Index
....................................................... 4Introduction .........................................
21 At a glance
........................................... 27 Safety ...................................................
37 Opening/closing
................................. 73 Seats, steering wheel and mirrors ....
95 Lights and windshield wipers
..........109 Climate control
................................. 123 Driving and parking ..........................
137 On-board computer and displays
....207 Stowage and features ......................
269 Maintenance and care
......................297 Breakdown assistance
.....................311 Wheels and tires ...............................
325 Technical data ...................................
363 Contents
3

1, 2, 3 ...
12 V socket see Sockets

4ETS
see ETS/4ETS (Electronic
Traction System)
4MATIC (permanent four-wheel
drive) .................................................. 183
4MATIC off-road system ................... 183A
ABS (Anti-lock Braking System) Display message

............................ 229
Function/notes ................................ 64
Important safety notes .................... 64
Warning lamp ................................. 258
Activating/deactivating cooling
with air dehumidification ................. 128
Active Blind Spot Assist Activating/deactivating (on-
board computer) ............................ 219
Display message ............................ 245
Function/information .................... 199
Active Driving Assistance package . 199
Active Lane Keeping Assist Activating/deactivating (on-
board computer) ............................ 219
Display message ............................ 244
Function/information .................... 203
Active light function .........................115
Active multicontour seat ..................100
Active Parking Assist Display message ............................ 245
Important safety notes .................. 186
Active Service System
see ASSYST PLUS
ADAPTIVE BRAKE ................................. 69
Adaptive Highbeam Assist Display message ............................ 239
Function/notes ............................. 115
Switching on/off (on-board
computer) ...................................... 221
Additives (engine oil) ........................369Air bags
Display message
............................ 235
Front air bag (driver, front
passenger) ....................................... 42
Important safety notes .................... 41
Knee bag .......................................... 43
PASSENGER AIR BAG OFF
indicator lamp .................................. 45
Pelvis air bag ................................... 44
Safety guidelines ............................. 40
Side impact air bag .......................... 43
Window curtain air bag ....................45
Air-conditioning system
see Climate control
AIR FLOW ........................................... 129
AIRMATIC Display message ............................ 243
Function/notes ............................. 180
Air vents
Glove box ....................................... 134
Important safety notes .................. 133
Rear ............................................... 135
Setting ........................................... 133
Setting the center air vents ...........134
Setting the side air vents ............... 134
Alarm system
see ATA (Anti-Theft Alarm system)
Ambient lighting
Setting the brightness (on-board
computer) ...................................... 221
Setting the color (on-board
computer) ...................................... 221
AMG adaptive sport suspension
system ................................................ 182
Anti-lock braking system
see ABS (Anti-lock Braking System)
Anti-theft alarm system
see ATA (Anti-Theft Alarm system)
Ashtray ............................................... 279
Assistance menu (on-board
computer) .......................................... 217
ASSYST PLUS Displaying a service message ........ 302
Hiding a service message .............. 302
Notes ............................................. 302
Resetting the service interval
display ........................................... 3024
Index

Service message ............................ 302
Special service requirements .........
302
ATA (Anti-Theft Alarm system)
Activating/deactivating ................... 71
Function ........................................... 71
Switching off the alarm .................... 71
ATTENTION ASSIST
Activating/deactivating ................. 218
Display message ............................ 242
Function/notes ............................. 191
Audio system
see separate operating instructions
Authorized Centers
see Qualified specialist workshop
Authorized Mercedes-Benz Center
see Qualified specialist workshop
Authorized workshops
see Qualified specialist workshop
AUTO lights
Display message ............................ 238
see Lights
Automatic engine start (ECO start/
stop function) .................................... 144
Automatic engine switch-off (ECO
start/stop function) .......................... 143
Automatic headlamp mode ..............111
Automatic transmission Automatic drive program ............... 150
Changing gear ............................... 149
DIRECT SELECT lever .....................146
Display message ............................ 251
Drive program display ....................147
Driving tips .................................... 149
Emergency running mode ..............154
Engaging drive position .................. 148
Engaging neutral ............................ 148
Engaging park position (AMG
vehicles) ........................................ 147
Engaging reverse gear ................... 147
Engaging the park position ............ 147
Kickdown ....................................... 149
Manual drive program ....................152
Overview ........................................ 146
Problem (malfunction) ...................154
Program selector button ................149
Pulling away ................................... 141
Selector lever ................................ 146
Shift ranges ................................... 151Starting the engine ........................
141
Steering wheel paddle shifters ......150
Transmission position display ........ 146
Transmission position display
(DIRECT SELECT lever) ................... 147
Transmission positions .................. 148
Automatic transmission
emergency mode ............................... 154 B
Backup lamp Changing bulbs

