322 Controls in detail
Locking and unlocking
SmartKey
Your vehicle comes supplied with two
SmartKeys, each with remote control and
a removable mechanical key.
The locking tabs for the mechanical key
portion of the two SmartKeys are of differ-
ent color to help distinguish each
SmartKey unit.
The SmartKey provides an extended oper-
ating range. To prevent theft, however, it is
advisable to only unlock the vehicle when
you are in close proximity to it.
The SmartKey centrally locks and unlocks,
when set to factory settings (
page 324):

the doors

the trunk

the fuel filler flap
SmartKey with remote control
1‹ Lock button
2ŠOpening button for trunk
(
page 461)
3Mechanical key locking tab
4ŒUnlock button
5Battery check lamp
6ÂPanic button (
page 63)
!To prevent possible malfunction, avoid ex-
posing the SmartKey to high levels of electro-
magnetic radiation.
Warning!G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. A child’s
unsupervised access to a vehicle could
result in an accident and/or serious
personal injury.
Warning!G
To prevent possible personal injury, always
keep hands and fingers away from the door
or trunk lid opening when closing a door or
the trunk. Be especially careful when small
children are around.
Before closing doors, make sure there is no
possibility of someone getting caught in a
door during closing.

326 Controls in detail
Locking and unlocking
SmartKey with KEYLESS-GO*
Vehicles equipped with KEYLESS-GO come
with two SmartKeys with KEYLESS-GO,
each with remote control and a removable
mechanical key.
The locking tabs for the mechanical key
portion of the two SmartKeys with
KEYLESS-GO are of different color to help
distinguish each SmartKey with
KEYLESS-GO unit.
The KEYLESS-GO function is integrated
into the SmartKey. On these vehicles, the
validity of the SmartKey with KEYLESS-GO
is checked every time you grasp an outside
door handle.
With the KEYLESS-GO function, you can
lock and unlock the vehicle without using
the remote control buttons on the
SmartKey and start the engine without in-
serting the SmartKey in the starter switch.If the SmartKey with KEYLESS-GO is valid,
your vehicle unlocks:

the doors

the trunk

the fuel filler flap
SmartKey with KEYLESS-GO
1‹ Lock button
2ŠOpening button for trunk
(
page 461)
3Locking tab for mechanical key
4ΠUnlock button
5Battery check lamp
6ÂPanic button (
page 63)
!To prevent possible malfunction, avoid ex-
posing the SmartKey with KEYLESS-GO to high
levels of electromagnetic radiation.
Warning!G
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO* with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. A child’s unsupervised ac-
cess to a vehicle could result in an accident
and/or serious personal injury.
Children could start the vehicle with a valid
SmartKey with KEYLESS-GO left in the
vehicle or with the KEYLESS-GO button on
the starter switch, or could release the
electronic parking brake, thereby putting
themselves and others in danger. Switch off
the engine and take the SmartKey with
KEYLESS-GO with you even if you are only
leaving the vehicle for a short while.

462 Controls in detail
Trunk
Trunk opening-height restriction
The trunk lid opening height can be limited
when transporting goods on a roof rack
(e.g. presence of an optional MB sport lug-
gage container). When activated, the trunk
opens to approximately the height of the
roof edge.
Activate the limiting opening height of
trunk lid using the COMAND system
(
page 242).
Closing trunkClosing trunk from inside automatically
1Remote trunk opening/closing switch
Press and hold switch1 until the
trunk is closed.
The indicator lamp in the switch goes
out when the trunk is closed.
To interrupt the closing procedure:
Release switch1.
iDo not place the SmartKey in the open
trunk. You may lock yourself out.
iIf the vehicle was previously centrally
locked, the trunk will lock automatically after
closing it. All turn signal lamps flash three times
to confirm locking.
Vehicles with KEYLESS-GO*: To prevent a possi-
ble inadvertent lockout, the trunk will open auto-
matically if a SmartKey with KEYLESS-GO* is
recognized inside the vehicle or in the trunk.
The vehicle is only locked when the turn signals
flash three times. If you are carrying a second SmartKey with KEYLESS-GO* with you, you can
still lock the vehicle.
Warning!G
Maintain sight of trunk area while operating
door mounted switch. Monitor the closing
procedure carefully to make sure no one is
in danger of being injured.
To interrupt the closing procedure, release
the door mounted remote trunk open-
ing/closing switch.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the remote trunk
opening/closing switch can be operated.
Therefore, do not leave children unattended
in the vehicle, or with access to an unlocked
vehicle. A child’s unsupervised access to a
vehicle could result in an accident and/or
serious personal injury.
iIf the trunk lid comes into contact with an
object while closing (e.g. luggage that has been
piled too high) in the upper motion sequence, the
closing procedure is stopped and the trunk re-
opens slightly.
iYou can also close the trunk by hand.

