ContentsUseful features .................................. 221
Storage compartments................. 221
Ashtrays ....................................... 227
Cigarette lighter ........................... 228
Heated steering wheel* ............... 228
Telephone*................................... 229
Tele Aid ........................................ 230
Garage door opener ..................... 238
Infrared reflecting windshield ....... 244
Operation........................................ 245
The first 1000 miles (1500 km) ......... 246
Driving instructions............................ 247
Drive sensibly – save fuel ............. 247
Drinking and driving ..................... 247
Pedals .......................................... 247
Power assistance ......................... 247
Brakes .......................................... 248
Driving off .................................... 249
Parking ......................................... 249
Tires ............................................. 250
Hydroplaning ................................ 251
Tire traction.................................. 251
Tire speed rating .......................... 251
Winter driving instructions ........... 252
Standing water ............................. 253
Passenger compartment .............. 254
Driving abroad.............................. 254
Control and operation of radio
transmitters ................................. 254
Catalytic converter ....................... 255
Emission control .......................... 255
Coolant temperature .................... 256At the gas station .............................. 257
Refueling ...................................... 257
Check regularly and before a
long trip ....................................... 258
Engine compartment ......................... 260
Hood ............................................ 260
Engine oil ..................................... 261
Transmission fluid level................ 266
Active Body Control (ABC)
fluid level ..................................... 266
Coolant ........................................ 266
Battery ......................................... 268
Windshield washer system and
headlamp cleaning system........... 269
Tires and wheels................................ 270
Important guidelines .................... 270
Life of tires................................... 271
Direction of rotation..................... 271
Checking tire inflation pressure ... 271
Rotating wheels ........................... 279
Winter driving .................................... 280
Winter tires .................................. 280
Block heater (Canada only) .......... 281
Snow chains................................. 281

262OperationEngine compartmentChecking the engine oil level with the
control system
When checking the oil level the vehicle
must

be parked on level ground


be at normal operating temperature


have been stationary for at least five
minutes with the engine turned off
To check the engine oil level via the multi-
function display, do the following:

Turn the SmartKey in the starter switch
to position2 or press the KEYLESS-GO
start/stop button* twice.
The standard display (
page 134) should
appear in the multifunction display.

Press buttonk or j on the
steering wheel until the following mes-
sage is seen in the multifunction dis-
play:CORRECT MEASUREMENT
ONLY IF VEH. LEVEL
After about three seconds this mes-
sage is displayed:ENGINE OIL LEVEL
MEASURING NOW!One of the following messages will sub-
sequently appear in the indicator:

ENGINE OIL LEVEL
OK


ADD 1.0 QT. TO
REACH MAX. OIL LEVEL!(Canada:
1.0 LITER
)


ADD 1.5 QTS. TO
REACH MAX. OIL LEVEL!(Canada:
1.5 LITERS
)


ADD 2.0 QTS. TO
REACH MAX. OIL LEVEL!(Canada:
2.0 LITERS
)

If necessary, add engine oil.
For adding engine oil see (
page 265).
For more information on engine oil, see
“Technical data” section (
page 372) and
(
page 374).iIf you want to interrupt the checking
procedure, press the k or j but-
ton on the multifunction steering
wheel.

263 Operation
Engine compartment
Other display messages
If the SmartKey or KEYLESS-GO start/stop
button* is not in position 2, the following
message will appear:FOR ENGINE OIL LEVEL
IGNITION ON!
Switch on ignition.
If you see the message:
PERF. SERV ON TIME
If engine is at normal operating
temperature, wait five minutes before
repeating check procedure.

If engine is not yet at normal operating
temperature, wait 30 minutes before
repeating check procedure.If you see the message:
ENGINE OIL LEVEL
NOT WHEN ENGINE ON!
Turn off the engine.

If the engine is at normal operating
temperature, wait five minutes before
checking oil.

If the engine is not yet at normal oper-
ating temperature, you must wait
30 minutes before checking oil.
If there is excess engine oil with the engine
at normal operating temperature, the fol-
lowing message will appear:
ENGINE OIL LEVEL
REDUCE OIL LEVEL
Have excess oil siphoned or drained
off. Contact an authorized
Mercedes-Benz Center.For more information on messages in the
display concerning engine oil, see the
“Practical hints” section (
page 310).
!Excess oil must be siphoned or drained
off. It could cause damage to the en-
gine and catalytic converter not cov-
ered by the Mercedes-Benz Limited
Warranty.iPerform the engine oil level check with
the dipstick (CL 500, and CL 55 AMG
only) if it cannot be completed with the
control system .
In this case we recommend that you
have the system checked at a
Mercedes-Benz Center.

264OperationEngine compartmentChecking the engine oil level with the
oil dipstick (CL 500, CL 55 AMG only)
When checking the oil level the vehicle
must

be parked on level ground


be at normal operating temperature


have been stationary for at least five
minutes with the engine turned off
To check the engine oil level with the oil
dipstick, do the following:

Open the hood (
page 260).

