324 Operation
At the gas station
Check regularly and before a long trip
1Coolant level
2Brake fluid
3Windshield washer and headlamp
cleaning system*Windshield washer system and head-
lamp cleaning system*
For more information on refilling the wash-
er reservoir, see “Windshield washer sys-
tem and headlamp cleaning system*”
(
page 330).
Coolant
For more information on coolant, see
“Coolant level” (
page 329) and see “Fu-
els, coolants, lubricants, etc.”
(
page 476).
Brake fluid
For information on brake fluid, see “Brake
fluid” (
page 480).Engine oil level
For more information on engine oil, see
“Engine oil” (
page 327).
Vehicle lighting
Check function and cleanliness. For more
information on replacing light bulbs, see
“Replacing bulbs” (
page 430).
For more information, see “Lighting”
(
page 108).
Tire inflation pressure
For information on tire inflation pressure,
see “Checking tire inflation pressure”
(
page 341).iOpening the hood (page 325).!If you find that the brake fluid in the brake
fluid reservoir has fallen to the minimum mark or
below, have the brake system checked for brake
pad thickness and leaks immediately. Notify an
authorized Mercedes-Benz Center immediately.
Do not add brake fluid as this will not solve the
problem. For more information, see “Practical
hints” (
page 376) and (page 400).

452 Practical hints
Jump starting
The battery is located in the engine com-
partment on the right hand side. For jump
starting, use the under hood terminals in
front of the battery.
Make sure the two vehicles do not
touch.
Turn off all electrical consumers,
except hazard warning flashers or work
lights.
Apply the parking brake (page 134).
Make sure gear selector lever* is set to
positionP (manual transmission to
Neutral).
Open the hood (page 326).
Slide red cover2 from positive under
hood terminal3 in direction of arrow. 1Positive terminal of charged battery
2Positive under hood terminal cover
3Positive under hood terminal in front of
discharged battery
4Negative under hood terminal
5Negative terminal of charged battery
Connect positive terminal1 of the
charged battery with positive under
hood terminal3 in front of the dis-
charged battery with the jumper cable.
Clamp cable to charged battery1
first.
Start the engine of the vehicle with the
charged battery and run at idle speed.
Connect negative terminal5 of the
charged battery to jumper cables and
attach other end to negative under
hood terminal4 on the vehicle. Clamp
cable to charged battery5 first
Start the engine of the disabled
vehicle.
You can now turn on the electrical con-
sumers. Do not switch on the headlamps
under any circumstances.
Remove the jumper cables first from
the negative terminals4 and5 and
then from the positive terminals3
and1.
You can now switch on the headlamps.
Slide red cover2 from positive under
hood terminal3 back.
Close the hood (page 326).
Have the battery checked at the near-
est authorized Mercedes-Benz Center.
!Never invert the terminal connections.

488 Index
Phone cook 233
Radio operation 194
Satellite radio* operation 200
Sound settings 189
Surround sound* (Canada only) 190
SYS menu 192
SYS menu, Bluetooth
® settings 192
SYS menu, display settings 192
SYS menu, language settings 193
SYS menu, reset to factory
settings 193
Telephone menu* 222
Volume 189
Auto-dimming*, Rear view mirrors 100
Automatic central locking 80
Activating/deactivating
(Control system) 173
Automatic climate control (3-zone) see Cli-
mate control system
Automatic headlamp mode 109, 172
Automatic lighting control, Interior
lighting 115
Automatic shift program 144Automatic transmission
Accelerator position 142
Emergency operation (limp-home
mode) 146
Fluid 476, 477
Fluid level 328
Gear ranges 143
Gear shifting malfunctions 146
Hill start assist system 246
Kickdown 142
Shifting procedure 139
Starting the engine 127
Transmission fluid 328
Automatic transmission*
Automatic shift program 144
Gear selector lever 138
Gear selector lever control one-touch
gearshifting 145
Gear selector lever positions 140
Program mode selector switch 144
Aux socket 220B
Backrest 281
Backup lamps
Replacing bulbs 430, 431
Bar 356
BAS 60
Batteries, SmartKey
Checking battery condition 78
Replacing 428
Batteries, SmartKey with KEYLESS-GO*
(Canada only)
Checking battery condition 78
Replacing 428
Battery 448
Battery, vehicle 446
Charging 449
Discharged, Jump starting 451
Disconnecting 448
Message in display 399
Reconnecting 450
Removing 449
Bead 356
Beverage holder see Cup holder

