MERCEDES-BENZ C230 KOMPRESSOR COUPE 2004 CL203 Owner's Manual

181 Controls in detail
Audio system
Phone book
The numbers stored in the phone book can
be called up either by name or number.
Calling up the phone book
Pressd, c, f or e but-
ton.Switching between name search and
number search

Press the
ABC
key.
The name search is called up.
or

Press the
NUM
key.
The number search is called up.
Searching and calling up phone book en-
tries by name

Press the
ABC
key.
The current name is highlighted on the
display.

Press either thed orc button.
The stored entries are selected accord-
ing to the alphabetical order of the ini-
tial letter.
or

Press either thef ore button.
The stored entries are selected in
increments of four.
or

Press the desired numerical key2 to
9.
The stored entries are selected accord-
ing to the alphabetical order of the ini-
tial letters (e.g. for B -Brown, press
button2 twice).iSeveral characters and symbols cannot
be shown on the display for technical
reasons. They have been replaced with
spaces.

182 Controls in detailAudio systemSearching and selecting phone book en-
tries by number
Press the
NUM
key.
The current number is marked in the
display.

Press either thed or cbutton.
The stored entries are selected
according to numerical order.
or

Press either thef or ebutton.
The stored entries are selected in
increments of 5 (e.g. Entry
M5, Entry
M10
, etc.)Starting dialing process

Once you have selected a number,
press the
SND
key.
Repeat dialing
If the number dialed is busy, you can again
place calls to the last ten telephone num-
bers dialed using the repeat dialing func-
tion.Manual repeat dialing (redial)

Press the
SND
key.
The last number dialed is shown in the
display.

Select the desired telephone number
usingd, c, f or
ebutton.
The abbreviation
L and the number of
the entry are shown in the top line of
the display.

When you have selected a number,
press the
SND
key.
The call will be made.

183 Controls in detail
Audio system
Automatic repeat dialing (redial)
If a call cannot be connected, press
the
SND
key.
REDIAL
will appear on the display and re-
peated attempts to place the call will be
made for the next four minutes.
Selecting numbers directly from the
directory

Enter previously selected 3-digit
(1-999) number of the entry using
number keys4 to M.

Press the
RCL
key.
The telephone number stored under
that entry will be dialed.

Press the
SND
key.
The call will be made.Speed dialing

Input desired entry number using
number keys4 to M.
A maximum of two digits can be en-
tered.
If necessary, correct the last number
entered with the
CLR
key.

Press the
SND
key.
The telephone number stored under
that entry will be dialed. The number,
Land the full entry number will be
shown in the display.Quick-dialing

Press one of the desired number
buttons4 toM longer than
one second.
The telephone number saved under
that number will be dialed.!Please be aware that button4
might already be reserved for an emer-
gency call number.

184 Controls in detailAudio systemEmergency call
Press button4 longer than
one second.

A call will be placed to the saved num-
ber (e.g. 911).
You can make an emergency call to an
emergency rescue station with a mobile
communications network.
The emergency call will be placed as long
as the corresponding mobile communica-
tions network is available. To do this,
switch the telephone on if this has not al-
ready been done.The call will also be placed even if the un-
lock code is not entered.
Emergency calls may not be possible with
all telephone networks or if certain net-
work services and/or telephone functions
are active. Check with your local network
operation company. It may take some time
to set up an emergency call.
To use this function you must ensure that
the number stored in memory location 1 is
the number to be dialed in case of emer-
gency.
If an emergency call cannot be connected,
the message
SYSTM BUSY
appears.Accepting an incoming call
Accepting an incoming call in telephone
mode
With an incoming call, a ringing tone can
be heard and the caller’s telephone num-
ber, or the name under which this tele-
phone number has been saved in the
telephone book, appears on the display. If
the caller’s number is not transmitted,
CALL
will appear in the display.

Press the
SND
key to accept call.
!Please be aware that the 911 emergen-
cy call system is a public service. Using
it without due cause is a criminal of-
fense.

