ContentsAt the gas station............................... 550
Refueling ...................................... 550
Check regularly and before a
long trip ........................................ 552
Engine compartment.......................... 553
Hood ............................................ 553
Engine oil...................................... 554
Transmission fluid level ................ 558
Active Body Control (ABC)
fluid level ...................................... 558
Coolant level ................................ 559
Windshield washer system and
headlamp cleaning system ........... 560
Tires and wheels ................................ 561
Important guidelines .................... 561
Tire care and maintenance ........... 562
Direction of rotation ..................... 564
Loading the vehicle ...................... 564
Recommended tire
inflation pressure ......................... 569
Checking tire inflation pressure ... 571
Tire labeling .................................. 577
Load identification........................ 581
DOT, Tire Identification Number
(TIN) ............................................. 581Maximum tire load ....................... 582
Maximum tire inflation pressure .. 583
Uniform Tire Quality Grading
Standards (U.S. vehicles) ............. 583
Tire ply material ........................... 585
Tire and loading terminology ........ 585
Rotating tires ............................... 589
Winter driving .................................... 590
Winter tires .................................. 590
Snow chains ................................. 591
Maintenance ...................................... 592
Maintenance service indicator
message....................................... 592
Calling up the maintenance
service indicator display............... 593
Resetting the maintenance
service indicator........................... 594
Vehicle care ....................................... 595
Cleaning and care of vehicle ........ 595
Practical hints................................. 607
What to do if …? ................................ 608
Lamps in instrument cluster ........ 608
Air bag off indicator lamp............. 620
Vehicle status messages in the
multifunction display.................... 622
Where will I find ...? ........................... 681
First aid kit ................................... 681
Vehicle jack, vehicle tool kit,
luggage bowl, Minispare wheel .... 681
Unlocking/locking in an emergency .. 684
Unlocking the vehicle................... 684
Locking the vehicle ...................... 685
Replacing SmartKey batteries ........... 686
Replacing bulbs ................................. 688
Bulbs ............................................ 689
Replacing bulbs for front lamps ... 691
Replacing bulbs for the
rear lamps .................................... 693
Replacing wiper blades ...................... 694
Placing wiper arms in
vertical position ........................... 694
Removing wiper blades ................ 695
Installing wiper blades ................. 695

104 Control systemsCOMAND satellite radioSubmenu overviewWarning!
G
Please devote your attention first and fore-
most to the traffic situation you are in.
Before your journey, please familiarize your-
self with the radio functions.
Only use the COMAND when road and traffic
conditions permit you to do so. Otherwise
you could be involved in an accident in
which you or others could be injured.
i
The components and operating principles of
COMAND can be found on (
page 83).
Sat Radio
Presets
Info
Category
Sound
Channel List
Station presets
Show program info
Select category
Treble
Save Channel
Bass
Channel Entry
Balance/Fader
Service
3D Sound

107 Control systems
COMAND satellite radio
Main satellite radio menu
1Main area with channel display
2Preset position of selected channel
3Selected channel
4Selected program category
5Sound settings
6To select program category
7Artist and song title
8Other channel information
9Preset options
aSatellite radio options
Selecting program category
Select “Audio”
“Audio”
“Sat Ra-
dio”
“Category”.
The category list appears.

Select category by rotating ymz or
slidingqmr and press n.
When selecting a channel using the
channel search function or the channel
list, you have access to the channels
you subscribe to and which are includ-
ed in the selected category.
i
Main area1 can show all channels includ-
ed in your subscription. Which channels are
shown depends on the selected program
category4.
Note that categories and channels shown in illus-
trations are dependent on programming content
delivered by the service provider. Programming
content is subject to change.
Therefore, channel and categories shown in illus-
trations and descriptions contained in this man-
ual may differ from the channels and categories
delivered by the service provider.
i
The channels are categorized. Categories al-
low you to tune to stations broadcasting a cer-
tain type of program.
i
If only the preview channel is activated, only
certain categories are available on the list. Which
categories these are depend on the service
provider.
i
When you select the category “All Chan-
nels”, you have access to all the channels you
subscribe to, regardless of category, when you
are tuning in a channel using the channel search
function or the channel list.

108 Control systemsCOMAND satellite radioTuning in channels
You have the following selection options:

The channel search function


The channel presets


The manual channel number entry


The channel list
Tuning in channels using channel
search function

Slide omp or rotate ymz when the
main area is selected.
Depending on the direction in which
the controller is being pressed or rotat-
ed, the system searches upward or
downward and stops at the next receiv-
able channel.Tuning in channels using channel
presets

Select “Audio”
“Audio”
“Sat Ra-
dio”
“Presets”.
or

Press n when the main area is select-
ed.
The preset menu appears. The dotR
in front of a preset position indicates
that this is the channel currently select-
ed and being listened to.