463 Controls in detail
Trunk
Closing trunk from outside
automatically
Vehicles without KEYLESS-GO*
1Trunk closing switch
Vehicles with KEYLESS-GO*
1Trunk closing switch
Press trunk closing switch1 briefly.
The trunk closes.
Warning!G
Monitor the closing procedure carefully to
make sure no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the trunk lid opening when closing the trunk.
Be especially careful when small children
are around. To stop the closing procedure,
do one of the following:

press button Š on the SmartKey or
SmartKey with KEYLESS-GO

press the trunk opening/closing switch
(on the driver’s door)

press the trunk closing switch

press the KEYLESS-GO locking/closing
switch*

pull the trunk lid handle
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the remote trunk
opening/closing switch can be operated.
Therefore, do not leave children unattended
in the vehicle, or with access to an unlocked
vehicle. A child’s unsupervised access to a
vehicle could result in an accident and/or
serious personal injury.
iIf the trunk lid comes into contact with an
object while closing (e.g. luggage that has been
piled too high) in the upper motion sequence, the
closing procedure is stopped and the trunk re-
opens slightly.
iYou can also close the trunk by hand.

492 Controls in detail
Useful features
Programming integrated remote
control
Step 1:
Switch on the ignition (page 336).
Step 2:
If you have previously programmed a
signal transmitter button and wish to
retain its programming, proceed to
step 3.
If you are programming the integrated
remote control for the first time, press
and hold the two outer signal transmit-
ter buttons2 and4 and release
them only when indicator lamp1 be-
gins to flash after approximately
20 seconds (do not hold the button for
longer than 30 seconds). This proce-
dure erases any previous settings for
all three channels and initializes the
memory.If you later wish to program a second
and/or third hand-held transmitter to
the remaining two signal transmitter
buttons, do not repeat this step and be-
gin directly with step 3.
Step 3:Hold the end of hand-held remote
control5 of the device you wish to
train approximately 2 to 5 in
(5 to12 cm) away from the signal trans-
mitter button (2, 3 or4) to be pro-
grammed, while keeping indicator
lamp1 in view.
Step 4:
Using both hands, simultaneously
press hand-held remote control
button6 and the desired signal trans-
mitter button (2, 3 or4). Do not
release the buttons until step 5 is com-
pleted.
Indicator lamp1 will flash, first slowly
and then rapidly.Step 5:
After indicator lamp1 changes from a
slow to a rapidly flashing light, release
the hand-held remote control button
and the signal transmitter button.
Step 6:
Press and hold the just-trained signal
transmitter button (2, 3 or4) and
observe indicator lamp1.
If indicator lamp1 stays on
constantly, programming is complete
and your device should activate when
the respective signal transmitter
button (2, 3 or4) is pressed and
released.
iIndicator lamp1 flashes immediately the
first time the signal transmitter button is pro-
grammed. If this button has already been pro-
grammed, the indicator lamp will only start
flashing after 20 seconds.