185 Controls in detail
Audio system
Accepting an incoming call in cassette,
CD or radio mode
If the telephone is activated in the back-
ground (receiving symbol
S visible on dis-
play), the audio souce is muted when a call
is received. The ringing tone is heard and
the caller’s telephone number or the name
under which this telephone number has
been saved in the telephone book appears
on the display. If the caller’s number is not
transmitted,
CALL
appears in the display.

Press the
SND
key to accept the call.Muting a call
It is possible to mute a call; the caller is
then no longer able to hear you.
Mute on

Press the
MUT
key.
Mute off

Press the
MUT
key.
Terminating a call

Press the
END
key.
The current call is terminated.Call waiting
If you receive another call during an al-
ready active call, you can accept the sec-
ond call and switch between the two.
Accepting a second call

Press the
SND
key.
You are connected with the second
caller, the first call is muted.
Switching between the calls

Press the
SND
key.
Terminating the second call

Press the
END
key.
The current call will be terminated. You
are connected with the muted call
again.

186 Controls in detailPower windows
Power windowsOpening and closing the windows
The side windows can be opened and
closed electrically. The switches for all the
side windows are on the driver’s door. The
switch for the passenger door is on the
passenger door.
1Left front window
2Right front window

Turn SmartKey in the starter switch to
position1 or2.
Warning!
G
When closing the windows, make sure there
is no danger of anyone being harmed by the
closing procedure.
The closing of the door windows can be im-
mediately halted by releasing the switch or,
if switch was pulled past the resistance
point and released, by either pressing or
pulling the respective switch.
If the window encounters an obstruction
t h a t b l o c k s i t s p a t h i n a c i r c u m s t a n c e w h e r e
you pulled the switch past the resistance
point and released it to close the window,
the automatic reversal function will stop the
window and open it slightly.
If the window encounters an obstruction
t h a t b l o c k s i t s p a t h i n a c i r c u m s t a n c e w h e r e
you are closing the window by pulling and
holding the switch, or by pressing and hold-
ing button‹ on the SmartKey, the auto-
matic reversal function will not operate
When leaving the vehicle, always remove the
SmartKey from starter switch, and lock your
vehicle. Do not leave children unattended in
the vehicle, or with access to an unlocked
vehicle. Unsupervised use of vehicle equip-
ment can cause an accident and/or serious
personal injury.iYou can also open or close the win-
dows using the:

SmartKey (summer opening/con-
venience feature) (
page 188).


buttonO in the control panel of
the climate control (
page 151).

187 Controls in detail
Power windows
Opening the windows
Press switch1 or2 to the resistance
point.
The corresponding window will move
downwards until you release the
switch.
Closing the windows

Pull switch1 or2 to the resistance
point.
The corresponding window will move
upwards until you release the switch.Fully opening the windows
(Express-open)

Press switch1 or2 past the resis-
tance point and release.
The corresponding window opens com-
pletely.
Fully closing the windows
(Express-close)

Pull switch1 or2 past the resis-
tance point and release.
The corresponding window closes com-
pletely.
Stopping windows

Press or pull respective switch again.
Warning
G
If you pull and hold the switch up when clos-
ing the window, and upward movement of
the window is blocked by some obstruction
including but not limited to arms, hands, fin-
gers, etc., the automatic reversal will not op-
erate.
!If the upward movement of the window
is blocked during the closing proce-
dure, the window will stop and open
slightly.
Remove the obstruction, pull the
switch again past the resistance point
and release.
If the window still does not close when
there is no obstruction, then pull and
hold the switch again. The side window
will then close without the obstruction
sensor function.Warning!
G
Driver's door only:
If within five seconds you again pull the
switch past the resistance point and re-
lease, the automatic reversal will not func-
tion.

188 Controls in detailPower windowsOpening and closing the windows with
the SmartKey
The panorama sliding/pop-up roof*
(p a g e 1 8 9 ) w i l l a l s o b e o p e ne d o r c l o s e d
when the power windows are operated
with the SmartKey.

Aim transmitter eye at the front door
handle.Opening (Summer opening feature)

Press and hold button Πafter un-
locking the vehicle.
The windows and panorama slid-
ing/pop-up roof* (
page 189) begin
to open after approximately
one second.

