towing MERCEDES-BENZ CL600 2007 C216 Owner's Manual

Contents
Practical hints................................. 565
What to do if …?................................. 566
Lamps in instrument cluster ........ 566
Air bag off indicator lamp............. 578
Vehicle status messages
in the multifunction display .......... 580
Where will I find ...? ........................... 632
First aid kit ................................... 632
Vehicle jack, vehicle tool kit,
luggage bowl, Minispare wheel .... 632
Unlocking/locking in an emergency .. 635
Unlocking the vehicle ................... 635
Locking the vehicle ...................... 636
Mechanically releasing
the electronic parking brake ........ 637
Opening/closing in an emergency..... 638
Power tilt/sliding sunroof ............ 638
Replacing SmartKey batteries ........... 639
SmartKey/SmartKey
with KEYLESS-GO*....................... 639Replacing bulbs .................................. 641
Bulbs ............................................. 642
Replacing bulbs
for front lamps .............................. 644
Replacing bulbs
for the rear lamps ......................... 646
Replacing wiper blades....................... 647
Placing wiper arms
in vertical position ........................ 647
Removing wiper blades ................. 648
Installing wiper blades .................. 648
Flat tire ............................................... 649
Preparing the vehicle .................... 649
Mounting the Minispare wheel...... 649Batteries............................................. 655
Disconnecting starter battery ....... 657
Removing starter battery .............. 658
Charging battery ........................... 658
Reinstalling starter battery ........... 659
Reconnecting starter battery ........ 659
Jump starting...................................... 660
Towing the vehicle.............................. 663
Installing towing eye bolt .............. 666
Fuses.................................................. 667
Fuse boxes
in engine compartment................. 668
Fuse boxes
in passenger compartment ........... 669
Emergency engine shut-down ....... 670

27 At a glance
Exterior view
ItemPage
1Trunk

Unlocking

Opening and closing

Minispare wheel

Vehicle tool kit
461
461
649
632
2Rear lamps642
3Rear window, defrosting457
4Fuel filler flap
Gasoline509
687
5Doors

Locking and unlocking

Opening and closing
322
333
ItemPage
6Exterior rear view mirror
Parking position355
356
7Towing the vehicle663
8Rims and tires

Checking tire inflation
pressure

Minispare wheel

Flat tire
678
530
634
649
9Hood, opening
Engine oil
Coolant512
513
518
ItemPage
aHeadlamp cleaning system367
bFront lamps642
cWindshield wipers
Wiper blades, replacing
Wiper blades, cleaning372
647
562
dWindow, cleaning562
ePower tilt/sliding sunroof466

78 Safety and Security
Anti-theft systems
Disarming: Unlock your vehicle with
the SmartKey or KEYLESS-GO*.
The turn signal lamps flash once to in-
dicate that the alarm system is dis-
armed.
Tow-away alarm
Depending on production date, your vehi-
cle may not be equipped with the tow-away
alarm.
Once the tow-away alarm is armed, a visual
and audible alarm will be triggered when
someone attempts to raise the vehicle.To cancel the alarm after it has been trig-
gered, see “Canceling the alarm”
(
page 78).
Arming: Lock your vehicle with the
SmartKey or KEYLESS-GO*.
The tow-away alarm is automatically
armed after about 30 seconds.
Disarming: Unlock your vehicle with
the SmartKey or KEYLESS-GO*.
To prevent triggering the tow-away alarm
feature, switch off the tow-away alarm be-
fore towing the vehicle, or when parking ona surface subject to movement, such as a
ferry or auto train.
To switch off the tow-away alarm, see
“Switching the tow-away alarm on/off”
(
page 243).
Canceling the alarm
To cancel the alarm, do one of the follow-
ing:
Insert the SmartKey or SmartKey with
KEYLESS-GO* in the starter switch.
Press the Œ or ‹ button on the
SmartKey or SmartKey with
KEYLESS-GO*.
In vehicles with KEYLESS-GO*:
Grasp an outside door handle.
The SmartKey with KEYLESS-GO must
be within 3 ft (1 m) of the vehicle.
Press the KEYLESS-GO start/stop but-
ton (
page 337).
The SmartKey with KEYLESS-GO must
be inside the vehicle.
iIf the turn signal lamps does not flash three
times one of the following elements may not be
properly closed:

a door

the trunk
Close the respective element and lock the vehi-
cle again.
iThe alarm system will rearm automatically
again after approximately 40 seconds if no door
was opened.
iIf the alarm stays on for more than
30 seconds, a call to the Response Center is ini-
tiated automatically by the Tele Aid system
(
page 482) provided Tele Aid service was sub-
scribed to and properly activated and that neces-
sary mobile phone, power supply and GPS
coverage are available.
iWhen you unlock your vehicle, the tow-away
protection disarms automatically.
The tow-away alarm remains disarmed until you
lock your vehicle again.