Select station preset and briefly
pressn.
or

Enter a position number with the tele-
phone keypad using digits 1 to 9
(page 86).
COMAND tunes in the corresponding
channel as long as it is included in your
subscription and is still available.
If the channel is not included in your sub-
scription, you will see the message de-
scribed in the section “Satellite radio
service is not activated” (
page 106).
i
This function is not possible when only the
preview channel is activated. If you try to tune in
a channel in this instance, you will see the
screen described in the section “Satellite radio
service is not activated” (
page 106).
i
Which channels are found by the channel
search function depends on which channels you
have subscribed to and the program category
you have selected (
page 107).

410 Controls in detailDriving and parking
For more information, see “Driving instruc-
tions” (
page 539).
Turn signalsCombination switch1Turn signals, right
2Turn signals, left
Press the combination switch in the
direction of arrow1 or2.
The corresponding turn signal indicator
lampL orK in the instrument
cluster flashes (
page 30).
The combination switch resets automati-
cally after major steering wheel move-
ments.
Warning!
G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced vehi-
cle control. Your vehicle’s ABS will not pre-
vent this type of loss of control.Warning!
G
It is dangerous to shift the gear selector le-
ver out of position P or N if the engine speed
is higher than idle speed. If your foot is not
firmly on the brake pedal, the vehicle could
accelerate quickly forward or in reverse. You
could lose control of the vehicle and hit
someone or something. Only shift into gear
when the engine is idling normally and when
your right foot is firmly on the brake pedal.
!
Shift the automatic transmission to
positionP or R only when the vehicle is stopped
in order to avoid damaging the transmission.
!
Do not run cold engine at high engine
speeds. Running a cold engine at high engine
speeds may shorten the service life of the en-
gine. This is not covered by the Mercedes-Benz
Limited Warranty
CL 63 AMG and CL 65 AMG only:
At engine temperatures below 68°F (20° C), the
maximum speed is restricted in order to protect
the engine. Avoid driving the vehicle at full speed
while the engine is cold in order to prevent pre-
mature engine wear as well as diminished com-
fort.
!
Simultaneously depressing the accelerator
pedal and applying the brakes reduces engine
performance and causes premature brake wear
and drivetrain wear which is not covered by the
Mercedes-Benz Limited Warranty.


593 Operation
Maintenance

To clear the maintenance service
indicator message: Press L
(page 283).
The maintenance service indicator
message is cleared and the standard
display appears in the multifunction
display (
page 286).Maintenance service term exceeded
If you have exceeded the suggested
maintenance service term, you will see the
following message in the multifunction
display:
“Service A Exceeded by XXX miles (km)
Service A Exceeded by XX days”
In addition, a signal sounds when the
message appears.
Any authorized Mercedes-Benz Center will
reset the maintenance service indicator
following a completed maintenance
service.Calling up the maintenance service
indicator display
You can call up the maintenance service in-
dicator display at any time to check when
the next maintenance service is due.
Switch on the ignition (
page 365).
The standard display of the control sys-
tem appears (
page 286).

Press ( or & on multifunction
steering wheel to select “Service”
menu.

Press % or $ to select the main-
tenance service indicator display.

Press #.
The service deadline appears in the
multifunction display.
i
The maintenance service indicator message
is automatically cleared


after approximately 10 seconds when you
switch on the ignition or when reaching the
service threshold while driving


after approximately 30 seconds, once the
suggested maintenance service term has
passed
You can also clear it yourself.
i
The menu overview can be found on
(
page 284).

594 OperationMaintenance
Resetting the maintenance service indicator
In the event that the maintenance service
on your vehicle is not carried out by an au-
thorized Mercedes-Benz Center, you can
have the maintenance service indicator re-
set. The automotive maintenance facility
carrying out the maintenance service will
find the information for resetting the main-
tenance service indicator in the mainte-
nance-relevant information for your
vehicle. Such information is available from
any authorized Mercedes-Benz Center or
directly from Mercedes-Benz.
i
If the battery is disconnected, the days of
disconnection will not be included in the count
shown by the maintenance service indicator.
To arrive at the true maintenance service dead-
line, you will need to subtract these days from
the days shown in the maintenance service indi-
cator message or maintenance service indicator
display.
i
If the maintenance service indicator was in-
advertently reset, have an authorized
Mercedes-Benz Center correct it.
Only reset if the proper maintenance service has
been performed. Resetting the system without
performing the proper service as called for by
the maintenance service indicator will result in
engine damage and/or other vehicle damage not
covered by the Mercedes-Benz Limited
Warranty.