494 Controls in detail
Useful features
If you live in Canada or if you are having
difficulties programming a gate operator
(regardless of where you live) by using the
programming procedures, replace step 4
with the following:
Step 4:
Press and hold the signal transmitter
button (2, 3 or4). Do not release
this button until it has been successful-
ly trained.
While still holding down the signal
transmitter button (2, 3 or4),
“cycle” your hand-held remote control
button6 as follows: Press and hold
button6 for 2 seconds, then release
it for 2 seconds, and again press and
hold it for 2 seconds. Repeat this se-
quence on the hand-held remote con-
trol until the frequency signal has been
learned. Upon successful training, indi-
cator lamp1 will flash slowly and then
rapidly after several seconds.
Proceed with programming step 5 and
step 6 to complete.Reprogramming a single signal trans-
mitter button
To program a device using a signal trans-
mitter button previously trained, follow
these steps:
Switch on the ignition (page 336).
Press and hold the desired signal
transmitter button (2, 3 or4).
Do not release the button.
Indicator lamp1 will begin to flash af-
ter 20 seconds. Without releasing the
signal transmitter button, proceed with
programming starting with step 3.Operation of integrated remote control
Switch on the ignition (page 336).
Select and press the appropriate inte-
grated signal transmitter button (2,
3 or4) to activate the remote con-
trolled device.
The integrated remote control trans-
mitter continues to send the signal as
long as the button is pressed – up to
20 seconds.
Erasing integrated remote control
memory
Switch on the ignition (page 336).
Simultaneously press and hold outer
signal transmitter buttons2 and 4,
for approximately 20 seconds, until
indicator lamp1 flashes rapidly. Do
not hold for longer than 30 seconds.
The codes of all three channels are
erased.
iUpon completion of programming the inte-
grated remote control, make sure you retain the
hand-held remote control that came with the ga-
rage door opener, gate operator or other device.
You may need it for use in other vehicles, for fu-
ture programming of an integrated remote con-
trol, or simply for continued use as a hand-held
remote control to operate the respective device
in other situations.
iIf you sell your vehicle, erase the codes of all
three channels.

700 Index
Emergency operations
Locking the vehicle 635
Mechanically releasing
the electronic parking brake 637
Releasing from inside 464
Remote door lock 489
Remote door unlock 489
Tilt/sliding sunroof 638
Unlocking the trunk 636
Unlocking the vehicle 635
Emergency Tensioning Device see ETD
Emergency, In case of
Battery, Jump starting 660
First aid kit 632
Flat tire 649
Fuses 667
Roadside Assistance 16
Roadside Assistance (Tele Aid) 485
Towing the vehicle 663
Emission control 507
Emission control information label 675
Emission control system warranties 14Engine
Belt layout 676
Cleaning 556
Compartment 512
Coolant 518, 685, 689
Malfunction indicator lamp 31, 570
Number 674, 675
Oil 516, 684, 686
Oils 513
Residual heat and ventilation 460
Starting 378
Technical data 677
Turning off 387
Engine coolant see Coolant
Engine oil 513
Adding 516
Additives 686
Checking level 513
Checking level (Dipstick) 516
Checking level (Instrument
cluster control system) 514
Consumption 513Dipstick 516
Filler neck 516, 517
Messages in display 515, 623
Recommended engine oils
and oil filters 684
ESP
®69
Messages in display 594, 605
Warning lamp 31, 567, 572
ETD 55
Safety guidelines 44
Exterior lighting
Delayed switch-off (COMAND) 235
Locator lighting (COMAND) 236
Exterior rear view mirrors
Adjusting 353
Auto-dimming
on the driver’s side 355
Fold in automatically when locking
(COMAND) 237
Lower mirror when reversing
(COMAND) 237
Power folding 354

703 Index
I
Identification labels 674
Identification Number, Vehicle (VIN) 675
Ignition 336, 338
Switching on 336
Switching on, KEYLESS-GO* 338
Immobilizer 77
Indicator lamps see
Lamps, indicator and warning
Individualization
Voice Control 320
Infant and child restraint systems
see Children in the vehicle
Infrared reflecting windshield 496
Inside door handle 333
Instrument cluster 30, 402
Coolant temperature gauge 31, 403
Fuel gauge 31
Illumination 402, 448
Lamps 566
Multifunction display 256
Outside temperature indicator 404
Selecting the language
(COMAND) 231Interior lighting 369
Activating automatic control 370
Ambient lighting (COMAND) 240
Deactivating automatic control 370
Delayed switch-off (COMAND) 241
Reading lamps in the front 370
Interior rear view mirror
Adjusting 353
Auto-dimming 355
Interior storage spaces see
Storage compartments
J
Jack 633, 650
Jacking up the vehicle 650
Jump starting 660K
Key, Mechanical 635
Loss of 332
Key, SmartKey 322
Battery check lamp 322, 325
Factory setting 324
Global locking and unlocking 324
Lock button 322
Locking and unlocking 322
Loss of 332
Messages in display 615
Opening button for trunk 322
Panic button 63
Remote control 322
Restoring to factory setting 325
Selective setting 325
Starting the engine 379
Switching on ignition with 336
Turning off engine 387
Unlock button 322

