MERCEDES-BENZ CLS500 2008 W219 Owner's Manual

130 Controls in detail
Lighting
Combination switch
Combination switch
1High beam
2High beam flasherHigh beam
Turn the exterior lamp switch to
positionB (
page 126).
Push the combination switch in direc-
tion of arrow1 to switch on the high
beam.
The high beam headlamp indicator
lampA in the instrument cluster
comes on (
page 26).
Pull the combination switch in direction
of arrow2 to its original position to
switch off the high beam.
The high beam headlamp indicator
lampA in the instrument cluster
goes out.
High beam flasher
Pull the combination switch briefly in
direction of arrow2.Corner-illuminating front fog lamps*
(CLS 550 with Bi-Xenon* headlamps
only)
The corner-illuminating front fog lamps im-
prove illumination of the area in the direc-
tion into which you are turning.
Corner-illuminating front fog lamps will op-
erate with the engine running and with

the exterior lamp switch in
positionB (
page 126)
or

the exterior lamp switch in
positionU (
page 126)
or

the daytime running lamp mode
activated (
page 128)
iWith the automatic headlamp mode activat-
ed: The corner-illuminating front fog lamps will
only come on in low ambient lighting conditions.

131 Controls in detail
Lighting
Driving forward
Switching on corner-illuminating front
fog lamps
Switch on the left or right turn signal
(
page 55), depending on whether
you are turning left or right.
The respective front fog lamp comes on
and illuminates the area in the direc-
tion into which you are turning.
or
Turn steering wheel in desired direc-
tion.
The front fog lamp on the side of your
steering direction comes on.Switching off corner-illuminating front
fog lamps
The combination switch for the turn signal
resets automatically after major steering
wheel movements. This will switch off the
corner-illuminating front fog lamps if they
where activated by switching on the left or
right turn signal.
If the turn signal should stay on after mak-
ing the turn, the turn signal and corner-illu-
minating front fog lamps can be switched
off by returning the combination switch to
its original position.
iIf you are driving faster than 25 mph
(40 km/h) or have the front fog lamps switched
on, the corner-illuminating function is not avail-
able.iIf you have switched on the turn signal for
one side but turn the steering wheel in the other
direction, the corner-illuminating lamp lights up
on the side of the turn signal.
The corner-illuminating front fog lamp remains lit
for a maximum of three minutes. Afterward, it
goes out even if the turn signal is still switched
on.
iThe corner-illuminating front fog lamps tem-
porarily come on on both sides of the vehicle if
you turn the steering wheel in one direction and
then in the other direction shortly thereafter.
iThe corner-illuminating front fog lamps will
come on automatically depending on the steer-
ing angle, even if you did not switch on either
turn signal. If the corner-illuminating front fog
lamps came on automatically, they will also go
out automatically depending on the steering
angle.
iThere may be a brief delay before the cor-
ner-illuminating front fog lamps switch off.

132 Controls in detail
Lighting
Driving in reverse
Switching on corner-illuminating front
fog lamps
Place the gear selector lever in
positionR.
The front fog lamp opposite to your
steering direction comes on.
Switching off corner-illuminating front
fog lamps
Place the gear selector lever out of
positionR.
The respective front fog lamp goes out.
Hazard warning flasher
The hazard warning flasher can be
switched on at all times, even with the
SmartKey removed from the starter switch
or with the SmartKey with KEYLESS-GO*
removed from the vehicle.
The hazard warning flasher switches on
automatically when an air bag deploys.
The hazard warning flasher switch is locat-
ed on the center console.
1Hazard warning flasher switchSwitching on hazard warning flasher
Press the hazard warning flasher
switch1.
All turn signals are flashing.
Switching off hazard warning flasher
Press hazard warning flasher switch1
again.
iWith the hazard warning flasher activated
and the combination switch set for either left or
right turn, only the respective left or right turn
signals will operate when the ignition is switched
on.
iIf the hazard warning flasher has been acti-
vated automatically, press hazard warning flash-
er switch1 once to switch off.

133 Controls in detail
Lighting
Interior lighting in the front
The controls are located in the overhead
control panel.1Left front reading lamp on/off
2Rear interior lighting on/off
3Automatic control on/off
4Front interior lighting on/off
5Right front reading lamp on/off
6Interior lighting
7Ambient lighting
8Front reading lamps
Deactivating automatic control
Press switch3.
The interior lighting remains switched
off in darkness, even when you:

unlock the vehicle

remove the SmartKey from the
starter switch

open a door

open the trunk
Activating automatic control
Press switch3.
The interior lighting switches on in
darkness, when you:

unlock the vehicle

remove the SmartKey from the
starter switch

open a door

open the trunk
The interior lighting switches off after a
preset time (
page 162).
!An interior lamp switched on manually does
not go out automatically.
Leaving an interior lamp switch in the ON posi-
tion for extended periods of time with the engine
turned off could result in a discharged battery.
iThe interior lighting is factory-set to auto-
matic mode.
iIf a door remains open, the interior lamps
switch off automatically after approximately
5minutes.

