load capacity MERCEDES-BENZ CLK320 2001 A208 Owner's Manual

160 Interior equipment
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Fold down:
Pull locking handle and fold backrest forward.
Set up:
Pull backrest up until it locks in its upright position.
Check for secure locking by pushing and pulling on the
backrest.
Note:
To prevent unauthorized persons from access to the
trunk, always lock backrest in its upright position.Loading instructions
The total load weight including vehicle occupants and
luggage/cargo should not exceed the vehicle capacity
weight indicated on the certification label which can be
found on the left door pillar.
The handling characteristics of a fully loaded vehicle
depend greatly on the load distribution. It is therefore
recommended to load the vehicle according to the
illustrations shown, with the heaviest items being
placed towards the front of the vehicle.
Wa r n i n g !
Always lock backrest in its upright position when
rear seat bench is occupied by passengers, cargo is
being carried in the trunk, or the extended cargo
area is not in use.
P82.55-2002-26

266 Battery
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hintsCar care Index
If a tire constantly loses air, it should be inspected for
damage.
The spare tire should be checked periodically for
condition and inflation. Spare tire will age and become
worn over time even if never used, and thus should be
inspected and replaced when necessary.Battery
Important!
Battery replacement information:
The maintenance-free battery is located in the trunk
under the trunk floor.
The service life of the battery is dependent on its
condition of charge. The battery should always be kept
sufficiently charged, in order to last an optimum length
of time.
Wa r n i n g !
Do not overinflate tires. Overinflating tires can
result in sudden deflation (blowout) because they
are more likely to become punctured or damaged
by road debris, potholes etc.. Follow recommended
inflation pressures.Do not overload the tires by exceeding the specified
vehicle capacity weight (as indicated by the label
on the driver’s door latch post). Overloading the
tires can overheat them, possibly causing a
blowout.
Wa r n i n g !
Failure to follow these instructions can result in
severe injury or death.Never lean over batteries while connecting, you
might get injured.Battery fluid contains sulfuric acid. Do not allow
this fluid to come in contact with eyes, skin or
clothing. In case it does, immediately flush affected
area with water and seek medical help if necessary.A battery will also produce hydrogen gas, which is
flammable and explosive. Keep flames or sparks
away from battery, avoid improper connection of
jumper cables, smoking etc..

310 Index
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
Basic setting .............................................................. 122
Defogging windows .................................................. 123
Defrosting ................................................................... 123
Display and controls ................................................. 122
Dust filter ................................................................... 126
Economy ..................................................................... 123
Rear window defroster ............................................. 124
Residual engine heat utilization (REST) ............... 125
Special settings ......................................................... 123
Automatic transmission ............................................... 191
Emergency Operation .............................................. 199
Fluid level ...................................................................252
Program mode selector switch ............................... 198
Selector lever position .............................................. 194
Transmission selector lever,
manually unlocking .............................................272
BBabySmart
TM airbag deactivation system ..................... 64
Self-test ......................................................................... 64
Backrest, front seat .......................................................... 53
BAS (Brake assist system) ............................................ 213
Malfunction indicator lamp .....................................229Battery ............................................................................ 266
Battery recycling ...................................................... 267
BATTERY/ALTERNATOR - malfunction
and warning messages ............................................ 233
Block heater ................................................................... 209
BRAKE ASSIST - malfunction
and warning messages ............................................ 234
Brake assist system (BAS) ............................................ 213
Malfunction indicator lamp .................................... 229
Brake fluid ....................................................202, 302, 303
Capacity ..................................................................... 302
BRAKE FLUID - malfunction
and warning messages ............................................ 235
BRAKE LINING WEAR - malfunction
and warning messages ............................................ 235
Brake pad wear .............................................................. 235
Brake warning lamp ..................................................... 227
Brake fluid low ......................................................... 227
Brakes .................................................... 200, 202, 213, 217
CCapacities
Fuels, coolants, lubricants etc. .............................. 302
Cargo area ....................................................................... 159
Loading instructions ................................................. 160
