Page 27 of 474
26 At a glanceMultifunction steering wheel
Item
Page
1
Multifunction display
130
Operating control system
131
2
Selecting the submenu or
setting the volume:
Press buttonæup/to increaseçdown/to decrease
3
Telephone*:
Press buttonsto take a calltto end a call
Item
Page
4
Menu systems:
Press buttonèfor next menuÿfor previous menu
5
Moving within a menu:
Press buttonjfor next displaykfor previous displayiC 230 Sport and C 350 Sport:
Steering wheel in these vehicles will
vary from steering wheel shown.
However, multifunction steering wheel
symbols and feature description apply
to Sport models as well.
Page 132 of 474
131 Controls in detail
Control system
Multifunction steering wheel
The displays in the multifunction display
and the settings in the control system are
controlled by the buttons on the multifunc-
tion steering wheel.Pressing any of the buttons on the multi-
function steering wheel will alter what is
shown in the multifunction display.
The information available in the multifunc-
tion display is arranged in menus, each
containing a number of functions or sub-
menus.
The individual functions are then found
within the relevant menu (radio or CD op-
erations under
AUDIO
, for example). These
functions serve to call up relevant informa-
tion or to customize the settings for your
vehicle.
1
Multifunction displayOperating the control system
2
Selecting the submenu or setting
the volume:
Press buttonæup/to increaseçdown/to decrease
3
Telephone*:
Press buttonsto take a calltto end a call
4
Menu systems:
Press buttonèfor next menuÿfor previous menu
5
Moving within a menu:
Press buttonjfor next displaykfor previous display
iC 230 Sport and C 350 Sport:
Steering wheel in these vehicles will
vary from steering wheel shown.
However, multifunction steering wheel
symbols and feature description apply
to Sport models as well.
Page 168 of 474
167 Controls in detail
Automatic transmission*
Automatic shift program
The program mode selector switch is
located on the lower part of the center
console.
1Program mode selector switch
C Comfort For comfort driving
S Sport For standard driving
The current gear selector lever position
and the selected program mode (
C/S) are
indicated in the multifunction display
(
page 163).
Effect
ï
The transmission shifts through
sixth gear only (applies to
vehicles with 7-speed automatic
transmission only).
î
The transmission shifts through
fifth gear only (applies to
vehicles with 7-speed automatic
transmission only).
é
The transmission shifts through
fourth gear only.
è
The transmission shifts through
third gear only.
With this selection you can use
the braking effect of the engine.
Effect
ç
The transmission shifts through
second gear only.
Allows the use of engine’s
braking power when driving:
on steep downgrades
in mountainous regions
under extreme operating
conditions
æ
The transmission operates in
first gear only.
For maximum use of engine’s
braking effect on very steep or
lengthy downgrades.
Page 212 of 474
211 Controls in detail
Audio system
Search
Press S or T button to tune in
the next receivable weather band
station.Scan search
Starting scan search
Press
SC soft key.
SC will appear in the display. The
radio briefly tunes in all receivable
weather band stations.
Ending scan search
Press
SC soft key or S or T.
The weather band station last
played will be selected and
SC
disappears from the display.Introduction to satellite radio*
(USA only)
SIRIUS satellite radio provides 100 chan-
nels of digital-quality radio, among others
music, sports, news, and entertainment,
free of commercials. SIRIUS satellite radio
uses a fleet of high-power satellites to
broadcast 24 hours per day, coast to
coast, in the contiguous U.S.
This diverse, satellite-delivered program-
ming is available for a monthly subscrip-
tion fee.
For more information and service
availability call the SIRIUS Service
Center (
page 216), or contact
www.siriusradio.com.
iIf no weather band station is received
after three consecutive scans of the
complete frequency range, then the
scan stops at the channel with which it
began and
NO WB FOUND
appears in the
display.
If this happens, switch back to
standard radio mode.
Page 259 of 474
258 Controls in detailUseful featuresArmrest storage compartments
1Handle
2Button, passenger side
3Button, driver’s side
Opening storage compartment
Pull handle1 and lift armrest.
Closing storage compartment
Press armrest down until it engages
into place.Opening telephone compartment
Press button3 on driver’s side or
button2 on passenger side and lift
armrest.
Closing telephone compartment
Press armrest down until it engages
into place.
Armrest in the rear passenger
compartment
Pull the top of the armrest out and fold
it down.Parcel net in front passenger footwell
(all models, except C 280 4MATIC and
C 350 4MATIC)
A small convenience parcel net is located
in the front passenger footwell. It is for
small and light items, such as road maps,
mail, etc.
Warning!