.............................. 120
Bag hook ............................................ 275
BAS (Brake Assist System) ................. 64
BAS PLUS (Brake Assist System
PLUS) .................................................... 65
Battery (SmartKey) Checking .......................................... 77
Important safety notes .................... 77
Replacing ......................................... 77
Battery (vehicle)
Charging ........................................ 316
Display message ............................ 241
Important safety notes .................. 314
Jump starting ................................. 317
Blind Spot Assist
Activating/deactivating ................. 219
Display message ............................ 245
Notes/function .............................. 195
see Active Blind Spot Assist
Bottle holder ...................................... 277
Brake Assist see BAS (Brake Assist System)
Brake fluid
Display message ............................ 231
Notes ............................................. 369
Brake lamps
Display message ............................ 237
Brakes
ABS .................................................. 64
BAS .................................................. 64
BAS PLUS ........................................ 65
Brake fluid (notes) .........................369
Display message ............................ 229
Driving tips .................................... 162
High-performance brake system .... 163
Important safety notes .................. 162 Index
5

Maintenance
.................................. 162
Parking brake ................................ 158
Warning lamp .................................
257
Breakdown
see Flat tire
see Towing away
Bulbs
see Changing bulbs C
California Important notice for retail
customers and lessees ....................22
Calling up a malfunction
see Display messages


Car
see Vehicle
Care
Carpets .......................................... 309
Car wash ........................................ 303
Display ........................................... 307
Exterior lights ................................ 306
Gear or selector lever ....................309
Interior ........................................... 307
Matte finish ................................... 305
Night View Assist Plus ...................308
Notes ............................................. 303
Paint .............................................. 305
Plastic trim .................................... 308
Power washer ................................ 304
Rear view camera .......................... 307
Roof lining ...................................... 309
Seat belt ........................................ 309
Seat cover ..................................... 309
Sensors ......................................... 307
Steering wheel ............................... 309
Tail pipes ....................................... 307
Trim pieces .................................... 309
Washing by hand ........................... 304
Wheels ........................................... 306
Windows ........................................ 306
Wiper blades .................................. 306
Wooden trim .................................. 309
Cargo tie down rings .........................274
Car wash (care) ................................. 303
CD player/CD changer (on-board
computer) .......................................... 215Center console
Lower section .................................. 33
Lower section (AMG vehicles) ..........34
Upper section .................................. 32
Central locking
Automatic locking (on-board
computer) ...................................... 222
Locking/unlocking (SmartKey)

........75
Changing bulbs
Important safety notes .................. 119
Overview of bulb types ..................119
Reversing lamps ............................ 120
Child-proof locks
Important safety notes .................... 62
Rear doors ....................................... 63
Children
In the vehicle ................................... 58
Restraint systems ............................ 58
Special seat belt retractor ............... 60
Child seat
LATCH-type (ISOFIX) child seat
anchors ............................................ 61
Top Tether ....................................... 61
Cigarette lighter ................................ 280
Cleaning Mirror turn signal ........................... 307
Climate control
Automatic climate control (3-
zone) .............................................. 127
Controlling automatically ...............129
Cooling with air dehumidification ..128
Defrosting the windows ................. 132
Defrosting the windshield .............. 131
Dual-zone automatic climate
control ........................................... 125
Important safety notes .................. 124
Indicator lamp ................................ 129
Information on using 3-zone
automatic climate control .............. 128
Maximum cooling .......................... 131
Notes on using automatic climate
control ........................................... 126
Overview of systems ......................124
Problems with cooling with air
dehumidification ............................ 129
Problem with the rear window
defroster ........................................ 132
Rear control panel .........................1276
Index

