in vehicles for
Canada.
If the battery has been disconnected or
completely discharged, the exterior mirrors
must be reset. The exterior mirrors will
otherwise not fold in when you select the
"Fold in mirrors when locking" function in the
on-board computer ( Y page 209).
XMake sure that the SmartKey is in
position 1 in the ignition lock.XBriefly press button :.
Folding the exterior mirrors in or out
automatically
This function is only available in vehicles for
Canada.
If the "Fold in mirrors when locking" function
is activated in the on-board computer
( Y page 209):
R the exterior mirrors fold in automatically as
soon as you lock the vehicle from the
outside.
R the exterior mirrors fold out again
automatically as soon as you unlock the
vehicle and then open the driver's or front-
passenger door.
i The mirrors do not fold out if they have
been folded in manually.
Exterior mirror out of position
If an exterior mirror has been pushed out of
position, proceed as follows:
XVehicles without electrically folding
exterior mirrors: move the exterior mirror
into the correct position manually.XVehicles with electronically folding
mirrors 6
: press the mirror-folding button
( Y page 101) repeatedly until you hear the
mirror engage in position.
The mirror housing is engaged again and
you can adjust the exterior mirrors as usual
( Y page 101).
Automatic anti-glare mirrors
GWARNING
If incident light from headlamps is prevented
from striking the sensor in the rear-view
mirror, for instance, by luggage piled too high
in the vehicle, the mirror's automatic anti-
glare function will not operate.
Incident light could then blind you. This may
distract you from the traffic conditions and,
as a result, you may cause an accident.
The rear-view mirror and the exterior mirror
on the driver's side automatically go into anti-
glare mode if the ignition is switched on and
incident light from headlamps strikes the
sensor in the rear-view mirror.
The mirrors do not go into anti-glare mode if
reverse gear is engaged or the interior lighting
is switched on.
Parking position for the exterior
mirror on the front-passenger side
Setting and storing the parking position
You can position the front-passenger side
exterior mirror in such a way that you can see
the rear wheel on that side as soon as you
6 Canada only102MirrorsSeats, steering wheel and mirrors

Useful information
i This Operator's Manual describes all
models and all standard and optional
equipment of your vehicle available at the
time of publication of the Operator's
Manual. Country-specific differences are
possible. Please note that your vehicle may
not be equipped with all features
described. This also applies to safety-
related systems and functions.
i Please read the information on qualified
specialist workshops ( Y page 24).
Exterior lighting
Important safety notes
For reasons of safety, Mercedes-Benz
recommends that you drive with the lights
switched on even during the daytime. In some
countries, operation of the headlamps varies
due to legal requirements and self-imposed
obligations.
Information about driving abroad
Converting to symmetrical low beam
when driving abroad: switch the headlamps
to symmetrical low beam in countries in
which traffic drives on the opposite side of the
road to the country where the vehicle is
registered. This prevents glare to oncoming
traffic. Symmetrical lights do not illuminate
as large an area of the edge of the road.
Have the headlamps converted at a qualified
specialist workshop, e.g. an authorized
Mercedes-Benz Center, as close to the border
as possible before driving in these countries.
Converting to asymmetrical low beam
after returning: have the headlamps
converted back to asymmetrical low beam at
a qualified specialist workshop, e.g. an
authorized Mercedes-Benz Center, as soon as
possible after crossing the border again.
Light switch
Operation
Depending on the date of manufacture of your
vehicle, the c or à symbol for the
automatic headlamp mode/daytime running
lamps is located on the light switch.
Illustration: light switch with the à symbol for
the automatic headlamp mode/daytime running
lamps
1 WLeft-hand standing lamps2XRight-hand standing lamps3TParking lamps, license plate and
instrument cluster lighting4 ÃAutomatic headlamp mode/daytime
running lamps5 LLow-beam/high-beam headlampsBRRear fog lampCNFront fog lamps 77
Only vehicles with front fog lamps have the fog lamps function.106Exterior lightingLights and windshield wipers

