MERCEDES-BENZ CL-Class 2008 C216 Comand Manual

270 Control systemsCOMAND automatic climate controlThe automatic climate control menu is
called up via the climate control settings.Climate control settings with functions
(submenus)1Temperature, left
2Air distribution, left
3Air volume, left
4Central menu, climate control
5Air volume, right
6Air distribution, right
7Temperature, right
Setting temperature
Use the temperature controls %$
(page 491) in the center console or
COMAND climate control settings to sepa-
rately adjust the air temperature on each
side of the passenger compartment.

Select climate control settings
Tem-
perature, left or right and then
pressn.

Changing temperature: Slide qmr or
rotate ymz.

Exiting menu: Press n, back
buttonL in the center console
(page 84) or slideomp.
The setting is saved.

271 Control systems
COMAND automatic climate control
Adjusting air distribution
You can adjust the air distribution sepa-
rately for the driver’s and front passenger’s
side.
Select climate control settings
Air
distribution, left or right.

Changing air distribution:
Rotateymz.
The symbol for air distribution changes.
The direction and size of the arrows
represent the air distribution.
or

Switching back to automatic mode:
Rotateymz and select “AUTO”.

Exiting menu: Press n, back
buttonL in the center console
(page 84) or slideomp.
The setting is saved.
Adjusting air volume
Use buttonsQ (
page 491) in the cen-
ter console or COMAND climate control
settings to separately adjust the air vol-
ume on each side of the passenger com-
partment.

Select climate control settings
Air
volume, left or right.
i
When you change the air distribution, the au-
tomatic function of the climate control system is
switched off.
i
When you change the air volume, the auto-
matic function of the climate control system is
switched off.


272 Control systemsCOMAND automatic climate control
Changing air volume: Slide qmr or
rotate ymz.
or

Switching back to automatic mode:
Rotateymz and select “AUTO”.

Exiting menu: Press n, back
buttonL in the center console
(page 84) or slideomp.
The setting is saved.Central climate control menu via
COMAND
The central climate control menu is in the
center of the climate control settings.
When the automatic climate control is
switched on, you will see “on” in the cen-
tral menu. The following functions can only
be operated in the central climate control
menu via COMAND:
Select climate control settings
Cen-
tral menu.Switching cooling on or off
The cooling function, only operational
when the engine is running, cools the vehi-
cle interior down to the selected tempera-
ture. The cooling function also
dehumidifies the air in the vehicle interior,
thus preventing the windows from fogging
up.
Function
Page
Switching off cooling (“AC
OFF”)
272
Central climate control (“Mono”)
273
Footwell temperature
274
Air flow from air vents
275


273 Control systems
COMAND automatic climate control
The “AC
OFF” function is used to permanent-
ly switch off the cooling function of the au-
tomatic climate control system.

Select climate control settings
Cen-
tral climate control menu.

Selecting “AC
OFF”: Slide qmr or
rotateymz.

Confirming selection: Press n.
A checkmark appears when the cooling
is switched off.
“AC
OFF” appears in the central menu of
the climate control settings.Selecting “Mono” mode
“Mono” is used to adjust the climate zones
for the entire vehicle at the same time.
When the “Mono” function is switched on
and you change the climate on the driver’s
side, these changes will be carried out in
the same manner for all climate zones.

Select climate control settings
Cen-
tral climate control menu.

Selecting “Mono”: Slide qmr or
rotateymz.

Confirming selection: Press n.
A checkmark appears when the func-
tion has been selected.

Exiting menu: Press back button L
in the center console (
page 84) or
slideomp.
i
Condensation may drip out from underneath
the vehicle. This is normal and not an indication
of a malfunction.Warning!
G
If you turn off the cooling function, the
vehicle will not be cooled when weather
conditions are warm. The windows can fog
up more quickly. Window fogging may
impair visibility and endanger you and
others.
!
If the air conditioning cannot be turned on
again, this indicates that the air conditioning is
losing refrigerant. The compressor has turned it-
self off.
Have the air conditioning checked at the nearest
authorized Mercedes-Benz Center.

274 Control systemsCOMAND automatic climate controlThe “Mono” function is automatically
switched off when you:

change an automatic climate control
setting for the front passenger’s side
using COMAND


operate a button from the automatic
climate control for the front passen-
ger’s side


operate one of the buttons for the rear
climate control systemAdjusting footwell temperature
The “Footwell Temperature” function is
used to adjust the temperature difference
between the footwell and the rest of the
passenger compartment.
The higher the selected value, the higher
the temperature in the footwell will be.

