210 Controls in detailAudio systemAutostore – automatic station memory
The Autostore memory function provides
an additional memory level. The station
memory for manually stored stations is not
overwritten.

Calling up Autostore memory level and
storing stations
Press
AS soft key briefly.
The radio switches to the Autostore
memory level.
AS and
SEARCH

appear in the display and the radio
finds the ten stations with the
strongest signals. These stations
are stored on the station
buttons1 to R in order of
signal strength.


Calling up stations
Press desired station button1
to R.


Leaving the Autostore memory level
Press
FM or
AM
soft key briefly.
Interrupting radio mode
The radio mode is interrupted by an
incoming call on the telephone*
(
page 229).


Mute on
Press U button.
The radio mode is interrupted and MUTED
appears in the display.


Mute off
Press U button.
The radio mode is again active.Weather band

Press
WB soft key.
The weather band station last received
is tuned in.
Selecting a weather band station
directly

Select desired weather band station
with buttons 1 to 7.
If a station cannot be tuned in, a search
is automatically started.

211 Controls in detail
Audio system
Search
Press S or T button to tune in
the next receivable weather band
station.Scan search


Starting scan search
Press
SC soft key.
SC will appear in the display. The
radio briefly tunes in all receivable
weather band stations.


Ending scan search
Press
SC soft key or S or T.
The weather band station last
played will be selected and
SC
disappears from the display.Introduction to satellite radio*
(USA only)
SIRIUS satellite radio provides 100 chan-
nels of digital-quality radio, among others
music, sports, news, and entertainment,
free of commercials. SIRIUS satellite radio
uses a fleet of high-power satellites to
broadcast 24 hours per day, coast to
coast, in the contiguous U.S.
This diverse, satellite-delivered program-
ming is available for a monthly subscrip-
tion fee.
For more information and service
availability call the SIRIUS Service
Center (
page 216), or contact
www.siriusradio.com.
iIf no weather band station is received
after three consecutive scans of the
complete frequency range, then the
scan stops at the channel with which it
began and
NO WB FOUND
appears in the
display.
If this happens, switch back to
standard radio mode.

212 Controls in detailAudio system
Program categories
The channels are categorized. Categories
allow you to tune to stations broadcasting
a certain type of program (category mode)
(page 214).Calling up the SAT main menu

Press
SAT
soft key.
SAT
is displayed in the upper left-hand
corner of the display.
Prior to activation of the satellite radio
service (
page 212).
After activation of satellite radio
service (page 213).
Prior to activation of the satellite radio
service
The telephone number of the SIRIUS
Service Center (888-539-7474) is
displayed.
iAdditional satellite radio equipment
and a subscription to a satellite radio
service provider are required for the
satellite radio operation described
here.
Contact an authorized Mercedes-Benz
Center for details and availability for
your vehicle.
Note that categories and channels
shown in illustrations are dependent on
programming content delivered by the
service provider. Programming content
is subject to change. Therefore,
channels and categories shown in
illustrations and descriptions
contained in this manual may differ
from the channels and categories
delivered by the service provider.
iSatellite radio service may be unavail-
able or interrupted from time to time
for a variety of reasons, such as envi-
ronmental or topographic conditions
and other things beyond the service
provider’s or our control. Service might
also not be available in certain places
(e.g., in tunnels, parking garages, or
within or next to buildings) or near
other technologies.

213 Controls in detail
Audio system

Press
ESN
soft key.
The twelve-digit electronic serial
number (ESN) of the SAT tuner*
installed in your vehicle is displayed.
This information is required to call the
SIRIUS Service Center for an activation
request.
After activation of the satellite radio
service
The satellite radio main menu appears.
The radio station selected last is audible,
provided it can be received.The first channel 001 is called up and the
PTY system changes to All categories.
If no station can be received,
ACQUIRING

appears in the display.
If the Satellite radio service is not
activated,
ACQUIRING
will also appear in the
radio display and
NO SAT
will appear in the
multifunction display.Selecting a station
The following options are available:


Selecting a station using the selected
category (
page 214).