Pull out oil dipstick1 (
page 265).

Wipe oil dipstick1 clean.

Fully insert oil dipstick1 into the dip-
stick guide tube.

Pull out oil dipstick1 again after ap-
proximately three seconds to obtain
accurate reading.
Oil dipstickThe oil level is correct when it is between
the lower (min) and upper (max) mark of
the oil dipstick.

If necessary, add engine oil.
For adding engine oil see (
page 265).
For more information on engine oil, see the
“Technical data” section (
page 372) and
(
page 374).
For more information on messages in the
display concerning engine oil, see the
“Practical hints” section (
page 310)
iThe engine oil level can be checked by
either the oil dipstick or via the multi-
function display in the instrument clus-
ter (
page 262). The amount of engine
oil needed is shown more precisely in
the multifunction display.
iThe filling quantity between upper and
lower oil dipstick marking level is ap-
proximately 2.1 US qt (2.0 l).

311 Practical hints
What to do if …?
When the message
ADD 1.0 QT. ENGINE
OIL AT NEXT REFUELING!
(Canada:
1 Liter
) appears while the engine is run-
ning and at operating temperature, the en-
gine oil level has dropped to approximately
the minimum level.When this occurs, the warning will first
come on intermittently and then stay on if
the oil level drops further.
Visually check for oil leaks. If no obvious oil
leaks are noted, drive to the nearest ser-
vice station where the engine oil should be
topped to the required level with an ap-
proved oil.
Display symbol
Display message
Possible cause
Possible solution
:
ENGINE OIL
VISIT WORKSHOP!
It may be that there is water in the engine
oil.

Have the engine oil level checked
(page 262).
ENGINE OIL LEVEL
VISIT WORKSHOP!
The engine oil has dropped to a critical
level.

Check the engine oil level (
page 262)
and add engine oil as required
(
page 265).

If you must add engine oil frequently,
have the engine checked for possible
leaks.
ENGINE OIL SENSOR
VISIT WORKSHOP!
The measuring system is malfunctioning.

Have the measuring system checked by
an authorized Mercedes-Benz Center.
!The engine oil level warnings should
not be ignored. Extended driving with
the symbol displayed could result in
serious engine damage that is not
covered by the Mercedes-Benz Limited
Warranty.

372 Technical dataFuels, coolants, lubricants, etc.
Fuels, coolants, lubricants, etc.CapacitiesVehicle components and their respective
lubricants must match. Therefore use only
brands tested and approved by us.Please refer to the Factory Approved Ser-
vice Products pamphlet, or inquire at your
Mercedes-Benz Center.
Model
Capacity
Fuels, coolants, lubricants, etc.
Engine with oil filter
CL 500
CL 55 AMG
CL 600
8.5 US qt (8.0 l)
7.9 US qt (7.5 l)
9.5 US qt (9.0 l)
Approved engine oils
Automatic transmission
CL 500
CL 55 AMG
CL 600
9.1 US qt (8.6 l)
9.1 US qt (8.6 l)
8.1 US qt (7.7 l)
MB Automatic Transmission Oil
Rear axle
CL 55 AMG
and CL 600
1.7 US qt (1.6 l)
2.1 US qt (2.0 l)
Hypoid gear oil SAE 85 W 90
Hydraulic system for ABC
approx. 4.2 US qt (4.0 l)
MB Hydraulic fluid
Power steering
approx. 1.1 US qt (1.0 l)
MB Power Steering Fluid
(Pentosin CHF 11S)
Front wheel hubs
approx. 3.5 oz (100 g) each
High temperature roller bearing grease
Brake system
0.7 US qt (0.7 l)
MB Brake Fluid (DOT 4+)
Cooling system
CL 500
CL 55 AMG
CL 600
approx. 12.1 US qt (11.5 l)
approx. 15.3 US qt (14.5 l)
approx. 15.85 US qt (15 l)
MB 325.0 Anticorrosion / Antifreeze

373 Technical data
Fuels, coolants, lubricants, etc.
Model
Capacity
Fuels, coolants, lubricants, etc.
Low temperature cooling system
CL 600
2.3 US qt (2.2 l)
MB 325.0 Anticorrosion / Antifreeze
Fuel tank
including a reserve of
CL 500
CL 55 AMG
CL 600
23.2 US gal (88.0 l)
2.9 US gal (11.0 l)
Premium unleaded gasoline:
Minimum Posted Octane 91
(Avg.of96RON/86MON)
Air conditioning system
R-134a refrigerant and special PAG
lubricant oil (never R-12)
Windshield washer and
headlamp cleaning system:
7.1 US qt (6.7 l)
MB Windshield Washer Concentrate
1
1Use MB Windshield Washer Concentrate “S” and water for temperatures above freezing or MB Windshield Washer Concentrate “S” and commercially available pre-
mixed windshield washer solvent / antifreeze for temperatures below freezing point. Follow suggested mixing ratios (page 379).

