Contents
COMAND seats.................................. 250
Operating seats via COMAND ...... 250
Lumbar support (CL 550) ............. 251
Drive-dynamic
multicontour seats* ..................... 252
Instrument cluster control system ..... 256
Multifunction display .................... 256
Multifunction steering wheel ........ 257
Menus .......................................... 258
Trip menu ..................................... 260
Navi menu .................................... 261
Audio menu .................................. 263
Telephone menu*......................... 265
Assistance menu* ........................ 268
Service menu ............................... 269
Settings menu .............................. 271
Voice Control..................................... 273
Operating safety........................... 273
Voice Control introduction................. 274
Spelling ........................................ 275
Command types ........................... 275
Active System .............................. 275
Controls ....................................... 276
Symbols ....................................... 277Voice Control telephone ..................... 278
Telephone operation ..................... 278
Telephone commands ................... 279
Voice Control navigation .................... 285
Important notes ............................ 285
Navigation operation..................... 286
Navigation commands .................. 286
Dialog for entering
a complete address ...................... 287
Commands for entering
parts of an address ....................... 292
Voice Control address book ............... 295
COMAND address book overview . 295
Operation with
address book not open (global) .... 295
Operation with
address book open (local)............. 296
Operating and using
address book ................................ 296
Available commands
with the address book not open ... 296
Available commands
with the address book open.......... 298
Voice Control radio............................. 299
Radio operation ............................ 299
Radio commands .......................... 299Voice Control
CD/DVD changer/MP3...................... 303
Operation...................................... 303
Commands ................................... 304
Voice Control command list ............... 305
Command list ............................... 305
Voice Control troubleshooting............ 317
Help function ................................ 317
Help commands............................ 317
Help window ................................. 317
Entering digits and spelling ........... 317
What to do if ... ............................. 318
Voice Control individualization ........... 320
ProCarManuals.com

19 Introduction
Symbols
Symbols
Trademarks:

Bluetooth® is a registered trademark of
of Bluetooth SIG Inc.

ESP® and PRE-SAFE® are registered
trademark of DaimlerChrysler.

HomeLink® is a registered trademark
of Prince, a Johnson Controls
Company.

LOGIC7® is a registered trademark of
Harman International Industries, Incor-
porated.

SIRIUS and related marks are trade-
marks of SIRIUS Satellite Radio Inc.The following symbols are found in this
Operator’s Manual:
* Optional equipment is identified
with an asterisk. Since standard
equipment varies between models,
the descriptions and illustrations in
this manual may differ slightly from
the actual equipment of your
vehicle.
This symbol points to instructions for
you to follow.
A number of these symbols appearing
in succession indicates a multiple-step
procedure.
 page This symbol tells you where to
look for further information on a
topic.
This continuation symbol marks
a warning which is continued on
the next page.
This continuation symbol marks
a procedure which is continued
on the next page.
-> This symbol is used to indicate
cross-references to term defini-
tions.
“Display” Words appearing in the multi-
function display and COMAND
display are printed in the type
shown here.
Warning!G
Warning notices draw your attention to
hazards that may endanger your health or
life, or the health or life of others.
!Highlights hazards that may result in
damage to your vehicle.
iHelpful hints or further information you may
find useful.
ProCarManuals.com

274 Control systems
Voice Control introduction
The Voice Control System gives you the ca-
pability to control the following systems on
your vehicle using spoken commands:

Telephone* (page 278)

Navigation (page 285)

Address book (page 295)

Audio (page 299) (AM/FM radio,
CD/DVD changer, MP3 player)You control these systems using spoken
commands. Moreover, controls such as
the buttons on the multifunction steering
wheel (
page 276) allow you to keep your
hands on the steering wheel.
The command vocabulary consists of
approximately 300 ready to use phrases.
The Voice Control System recognizes com-
mands and number sequences, irrespec-
tive of the speaker. To optimize speech
recognition for your voice follow the indi-
vidualization process (
page 320).
You can use the Voice Control System to
call up all of COMAND’s main menu items,
with the exception of the main menus for
“Vehicle” and “Navi”.The commands and digit sequences can be
spoken without pausing between the indi-
vidual words. If an unavailable or incorrect
command is used, the Voice Control Sys-
tem will prompt you for a new command by
asking “Please repeat” or “Please repeat
your entry”.
In order to provide for a safe and comfort-
able dialog, the Voice Control System ac-
knowledges important commands.
ProCarManuals.com

