41 CD operation
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings 10Turn to the right – raising the volume
Turn to the left – lowering the volume
11Press
briefly:
previous track, page 51
Press for longer than 2 seconds:
fast backward, page 55
12Press briefly:
next track, page 51
Press for longer than 2 seconds:
fast forward, page 55
13Press to mute CD audio, press again to cancel mute
function, page 62
14Requesting and displaying Info Services, page 208
Adjust system settings (brightness, language,
clock, day/night-display), page 211
15Color screen with main CD menu 1Switching the COMAND on/off, page 13
2Switching on CD operation (CD drive in the control
unit, CD changer), page 50
3CD drive:
Inserting an audio CD, page 44
Inserting a navigation CD, page 44
4Ejecting an audio CD, page 44
Ejecting a navigation CD, page 44
5Selecting tracks, page 51
Selecting CD’s, page 53
6Starting and ending the input mode for track
selection, page 52
7Press
briefly:
Deleting the character entered last, page 57
Press for longer than 2 seconds:
Deleting a complete name, page 57
8Return to previous menu
9Turn to highlight a function or a menu field,
Press to perform a function or activate a sub-menu
05-CD-20-US.pm507.06.2001, 11:55 Uhr 41

42 CD operation
AudioTelephone Navigation
Index Info Services and
system settings Introduction
Notes:
An 8-cm CD adapter may cause damage to the CD
changer and
should no
t be used.
Use only CDs which bear the label shown above. Load
the CD changer with 12-cm CDs only, do not use 8-cm
CDs. General information on CD playback
Warning!
The CD changer is a Class 1 laser product. There is
a danger of invisible laser radiation if the cover is
opened or damaged.
Do not remove the cover. The CD changer does not
contain any parts which can be serviced by the user.
For safety reasons, have any service work performed
only by qualified personnel.
05-CD-20-US.pm507.06.2001, 11:55 Uhr 42

43 CD operation
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings CD playback
Both the CD drive in the COMAND operating unit and
the CD changer with its magazine can be used to play
CDs.
In addition to audio CDs, the CD drive can also read in
the data on the navigation CD.
A total of 7 CDs can be loaded into the system (CD
drive and 6 slots in the magazine of the CD changer).
Loading a CD into the CD drive, page 44.
Loading CDs in the CD changer, page 45.The status line (page 49) indicates which component is
being used for CD playback.
05-CD-20-US.pm507.06.2001, 11:55 Uhr 43

44 CD operation
AudioTelephone Navigation
Index Info Services and
system settings Introduction
Loading a CD into the CD drive
P82.85-2718-26
1
2
1Eject button
2CD slot
Press (1) to eject an CD if necessary.Insert a CD as illustrated with the label facing up into
the CD drive (2) until it is automatically pulled in.
Notes:
Refer to page 65 for information on how to handle CDs.
Changing the navigation CD, page 137.
Important!
After changing a navigation CD the menu (page 137)
can appear. The program stored on the navigation
CD is loaded.
Do not interrupt the loading process. Do not insert
an audio CD until the loading process has been
completed.
05-CD-20-US.pm507.06.2001, 11:55 Uhr 44

45 CD operation
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings Loading CDs in the CD changer
P82.85-2086-26
P82.85-2087-26
The CD changer is in the trunk. It can accommodate up
to 6 CDs.
Open the sliding door by pushing in the direction of the
arrow indicated above. Push the door completely open
until it locks in the open position.Press the green eject button. The magazine will slide
upwards.
Note:
The magazine can be ejected even if COMAND is
switched off. However, the eject button will not function
if the battery is not connected or drained.
05-CD-20-US.pm507.06.2001, 11:55 Uhr 45

46 CD operation
AudioTelephone Navigation
Index Info Services and
system settings Introduction
P82.85-2088-26
Pull the disk tray forward until it stops.
Note:
Do not attempt to remove the tray from the magazine.Place a CD in the tray. The CD should be inserted with
the label side up.
P82.85-2890-26
05-CD-20-US.pm507.06.2001, 11:55 Uhr 46

47 CD operation
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings
P82.85-2891-26
1
P82.85-2991-26
3
2
Slide the magazine into the CD changer until it clicks
into place (listen for the click). Close the sliding door
(3) by pressing gently down on the door release button.
Spring pressure gently closes the door.
Note:
Make sure that the tip of the arrow on the side of the
magazine (1) is pointing in the direction of the arrow
(2).
Do not force the magazine into the changer. If the
magazine does not enter smoothly, please, check for
proper orientation of the magazine. Push the CD magazine into the magazine completely.
1Arrow tip on the rack wall
05-CD-20-US.pm507.06.2001, 11:55 Uhr 47

48 CD operation
AudioTelephone Navigation
Index Info Services and
system settings Introduction
Menu overview - CD operation
P82.85-7084-29
54
32
1
05-CD-20-US.pm507.06.2001, 11:55 Uhr 48

49 CD operation
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings 5Settings menu,
Selecting playback mode, page 60
Note:
The “Magazine Mix”, “CDs Scan” and “CD Repeat”
functions are not available for the CD drive.
6CD select menu,
Selecting tracks, page 51
Selecting CD’s, page 53 1Main CD menu
2Status line
CD 0: the CD drive is in operation
CD 1-6: the CD changer is in operation
The numbers 1-6 stand for the selected CD
magazine slot containing a playable audio CD.
3Main sound settings menu,
Adjust sound settings, page 69
4CD Naming menu,
Entering, altering and deleting CD names,
page 57
05-CD-20-US.pm507.06.2001, 11:55 Uhr 49

50 CD operation
AudioTelephone Navigation
Index Info Services and
system settings Introduction
P82.85-2978-26
3
2
1
Switching on CD operation
1CD function with the number of the magazine slot
currently playing:
CD changer: CD 1-6
2Track number and elapsed playback time, the
name of the CD may appear above this information
if the playing CD has been previously named by the
user
3Scan function and menu fields to activate menusPress
.
The main CD menu will appear on the screen.
When you switch to CD operation, he COMAND system
will check which component was used last (CD drive or
CD changer) and whether or not there are any CDs
inserted.
If there is no CD in the component last used, the
system will automatically switch to the other
component.
CD drive - playback will begin with the first track on
the CD
CD changer - playback will begin with the first track on
the first CD detected in the magazine
If the CD changer was used last, the following message
will appear: “CD loading” when the magazine is
changed.
Error messages, page 63.
05-CD-20-US.pm507.06.2001, 11:55 Uhr 50