G
The parcel net is intended for storing
light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
parcel net. In an accident, during hard brak-
ing, or sudden maneuvers, they could be
thrown around inside the vehicle and cause
injury to vehicle occupants.
The parcel net cannot protect transported
goods in the event of an accident.
Page 431 of 474
430 Technical dataEngineModel
C 230 (203.052)
1
C 230 Sport (203.052)
1
1The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment.
C 280 (203.054)
1
C 280 4MATIC (203.092)
1
Engine
272
272
Mode of operation
4-stroke engine, gasoline injection
4-stroke engine, gasoline injection
No. of cylinders
6
6
Bore
3.46 in (88.00 mm)
3.46 in (88.00 mm)
Stroke
2.69 in (68.40 mm)
3.23 in (82.10 mm)
Total piston displacement
152.3 cu in (2 496 cm
3)
182.8 cu in (2 996 cm
3)
Compression ratio
11.2:1
11.1:1
Output acc.
to SAE J 1349
201 hp/6 200 rpm
2
(150 kW/6 200 rpm)
2Premium fuel required. Performance may vary with fuel octane rating.
228 hp/6 000 rpm
2
(170 kW/6 000 rpm)
Maximum torque acc.
to SAE J 1349
181 lb-ft/2 700 – 5 000 rpm
(245 Nm/2 700 – 5 000 rpm)
221lb-ft/2700–5000rpm
(300 Nm/2 700 – 5 000 rpm)
Maximum engine speed
6500 rpm
6500 rpm
Firing order
1-4-3-6-2-5
1-4-3-6-2-5
Poly-V-belt
2404 mm
2404 mm
Page 432 of 474
431 Technical data
Engine
Model
C 350 (203.056)
1
C 350 Sport (203.056)
1
C 350 4MATIC (203.087)
1
Engine
272
Mode of operation
4-stroke engine, gasoline injection
No. of cylinders
6
Bore
3.65 in (92.90 mm)
Stroke
3.38 in (86.00 mm)
Total piston displacement
213.5 cu in (3 498 cm
3)
Compression ratio
10.5:1
Output acc.
to SAE J 1349
268 hp/6 000 rpm
2
(200 kW/6 000 rpm)
Maximum torque acc.
to SAE J 1349
258 lb-ft/3 000 rpm
(350 Nm/3 000 rpm)
Maximum engine speed
6700 rpm
Firing order
1-4-3-6-2-5
Poly-V-belt
2404 mm
1The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the
corresponding data of all special bodies and special equipment.2Premium fuel required. Performance may vary with fuel octane rating.
Page 434 of 474
433 Technical data
Rims and Tires
iThe following pages also list the ap-
proved wheel rim and tire sizes for
equipping your vehicles with winter
tires. Winter tires are not available as
standard or optional factory equip-
ment, but can be purchased from an
authorized Mercedes-Benz Center.
Depending on vehicle model and the
standard or optional factory-equipped
wheel rim/tire configuration on your
vehicle (Appearance Package, Sport
Package etc.), equipping your vehicle
with winter tires approved for your ve-
hicle model may also require the pur-
chase of two or four wheel rims of the
recommended size for use with these
winter tires. See an authorized
Mercedes-Benz Center for more infor-
mation.
Page 435 of 474
434 Technical dataRims and TiresSame size tiresModel
C230
1
C280
C2804MATIC
C350
C3504MATIC
1Canada only
C230 Sport
C350 Sport
Rims (light alloy)
7 J x 16 H2
7.5 J x 17 H2
Wheel offset
1.22 in (31 mm)
1.42 in (36 mm)
All-season tires
2
2Radial-ply tires
205/55 R16 91H M+S
-
Summer tires
2
-
-
Winter tires
2,3
3Not available as factory equipment.
205/55 R16 91H M+S .
225/45 R17 91H M+S .
or
225/45 R17 91H M+S .MOExtended
4
4Must be used in conjunction with Run Flat Indicator* only.
Page 436 of 474
435 Technical data
Rims and Tires
Mixed size tiresModel
C230Sport
C350Sport
Front axle:
Rims (light alloy)
7.5 J x 17 H2
Wheel offset
1.42 in (36 mm)
Summer tires
1
1Radial-ply tires
225/45 R17 91W
or
225/45 R17 91W MOExtended
2
2Must be used in conjunction with Run Flat Indicator* only.Rear axle:Rims
8.5 J x 17 H2
Wheel offset
1.18 in (30 mm)
Summer tires
1,3
3Must not be used with snow chains.
245/40 R17 91W
or
245/40 R17 91W MOExtended
2
