80 Control systems
COMAND operating safety
Warning!G
Any alteration of electronic components or
software can cause malfunctions.
Radio, satellite radio (USA only), amplifier,
CD changer, navigation module, telephone
and voice control systems* are intercon-
nected. Therefore, if one of the components
is not operational, or has not been re-
moved/ replaced properly, the function of
other components could be impaired.
Such conditions might seriously impair the
operating safety of your vehicle.
We recommend to have any service work on
electronic components carried out by an au-
thorized Mercedes-Benz Center.
Warning!G
In order to avoid distraction which could
lead to an accident, the driver should enter
system settings while the vehicle is at a
standstill, and operate the system only
when permitted by road, weather and traffic
conditions.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/ h), your car covers a
distance of 44 feet (approximately 14 m) ev-
ery second.
COMAND supplies you with information to
help you select your route more easily and
guide you conveniently and safely to your-
destination. For safety reasons, we encour-
age the driver to stop the vehicle in a safe
place before answering or placing a call, or
consulting the COMAND screen to read nav-
igational maps, instructions, or downloaded
information.
Warning!G
While the navigation system provides direc-
tional assistance, the driver must remain fo-
cused on safe driving behavior, especially
attention to traffic and street signs, and
should utilize the system’s audio cues while
driving.
The navigation system does not supply any
information on stop signs, yield signs, traffic
regulations or traffic safety rules. Their ob-
servance always remains in the driver’s per-
sonal responsibility. DVD maps do not cover
all areas nor all routes within an area.
ProCarManuals.com

81 Control systems
COMAND introduction
COMAND introduction
COMAND (Cockpit Management and Data
System) is an information and operating
center for vehicle sound and communica-
tions systems, including the radio and nav-
igation system, as well as other optional
equipment (satellite radio, telephone*,
etc.).
Availability of functions while the vehi-
cle is in motion
For safety reasons, certain COMAND func-
tions are not available while the vehicle is
in motion or they are only available to a
limited extent. You will notice this, for ex-
ample, by the fact that certain menu items
cannot be selected or that the COMAND
display shows a corresponding message.
Switching COMAND on or off
Press the o shortcut button in the
center console (
page 82).
COMAND calls up the menu last select-
ed.
COMAND components
In your vehicle, COMAND can be used to
operate:

audio functions

the navigation system

the telephone* and communication
functions (SMS*)

various vehicle settings
COMAND consists of the following:

COMAND shortcut buttons

COMAND display

telephone* keypad

COMAND controller
iWhen you switch off COMAND, you also
switch off the currently playing audio source.
During a telephone call, you cannot switch off
COMAND.
ProCarManuals.com

82 Control systems
COMAND introduction
COMAND shortcut buttons
Use the COMAND shortcut buttons to se-
lect main functions directly.
Example:
Switching directly to Radio or CD
menu: Press M once or twice.COMAND display
In the COMAND display, you will find the
function currently selected and the corre-
sponding menus. The COMAND display is
divided into several areas.
1Status line
2Main functions
3Main area
4Submenus
5Climate control settings
A white bar under the main functions 2 in-
dicates the active area.
Once you have selected a main
function2, the main area 3 is active.
iDuring Dynamic Rear View Monitor* opera-
tion (
page 439) it is not possible to operate
the COMAND shortcut buttons.
FunctionPage
1PFavorite button231
2MShortcut button for:

CD/DVD

radio
115
96
3LBack button89
4OSeat menu250
5NShortcut button for:

telephone*

navigation
120
156
6oCOMAND on/off
button81
7,Volume control91
8FMute button91
ProCarManuals.com

83 Control systems
COMAND introduction
Instrument cluster multifunction
display
This section describes features and con-
trols via the COMAND controller, display
and shortcut buttons only.
Please refer to the “Instrument cluster
control system” section of this manual
(
page 256) for function descriptions and
operation of the instrument cluster multi-
function display and multifunction steering
wheel buttons as they relate to COMAND
features described in this section.Adjusting COMAND display illumina-
tion
1Knob
Brightening illumination: Turn
knob1 clockwise.
Dimming illumination: Turn knob1
counterclockwise.Swiveling COMAND display
1Button for swiveling display to the left
2Button for swiveling display to the right
You can swivel the COMAND display to the
left or right. The buttons are on the
right-hand side of the instrument cluster.
iThe layout of the menus may vary depending
on your vehicle’s equipment. This manual shows
the menus for a fully equipped vehicle.
ProCarManuals.com

84 Control systems
COMAND introduction
Telephone keypad*
With the help of the telephone keypad, you
can use your mobile phone if it is inserted
in the cradle.
1Telephone keypad
2Folding coverCOMAND controller
Use the COMAND controller to select
menu functions shown on the COMAND
display.
1COMAND controller
You can operate the COMAND controller
as follows:

press briefly or press and hold

rotate to the left or right

slide to the left, right, up, down or
diagonallyIn this way, you can move through the
menus, select menu items or exit menus.
You can move through the menus either by
rotating or sliding the controller.
Operating COMAND controller
ProCarManuals.com

85 Control systems
COMAND introduction
SymbolHow to use the COMAND controllerFunction
n
Press briefly.
Select menu item.

Exit full-screen image with Navi.
Press and hold until the selected ac-
tion has been carried out.
Save a station.