Engine ............................................ 239
General notes ................................
228
Hiding (on-board computer) ........... 228
KEYLESS-GO
.................................. 254
Lights ............................................. 236
Safety systems .............................. 229
SmartKey ....................................... 253
Tires ............................................... 248
Vehicle ........................................... 251
Distance display (on-board
computer) .......................................... 217
Distance recorder see Trip odometer
Distance warning (warning lamp) ....266
DISTRONIC PLUS Deactivating ................................... 176
Display message ............................ 246
Displays in the multifunction
display ........................................... 175
Function/notes ............................. 167
Important safety notes .................. 167
Setting the specified minimum
distance ......................................... 174
Warning lamp ................................. 266
Doors
Automatic locking (on-board
computer) ...................................... 222
Automatic locking (switch) ............... 81
Central locking/unlocking
(SmartKey) ....................................... 75
Control panel ................................... 36
Display message ............................ 252
Emergency locking ........................... 82
Emergency unlocking .......................82
Important safety notes .................... 80
Opening (from inside) ......................81
Drinking and driving .........................160
Drinks holder see Cup holder
Drive program
Automatic ...................................... 150
Display ........................................... 146
Display (DIRECT SELECT lever) ...... 147
Manual ........................................... 152
SETUP (on-board computer) .......... 225
Drive program selector ..................... 150
Driver's door see Doors Driving abroad
Mercedes-Benz Service ................. 303
Symmetrical low beam .................. 110
Driving on flooded roads ..................164
Driving safety systems ABS (Anti-lock Braking System) ....... 64
ADAPTIVE BRAKE ............................. 69
BAS (Brake Assist System) ..............64
BAS PLUS (Brake Assist System
PLUS) ............................................... 65
Electronic brake force distribution ... 69
ESP ®
(Electronic Stability
Program) .......................................... 66
ETS/4ETS (Electronic Traction
System) ........................................... 66
Important safety information ........... 63
Overview .......................................... 63
PRE-SAFE ®
Brake ............................. 69
Driving systems
Active Blind Spot Assist ................. 199
Active Driving Assistance
package ......................................... 199
Active Lane Keeping Assist ............ 202
Active Parking Assist .....................186
AIRMATIC ...................................... 180
AMG adaptive sport suspension
system ........................................... 182
ATTENTION ASSIST ........................ 191
Blind Spot Assist ............................ 195
Cruise control ................................ 165
Display message ............................ 242
DISTRONIC PLUS ........................... 167
HOLD function ............................... 178
Lane Keeping Assist ...................... 197
Lane Tracking package .................. 195
Night View Assist Plus ...................192
PARKTRONIC ................................. 183
RACE START (AMG vehicles) ..........179
Rear view camera .......................... 189
Driving tips
AMG ceramic brakes ..................... 163
Automatic transmission ................. 149
Brakes ........................................... 162
Break-in period .............................. 138
Downhill gradient ........................... 162
Drinking and driving .......................160
Driving abroad ............................... 1108
Index

Lane Keeping Assist
Activating/deactivating .................219
Display message ............................ 244
Function/information .................... 197
Lane Tracking package .....................195
Lap time (RACETIMER) ......................225
LATCH-type (ISOFIX) child seat
anchors ................................................ 61
Light function, active Display message ............................ 238
Lights
Activating/deactivating the
interior lighting delayed switch-off . 222
Active light function .......................115
Automatic headlamp mode ............ 111
Cornering light function .................114
Driving abroad ............................... 110
Hazard warning lamps ................... 114
High beam flasher .......................... 114
High-beam headlamps ...................113
Light switch ................................... 110
Low-beam headlamps .................... 112
Parking lamps ................................ 112
Setting the brightness of the
ambient lighting (on-board
computer) ...................................... 221
Setting the brightness of the
display/switch (on-board
computer) ...................................... 220
Setting the color of the ambient
lighting (on-board computer) ......... 221
Standing lamps .............................. 112
Switching Adaptive Highbeam
Assist on/off ................................. 221
Switching the daytime running
lamps on/off (on-board
computer) ...................................... 221
Switching the exterior lighting
delayed switch-off on/off (on-
board computer) ............................ 221
Switching the surround lighting
on/off (on-board computer) ..........221
Turn signals ................................... 113
see Changing bulbs
see Interior lighting
Light sensor (display message) .......238
Loading guidelines ............................270Locking
see Central locking
Locking (doors)
Automatic ........................................ 81
Emergency locking ........................... 82
From inside (central locking
button) ............................................. 81
Locking centrally
see Central locking
Locking verification signal (on-
board computer) ............................... 222
Low-beam headlamps Display message ............................ 236
Setting for driving abroad
(symmetrical) ................................. 110
Switching on/off ........................... 112
Lumbar support
Adjusting the 4-way lumbar
support .......................................... 101
Luxury head restraints .......................99 M
M+S tires ............................................ 328
Malfunction message see Display messages