Select climate control settings
Cen-
tral climate control menu.

Selecting “Footwell Temperature”:
Slide qmr or rotate ymz and then
pressn.

Changing temperature difference:
Slide qmr or rotate ymz.

Exiting menu: Press n, back
buttonL in the center console
(page 84) or slideomp.
The setting is saved.
i
In automatic mode, this setting optimizes
the footwell temperature when outside tempera-
tures are low.

275 Control systems
COMAND automatic climate control
Adjusting air flow from air vents
The “Airflow” setting defines air distribu-
tion and air volume in automatic mode:

“Focused” (default setting, increased
air flow)


“Medium” (reduced air flow)


“Diffuse” (minimal air flow)

Select climate control settings
Cen-
tral climate control menu
“Airflow”.
A selection list appears.
The current setting is indicated by a
dotR.

Changing air flow: Slide qmr or
rotateymz.

Confirming selection: Press n.
i
In automatic mode, this setting optimizes
the air flow when outside temperatures are high.
i
When the interior ambient temperature of
the vehicle is very hot and the automatic climate
control is cooling the interior, the setting for air
flow is temporarily overridden.

276 Control systemsCOMAND seatsWhen adjusting the seats, observe the
safety notes in the section “Seats”
(page 368).
Operating seats via COMAND
The following seat adjustments can be
made via COMAND:Selecting a seat
You must first select the seat for which you
would like to make adjustments.
1Seat menu button

Press O.
The main area is active.

Switching to the bottom menu line:
Slide qmr.
Example illustration (vehicles with Drive-dy-
namic multicontour seat*)
Selecting seat: Slide omp or
rotateymz.

Confirming selection: Press n.
i
The components and operating principles of
COMAND can be found on (
page 83).
Settings
Page
Lumbar support (CL 550)
277
Drive-dynamic multicontour
seats*
278

277 Control systems
COMAND seats
Exiting menu
There are several ways to exit the seat
menu.
Press O again.
or

Press any shortcut button.
or

Select another main function from the
main menu line.
Lumbar support (CL 550)
To support the spine, you can adjust the
curvature of the front seat backrests.
Press O.
The main area of the COMAND display
is active. A scale appears.
1Scale
2Cursor
3Current seat
4Current setting

Select seat (
page 276).

Adjusting lumbar support:
Slideomp or rotate ymz until desired
setting is reached.

Confirming selection: Press n.

Switching to the bottom menu line:
Slide omp.

Confirming selection: Press n.
i
After you have pressed
O
, the seat last
adjusted is active.

278 Control systemsCOMAND seatsDrive-dynamic multicontour seats*
Drive-dynamic multicontour seats allow
several individual support adjustments and
can automatically adjust lateral support to
your driving style (
page 281).Multicontour adjustments
To support the spine, you can individually
adjust the backrest contour of the front
seats by regulating the air pressure in the
air chambers.
The settings are made on the COMAND
display.
You can adjust the following air chambers:


sides of seat cushion


sides of backrest


backrest curvature in lumbar area


backrest curvature in shoulder areaAdjusting sides of seat cushion
This function is used to adjust the air
chambers in the sides of the seat cushion.

Select seat (
page 276).

Selecting “Seat sides”: Slide omp or
rotate ymz.

Confirming selection: Press n.
A scale appears.
i
If PRE-SAFE
® has been activated, the air
pressure in the air chambers (on the sides of the
seat cushion and backrest) of the drive-dynamic
multicontour seats is increased.
i
Whether adjustments are being made manu-
ally or automatically, noises may be heard from
air pumping into or releasing from the air
chambers.

279 Control systems
COMAND seats
1Scale
2Cursor
3Current setting
Slide qmr or rotate ymz until desired
setting is reached.

Saving setting: Press n.Adjusting backrest sides
This function is used to adjust the air
chambers in the backrest sides.

Select seat (
page 276).

Selecting “Seatback Sides”:
Slideqmr or rotate ymz.

Confirming selection: Press n.
A scale appears.

Slide qmr or rotate ymz until desired
setting is reached.

Saving setting: Press n.Adjusting backrest curvature in lumbar
area
This function is used to adjust the air
chambers in the lumbar area of the back-
rest.

Select seat (
page 276).

Selecting “Lumbar”: Slide omp or
rotateymz.

Confirming selection: Press n.
Cross-hairs appear. You can use them
to make two settings:

vertical: shift the point of greatest
curvature upward or downward


horizontal: adjust the degree of
curvature