Tuning via station presets
(page 213).


Tuning via scan search (
page 215).


Tuning via manual channel input
(page 214).


Tuning via the program category list
(page 214).
Tuning via station presets
Ten satellite radio station presets are
available.
You can access the presets via number
keys.
iCredit card information may also be
required for your application.
The activation process takes approxi-
mately 5 to 10 minutes after calling the
SIRIUS Service Center.
iThe system will tune to a default
station if no station had been selected
previously.

214 Controls in detailAudio systemAccessing via number keys
Enter number of preset you wish to
select, e.g. 1.
The radio plays the station stored
under this number and the PTY function
changes to the category corresponding
to the station.
Tuning via manual channel input
Example: tuning in channel 16

Press * button.
Input line appears in the main radio
menu.

Use number keys to enter desired
channel within 8 seconds, e.g.1
6.
The system tunes to channel 16.
The station you have selected begins to
play.
Tuning via the program category list
The category list contains all currently
receivable categories of programs. It is
arranged alphabetically.


Selecting a category
Press
PTY
soft key.
The current PTY category of the
station is displayed.

Press
<<<
or
>>>
soft key.
This switches between the
individual categories.
When changing the category, the
channel selected last in the new
category becomes audible.
iYou can only enter available channel
numbers.

215 Controls in detail
Audio system
The system will automatically switch to
a station of the selected category if the
currently selected station is not of the
selected category. Otherwise, the
currently selected station remains
tuned.


Tuning a station within the selected
category
The channels identified for the
currently selected category are
arranged numerically. Only one entry is
visible at a time.
Press S or T button briefly.
The next station within the category
is started.
or

Press and hold S or T
button for approx. 3 seconds until
desired station has been reached.Tuning via scan search
Scan search is characterized as follows:


Scan search plays a channel for
approx. 8 seconds and then skips to
the next channel within the current cat-
egory.


Scan search can be terminated
manually.

Press
SC soft key.
The search starts. SC appears in the
display.

Press
SC soft key again.
The search stops.Obtaining additional text information
Additional text information (artist, title)
related to the current channel can be
displayed.

Press
INF
soft key.
The title being played is displayed.

Press
INF
soft key again.
The name of the artist performing the
title being played is displayed.
iIf a button is not pressed within
4 seconds, the radio will return to the
standard display.

216 Controls in detailAudio systemStoring stations
Tune in desired station.

Press and hold desired station
button1 to R until a brief signal
tone is heard.
The frequency is stored on the selected
station button.
The radio saves the current station at
the memory preset selected. The
memory preset selected appears in the
status line, e.g. S3.Calling up the ESN information menu

Press
INF
soft key.

Press
ESN
soft key.
The twelve-digit electronic serial
number (ESN) of the SAT tuner*
installed in your vehicle is displayed.

Press
RET
soft key to exit the menu.
CD mode
Safety precautions
iThere are ten presets available.
An existing entry is overwritten in the
memory list when a new entry is given.
Warning!
G
The single CD player and the CD changer*
are Class 1 laser products. There is a danger
of invisible laser radiation if the housing is
opened or damaged.
Do not open the housing. The single CD
player and the CD changer* do not contain
any parts that can be serviced by the user.
For safety reasons, have any service work
which may be necessary performed only by
qualified personnel.