384 Technical termsCOMAND
(C
ockpit M
anagement and D
ata Sys-
tem)
Information and operating center for
vehicle sound and communications
systems, including the radio and navi-
gation system, as well as other optional
equipment (CD changer, telephone,
etc.).
Control system
The control system is used to call up
vehicle information and to change
component settings. Information and
messages appear in the multifunction
display. The driver uses the buttons on
the multifunction steering wheel to
navigate through the system and to ad-
just settings.
Cruise control
A driving convenience system for auto-
matically maintaining the vehicle speed
set by the driver.Distronic*
A driving convenience cruise control
system which helps the driver maintain
a pre-selected speed:


If there is no vehicle directly ahead,
the system operates in the same
way as conventional ->cruise con-
trol.


If a slower moving vehicle is ahead,
Distronic will reduce your vehicle
speed to the extent permitted by re-
duced throttle and up to 20% brak-
ing power to maintain the preset
minimum following distance.
Engine number
The number set by the manufacturer
and placed on the cylinder block to
uniquely identify each engine pro-
duced.Engine oil viscosity
Measurement for the inner friction (vis-
cosity) of the oil at different tempera-
tures. The higher the temperature an
oil can tolerate without becoming thin,
or the lower the temperature it can tol-
erate without becoming viscous, the
better the viscosity.
ESP
(E
lectronic S
tability Pr
ogram)
Improves vehicle handling and direc-
tional stability.
ETD
(E
mergency T
ensioning D
evice)
Device which deploys in certain frontal
and rear collisions exceeding the sys-
tem's threshold to tighten the seat
belts.
->SRS

392 Index
Front lamps 336
High beam 336
High mounted brake lamp 337
License plate lamps 337, 340
Low beam 336
Parking lamps 336, 337, 339
Rear fog lamp 337, 340
Side marker lamps 336, 339
Standing lamps 336, 337, 339
Tail lamp assemblies 337, 340
Turn signal lamps 336, 337
C
CAC (Customer Assistance Center) 383
California
Important notice 11
Calling up
Distronic* settings 142
Range (distance to empty) 144
Service indicator 283
CAN system 383
Cargo tie-down hooks 220
Cassette player
Operating 136Catalytic converter 255
CD changer* 137
CD mode 137
CD player
Operating 136
Center console 25
AIRBAG OFF indicator lamp 298
Lower part 26
Upper part 25
Centigrade
Setting temperature units 148
Central locking
Automatic 105
From inside 106
Switch 106
Switching on/off (control
system) 153
Unlocking from inside 106
Central locking switch 106
Changing
Batteries (SmartKey) 333
Battery (SmartKey with
KEYLESS-GO*) 334
Key setting 154SmartKey with KEYLESS-GO*
setting 94
Vehicle level 212
Changing CDs 137
Charcoal filter 181
Activating 181
Deactivating 181
Charging
Vehicle battery 349
CHECK ENGINE malfunction indicator
lamp 294
Checking
Coolant level 266
Oil level 259, 261
Oil level via control system 262
Tire inflate pressure 259
Vehicle lighting 259
Checking the batteries
SmartKey 91
Child safety 69
Airbags 62
Infant and child restraint systems 66,
69
LATCH child seat mounts 74

397 Index
Engine malfunction indicator lamp 23,
294
Engine number 384
Engine oil 261
Adding 265
Additives 374
Checking level 261
Consumption 261
Display messages 310
Filler neck 265
Messages in display 263, 310
Viscosity 384
Engine oil level see Oil level 259
Entry position
Messages in display 312
ESP 79, 384
Switching off 80
Switching on 81
Synchronizing 303
Warning lamp 295
ETD 384
Safety guidelines 64
ETD (Emergency tensioning device) 68
Exterior lamp switch 119Exterior rear view mirrors
Adjusting 40
Folding electrically 169
Parking position for 156
F
Fahrenheit
Setting temperature units 148
Fastening the seat belts 42
Fine adjustment
Cruise control 197
Distronic* 204
First aid kit 329
Flat tire 343
Lowering the vehicle 347
Mounting the Spare wheel 343
Preparing the vehicle 343
Flexible Service System (FSS) 282, 385
Fog lamp, rear 122, 337
Replacing bulb 340
Fog lamps
Replacing bulbs 336
Fog lamps, front
Messages in display 314
Switching on 122Folding electrically
Exterior rear view mirrors
169
Front airbags 65
Front lamps
Messages in display 314–318
Replacing bulbs 336, 338
Switching on 119
Front seat
Head restraints 108
Head restraints installing 108
Head restraints removing 108
FSS (Flexible Service System) 282, 385
Fuel 258
Fuel reserve warning lamp 296
Premium unleaded gasoline 258
Reserve warning lamp 23
Fuel consumption statistics
After start 143
Since last reset 143
Fuel filler flap 257
Locking 257
Opening 334
Unlocking 257
