MERCEDES-BENZ CL-Class 2008 C216 Comand Manual

100 Control systemsCOMAND FM/AM radioSelecting stations using the station list
Select “Audio”
“Audio”
“FM/AM
Radio”
“FM”.

Select “Radio”
“Station List”.
The station list appears. The dot R in
front of a list entry indicates the cur-
rently selected station. A number in
front of the list entry indicates the pre-
set position in the station preset mem-
ory.

Select a station by rotating ymz or
sliding qmr and press n.Selecting stations/channels using the
search function

Slide omp or rotate ymz when the
main area is selected.
Depending on the direction in which
the controller is being slid or rotated,
the system searches upward or down-
ward and stops at the next receivable
station/channel.Selecting stations using station
presets

Select “Audio”
“Audio”
“FM/AM
Radio”
“FM” or “AM”.

Select “Presets”.
or

Press n when the main area is select-
ed.
The preset menu appears. The dot R
in front of a preset position indicates
that the currently selected station is
saved there.

Select station preset by rotating ymz
or sliding qmr and press n.
or

Enter a position number with the tele-
phone keypad using the A- 9
buttons (
page 86).
i
The station list is only available for the FM
waveband. It contains all the stations that can be
currently received and is sorted by station fre-
quencies.
i
This function is not available for Weather
Band.

101 Control systems
COMAND FM/AM radio
Selecting stations by entering the fre-
quency manually
Select “Audio”
“Audio”
“FM/AM
Radio”
“FM” or “AM”.
Entering the frequency using the
COMAND controller

Select “Radio”
“Frequency Entry”.
The menu for manual frequency entry
appears.

Exiting menu without making an en-
try: Press L back button in the cen-
ter console (
page 84).

Increasing or decreasing number:
Slide qmr or rotate ymz.

Selecting the next number:
Slidemp.

Confirming frequency entry:
Pressn.
COMAND tunes in to the frequency en-
tered.
Entering the frequency using the tele-
phone keypad

Press> on the telephone keypad
(page 86).

Enter frequency using the R- 9
buttons.
COMAND tunes in to the frequency en-
tered.Selecting channels using the channel
list

Select “Audio”
“Audio”
“FM/AM
Radio”
“WB”
“Channel”.
or

Press n when the main area is select-
ed.
The channel list appears. The dotR in
front of a list entry indicates the cur-
rently selected channel.

Select channel by rotating ymz or
slidingqmr and press n.
i
This function is not available for Weather
Band.
i
You can only select currently permitted
numbers.
i
If you enter a frequency in the AM waveband
which is outside the frequency range, COMAND
tunes in to the next lowest frequency.
i
This function is only available for Weather
Band.

102 Control systemsCOMAND FM/AM radioSaving stations
You have the following options:

Saving stations manually


Saving stations using Autostore
Saving stations manually
Option 1

Select “Audio”
“Audio”
“FM/AM
Radio”
“FM” or “AM”.

Select “Radio ”
“Save Station”.
Option 2

Press n when the main area is select-
ed.Option 3

Select “Audio”
“Audio”
“FM/AM
Radio”
“FM” or “AM”.

Select “Presets”.
All three of these will call up a station pre-
set screen. The dot R in front of a preset
position indicates that the currently select-
ed station is saved there.

Selecting a preset position:
Slideqmr or rotate ymz.Saving a station to a selected preset
position
If you have called up the station preset
screen using option 1:

Press n briefly.
In options 2 and 3:

Press and hold n until you hear a
signal.
The station is saved.
i
Twenty stations can be saved in each wave-
band except for Weather Band.

103 Control systems
COMAND FM/AM radio
Saving using autostore
Option 1
Press n when the main area is select-
ed.

Select “Autostore”.
Option 2

Select “Audio”
“Audio”
“FM/AM
Radio”
“FM” or “AM”.