217 Controls in detail
Audio system
General notes
The system may not be able to play audio
CDs with copy protection.
Playing copied CDs may cause
malfunctions during playback.Do not use CDs with an 8 cm diameter, not
even with a CD adapter. Attempting to play
CDs with an 8 cm diameter or playing such
CDs with an adapter may cause damage to
the CD drive. Such damage is not covered
by the Mercedes-Benz Limited Warranty.
Should excessively high or low tempera-
tures occur while in CD changer mode*,
CD TEMP
will appear in the display, and the
CD will be muted until the temperature has
reached an acceptable level for the system
to continue operation.
The single CD player and the CD changer*
play audio CDs.
Warning!
G
In order to avoid distraction which could
lead to an accident, the driver should insert
CDs with the vehicle at a standstill and
operate the audio system only if permitted
by road, weather and traffic conditions.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your car covers a
distance of 44 feet (approximately 14 m)
every second.
!If you affix stickers to the CDs, they can
become warped due to the heat that
develops in the CD drive or
CD changer*.
In certain situations, the CDs can then
no longer be ejected and cause
damage to the drive. Such damage is
not covered by the Mercedes-Benz
Limited Warranty.!Your CD drive or CD changer* has been
designed to play CDs which
correspond to the EN 60908 standard.
You can therefore only use CDs with a
maximum thickness of 1.3 mm.
If you insert thicker data carriers, e.g.
ones that have data on both sides (one
side with DVD data, the other side with
audio data), they cannot be ejected and
will damage the drive.

218 Controls in detailAudio systemTips on handling CDs

Handle CDs carefully to prevent
interference during playback.


Avoid scratches, fingerprints and dust
on the CDs.


Do not write on CDs or apply any labels
or other material to them.


Clean CDs from time to time with a
commercially available cleaning cloth.
Never wipe the CD in a circular motion;
instead, wipe it in a straight line start-
ing in the center and moving outward.
Do not use solvents, anti-static sprays,
etc. for cleaning.


Replace the CD in its case after use.


Protect CDs from heat and direct
sunlight.MP3
The CD changer* can play audio CDs as
well as CDs with MP3 files.
Information on MP3 data carriersCompatible MP3 data carriers
The CD changer can read the following
data carriers in MP3 mode:


CD-DA


CD-R


CD-RW
Compatible file systems and compres-
sion methods
Use Romeo or Joliet. Depending on file for-
mat used, up to 128 characters are possi-
ble.
The following compression methods are
compatible:


MP3


WMA


WAV
iCD media, CD burning software and
CD writers are available in great vari-
ety. Due to this variety, it cannot be
guaranteed that the CD changer will be
able to play every user-written CD.
The burning process can lead to data
errors and aging of the medium may re-
sult in data loss. Therefore, the
CD changer may be restricted in its
ability to play MP3 data carriers; it may
play them with reduced sound quality,
or it m ay not b e a bl e to pl ay them a t al l.
Problems may be encountered during
playback of user-written CDs with a
storage capacity of more than 700 MB.
These CDs do not meet valid standards
as of this printing.

219 Controls in detail
Audio system
Compatible bit and sampling rates
Fixed and variable bit rates of up to
320 kBit/s are possible.
The following table lists possible sampling
rates:Information on copyright
The music tracks that you create for use in
MP3 mode or that you play in MP3 mode
are subject to copyright laws under appli-
cable international and national regula-
tions.
In many countries, the reproduction of
copyrighted materials is not permitted,
even if only for personal use, without the
express prior consent of the copyright
holder.
Please check the current copyright laws
for your country and comply with them.
These restrictions do not apply, for exam-
ple, to your own compositions and record-
ings, or for recordings for which
authorization has been obtained from the
copyright holder.MP3 playback
You can play an MP3 CD on the
CD changer* as you would any standard
audio CD. All of the functions described for
the CD changer also apply for the playback
of MP3 CDs. Keep in mind that the single
CD player in the audio system unit is not
able to read MP3 CDs.
The first 99 tracks on the CD, including
tracks in subdirectories, are recognized
and played. Any additional tracks will not
be played.MPEG1
Audio Layer3
44.1 KHz, 48 KHz,
32 KHZ
MPEG2
Audio Layer3
22.5 KHz, 24 KHz,
16 KHz
MPEG2.5
Audio Layer3
11.025 KHz,
12 KHz, 8 KHz
WMA
32 KHz, 44.1 KHz,
48 KHz
iOnly use MP3 tracks with a bit rate of
128 kBit/s or higher and with the spec-
ified sampling rates.
The use of rates other than those spec-
ified may lead to noticeably inferior
sound quality.
iDue to the branched data structure,
playback of the first track may be de-
layed slightly.
