MERCEDES-BENZ CLK-Class 2006 C209 Comand Manual

129 Navigation*
Destination input
Selecting a destination using the map
Press c.
Push the joystick to H, h, g, G,
F, f.
or
Press the Map soft key, e.g. in the Start
route guidance menu (
page 133).
The map is shown in full view and
cross-hairs appear.
If soft key displays are hidden:
Press any soft key.
The soft key displays will appear.Available soft keys
POIs soft key:
Spotlight a POI if POIs are on the map
(
page 159).
Memory soft key:
Set a memory point and saved it in the
Last destinations memory
(
page 117).
Display soft key:
The Map view display will appear.
(
page 146).
Soft key +:
Enlarge visible map section.
Soft key ):
Reduce visible map section.
Back soft key:
Returns you to the previous menu.
i
The system automatically places the
cross-hairs on the current destination
address.
i
c was pressed:
If no soft key is selected within approx.
8 seconds, the soft key display will
disappear again.
i
The POIs, Memory and Display soft
keys are available if the
Map soft key
was pressed.

130 Navigation*
Destination input
Push the joystick to H, h, g, G
to move the cross-hairs.
Push the joystick to F or f to move
the cross-hairs diagonally.This allows you to select your destination.
Release the button.
If the system is able to assign a street
name to the selected location, it is
displayed on the status bar.
If a street name can not be assigned,
COMAND increases the zoom by one
increment each time E is pressed
until a street name can be selected.
Press E.
The system uses the point at the center
of the cross-hairs as destination.
The Start route guidance menu will
appear (
page 133).
i
If you press the Back soft key, your
selection will be discarded. The system
then uses the data of the previous
destination.
i
If a POI is close to the center of the
cross-hairs, a selection list will appear.
You can now select between a POI and
the address destination.

131 Navigation*
Destination input
Activate the Navigation main menu
(
page 114).
Press the Home soft key.
The message
No home address
available! Please enter home
address
will appear.
Press the Change soft key to edit a
home address.
or
The actual home address is shown.Here you can use the following
functions
changing to the map (page 129)
setting the routing mode
(
page 116)
editing home address (page 131)
starting route guidance
(
page 133)Editing home address
Press the Change soft key.
The Change home address menu will
appear.
You can use the following functions
selecting a destination from the
Destination memory (
page 154)
entering destination address
(
page 120)
Selecting home address

132 Navigation*
Destination input
selecting a destination from the Last
destinations memory (
page 152)
selecting a Point of Interest
(
page 156)
entering a POI by phone number
(
page 160)
selecting a destination from the
Today’s plan memory (
page 162)After entering the address the screen may
look as follows
Press E.
The home address is saved.
The Start route guidance menu will
appear (
page 133).

133 Navigation*
Route guidance

Route guidance
Route guidance can be started if the
destination input is complete and
Start
route guidance
is displayed at the
bottom of the main area.
Start route guidance menu
1Destination address
2Arrow indicates the direction to the
destination and the distance to the
destination (as the crow flies)
Press E.
Route calculation and route guidance
begins.
1Routing mode
Setting the routing mode (
page 116)
2Arrow indicate the direction of the
destination, the distance to destination
and
CALC RTE indication
3The road you are currently driving onRoute calculation can take some time,
depending on the distance to the
destination and the routing mode.
During route calculation, an arrow pointing
towards the destination, the distance to
the destination (as the crow flies) and
CALC RTE are displayed.
Route guidance begins when route
calculation is complete.
The system will calculate a new route
during active route guidance if the driver
does not follow the route guidance.
Starting route guidance
Route calculation
Recalculating an existing route

134 Navigation*
Route guidance
After route calculation, the system assists
route guidance using pictorial displays
(
page 135) and voice instructions. Repeating current voice instructions
If you have not understood a navigation
announcement, you can at any time have a
current announcement repeated.
Press j.
The current navigation announcement
is repeated.
Switching voice instructions On/Off
Switching off
Press J during a navigation
announcement.
The message
Voice announcements
muted
will appear briefly. Further route guidance takes place
using only the symbols in the display.
If a new route guidance cycle is started,
the announcements are automatically
switched on again.
Switching on again
Press j.
Voice instructions
WarningG
Voice instructions are intended to direct you
while driving without diverting your attenti-
on from the road and driving.
Always use this feature instead of consulting
the map display for directions. Consulting
the map displays for directions may cause
you to divert your attention from driving and
increase the risk of an accident.