Release the Πbutton to stop proce-
dure.
Closing (Convenience feature)

Press and hold button ‹ after lock-
ing the vehicle.
The windows and panorama slid-
ing/pop-up roof* begin to close after
approximately one second.

Release the ‹ button to stop proce-
dure.
Make sure all side windows and the pan-
orama sliding/pop-up roof* are properly
closed before leaving the vehicle.
Synchronizing power windows
The power window must be resynchro-
nized each time

after the battery has been disconnect-
ed.


if the power windows cannot be fully
opened (Express-open) or closed (Ex-
press-close).
Synchronizing the power windows

Switch on ignition.

Pull the power window switches until
the side windows are closed.
Hold the switches for approximately
one second.
The power window are adjusted.
Warning!
G
Never operate the windows or panorama
sliding /pop-up roof* if there is the possibil-
ity of anyone being harmed by the opening
or closing procedure.
In the event that the procedure causes po-
tential danger, the procedure can be imme-
diately halted by releasing the button on the
SmartKey. To reverse direction of move-
ment, press Œ for opening or ‹ for
closing.

189 Controls in detail
Panorama sliding/pop-up roof*
Panorama sliding/pop-up roof*
Opening and closing the roller sun-
blinds for the panorama sliding/pop-up roof
The sliding/pop-up roof and the roller sun-
blinds can be opened and closed electri-
cally. The switch for the sliding/pop-up
roof and the roller sunblinds is on the over-
head control panel.
The roller sunblinds only operate with pan-
orama sliding/pop-up roof closed.1, 4 Open
2, 3 Close

Turn SmartKey in the starter switch to
position1 or2.
Opening and closing the roller sun-
blinds

To open or close the roller sunblinds,
move the switch to the resistance point
in the required direction1to4.
Release the switch when the roller sun-
blinds have reached the desired posi-
tion.
Warning!
G
When opening or closing the panorama
sliding / pop-up roof, make sure there is no
danger of anyone being harmed by the open-
ing or closing procedure.
If the panorama sliding / pop-up roof is
closed with the convenience closing feature
and becomes blocked, it will not open auto-
matically. Should this occur, press the
Œbutton on the SmartKey and hold it
down; the panorama sliding / pop-up roof
opens again.
The panorama roof is made out of glass. In
the event of an accident, the glass may shat-
ter. This may result in an opening in the roof.
In a vehicle rollover, occupants not wearing
their seat belts or not wearing them properly
may be thrown out of the opening. Such an
opening also presents a potential for injury
for occupants wearing their seat belts prop-
erly as entire body parts or portions of them
may protrude from the passenger compart-
ment.

190 Controls in detailPanorama sliding/pop-up roof*Fully opening the roller sunblinds
(Express-open)
Move the panorama sliding/pop-up
roof switch or the rear roller sunblind
switch past the resistance point in
direction4 and release.
The roller sunblinds opens completely.
Stopping the roller sunblinds

Move the switch in any direction.Opening and closing the panorama
sliding/pop-up roof
The panorama sliding/pop-up roof only op-
erates with the roller sunblinds opened.
1Push up to raise roof at rear
2Pull down to lower roof at rear
3Push forward to slide roof closed
4Push back to slide roof open
Warning!
G
When closing the roller sunblinds, make
sure that no one is in danger of being injured
by the closing procedure. The closing of the
roller sunblinds can be immediately halted
by releasing the switch.
Warning!
G
When opening or closing the panorama
sliding / pop-up roof, make sure there is no
danger of anyone being harmed by the open-
ing or closing procedure.
The opening procedure of the panorama
sliding/pop-up roof can be immediately
halted by releasing the switch or, if the
switch was moved past the resistance point
and released, by moving the switch in any di-
rection.
The closing procedure of the panorama
sliding/pop-up roof can be immediately
halted by releasing the switch.
When leaving the vehicle, always remove the
SmartKey from starter switch and lock your
vehicle. Do not leave children unattended in
the vehicle, or with access to an unlocked
vehicle. Unsupervised use of vehicle equip-
ment may cause an accident and/or serious
personal injury.