380 Controls in detail
Driving and parking
Press KEYLESS-GO start/stop button
once.
The engine starts if the SmartKey with
KEYLESS-GO is in the vehicle.
For information on turning off the engine
with KEYLESS-GO, see “Turning off the en-
gine” (
page 387).Starting difficulties
The engine does not start. You can hear
the starter.
There could be a malfunction

in the engine electronics, or

in the fuel supply system
Carry out the following steps:
If you are starting the engine with the
SmartKey: Turn SmartKey in starter
switch to position0 and repeat starting
procedure.
If you are starting the engine with
KEYLESS-GO*: Close any doors that
may be open to allow for better detec-
tion of the SmartKey with
KEYLESS-GO*.
or
Remove the KEYLESS-GO* start/stop
button from starter switch.
Start the engine with the SmartKey as
radio signals from another source may
be interfering with the SmartKey with
KEYLESS-GO*.
Repeat the starting procedure
(
page 378).
If the engine does not start after several
starting attempts:
Call Roadside Assistance.
Contact an authorized Mercedes-Benz
Center or call Roadside Assistance.
iYou can also start the engine with the auto-
matic transmission set to N.
iIf you wish to start the vehicle with the
SmartKey instead of the KEYLESS-GO feature,
remove the KEYLESS-GO start/stop button from
the starter switch and proceed as described in
“Starting with the SmartKey” (
page 379).
!Remember that extended starting attempts
can drain the battery.

ProCarManuals.com

434 Controls in detail
Driving systems
Switching Parktronic system on/off
The Parktronic system can be switched off
manually.
1Parktronic button
2Indicator lampSwitching off the Parktronic sys-
tem: Press button 1.
Indicator lamp 2 comes on.
Switching on the Parktronic system:
Press button 1 again.
Indicator lamp 2 goes out.
Parktronic system malfunction
If only the red distance segments illumi-
nate and an acoustic warning sounds,
there is a malfunction in the Parktronic
system. The Parktronic system will auto-
matically switch off after 20 seconds and
the indicator lamp in the Parktronic switch
comes on.
Have the Parktronic system checked
by an authorized Mercedes-Benz
Center as soon as possible.
If only the red distance segments illumi-
nate and no acoustic warning sounds, the
Parktronic system sensors are dirty or
there is an interference from other radio or
ultrasonic signals. The Parktronic system
will automatically switch off after 20 sec-
onds and the indicator lamp in the
Parktronic switch comes on.
Switch off the ignition (page 336).
Clean the Parktronic system sensors
(
page 559).
Switch on the ignition.
or
Check the Parktronic system operation
at another location to rule out interfer-
ence from outside radio or ultrasonic
signals.
iThe Parktronic system is automatically
switched on when the ignition is switched on
(
page 336).
ProCarManuals.com

479 Controls in detail
Useful features
Telephone*
Radio transmitters, such as a portable tele-
phone or a citizens band unit, should only
be used inside the vehicle if they are con-
nected to an antenna that is installed on
the outside of the vehicle.
The external antenna must be approved by
Mercedes-Benz. Please contact an autho-
rized Mercedes-Benz Center for informa-
tion on the installation of an approved
external antenna. Refer to the radio trans-
mitter operation instructions regarding use
of an external antenna.
Warning!G
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system, pos-
sibly resulting in an accident and/or serious
personal injury.
Warning!G
Please do not forget that your primary re-
sponsibility is to drive the vehicle. A driver’s
attention to the road must always be
his/her primary focus when driving. For
your safety and the safety of others, we rec-
ommend that you pull over to a safe location
and stop before placing or taking a tele-
phone call.
If you choose to use the mobile phone
1
while driving, please use the hands-free de-
vice and only use the mobile phone when
road, weather and traffic conditions permit.
Some jurisdictions prohibit the driver from
using a mobile telephone while driving a ve-
hicle.
Only operate the COMAND (Cockpit Man-
agement and Data System)
1 if road, weather
and traffic conditions permit.
1Observe all legal requirements.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.
iVarious mobile phone cradles can be in-
stalled in the front center armrest, see separate
installation instructions for the mobile phone
cradle. These mobile phone cradles can be ob-
tained from an authorized Mercedes-Benz Cen-
ter.
The functions and services available to you while
using the mobile phone depend on your service
provider and the type of mobile phone you are
using. See also separate operating manual for in-
structions on how to use your mobile phone.
ProCarManuals.com

