240 Control systemsCOMAND navigation system (during route guidance)Cancel route guidance
Select “Destination”
“Cancel Route
Guidance” in map view with the menu
system displayed (
page 191).
Continuing cancelled route guidance
Select “Destination”
“Continue
Route Guidance” in map view with the
menu system displayed (
page 191).
COMAND calculates the route.
Route browser
Select “Route”
“Route Browser” in
map view with the menu system dis-
played (
page 191).
The route browser appears.
1Highlighted route section
2Current vehicle position; the triangle in-
dicates the vehicle’s direction of travel
3Information about the highlighted route
section

Displaying next or previous route
section: Select “Next” or “Previous”.

Increasing or reducing size of the
map: Select; or :.

Closing route browser:
Select “Back”.
i
The route browser shows an overview of the
route. You can use the route browser to move
along the route section by section and view infor-
mation about and details of each section of the
route.
i
The information 3 about the marked route
section shows the street name and the length of
the route section. Marked route section 1 is al-
ways highlighted in white and outlined in red.

241 Control systems
COMAND navigation system (during route guidance)
Displaying info
Select “Info” in map view with the
menu system displayed (
page 191).
The route information appears.
Example display with main destination and
stopover1Symbol = for stopover
2Distance to the destination
3Sequence of destinations (appears
with at least one stopover)
4Street
5City and abbreviation for province
(CDN) or state (USA)
6Country
7Symbol < for main destination
8Estimated driving time to the destina-
tion
9Estimated arrival time
i
COMAND uses the time set in COMAND as
the basis for calculating the estimated arrival
time. The clock must be set correctly in
COMAND (
page 255). The calculation of the
estimated arrival time does not additionally take
into account whether Daylight Saving Time or
standard time is applicable at the destination. If
the destination is in a different time zone, arrival
time display 8
is in local time. This is indicated
by “LT” in the display.
The following data cannot be seen until the route
calculation has been completed:


Distance to destination
1


Estimated arrival time
8


Estimated remaining travel time
7
If the destination is located within a partially dig-
itized area, the following data may differ from the
facts:

Distance to destination
1


Estimated arrival time
8


Estimated remaining travel time
7

242 Control systemsCOMAND navigation system (during route guidance)Displaying route information
Select “Route”
“ Route Info” in map
view with the menu system displayed
(page 191).
The route information appears.
Example display route information1Highlighted portion of route
2Info for highlighted portion of route
3Next portion of route

Closing route info: Slide omp or
press back button L in the center
console (
page 84).

Displaying next or previous route
section: Select “Next” or “Previous”.

Increasing or reducing size of the
map: Select; or :.

Closing route browser:
Select “Back”.
Detour function
Select “Route”
“Detour” in map view
with the menu system displayed
(page 191).
The detour function display appears.

Setting length of the blockage:
Select “More” or “Less” until the de-
sired length is set.
i
The detour function blocks a section of the
route ahead of you. You can set the length of the
blockage. If possible, COMAND calculates a de-
tour route.
i
The detour function may direct you to
off-road routes. See Off-road and Off-map for ad-
ditional routes and cautions (
page 237).

243 Control systems
COMAND navigation system (during route guidance)
1Blocked route section
2Current vehicle position; the triangle in-
dicates the vehicle’s direction of travel
3Information about the blocked route
section

Starting route calculation:
Select “Start”, see also (
page 218).

Deleting blockage: Select “Navi”

“Route”
“Detour”
“Delete”.

Select “Back”.
i
Blocked route section 1 is always highlight-
ed in red/white. The information about blocked
route section 3 shows which section of the
route is blocked and the length of the blocked
section.

244 Control systemsCOMAND navigation system (real-time traffic)A RDS-TMC (Radio Data System-Traffic
Message Channel) radio transmitter
broadcasts traffic reports COMAND can
receive and incorporate into the navigation
system. Traffic report messages and map
symbols can then be viewed in the
COMAND display. Events displayed are
those within receivable range of the vehi-
cle's location.Real-time traffic notifications in the
map
COMAND can display certain traffic events
in the map. The notifications are shown at
the map scales from 0.05 mi (50 m) to
500 mi (500 km).
Set the map scale: Turn ymz until the
desired map scale is set.
Turning clockwise enlarges the map,
turning counterclockwise reduces it.
Display example for a traffic jam on the
route1Symbol for event on the route
2Marker symbols for the affected route
section
3Current vehicle position and direction
of travel
4Map scale
i
Actual road and traffic conditions may be
different from the received messages.
i
COMAND marks the entire route section af-
fected with the appropriate symbols2, inde-
pendently of its actual length on the route
section. The symbols2 are shown in the direc-
tion of travel on the left or right of the route.Thus,
they also indicate which side of the roadway is
affected by the event.