Massage function (PULSE) ...............101
Matte finish (cleaning
instructions) ...................................... 305
mbrace Call priority .................................... 286
Display message ............................ 232
Downloading destinations
(COMAND) ..................................... 287
Downloading routes .......................290
Emergency call .............................. 284
Geo fencing ................................... 290
Important safety notes .................. 282
Locating a stolen vehicle ............... 289
MB info call button ........................ 286
Remote vehicle locking .................. 288
Roadside Assistance button .......... 285
Search & Send ............................... 287
Self-test ......................................... 283
Speed alert .................................... 290
System .......................................... 283
Triggering the vehicle alarm ........... 291 12
Index

Vehicle submenu ...........................
222
Video DVD operation ..................... 216
Operating system
see On-board computer

Outside temperature display ...........210
Overhead control panel ......................35
Override feature Rear side windows ........................... 63P
Paint code number ............................ 365
Paintwork (cleaning instructions) ...305
Panic alarm .......................................... 38
Parking ............................................... 157
Important safety notes

..................157
Parking brake ................................ 158
Position of exterior mirror, front-
passenger side ............................... 106
Rear view camera .......................... 189
see PARKTRONIC
Parking aid
Active Parking Assist .....................186
see Exterior mirrors
see PARKTRONIC
Parking brake
Display message ............................ 231
Notes/function .............................. 158
Warning lamp ................................. 263
Parking lamps
Switching on/off ........................... 112
PARKTRONIC
Deactivating/activating ................. 185
Driving system ............................... 183
Function/notes ............................. 183
Important safety notes .................. 183
Problem (malfunction) ...................186
Range of the sensors ..................... 184
Warning display ............................. 185
PASSENGER AIR BAG OFF indicator
lamp ...................................................... 45
Pedals ................................................. 160
Plastic trim (cleaning instructions) . 308
Power washers .................................. 304
Power windows see Side windows PRE-SAFE
®
(anticipatory occupant
protection) Display message

............................ 232
Operation ......................................... 52
PRE-SAFE ®
Brake
Activating/deactivating ................. 218
Display message ............................ 232
Function/notes ................................ 69
Warning lamp ................................. 266
Preventive occupant safety
system
see PRE-SAFE ®
(anticipatory
occupant protection)
Product information ............................21
Program selector button .................. 149
Pulling away (automatic
transmission) ..................................... 141 Q
Qualified specialist workshop ...........24 R
RACE START (AMG vehicles) .............179
RACETIMER (on-board computer) .... 225
Radar sensor system Activating/deactivating

.................223
Display message ............................ 243
Radio
Selecting a station .........................215
see separate operating instructions
Reading lamp ..................................... 117
Rear axle level control (AMG
adaptive sport suspension
system) .............................................. 182
Rear compartment Setting the air vents ......................135
Rear seat
Display message ............................ 252
Rear seat (folding the backrest
forwards/back) ................................. 273
Rear view camera Cleaning instructions ..................... 307
Function/notes ............................. 189
Switching on/off ........................... 190
Rear-view mirror
Dipping (automatic) .......................10614
Index

Cockpit
Function Page
:
Steering wheel paddle
shifters
150
;
Cruise control lever 165
=
Instrument cluster 29
?
Horn
A
DIRECT SELECT lever 146
B
PARKTRONIC warning
display
183
C
Overhead control panel 35
D
Climate control systems 124
E
Ignition lock 139
Start/Stop button
139 Function Page
F
Adjusting the steering
wheel
103
Steering wheel heating 103
G
Combination switch 113
H
Parking brake 158
I
Diagnostics connection 23
J
Opening the hood 298
K
Releasing the parking brake 158
L
Light switch 110
M
Night View Assist Plus 19228
CockpitAt a glance

BAS PLUS (Brake Assist System Plus)
i Observe the "Important safety notes"
section ( Y page 63).
BAS PLUS is only available in vehicles
equipped with DISTRONIC PLUS.
BAS PLUS provides braking assistance in
hazardous situations at speeds greater than
4 mph (7 km/h) and uses radar sensor
technology to assess the traffic situation.
With
the help of the radar sensor system, BAS
PLUS can detect obstacles that are in the
path of your vehicle for an extended period of
time.
BAS PLUS can also react to stationary
obstacles, e.g. stopped or parked vehicles, at
speeds of up to approximately 40 mph
(70 km/h).
To prevent a front-end collision, BAS PLUS
calculates the brake force necessary if:
R you approach an obstacle, and
R BAS PLUS has detected a risk of collision
For speeds above 20 mph (30 km/h): if you
apply the brakes forcefully, BAS PLUS
automatically increases the braking force to
a level suitable for the traffic conditions.
For speeds below 20 mph (30 km/h): if you
apply the brakes, BAS PLUS is activated.
Braking is performed as late as possible.
If BAS PLUS demands particularly high
braking force, preventative passenger
protection measures (PRE-SAFE ®
) are
activated simultaneously.
X Keep the brake pedal depressed until the
emergency braking situation is over.
ABS prevents the wheels from locking.
BAS PLUS is deactivated and the brakes
function as usual, if:
R you release the brake pedal.
R there