754 IndexLighter see Cigarette lighter
Lighting 391
Automatic headlamp mode 392
COMAND display illumination 85
Corner-illuminating lamps 395
Courtesy lighting 399
Daytime running lamp mode 393
Door entry lamps 399
High beam flasher 395
Instrument cluster
illumination 434, 483
Interior 398
Low beam headlamps 392
Manual headlamp mode 392
Trunk 399
Limp-Home Mode 433
Loading see Vehicle loading
Locator lighting (COMAND) 261
Lock button
Door handle
(KEYLESS-GO*) 359, 405
Key, SmartKey 352
Key, SmartKey with
KEYLESS-GO* 356Locking 412
Automatic central locking
(COMAND) 263
Vehicle in an emergency 685
Locking knob 362
Loss of
Key, Mechanical 361
Key, SmartKey 361
Key, SmartKey with
KEYLESS-GO* 361
Service and Warranty Information
Booklet 721
Low beam headlamps 392
Replacing bulbs 689
Lowering
Vehicle 701
Lubricants 733
Lumbar support (COMAND) 277M
Maintenance 16, 592
Automatic Call (Tele Aid) 530
Calling up service indicator
display 593
Clearing service indicator
message 592
Maintenance System 592
Resetting service indicator 594
Service indicator message 592
Service term exceeded 593
Maintenance System 592
Manual headlamp mode 392
Manual shift program
(CL 63 AMG and CL 65 AMG)
Deactivating 432
MAXCOOL
Maximum cooling 496
Maximum load rating, Tires 586
Maximum loaded vehicle weight 570,
586
Maximum tire inflation pressure 583,
587
Maximum tire load rating 582
Memory function 385

758 IndexProgram mode selector switch
Automatic shift program 427
Proper use of the vehicle 20
PSI 587
Push-start see Tow-start
R
RACETIMER see Control system
instrument cluster menus, AMG
Radio
FM/AM operation (COMAND) 98
Saving stations, FM/AM
(COMAND) 102
Selecting satellite radio channel
(Instrument cluster control
system) 290
Selecting stations 289
Submenu overview, FM/AM
(COMAND) 98
Switching wavebands, FM/AM
(COMAND) 99
Tuning in stations/channels 99
Voice Control 329
Radio transmitters, control and
operation 547
Range (distance to empty) 287Reading lamps in the front 399
Real-time traffic (COMAND) 244
Rear fog lamp
Replacing bulbs 689
Rear lamps see Tail lamps
Rear seats
Adjustment 368
Folding back and placing upright
rear head restraints 377
Head restraints 376
Ventilation* 376
Rear side windows
Blocking operation 63
Rear View Camera* 477
Camera lens 478
Cleaning camera lens 602
Switching on 480
View through the camera 478
Rear view mirrors see Mirrors
Rear window defroster 496
Activating 496
Deactivating 496
Recommended inflation pressure 587
Recovery services, Stolen vehicle
(Tele Aid) 530Refrigerant, Air conditioning 735, 736
Refueling 550
Regular checks 552
Remote
Door lock with Tele Aid 529
Door unlock with Tele Aid 529
Remote control, SmartKey 352
Remote control, SmartKey with
KEYLESS-GO* 356
Replacing
Bulbs 688
Front lamp bulbs 691
Rear lamp bulbs 689
Reporting safety defects 22
Reset (COMAND) 259
Residual engine heat and ventilation 498
Restraint systems
Messages in display 673
See Children in the vehicle
See SRS
Reverse gear position, Automatic
transmission 417, 421
Rims 587
And Tires 727
Tires and wheels 561

760 Index
Lower speed in cruise control 441
Lower speed in
DISTRONIC Plus* 454
Slower speed in cruise control 441
Slower speed in DISTRONIC
Plus* 454
Speed in DISTRONIC Plus* 453
Suspension tuning (ABC) 461
Temperature (interior) 494
To last stored speed (“Resume”
function) in cruise control 442
To last stored speed in DISTRONIC
Plus* (“Resume” function) 455
Vehicle level control (ABC) 462
Setting current speed 439
Settings
Calling up DISTRONIC Plus* 448
Control system instrument cluster
menus 301
Daytime running lamp mode 301
Resetting trip odometer 287
Shelf below rear window, Cleaning and
care of 605
Shift program mode, Automatic
transmission 427Shifting, Automatic transmission 417
Side impact air bags 47
Side marker lamps
Cleaning lenses 599
Messages in display 667
Side windows see Power windows
Sidewall 587
SIRIUS Satellite Radio see Satellite radio
SmartKey see Key, SmartKey
SmartKey with KEYLESS-GO* see Key,
SmartKey with KEYLESS-GO*
SMS messages 178
Snow chains 591
Spare wheel 696, 730
Mounting 696
Speed
Setting current 439
Setting to last stored speed in
DISTRONIC Plus*
(“Resume” function) 455
Speed settings
Cruise control 440, 441
DISTRONIC Plus* 453, 454
To last stored speed (“Resume”
function) in Cruise control 442SRS 54
Indicator lamp 31, 617
Messages in display 673
Standing water, Driving through 546
Starter battery 704
Starter switch 365
Positions 365
Starting difficulties, Engine 408
Starting, Engine 406
Steering column 379
Steering wheel
Adjustment 379
Cleaning 605
Easy entry/exit feature 373
Heated steering wheel* 380
Power steering fluid 734
Steering wheel gearshift control
Automatic transmission 428
Stolen Vehicle Recovery services 530
Storage compartments 509
Cup holder 513
Front armrest 510
Parcel net 511
Rear armrest 512
Storage compartment in front
armrest 510