243 Control systems
COMAND vehicle menu
Confirming selection: Press n.
or
Select “Vehicle”
“Vehicle”
“Trunk
Opening-height Restriction”.
A checkmark appears when the trunk
opening-height restriction is switched
on.
Confirming selection: Press n.
Switching the tow-away alarm on/off
Depending on vehicle production date,
your vehicle may not be equipped with the
tow-away alarm.
To prevent triggering the tow-away alarm
feature (
page 78), switch off the
tow-away alarm before towing the vehicle,
or when parking on a surface subject to
movement, such as a ferry or auto train.
Select “Vehicle”.
The main area is active.
Selecting “Tow-away Alarm” func-
tion: Slide omp or rotate ymz.
Confirming selection: Press n.or
Select “Vehicle”
“Vehicle”

“Tow-away Alarm”.
A checkmark appears when the
tow-away alarm is switched on.
Confirming selection: Press n.
iThe components and operating principles of
COMAND can be found on (
page 81).
iYou can program the tow-away alarm func-
tion (
page 231) using the favorite button in the
center console.
When you press the favorite button, you can
switch the functions on or off.

387 Controls in detail
Driving and parking
Turning off the engine
Shift the automatic transmission toP
(
page 393).Turning off with SmartKey
Turn the SmartKey in the starter switch
to position0 (
page 336) and remove
it.
The immobilizer is activated.iIf the engine cannot be turned off as de-
scribed, see “Emergency engine shut-down”
(
page 670).
Warning!G
Do not turn off the engine before the vehicle
has come to a complete stop. With the en-
gine not running, there is no power assis-
tance for the brake and steering systems. In
this case, it is important to keep in mind that
a considerably higher degree of effort is nec-
essary to brake and steer the vehicle.
!Observe instructions

when taking the vehicle through an
automatic conveyor type car wash
(
page 557)

when towing the vehicle (page 663)
!If you turn off the engine using the
SmartKey and

remove the SmartKey from the starter
switch
or

open a door
the transmission will shift to park positionP
automatically.
Keep in mind that turning off the engine with the
SmartKey alone only will automatically shift the
transmission to neutral positionN.

394 Controls in detail
Automatic transmission
If you want the gear position to remain in
neutral positionN, e.g. when taking the
vehicle through an automatic conveyor
type car wash or when towing the vehicle,
observe the following instructions.
!DISTRONIC Plus*:
The transmission will shift to park positionP
automatically, only when DISTRONIC Plus brings
your vehicle to a standstill, and when it meets at
least one of the following conditions at the same
time:

the engine is turned off

the driver’s or passenger door opens and the
seat belt is not engaged in the buckle
In addition to shifting to park positionP, the
electronic parking brake will be engaged auto-
matically.
iMake it a practice to always shift into park
positionP before turning off the engine and

remove the SmartKey from the starter
switch
or

open a door
or when using KEYLESS-GO*, before turning off
the engine with the start/stop button and open-
ing the driver’s or passenger door.
Effect
íReverse gear
Shift into reverse gearR only
when the vehicle is stopped.
ëNeutral
No power is transmitted from the
engine to the drive axle. When
the brakes are released, the
vehicle can be moved freely
(pushed or towed).
To avoid damage to the trans-
mission, never shift into neutral
positionN while driving.
If the ESP
® is deactivated or
malfunctioning:
Shift into neutral positionN only
if the vehicle is in danger of
skidding, e.g. on icy roads.
!If you turn off the engine using the
SmartKey or the KEYLESS-GO* start/stop
button, the transmission will shift to neutral
positionN automatically.
Warning!G
When leaving the SmartKey or SmartKey
with KEYLESS-GO* in the starter switch, do
not leave children unattended in the vehicle.
It is possible for children to switch on the
ignition which could result in unsupervised
use of vehicle equipment. Unsupervised use
of vehicle equipment could result in an
accident and/or serious personal injury.

486 Controls in detail
Useful features
Roadside Assistance button•
Press and hold Roadside Assistance
button • (for longer than
2 seconds).
A call to a Mercedes-Benz Roadside As-
sistance dispatcher will be initiated.
The button will flash while the call is in
progress. The message:

“Connecting call” appears in the
multifunction display

“Roadside Assistance Activated”
appears in the COMAND display
and the audio system is muted.
When the connection is established, the
message:

“Call connected” appears in the multi-
function display

“Roadside Assistance Activated”
appears in the COMAND display The Tele Aid system will transmit data gen-
erating the vehicle identification number,
model, color and location (subject to avail-
ability of cellular and GPS signals).
A voice connection between the Roadside
Assistance dispatcher and the occupants
of the vehicle will be established.
Describe the nature of the need for as-
sistance.
The Mercedes-Benz Roadside Assistance
dispatcher will either dispatch a qualified
Mercedes-Benz technician or arrange to
tow your vehicle to the nearest authorized
Mercedes-Benz Center. For services such
as labor and/or towing, charges may ap-
ply. Refer to the Roadside Assistance Man-
ual for more information.
These programs are only available in the
USA:

Sign and Drive services: Services such
as jump start, a few gallons of fuel or
the replacement of a flat tire with the
vehicle spare tire are obtainable.
iThe indicator lamp in the Roadside Assis-
tance button• remains illuminated in red for
approximately 10 seconds during the system
self-check after switching on the ignition (togeth-
er with the SOS button and the Information
button¡).
See system self-check (
page 483) if the indi-
cator lamp does not come on in red or stays on
longer than approximately 10 seconds.
If the indicator lamp in the Roadside Assistance
button• is flashing continuously and no
voice connection to the Response Center was
established, the Tele Aid system could not ini-
tiate a Roadside Assistance call (e.g. the relevant
mobile phone network is not available). The mes-
sage:

“Call failed” appears in the multifunction dis-
play for approximately 10 seconds

“Call could not be connected!” appears in
the COMAND display. Confirm the message
pressing
n (page 84).
Roadside Assistance calls can be terminated us-
ing button t on the multifunction steering
wheel or COMAND (
page 120).

525 Operation
Tires and wheels
1Seating capacity information on the
Tire and Loading Information placard
Steps for determining correct load limit
The following steps have been developed
as required of all manufacturers under
Title 49, Code of U.S. Federal Regulations,
Part 575 pursuant to the “National Traffic
and Motor Vehicle Safety Act of 1966”.
Step 1
Locate the statement “The combined
weight of occupants and cargo should
never exceed XXX kg or XXX lbs.” on
your vehicle’s Tire and Loading Infor-
mation placard.Step 2
Determine the combined weight of the
driver and passengers that will be
riding in your vehicle.
Step 3
Subtract the combined weight of the
driver and passengers from
XXX kilograms or XXX lbs.
Step 4
The resulting figure equals the avail-
able amount of cargo and luggage load
capacity. For example, if the “XXX”
amount equals 1400 lbs and there will
be five 150 lbs passengers in your
vehicle, the amount of available cargo
and luggage load capacity is 650 lbs
(1400 – 750 (5 x 150) = 650 lbs)
Step 5
Determine the combined weight of
luggage and cargo being loaded on the
vehicle. That weight may not safely
exceed the available cargo and luggage
load capacity calculated in step 4.Step 6 (if applicable)
If your vehicle will be towing a trailer,
load from your trailer will be trans-
ferred to your vehicle. Consult this
manual to determine how this reduces
the available cargo and luggage load
capacity of your vehicle (
page 527).
The following table shows examples on
how to calculate total and cargo load
capacities with varying seating configura-
tions and number and size of occupants.
The following examples use a load limit
of 1500 lbs. This is for illustration
purposes only. Make sure you are using
the actual load limit for your vehicle stated
on the vehicle’s Tire and Loading Informa-
tion placard (
page 524).

527 Operation
Tires and wheels
Certification label
Even after careful determination of the
combined weight of all occupants, cargo
and the trailer tongue load (if applicable)
(
page 527) as to not exceed the permis-
sible load limit, you must make sure that
your vehicle never exceeds the Gross Vehi-
cle Weight Rating (GVWR) and the Gross
Axle Weight Rating (GAWR) for either the
front or rear axle. You can obtain the
GVWR and GAWR from the certification
label. The certification label can be found
on the driver’s door B-pillar, see “Technical
data” (
page 674).Gross Vehicle Weight Rating (GVWR): The
total weight of the vehicle, all occupants,
all cargo, and the trailer tongue load
(
page 527) must never exceed the
GVWR.
Gross Axle Weight Rating (GAWR): The to-
tal allowable weight that can be carried by
a single axle (front or rear).
To assure that your vehicle does not ex-
ceed the maximum permissible weight
limits (GVWR and GAWR for front and rear
axle), have the loaded vehicle (including
driver, passengers and all cargo and, if
applicable, trailer fully loaded) weighed on
a suitable commercial scale.Trailer tongue load
The tongue load of any trailer is an impor-
tant weight to measure because it affects
the load you can carry in your vehicle. If a
trailer is towed, the tongue load must be
added to the weight of all occupants riding
and any cargo you are carrying in the
vehicle. The tongue load typically is
10 percent of the trailer weight and every-
thing loaded in it.
Your Mercedes-Benz has been designed
primarily to carry passengers and their
cargo. Mercedes-Benz does not recom-
mend trailer towing with your vehicle.

565 Practical hints
What to do if …?
Where will I find ...?
Unlocking/locking in an emergency
Opening/closing in an emergency
Replacing SmartKey batteries
Replacing bulbs
Replacing wiper blades
Flat tire
Batteries
Jump starting
Towing the vehicle
Fuses