Accept a destination for navigation.
ymz
Rotate.
Move through vertical or horizontal menus.

Move through text.

Program settings.
qmr
Slide.
Move through vertical menus.

Exit horizontal menus.
Slide and hold.
Move through a navigation map.
omp
Slide.
Move through horizontal menus.

Exit vertical menus.
Slide and hold.
Fast forward or reverse for audio CD or audio DVD playback.

Move through a navigation map.
wmx
Slide and hold.
Move through a navigation map.
ProCarManuals.com

86 Control systems
COMAND introduction
Operating COMAND
Menu overview
The illustration below shows the structure
of the main functions and their main
menus.Each main function has a main menu. Each
menu item in turn has several submenu
items.
NaviPageAudioPageTelephone*PageVehiclePage
Commands/menus
Map Display159FM/AM Radio95Telephone*120Exterior Lighting Delayed Switch-off235
Mode161Sat Radio
(USA only)100Address Book*214Locator Lighting236
CD107Telephone OFF*122Exterior Mirror Convenience Settings237
DVD-Audio107Automatic Locking238
MP3107Easy Entry/Exit Feature239
Audio OFF94Interior Lighting Delayed Switch-off241
Interior Ambient Light240
Rear Window Sunshade*242
Trunk Opening-height Restriction*242
Tow-away Alarm243
ProCarManuals.com

87 Control systems
COMAND introduction
Calling up the main menu
Illustration: audio main menu
You can call up the main menu of a main
function in the following manner:
Moving to the main function line:
Slideqm.
Selecting a main function: Slide omp
or rotate ymz.
Confirming selection: Press n.Vertical menus
Moving through the menu:
Slidermq or rotate ymz.
Selecting a menu item: Press n.
Exiting a menu without making a se-
lection: Slide ompin the opposite di-
rection of the list orientation or press
back button L.Horizontal menus
Moving through the menu:
Slideomp or rotate ymz.
Selecting a menu item: Press n.
Exiting a menu without making a se-
lection: Slide rmqin the opposite di-
rection of the list orientation or press
back button L.
ProCarManuals.com

88 Control systems
COMAND introduction
Entering characters
Illustration: entering a navigation destina-
tion
Selecting characters
Slide omp or rotate ymz.
Confirming selection: Press n.
COMAND completes your entry as
soon as it can be clearly identified. In
this case, you do not need to switch to
the list.
Deleting individual characters
Select and press ) repeatedly in the
bottom line.Deleting entire words or numbers
Press and hold ) in the bottom line
until the word or number is deleted.
Exiting character entry
Select and press “Back” in the bottom
line.
or
Press back button L in the center
console (
page 82).
Switching to the list
Slide qm.
or
Select and press ? in the second line
from the bottom.
Exiting list: Slide om to select “Back”.
Accepting first entry
Press nuntil you exit the character
entry window.Selecting list item
Illustration: list of towns and cities for navi-
gation
1Symbol for other selection options
(e.g. county)
Selecting a line: Slide rmq or
rotateymz.
Confirming selection: Press n.
Additional selection options are avail-
able for list entries featuring
symbol1. For example, cities marked
with symbol 1 indicate that the select-
ed country has more than one city fea-
turing that name. Confirming such a list
entry opens up another submenu.
ProCarManuals.com

89 Control systems
COMAND introduction
Back button
1Back button
Switching to the next highest menu:
Press L briefly.
COMAND switches to the next highest
menu level within the currently active
operating mode.
Switching to the main menu: Press
and hold L.
You will hear a signal, and COMAND
switches to the main menu of the cur-
rently active operating mode.Example of how to use COMAND
In the descriptions below, the main func-
tions always serve as the starting point for
locating the individual menu items.
Example:
“Audio”
“Audio”
“FM/AM Radio”

“Radio”
“Save Station”
If you already see one of the submenus on
the screen (e.g. the “Audio”
“Audio”

“Radio” submenu), it is not necessary to
perform the first steps.
The individual steps for the above-men-
tioned example are described below.
Switching to the main function line:
Slide qm.
Selecting “Audio” main function:
Slideompor rotate ymz.
Confirming selection: Press n.
The audio operating mode last selected
appears.
Selecting “Audio” in the main menu:
Slide qm.
Confirming selection: Press n.
A selection list with the functions of the
“Audio” main menu appears.
iIn the COMAND display, you will see the
submenu previously called up for each main
menu.
