MERCEDES-BENZ CLK COUPE 2001 A208 Comand Manual

Telephone
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings Telephone89 Accepting calls using COMAND
2“Call” – the system detects an incoming call, the
phone rings
If no telephone menu is shown on the screen press
if the phone is ringing. The above menu appears.Accepting a call:
Confirm the “Send” button by pressing the right-hand
rotary/pushbutton
. An audio source will switch to
mute.
Refusing a call, use one of the three ways:
• Press the right-hand rotary/pushbutton
to
confirm the “End” button
• Press
• Press
.
P82.85-6061-26
2

90 Telephone
Introduction AudioTelephone
Navigation
Index Info Services and
system settings
Ending a call, use one of the three ways:
• Press the right-hand rotary/pushbutton
to
confirm the “End” button
• Press
• Press
.
The main telephone menu will reappear.
Important!
If the menu of a different system is displayed on the
COMAND screen and/or the multifunction display, it is
possible to accept an incoming call by pressing
on
the steering wheel, page 96.
Note:
There is an incoming calls memory list. You can
activated the list by using the “Calls” menu field,
page 106. 3“00:01:21 h” – the call time appears
Switching the microphone for the hands-free telephone off:
Use the right-hand rotary/pushbutton
to highlight
the “Mute” button and confirm by pressing.
Volume set for hands-free operation:
Turn the left-hand rotary/pushbutton to the right
–
raising the volume
Turn the left-hand rotary/pushbutton to the left –
lowering the volume
P82.85-6062-26
3

Telephone
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings Telephone91 Accepting an incoming call using the mobile
telephone handset
The telephone is installed in the storage compartment
under the armrest, see your vehicle’s operating instruc-
tions.
Press the right-hand rotary/pushbutton
to confirm
the “Send” button.
Remove the telephone from its cradle and conduct your
call. Hands-free operation will switch off.
Ending a call:
Put the phone back in its mount.
Warning!
Please be sure to pay attention to the traffic
situation at all times. Use the mobile telephone
1
only when the traffic situation allows.
Some jurisdictions prohibit the driver from using
a cellular telephone while driving a vehicle.
Whether or not prohibited by law, for safety
reasons, the driver should not use the cellular
telephone while the vehicle is in motion. Stop the
vehicle in a safe location before answering or
placing a call.1 Observe all legal requirements.

92 Telephone
Introduction AudioTelephone
Navigation
Index Info Services and
system settings
Dialing a telephone number
Entering a telephone number
Press
. The main telephone menu will appear.
Enter the telephone number with the number keys
through
. The menu will change when the first digit
is entered.
Correcting input:
• Press
briefly – the last digit will be corrected
• Press longer than 2 seconds – the whole entry
will be corrected. Outgoing calls
You can use the following functions:
• Dialing a telephone number, page 92
• Dialing a number from phone book, page 95
• Redial, page 102
• Dialing from calls list, page 106
• Speed-dialing (only with COMAND), page 107
• Quick-dialing (for the first 10 memory locations),
page 109
• Emergency call, page 122
P82.85-6063-26

Telephone
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings Telephone93 Begin dialing
1If the number together with a name is stored in the
phone book, the name is displayed on the screen
after the “Send” button is pressed.
When the “Send” button is highlighted, press the right-
hand rotary/pushbutton
and confirm your entry.
Dialing will begin. The “End” button is highligted.
An active audio source will automatically be muted.Interrupt dialing, use one of the three ways:
• Press the right-hand rotary/pushbutton
to
confirm the “End” button
• Press
• Press
.
P82.85-6064-26
1

94 Telephone
Introduction AudioTelephone
Navigation
Index Info Services and
system settings
Conducting a callSubsequent dialing:
During a call you can press the number keys
through
,
and
to transmit other DTMF tones.
The numbers dialed will appear in the menu for
10 seconds after the last key is pressed (subsequent
dialing display).
When the call is answered, the call time will appear on
the screen.
Ending a call, use one of the three ways:
• Press the right-hand rotary/pushbutton
to
confirm the “End” button or call has been finished
by the other party
• Press
• Press
.
P82.85-6065-26

Telephone
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings Telephone95 Dialing a number from the phone book
Dialing using the multifunction steering wheel
In order to use this feature, the phone book must have
previously been downloaded to the COMAND memory.
This is performed automatically each time the portable
phone is connected to the coiled cord.
The telephone is ready for operation, page 87.
Press
or
as often as necessary until the
telephone mode appears in the multifunction display.
If the display ENTER CODE appears, enter the unlock
code first, page 86.
Message NO ENTRY will appear when the portable
phone has been put into the cradle and no entries are
stored in the phone book.Press
or
, to page forwards or backwards
through the redial memory in alphabetical order.
If
or
is pressed for longer than 2 seconds,
the phone book is scrolled through very quickly.
The name selected will appear in the display.
Note:
If you do not wish to place a call, press
.
The process will be cancelled and the message READY
will appear.
P82.85-6053-21

96 Telephone
Introduction AudioTelephone
Navigation
Index Info Services and
system settings
Press
, when the name you want is displayed.
The number will be dialed.
DIALING will appear in the display. The current audio
source will be muted automatically.
After dialing has been completed, the name will
reappear. It will remain in the display for the duration
of the phone call.
Press to end the call.
The message READY will appear. The audio source will
switch on again.
Press or
to display the next or previous
system.Notes:
Numbers are stored in the telephone book according to
memory locations; a memory location starts with “M”.
Memory locations available: M01-M99
P82.85-6054-21

Telephone
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings Telephone97 Dialing using COMAND
Phone book, names:
To access the phone book in the main telephone menu:
Use the right-hand rotary/pushbutton
to highlight
menu field (2) and press it to confirm.1Input line is empty – activates the “Phone book”
selection menu, page 98
When up to 3 letters are entered in the input line
the relevant page of the “Phone book” (names) will
be opened, page 98.
Use the right-hand rotary/pushbutton
to
highlight the letters one after the other and press
to confirm. The letters will be entered in the input
line.
2Activates the “Phone book” selection menu or
opens the phone book (names).
Note:
The phone book will also be opened if the right-hand
rotary/pushbutton
is pressed for longer than
2 seconds after input of the last letter.
P82.85-6066-26
1
2

98 Telephone
Introduction AudioTelephone
Navigation
Index Info Services and
system settings
The relevant page of the phone book will be accessed
after input of up to 3 letters in the telephone main
menu.
4Marked entry, sorted alphabetically
5Symbol, page back in the list
6Symbol, page forward in the list
Note:
The phone book stored in the phone is memory being
read downloaded. Use the right-hand rotary/pushbutton
to highlight the desired entry and press to confirm. The “Phone book” selection menu will be activated.
3Opens the first page of the phone book (names)
Press the right-hand rotary/pushbutton
and confirm
the marked menu field “Read phone book”. The phone
book will be opened.
Select the desired entry, see information on the right.P82.85-6067-26
3
P82.85-6068-26
4
56