Select “Presets”
“Autostore”.
Option 3

Select “Audio”
“Audio”
“FM/AM
Radio”
“Radio”
“Save Station”

“Autostore”.
Station name display
1Station name display
Switching the station name display
on/off: Select “Audio”
“Audio”

“FM/AM Radio”
“FM”
“Radio”

“Show Station Info”.The display is switched on or off, de-
pending on the previous setting. When
the display is switched on, a check-
mark appears in front of the
“Show Station Info” menu item.
i
This function is not available for Weather
Band. The Autostore function saves receivable
stations as presets in order of their reception
quality. All stations saved manually in the preset
memory will be lost if COMAND finds 20 sta-
tions. If COMAND finds less than 20 stations, for
example 9, then the stations saved in preset po-
sitions 1 – 9 will be over written.
i
In the FM waveband, COMAND can show
the name of the station currently tuned in. Sta-
tion name display 1 can only be seen when it is
switched on and if the station transmits a name.

104 Control systemsCOMAND satellite radioSubmenu overviewWarning!
G
Please devote your attention first and fore-
most to the traffic situation you are in.
Before your journey, please familiarize your-
self with the radio functions.
Only use the COMAND when road and traffic
conditions permit you to do so. Otherwise
you could be involved in an accident in
which you or others could be injured.
i
The components and operating principles of
COMAND can be found on (
page 83).
Sat Radio
Presets
Info
Category
Sound
Channel List
Station presets
Show program info
Select category
Treble
Save Channel
Bass
Channel Entry
Balance/Fader
Service
3D Sound

105 Control systems
COMAND satellite radio
Introduction to satellite radio
SIRIUS Satellite Radio provides over
130 channels of digital-quality radio, in-
cluding 100% commercial-free music,
sports, news and entertainment. SIRIUS
Satellite Radio uses a fleet of high-orbit
satellites to broadcast 24 hours per day,
coast to coast, in the contiguous U.S. and
Canada.
This diverse, satellite-delivered program-
ming is available for a monthly subscrip-
tion fee.
For more information and service availabil-
ity call the SIRIUS Service Center
(1-888-539-7474), or contact

www.sirius.com (USA)


www.siriuscanada.com (Canada)
Switching to satellite radio
Select “Audio”
“Audio”
“Sat Ra-
dio”.
or

Press the M shortcut button once or
twice. The Satellite radio menu appears
if it was the last active radio mode.
The screen which then appears de-
pends on the activation status of the
satellite radio service.
The following options are possible:

Satellite radio service is not
activated


Only the preview channel is
activated


Satellite radio service is fully
activated
i
A subscription to SIRIUS Satellite Radio ser-
vice provider is required for the satellite radio op-
eration described in this chapter. Contact an
authorized Mercedes-Benz Center for details
and availability for your vehicle.
i
Satellite radio service may be unavailable or
interrupted from time to time for a variety of rea-
sons, such as environmental or topographic con-
ditions and other things we can’t control. Service
might also not be available in certain places
(e.g., in tunnels, parking garages, or within or
next to buildings) or near other technologies. In
such situations, the satellite radio’s main menu
shows the “Acquiring signal...” screen. At this
point, the radio’s functions are restricted to
manual channel number entry (
page 109) and
service info display (
page 111).

106 Control systemsCOMAND satellite radioSatellite radio service is not activated
The telephone number of the SIRIUS Ser-
vice Center and the twelve-digit electronic
serial number (SIRIUS-ID) of the particular
receiver are displayed.
This information is required when calling
the SIRIUS Service Center for an activation
request.

Closing screen: Press n.
Only the preview channel is activated
The satellite radio preview channel ap-
pears.Satellite radio service is fully activated
The main satellite radio menu appears. You
will hear the channel last tuned in, provid-
ed that it can be received.
i
If a subscription is not included with system
purchase, credit card information is required to
activate your account. The activation process
takes approximately 5 to 10 minutes after calling
the SIRIUS Service Center.
i
It is also possible to activate the satellite ra-
dio service online. To do so please visit SIRIUS
Satellite Radio's website at www.sirius.com
(USA) or www.siriuscanada.com (Canada).
i
If only the preview channel is activated, you
cannot tune in another channel. If you try to do
this, you will see the screen described in the sec-
tion “Satellite radio service is not activated”
(
page 106).

