audio MERCEDES-BENZ CL-Class 2004 C215 Comand Manual

69 Audio
DVD operation
Stopping DVD playback
Display the soft keys (
page 67).

Press the
Stop
soft key.
DVD playback stops.
Restarting DVD playback

After playback has stopped, press the Play
soft key again.
The DVD is played from the start.
or

Select a movie (
page 74).Displaying full screen

During DVD playback with the soft keys
displayed press the
Full
screen
soft
key.
The soft keys disappear. The full screen
will appear.Activating DVD menu

Display the soft keys (
page 67).

Press the
Menu
soft key.
The highest level of the DVD menu is
displayed, if available (
page 70).
Activating Settings menu

Display the soft keys (
page 67).

Press the
Setting
soft key.
The DVD settings menu will appear
(
page 71).
iWhile DVD playback is stopped, you
can press the
Menu
soft key.
The DVD menu saved on the DVD is dis-
played, if available (page 70).

70 AudioDVD operationThe DVD menu is the menu saved on the
DVD. The structure of the menu may vary
depending on the DVD and allows certain
settings or actions.
For example, multilingual DVDs allow the
DVD language to be selected in the menu.
Activating DVD menu
Display the soft keys (
page 67).

Press the
Menu
soft key.
The highest level of the DVD menu is
displayed.

Remove the soft key display if necessa-
ry (
page 67).
The soft keys are automatically remo-
ved after a while.
Selecting an item from the DVD menu

Use h, H, g or G to select a
menu item.

Press E.
Your selection is confirmed. The
COMAND will perform the action defi-
ned by the menu item selected.Going up one level in the menu
A DVD menu may contain several subme-
nus. Submenus may include a menu item
to go up one level in the menu.

Select the appropriate menu item
(page 70).
DVD menuiWhen you display the soft keys again,
parts of the DVD menu may be hidden.

71 Audio
DVD operation
You can also proceed as follows:
Display the soft keys (
page 67).

Press the
Menu
soft key once or several
times.
With each depression of the soft key
you will move up one or several menu
levels (depending on the DVD) until the
topmost level is reached.
Removing DVD menu
A DVD menu or a submenu may include an
item for closing the DVD menu.

Select the appropriate menu item
(page 70).
You can also proceed as follows:

Display the soft keys (
page 67).

Press the
Back
soft key.
or

Press the
Stop
soft key.
DVD playback is stopped and the DVD
menu is opened.
Settings menu
Setting options:
4:3
, 16:9
or
Zoom
soft key:
You can change the aspect ratio
(
page 72).

Lang.
soft key:
You can change the DVD language
(
page 72).

Subtitle
soft key:
You can display and switch between
the subtitles (
page 73).

Angle
soft key:
You can change the camera view
(
page 74).
Activating the Settings menu

Display the soft keys (
page 67).

Press the
Setting
soft key.
The Settings menu will appear.
Settings menu

72 AudioDVD operationChanging the aspect ratio
The system will automatically select the
appropriate aspect ratio when a DVD is
played back.
You can manually change the aspect ratio
during playback of the DVD. To do this, use
the top left soft key. The soft key changes
each time you press it.
Possible aspect ratios are: 4:3, 16:9 and
Zoom.
The soft key indicates the aspect ratio to
which you will change when you press the
soft key.
Zoom is useful to watch movies in
cinematic aspect ratio. You can use the
function to reduce the width of the black
bars at the top and bottom.

In the Settings menu (
page 71),
press the soft key repeatedly until the
desired aspect ratio is set.
Changing the DVD language
Changing the DVD language:

During playback of the DVD, activate
the DVD settings menu (
page 71)

Press the
Lang.
soft key.
The language list is displayed. The con-
tent of the list depends on which langu-
ages the DVD supports.

Use g or G to select a language.

Press E.
The selected language is set.
iYou can only change the DVD language
if the DVD supports several languages.
iThe
Lang.
soft key has no function if
the Settings menu is activated from
within the DVD menu.
In this case, you need to change the
language in the DVD menu (
page 70)
if the menu item is available. Or remove
the DVD menu (
page 71) and again
press the
Lang.
soft key in the
Settings menu.
Some DVDs allow the language to be
selected additionally or exclusively in
the DVD menu saved on the DVD
(
page 70).

73 Audio
DVD operation
Displaying and switching between sub-
titles
During playback of the DVD, activate
the DVD settings menu (
page 71).

Press the
Subtitles
soft key.
The subtitles list will appear. The
content of the list depends on the DVD.

Use g or G to select a subtitle.