493 Controls in detail
Useful features
Step 7:
To program the remaining two signal
transmitter buttons, repeat the steps
above starting with step 3.
Rolling code programming
To train a garage door opener (or other
rolling code devices) with the rolling code
feature, follow these instructions after
completing the “Programming” portion
(steps 1 through 6) of this text. (A second
person may make the following training
procedures quicker and easier.)
Step 8:
Locate “training” button on the garage
door opener motor head unit.
Exact location and color of the button
may vary by garage door opener brand.
Depending on manufacturer, the “training” button may also be referred
to as “learn”or “smart” button. If there
is difficulty locating the transmitting
button, refer to the garage door opener
operator’s manual.
Step 9:
Press the “training” button on the ga-
rage door opener motor head unit.
The “training light” is activated.
You have 30 seconds to initiate the follow-
ing two steps.
Step 10:
Return to the vehicle and firmly press,
hold for 2 seconds and release the pro-
grammed signal transmitter button
(2, 3 or4).
Step 11:
Press, hold for 2 seconds and release
same signal transmitter button a sec-
ond time to complete the training pro-
cess.Step 12:
Confirm the garage door operation by
pressing the programmed signal trans-
mitter button (2, 3 or4).
Step 13:
To program the remaining two signal
transmitter buttons, repeat the steps
above starting with step 3.
Gate operator/Canadian programming
Canadian radio-frequency laws require
transmitter signals to “time-out” (or quit)
after several seconds of transmission
which may not be long enough for the
integrated signal transmitter to pick up the
signal during programming. Similar to this
Canadian law, some U.S. gate operators
are designed to “time-out” in the same
manner.
iIf indicator lamp1 flashes rapidly for about
2 seconds and then turns to a constant light,
continue with programming steps 8 through 12
as your garage door opener may be equipped
with the “rolling code” feature.iSome garage door openers (or other rolling
code equipped devices) may require you to
press, hold for 2 seconds and release the same
signal transmitter button a third time to com-
plete the training process.
ProCarManuals.com

495 Controls in detail
Useful features
Programming tips
If you are having difficulty programming
the integrated remote control, here are
some helpful tips:

Check the frequency of hand-held re-
mote control5 (typically located on
the reverse side of the remote). The in-
tegrated remote control is compatible
with radio-frequency devices operating
between 280-390 MHz.

Put a new battery in hand-held remote
control5. This will increase the likeli-
hood of the hand-held remote control
sending a faster and more accurate sig-
nal to the integrated remote control.

While performing step 3, hold
hand-held remote control5 at differ-
ent lengths and angles from the signal
transmitter button (2, 3 or4) you
are programming. Attempt varying an-
gles at the distance of 2 to 5 in
(5 to 12 cm) away or the same angle at
varying distances.

If another hand-held remote control is
available for the same device, try the
programming steps again using that
other hand-held remote control. Make
sure new batteries are in the hand-held
remote control before beginning the
procedure.

Straighten the antenna wire from the
garage door opener assembly. This
may help improve transmitting and/or
receiving signals.
iCertain types of garage door openers are in-
compatible with the integrated remote control. If
you should experience further difficulties with
programming the integrated remote control,
contact an authorized Mercedes-Benz Center, or
call Mercedes-Benz Customer Assistance Cen-
ter (in the USA only) at 1-800-FOR-MERCedes, or
Customer Service (in Canada) at
1-800-387-0100.
iUSA only:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interfer-
ence, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
iCanada only:
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation of the device.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
ProCarManuals.com