135 Navigation*
Route guidance
The navigation displays are only visible
while route guidance is active.
To switch to the navigation display from
another display, e.g. from CD operation:
Press b or c.
Two examples are shown below:
Display example 1:The road you are currently driving on is
shown on the status bar, in this case
EAST I-90. The indication 571 mi is the
distance to the next driving maneuver.
If the GPS position display (
page 148) is
active, the GPS data are shown instead of
the street name.Important map symbols:
Current vehicle location and direction
of travel y
If the map orientation
Heading Up
(page 148) is chosen, the arrow will
always point upward.
The remaining route section is
highlighted in blue color.
Navigation displays
i
Using the control system, the display
unit can be changed between km or
miles (see your vehicle’s Operator’s
Manual).
When the instrument cluster
multifunction display is set to miles,
the COMAND will indicate
distances in miles (mi) or feet (ft).
When the instrument cluster
multifunction display is set to
kilometers, the COMAND will
indicate distances in kilometers
(km) or meters (m).
i
The colored highlight only appears
when the system has completed the
route calculation.

136 Navigation*
Route guidance
Display example 2:
1Current vehicle location and direction
of travel y, remaining route section
2Name of the road you are to turn onto
3Symbol for the next driving maneuver,
distance bar and distance to the next
driving maneuver
4The road you are currently driving onIn the right half of the display, the symbol
for the next driving maneuver is indicated
(here: right turn).
On the very right side of the display next to
the turn symbol is the distance bar. It
indicates the distance to the next driving
maneuver (here: 800 ft).
The status bar shows the name of the
street after the driving maneuver, if
available, here:
MAIN ST
The destination is marked with a flag $ on
the map, an intermediate destination is
marked with a flag showing the letter
S.
Press any soft key.
The soft key displays appear.
i
Using the control system, the display
unit can be changed between km or
miles (see your vehicle’s Operator’s
Manual).
When the instrument cluster
multifunction display is set to miles,
the COMAND will indicate
distances in miles (mi) or feet (ft).
When the instrument cluster
multifunction display is set to
kilometers, the COMAND will
indicate distances in kilometers
(km) or meters (m).
i
If no other action is taken within
approx. 8 seconds, the soft key
displays will disappear again.

137 Navigation*
Route guidance
Altering the map scale
The current map scale is indicated on the
left side of the status bar.
Press the + or ) soft key.
The map section is zoomed in or
zoomed out. A bar indicating the map
scale appears on the status bar.
Selecting map orientation
A symbol is shown on the bottom left side
of the status bar.
Heading Up <:
Dynamic map alignment, map is
displayed facing driving direction
pointing up
or
North Up Y:
Map is displayed facing northYou can select the map orientation
(
page 148).
Changing the map display
While route guidance is active, you can
switch between split view and full view.
Split view:
The map is shown on the left side and
information on the next maneuver on
the right.
or
Full view:
Full view of the map.
Press c.
The display changes with every push of
the button.When you reach the destination, you will
see the destination flag. Route guidance
ends.
i
If GPS display (page 148) is active,
information on your current position is
shown on the status bar.
Arriving at destination

138 Navigation*
Route guidance
In navigation mode, press b.
The inquiry menu
Cancel route
guidance?
will appear.
Press E to confirm Yes.
Route guidance is cancelled. The
Navigation main menu appears.Continuing route guidance
Push the joystick to h to select No.
Press E.
Cancelling route guidance
i
You can continue route guidance from
the Navigation main menu
(
page 114).