Press E.
The selected subtitles are used.
or

Use g to select list entry No subtitles
.

Press E.
Subtitling is switched off.
iThe system cannot read languages in
DTS format. If you select such a langu-
age, the movie is played without sound.iThese functions are available only if the
DVD supports subtitles.iWhen you insert a DVD, subtitles are by
default switched off.
iThe
Subtitles
soft key has no
function if the Settings menu is opened
from within the DVD menu. In this case,
you need to change the subtitles in the
DVD menu (
page 70) if the menu
item is available.
Or remove the DVD menu (
page 71)
and again press the
Subtitles
soft
key in the Settings menu.
Some DVDs allow the subtitling func-
tion to be selected additionally or ex-
clusively in the DVD menu saved on the
DVD (
page 70).

74 AudioDVD operationChanging the camera view
During playback of the DVD, activate
the DVD settings menu (
page 71)

Press the
Angle
soft key.
A list of the available camera views will
appear.

Use g or G to select the desired
camera view.

Press E.
The selected camera view is used.

Display the soft keys (
page 67).

Press the
Brightn.
, Contr.
or
Color
soft key.

Press h or H.
The respective setting is changed.
If several movies are on the DVD, you can
select a movie directly.
Movies can be selected while the DVD is
played back or stopped.
E.g.: Select movie no. 3

Press 3.
The 3rd movie starts after a short
while.
iYou can only change the camera view if
several camera views are stored on the
DVD. The number of available
camera views depends on the DVD.
iThe
Angle
soft key cannot be selected
if the Settings menu is activated from
within the DVD menu (
page 70).
In this case, select the camera view in
the DVD menu.
Some DVDs supporting different
camera views don’t offer a switch
option. In this case, select the camera
view in the Settings menu.
Adjusting brightness, contrast and
color
Selecting a movieiMovie selection may also be possible in
the DVD menu saved on the DVD
(page 70).

75 Audio
DVD operation
If the movie is divided into chapters or sce-
nes, you can directly jump to a chapter or
scene or skip them while the movie is
playing. Some DVDs will not allow this in
certain portions of the movie (e.g. during
screen credits, age restriction and/or pa-
rental advisories).
Selecting a scene or chapter directly
E.g.: Scene/chapter 5
While the movie is playing, press *.

Press 5.
After a short while playback starts from
the 5th chapter or the 5th scene.Scene/chapter skip

Press D or d.
Button D = Next chapter or scene
Button d = Previous chapter or
scene or beginning of scene if scene
has been playing for more than 10
seconds

Keep D or d pressed during DVD
playback.
D = fast forward
d = reverse
Release the button to stop fast
forward/reverse.
Selecting a scene/chapter
iChapter/scene selection may also be
possible in the DVD menu stored on
the DVD (
page 70).
Fast forward/reverse

76 AudioDVD operation

80 Satellite radio*Satellite radio operationSee “Subscribing to satellite radio” for im-
portant subscription information
(page 79).

Press B to switch to satellite radio
operation.
The above message will appear at start
up or when the signal is not available.
The message
No Satellite Radio

will appear in a window.After the COMAND acquires the
signal, the Satellite radio main menu will
appear. The station last tuned to will begin
to play.
Satellite radio main menu1Program category
2Station name
3Memory preset selected and channel
numberMuting

Press J while listening to the satel-
lite radio.
The symbol R will appear in the symbol
bar.

Press J again to resume listening to
the current station.
The symbol R will have disappeared.
Switching on
iYou can display 2 in full:
Station information (
page 84)
iMuting will also be canceled if you
switch to an audio source, e.g. normal
radio, or if you alter the volume.

Satellite radio operation

97 Telephone*
Telephone operation
You can use the following functions in the
telephone menu:
Entering a telephone number
(page 98)

Use the redial function (
page 99)

Displaying the dialed numbers list
(page 100)

Displaying the answered calls list
(page 101)

Use speed-dialing (
page 102)

Use quick-dialing (
page 102)

Displaying the phone book
(page 104)

Adjusting balance/fader settings
(page 25)The system detects an incoming call, the
phone rings.
Incoming calls are indicated in a window in
any system (e.g. radio).
The window shows:

the caller’s number if it is transmitted
or

the caller’s name if her or his name and
number are saved in the phone book.Accepting a call

Press k.
or

Press E.
The display will change to the
call menu (
page 102). An active
audio source will be muted. You talk
over the hands-free set.
Rejecting a call

Press K.
or

Press H to highlight
Reject
and
than press E.
Incoming call