704 Index
Key, SmartKey with KEYLESS-GO* 326
Battery check lamp 326, 330
Factory setting 329
Global locking and unlocking 330
Important notes
on using KEYLESS-GO* 328
Lock button 326
Locking and unlocking 326
Locking using the lock button
on door or on trunk lid 331
Loss of 332
Messages in display 614
Opening button for trunk 326
Panic button 63
Remote control 326
Restoring to factory setting 331
Selective setting 330
Starting the engine 379
Switching on ignition with 338
Turning off engine 388
Unlock button 326
Kickdown 396
Kilopascal 545
Knee bag 46L
Labels 674
Certification 674
Emission control information 675
Tire and Loading Information 524
Vacuum line routing diagram 675
Lamp bulbs, exterior 641
Lamps, exterior
Front 642
Light sensor 617
Rear 642
Lamps, indicator and warning
ABS 31, 64, 566
Air bag Off 46
Battery check lamp (SmartKey
with KEYLESS-GO*) 330
Battery check lamp (SmartKey) 325
Brake warning lamp 31
Brakes 567
Combination low tire pressure*
malfunction telltale 31, 576
Distance warning lamp* 31, 572
DISTRONIC Plus* 31, 414, 572
Electronic parking brake 31, 568
Engine diagnostics 31, 570
Engine malfunction 31, 570ESP®31, 567, 572
Front passenger front
air bag off 50, 578
Fuel reserve 573
High beam headlamp 31
Maintenance service indicator 551
Park Assist* 31
Parktronic* 31
Seat belt telltale 31, 573
SRS 31, 575
TPMS* malfunction telltale 31, 576
Turn signals 31
Language (COMAND) 231
LATCH-type child seat anchors
see Children in the vehicle
Lever
For automatic transmission
(gear selector lever) 389
For cruise control 406
For DISTRONIC Plus* 417
License plate lamps
Messages in display 619
Replacing bulbs 642
Light alloy wheels, Cleaning 563

709 Index
Product information 13
Production options weight 546
Program mode see
Automatic transmission,
Automatic shift program
Program mode selector switch
Automatic shift program 399
Proper use of the vehicle 20
PSI 546
Push-start see Tow-startR
Radio
FM/AM operation (COMAND) 95
Saving stations, FM/AM
(COMAND) 98
Selecting satellite radio channel
(Instrument cluster
control system) 264
Selecting stations 263
Submenu overview, FM/AM
(COMAND) 95
Switching wavebands, FM/AM
(COMAND) 96
Tuning in stations/channels 96
Voice Control 299
Radio transmitters,
control and operation 506
Range (distance to empty) 261
Reading lamps in the front 370
Rear fog lamp
Replacing bulbs 642
Rear lamps see Tail lampsRear seats
Adjustment 339
Folding back and placing
upright rear head restraints 349
Head restraints 348
Ventilation* 347
Rear side windows
Blocking operation 62
Rear view mirrors see Mirrors
Rear window defroster 457
Activating 457
Deactivating 457
Recommended inflation pressure 546
Recovery services,
Stolen vehicle (Tele Aid) 490
Refrigerant, Air conditioning 685, 686
Refueling 509
Regular checks 511
Remote
Door lock with Tele Aid 489
Door unlock with Tele Aid 489
Remote control,
SmartKey 322
Remote control,
SmartKey with KEYLESS-GO* 326