490 Index
Dual-zone automatic climate
control 250
Front defroster 255
Rear climate control 268
Rear window defroster 256, 265
Residual engine heat and
ventilation 266
Setting the temperature 262
Temperature 253
Windshield, defogging 255
Clock 151
Setting time 170
Cockpit 24
Cold weather performance 483
COMAND* see separate COMAND
operating instructions
Combination switch 112
Corner-illuminating front fog
lamps* 112
High beam flasher 112
Turn signals 131
Windshield wipers 117
Control system 151
Multifunction display 151
Multifunction steering wheel 152
Resetting to factory default 165Control system menu 151
AUDIO 158
Menus overview 154
Navi* 158
Service menu 164
Settings menu 165
Standard display 156
TEL* 160
Trip computer 156
Vehicle status message
memory 164
Control system submenus 153, 155
Convenience 174
Instrument cluster 168
Lighting 171
Time/Date 170
Vehicle 173
Coolant 329
Adding 329
Anticorrosion/antifreeze mixing ratio
and quantity 484
Checking level 329
Messages in display 405
Temperature 321
Temperature gauge 27, 148Coolant level
Checking 329
Corner-illuminating front fog lamps* 112
Replacing bulbs 431
Cruise control 241
Activating 242
Canceling 243
Driving downhill 243
Driving uphill 243
Setting current speed 242
Setting to last stored speed
(“Resume” function) 245
Cruising range, fuel 483
Cup holder
In front seat armrest 287
In rear seat armrest 287
Curb weight 356

497 Index
L
Labels 462
Certification 462
Emission control information 463
Tire and Loading Information 335
Lamps, exterior 431
Light sensor 409
Lamps, indicator and warning
ABS 27, 59, 374
Air bag Off 40
Battery check lamp (SmartKey with
KEYLESS-GO* 77
Battery check lamp (SmartKey) 72
Brake warning lamp 27
Brakes 376
Engine diagnostics 27, 378
Engine malfunction 27, 378
ESP
®27, 376, 379, 380
Front passenger front air bag off 29,
45, 385, 386
Fuel reserve 380
High beam headlamps 27
Instrument cluster 374–383
Maintenance service indicator 362
Seat belt telltale 27, 380
SRS 27, 382Turn signals 27
Language 193
Language, Setting 168
LATCH-type child seat anchors see
Children in the vehicle
Lever
For cruise control 242
License plate lamps
Messages in display 411
Replacing bulbs 431, 437
Light alloy wheels, Cleaning 370
Light sensor
Message in display 409
Lighter see Cigarette lighter
Lighting 108
Automatic headlamp mode 109
Corner-illuminating front fog
lamps* 112
Daytime running lamp mode 110
Door entry lamps 116
High beam flasher 112
Instrument cluster illumination 148
Interior 114
Manual headlamp mode 108
Trunk 116
Limp-home mode 146Loading see Vehicle loading
Locator lighting 172
Lock button
Door handle (KEYLESS-GO*, Canada
only) 76, 125
Key, SmartKey 70
Key, SmartKey with KEYLESS-GO*
(Canada only) 73
Locking 133
Vehicle in an emergency 425
Locking knob 79
Loss of
Key, Mechanical 79
Key, SmartKey 79
Key, SmartKey with KEYLESS-GO*
(Canada only) 79
Service and Warranty Information
Booklet 461
Low beam headlamps
Replacing bulbs (Bi-Xenon*) 431
Replacing bulbs (Halogen) 431, 433
Lowering
Vehicle 445
Lubricants 476
Lumbar support* 91