Illustration: light switch with the c symbol for
the automatic headlamp mode/daytime running
lamps
1 WLeft-hand standing lamps2XRight-hand standing lamps3TParking lamps, license plate and
instrument cluster lighting4 cAutomatic headlamp mode/daytime
running lamps5 LLow-beam/high-beam headlampsBRRear fog lampCNFront fog lamps 7
The turn signals, high-beam headlamps and
the high-beam flasher are operated using the
combination switch ( Y page 109).
! Switch off the parking lamps and standing
lamps when you leave the vehicle. This
prevents the battery from discharging.
The exterior lighting (except the parking/
standing lamps) switches off automatically if
you:
R remove the SmartKey from the ignition lock
R open the driver's door with the SmartKey
in position 0
If you hear a warning tone when you leave the
vehicle, the lights may still be switched on.
XTurn the light switch to c or à .Low-beam headlampsXTo switch on the low-beam headlamps:
turn the SmartKey in the ignition lock to
position 2 or start the engine.XTurn the light switch to L.
The L indicator lamp in the instrument
cluster lights up.
Daytime running lamps
Daytime running lamps in Canada
The daytime running lamps function is
required by law in Canada. It cannot therefore
be deactivated.
XTurn the light switch to c or à .
With the engine running: depending on the
ambient light, the daytime running lamps or
the low-beam headlamps are switched on.
When the low-beam headlamps are
switched on, the L indicator lamp in the
instrument cluster lights up.
When the engine is running and the vehicle is
stationary: if you move the selector lever from
a drive position to P (vehicles with automatic
transmission) or if the parking brake is
applied, the low-beam headlamps go out after
three minutes.
When the engine is running, the vehicle is
stationary and in high ambient light
brightness: if you turn the light switch
to T , the daytime running lamps and the
parking lamps are switched on.
If the engine is running and you turn the light
switch to L, the manual settings take
precedence over the daytime running lamps.
Daytime running lamps in the USA
This function is only available on vehicles with
daytime running lamps.
In the USA, the daytime running lamps are
deactivated upon delivery from the factory.
XTo activate the daytime running lamps
(vehicles with a luxury multifunction 7 Only vehicles with front fog lamps have the fog lamps function.Exterior lighting107Lights and windshield wipers

steering wheel): you can activate the
daytime running lamps function using the
on-board computer ( Y page 207).XTurn the light switch to c or à .
With the engine running: depending on the
ambient light, the daytime running lamps or
the low-beam headlamps are switched on.
When the low-beam headlamps are
switched on, the L indicator lamp in the
instrument cluster lights up.
It is only possible to activate the high-beam
headlamps if the brightness of the ambient
light is at a low level.
However, the high-beam flasher can always
be used.
If the engine is running and you turn the light
switch to T or L , the manual settings
take precedence over the daytime running
lamps.
Automatic headlamp mode
XTo switch on automatic headlamp
mode: turn the light switch to c or
à .
SmartKey in position 1 in the ignition lock:
the parking lamps are switched on or off
automatically depending on the brightness
of the ambient light.
With the engine running: depending on the
brightness of the ambient light, the daytime
running lamps 8
or the low-beam headlamps
are switched on or off automatically.
When the low-beam headlamps are
switched on, the L indicator lamp in the
instrument cluster lights up.GWARNING
If the light switch is set to c or à , the
low-beam headlamps will not come on
automatically if it is foggy. This could
endanger you and others. Therefore, turn the
light switch to L in fog.
The automatic headlamp feature is only an
aid. The driver is responsible for the vehicle's
lighting at all times.
Front fog lamps
Only vehicles with front fog lamps have the
fog lamps function.
GWARNING
If you suspect that driving conditions will be
foggy, turn the light switch to L before you
start your journey. Otherwise, your vehicle
may not be visible and you could endanger
yourself and others.
XTo switch on the front fog lamps: turn
the SmartKey in the ignition lock to position
2 or start the engine.XTurn the light switch to L or c or
à .XPress the N button.
The green N indicator lamp in the
instrument cluster lights up.XTo switch off the front fog lamps: press
the N button.
The green N indicator lamp in the
instrument cluster goes out.
Rear fog lamp
XTo switch on the rear fog lamp: turn the
SmartKey in the ignition lock to position 2
or start the engine.XTurn the light switch to L or c or
à .
If the light switch is set to c or à ,
the rear fog lamp only lights up if the low-
beam headlamps are on.8 Only if daytime running lamps have been activated via the on-board computer.108Exterior lightingLights and windshield wipers