245 Control systems
COMAND navigation system (real-time traffic)
The following shows the possible symbol
displays.
1Traffic jam on the route (symbol with
red border)
2Traffic jam away from the route (sym-
bol with gray border)
3Stop and go traffic on the route (sym-
bol with red border)
4Stop and go traffic away from the route
(symbol with gray border)
5Blocked section on the route
6Traffic jam
7Stop and go traffic
Displaying real-time traffic reports
Displaying the message list
Select “Navi”
“Traffic”.
COMAND searches for real-time traffic
transmitters. When no traffic reports
are present, you will see a display to
this effect.List for inactive route guidance
When route guidance is inactive, the list
displays all streets for which messages are
present.
1Affected street list

Read a message: Select a street.
You can find an example message on
(page 246).

Close the list: Slide omp.
i
Instead of a street, an area or a region can
also be affected by a message, for example,
when visibility is limited due to fog.

246 Control systemsCOMAND navigation system (real-time traffic)List for active route guidance
When route guidance is active, the list dis-
plays only the streets which are part of the
route and for which messages are present.
1Show all messages (including those
which do not affect the route)
2Affected streets (only shown when
messages which affect the route are
present)
Display all messages: Select “Display
All Messages”.
All streets are shown for which mes-
sages are present, as well as for those
which are not on the route.

Read a message: Select a street.
You can find an example message on
(page 246).

Close the list: Slide omp once or re-
peatedly.
Example message
1Selection display (“Messages On
Route” or “All messages”)
2Symbol for message event (e.g. traffic
jam)
3Street affected by the message
4Message 1 of 1 for the affected street
5Message textThe symbols for the possible message
events are shown in the following.
1Traffic jam symbol
2Stop and go traffic symbol
3Warning message symbol
4Blocked section symbol

Scroll through the contents or to the
next message: Turn ymz or slide
qmr.

247 Control systems
COMAND navigation system (destination memory)
COMAND navigation system (destination memory)
Saving a destination in the destination memory
Saving after the address has been
entered
Select “Save” after entering the ad-
dress (
page 198).
You can now select save options.Saving during route guidance

Select “Destination”
“Save Destina-
tion” during route guidance.
You can now select save options.
Saving a destination from the list of last
destinations

Select “Navi”
“Destination”

“From Last Destinations”.
The list of last destinations appears.

Select desired destination.
The address of the destination is dis-
played.

Select “Save”.
You can now select save options.Selecting save options
Saving a destination without a name

Select “Save Without Name”.
COMAND saves the destination in the
destination memory and uses the ad-
dress as the destination name.
or

Select “Save as ‘My Address’ ”.

Select desired category, e.g. “Home”.
COMAND saves the destination in the
destination memory as your own ad-
dress.
Saving a destination with a name

Select “Save new entry”.

Select desired category, e.g. “Home”.
The input menu appears with the data
fields and the input characters.
i
This function also saves the destination in
the address book. There COMAND creates an
address book entry containing complete, naviga-
ble address data. You can then select this entry
in the address book and start navigation to the
address.


248 Control systemsCOMAND navigation system (destination memory)1Selected data field with input mark
(cursor)
2Input characters
Entering data: Proceed as described
in the “Changing the data field” operat-
ing step in the “Creating a new address
book entry” section (
page 164).Assigning a destination to an address
book entry

Select “Assign Address Book Entry”.

Select desired category, e.g. “Home”.
The menu appears for searching for an
address book entry.

Select desired address book entry. Pro-
ceed as described in the “Searching for
an address book entry” section
(page 166).
If the selected address book entry does
not yet contain any navigable address
data, COMAND saves the data.
If the selected address book entry al-
ready contains navigable address data,
you will see a question asking you if the
previous data should be overwritten.

Select “Yes” or “No”.
If you select “Yes”, COMAND saves the
data.
i
This function assigns the complete, naviga-
ble address data to an already existing address
book entry. You can then select this entry in the
address book and start navigation to the address
from there.


249 Control systems
COMAND navigation system (destination memory)
Deleting a destination from the destina-tion memory
Select “Navi”
“Destination”

“From Memory”.
Depending on the number of entries in
the destination memory, you will see
the destination memory list with or
without input characters.
Example illustration: destination memory
list without input charactersExample illustration: destination memory
list with input characters
1Input characters

Select desired destination. Proceed as
described for destination entry in the
“Entering a destination from the desti-
nation memory” section (
page 219).

Select “Delete” after selecting the des-
tination to be deleted.
A prompt appears asking whether you
want to delete the destination.

Select “Yes” or “No”.
If you select “Yes”, COMAND deletes
the destination.
i
If the navigable address data of the destina-
tion to be deleted has also been assigned to an
address book entry, COMAND deletes the data
there as well. If the corresponding address book
entry does not contain any further data, such as
telephone numbers, COMAND deletes the entire
address book entry.