is no longer any danger of a rear-end
collision.
R no obstacle is detected in front of your
vehicle. For BAS PLUS to assist you when driving, the
radar sensor system must be:
R
switched on (Y page 223)
R operational ( Y page 243)
If the radar sensor system is malfunctioning,
BAS PLUS will not be available. The brake
system is still available with complete brake
boosting effect and BAS. G
WARNING
BAS PLUS cannot always clearly identify
objects and complex traffic situations. BAS
PLUS cannot intervene in these cases. There
is a risk of an accident.
Always pay careful attention to the traffic
situation and be ready to brake.
In particular, the detection of obstacles can
be impaired if there is:
R dirt on the sensors or anything else
covering the sensors
R snow or heavy rain
R interference by other radar sources
R the possibility of strong radar reflections,
for example in parking garages
R a narrow vehicle traveling in front, e.g. a
motorbike
R a

vehicle traveling in front on a different line
relative to the center of your vehicle G
WARNING
BAS PLUS does not react:
R to people or animals
R to oncoming vehicles
R to crossing traffic
R when cornering
As

a result, BAS PLUS may not intervene in all
critical situations. There is a risk of an
accident.
Always pay careful attention to the traffic
situation and be ready to brake.
Following damage to the front end of the
vehicle, have the configuration and operation
of the radar sensors checked at a qualified Driving safety systems
65
Safety Z

specialist workshop. This also applies to
collisions at low speeds where there is no
visible damage to the front of the vehicle.
i
This
device has been approved by the FCC
as a "Vehicular Radar System". The radar
sensor is intended for use in an automotive
radar system only. Removing, altering or
tampering with the device will void any
warranties, and is not permitted by the
FCC. Do not tamper with, alter, or use the
device in any non-approved way.
Any unauthorized modification to this
device could void the user's authority to
operate the equipment. ESP
®
(Electronic Stability Program)
Important safety notes i
Observe the "Important safety notes"
section ( Y page 63).G
WARNING
If ESP ®
is malfunctioning, ESP ®
is unable to
stabilize the vehicle. Additionally, further
driving safety systems are deactivated. This
increases

the risk of skidding and an accident.
Drive on carefully. Have ESP ®
checked at a
qualified specialist workshop.
! Vehicles with 4MATIC: switch off the
ignition when the parking brake is being
tested on a brake dynamometer.
Application of the brakes by ESP ®
may
otherwise destroy the brake system.
Vehicles without 4MATIC: when towing your
vehicle with the rear axle raised, it is
important that you observe the notes on
ESP ®
(Y page 320).
ESP ®
is deactivated if the å warning lamp
in the instrument cluster lights up
continuously when the engine is running.
If the ÷ warning lamp and the å
warning lamp are lit continuously, ESP ®
is not
available due to a malfunction. Observe the information on warning lamps
(Y page 260) and display messages which
may be shown in the instrument cluster
(Y page 229).
If ESP
®
detects that the vehicle is deviating
from the direction desired by the driver, one
or more wheels are braked to stabilize the
vehicle.

The engine output is also modified to
keep the vehicle on the desired course within
physical limits. ESP ®
assists the driver when
pulling away on wet or slippery roads. ESP ®
can also stabilize the vehicle during braking.
If ESP ®
intervenes, the ÷ ESP®
warning
lamp flashes in the instrument cluster.
If ESP ®
intervenes:
X Do not deactivate ESP ®
under any
circumstances.
X Only depress the accelerator pedal as far
as necessary when pulling away.
X Adapt your driving style to suit the
prevailing road and weather conditions.
i Only use wheels with the recommended
tire sizes. Only then will ESP ®
function
properly.
ETS/4ETS (Electronic Traction System) Traction control is part of ESP
®
.
Traction control brakes the drive wheels
individually if they spin. This enables you to
pull

away and accelerate on slippery surfaces,
for example if the road surface is slippery on
one side. On vehicles with 4MATIC, more
drive torque is also transferred to the wheel
or wheels with traction.
Traction control remains active if you
deactivate ESP ®
. 66
Driving safety systems
Safety