107 Control systems
COMAND satellite radio
Main satellite radio menu
1Main area with channel display
2Preset position of selected channel
3Selected channel
4Selected program category
5Sound settings
6To select program category
7Artist and song title
8Other channel information
9Preset options
aSatellite radio options
Selecting program category
Select “Audio”
“Audio”
“Sat Ra-
dio”
“Category”.
The category list appears.

Select category by rotating ymz or
slidingqmr and press n.
When selecting a channel using the
channel search function or the channel
list, you have access to the channels
you subscribe to and which are includ-
ed in the selected category.
i
Main area1 can show all channels includ-
ed in your subscription. Which channels are
shown depends on the selected program
category4.
Note that categories and channels shown in illus-
trations are dependent on programming content
delivered by the service provider. Programming
content is subject to change.
Therefore, channel and categories shown in illus-
trations and descriptions contained in this man-
ual may differ from the channels and categories
delivered by the service provider.
i
The channels are categorized. Categories al-
low you to tune to stations broadcasting a cer-
tain type of program.
i
If only the preview channel is activated, only
certain categories are available on the list. Which
categories these are depend on the service
provider.
i
When you select the category “All Chan-
nels”, you have access to all the channels you
subscribe to, regardless of category, when you
are tuning in a channel using the channel search
function or the channel list.

108 Control systemsCOMAND satellite radioTuning in channels
You have the following selection options:

The channel search function


The channel presets


The manual channel number entry


The channel list
Tuning in channels using channel
search function

Slide omp or rotate ymz when the
main area is selected.
Depending on the direction in which
the controller is being pressed or rotat-
ed, the system searches upward or
downward and stops at the next receiv-
able channel.Tuning in channels using channel
presets

Select “Audio”
“Audio”
“Sat Ra-
dio”
“Presets”.
or

Press n when the main area is select-
ed.
The preset menu appears. The dotR
in front of a preset position indicates
that this is the channel currently select-
ed and being listened to.

Select station preset and briefly
pressn.
or

Enter a position number with the tele-
phone keypad using digits 1 to 9
(page 86).
COMAND tunes in the corresponding
channel as long as it is included in your
subscription and is still available.
If the channel is not included in your sub-
scription, you will see the message de-
scribed in the section “Satellite radio
service is not activated” (
page 106).
i
This function is not possible when only the
preview channel is activated. If you try to tune in
a channel in this instance, you will see the
screen described in the section “Satellite radio
service is not activated” (
page 106).
i
Which channels are found by the channel
search function depends on which channels you
have subscribed to and the program category
you have selected (
page 107).

109 Control systems
COMAND satellite radio
If the channel is no longer available or only
the preview channel is activated, you will
see the message “Invalid Channel”.
Closing message: Press n.
Tuning in channels using manual chan-
nel number entry
Entering the channel number using the
COMAND controller

Select “Audio”
“Audio”
“Sat Ra-
dio”
“Sat Radio”
“Channel Entry”.
The menu for manual channel number
entry appears.

Exiting menu without making an en-
try: Press L back button in the cen-
ter console (
page 84).

Increase or decreasing number:
Slide qmr or rotate ymz.

Selecting next number: Slideomp.

Confirming channel entry: Press n.
Further operation depends on whether
the selected channel number is valid or
if the channel is included in your sub-
scription.
Entering the channel number using the
telephone keypad

Press> on the telephone keypad
(page 86).

Enter channel number using the R-
9 buttons.
Further operation depends on whether
the selected channel number is valid or
if the channel is included in your sub-
scription.Channel number is valid and channel is
included in subscription
COMAND tunes in the channel entered.
Channel number is invalid
You will see the message “Invalid Chan-
nel”.

Closing message: Press n.
Channel number is valid but channel is
not included in subscription
You will see the screen described in the
section “Satellite radio service is not acti-
vated” (
page 106).

Closing display: Press n.
i
This function is not possible when only the
preview channel is activated. If you try to tune in
a channel in this instance, you will see the
screen described in the section “Satellite radio
service is not activated” (
page 106).