134 Controls in detail
Lighting
Manual control
Switching front/rear interior lighting on
and off
Press front/rear interior lighting
switch4 or2 to switch on the
desired interior light.
Press front/rear interior lighting
switch4 or2 again to switch off the
respective interior light.
Switching front reading lamps on and off
The front reading lamps are located in the
interior rear view mirror.
Press front reading lamp
switch1or5 to switch on the
desired front reading lamp.
Press front reading lamp
switch1or5 again to switch off the
respective front reading lamp.Ambient lighting
You can switch the ambient lighting7
(
page 133) on and off, using the “Control
system” (
page 161).
Interior lighting in the rear
The overhead control panel is located
above the rear seat bench.
1Left reading lamp on/off
2Left reading lamp
3Right reading lamp
4Right reading lamp on/off
5Rear interior lamp

135 Controls in detail
Lighting
Rear reading lamps
Press rear reading lamp switch1
or4 to switch on the respective rear
reading lamp.
Press rear reading lamp switch1
or4 again to switch off the respective
rear reading lamp.
Door entry lamps
For better orientation in the dark, the cor-
responding door entry lamps will switch on
in darkness when you open a door and the
automatic control is activated.
The door entry lamps will switch off when
the corresponding door is closed.Trunk lamp
The trunk lamp switches on if the trunk is
opened.
If the trunk remains open, the trunk light-
ing switches off automatically after ap-
proximately 10 minutes.
iIf you turn the SmartKey in the starter
switch to position0 and switch off the head-
lamps, the door entry lamps will remain lit for ap-
proximately 5 minutes.

136 Controls in detail
Instrument cluster
For a full view illustration of the instrument
cluster, see “At a glance” (
page 26).
1Reset button
The instrument cluster is activated when
you

open a door

switch on the ignition

press the reset button1

switch on the exterior lamps
You can modify the instrument cluster set-
tings in the instrument cluster submenu of
the control system (
page 155).Adjusting instrument cluster
illumination
Use the reset button (
page 136) to ad-
just the illumination brightness for the in-
strument cluster.To brighten illumination
Turn the reset button (page 136)
clockwise.
The instrument cluster illumination will
brighten.
To dim illumination
Turn the reset button (page 136)
counterclockwise.
The instrument cluster illumination will
dim.
Warning!G
No messages will be displayed if either the
instrument cluster or the multifunction dis-
play is inoperative.
As a result, you will not be able to see infor-
mation about your driving conditions, such
as speed or outside temperature, warn-
ing/indicator lamps, malfunction/warning
messages or the failure of any systems.
Driving characteristics may be impaired.
If you must continue to drive, please do so
with added caution. Contact an authorized
Mercedes-Benz Center as soon as possible.
iThe instrument cluster illumination is
dimmed or brightened automatically to suit am-
bient light conditions.
The instrument cluster illumination will also be
adjusted automatically when you switch on the
vehicle’s exterior lamps.

137 Controls in detail
Instrument cluster
Coolant temperature indicatorResetting trip odometer
Make sure you are viewing the trip odome-
ter display (
page 139).
If it is not displayed, press the è or
ÿ repeatedly until the trip odome-
ter appears.
Press and hold the reset button
(
page 136) until the trip odometer is
reset.
Warning!G

Driving when your engine is overheated
can cause some fluids which may have
leaked into the engine compartment to
catch fire. You could be seriously
burned.

Steam from an overheated engine can
cause serious burns and can occur just
by opening the hood. Stay away from
the engine if you see or hear steam com-
ing from it.
Stop the vehicle in a safe location away from
other traffic. Turn off the engine, get out of
the vehicle and do not stand near the vehicle
until the engine has cooled down.
!Excessive coolant temperature triggers the
coolant temperature warning lamp (
page 350)
and a warning in the multifunction display
(
page 376).
The engine should not be operated with the cool-
ant temperature above 248°F (120°C). Doing so
may cause serious engine damage which is not
covered by the Mercedes-Benz Limited Warran-
ty.
iDuring severe operating conditions, e.g.
stop-and-go traffic, the coolant temperature may
rise close to 248°F (120°C).

138 Controls in detail
Instrument cluster
Tachometer
The red marking on the tachometer de-
notes excessive engine speed.
To help protect the engine, the fuel supply
is interrupted if the engine is operated
within the red marking.Outside temperature indicator
The outside temperature is displayed in
the instrument cluster (
page 26).The temperature sensor is located in the
front bumper area. Due to its location, the
sensor can be affected by road or engine
heat during idling or slow driving. This
means that the accuracy of the displayed
temperature can only be verified by com-
parison to a thermometer placed next to
the sensor, not by comparison to external
displays (e.g. bank signs etc.).
When moving the vehicle into colder ambi-
ent temperatures (e.g. when leaving your
garage), you will notice a delay before the
lower temperature is displayed.
A delay also occurs when ambient temper-
atures rise. This prevents inaccurate tem-
perature indications caused by heat
radiated from the engine during idling or
slow driving.
!Avoid driving at excessive engine speeds, as
it may result in serious engine damage that is not
covered by the Mercedes-Benz Limited Warran-
ty.
Warning!G
The outside temperature indicator is not
designed to serve as an ice-warning device
and is therefore unsuitable for that purpose.
Indicated temperatures just above the freez-
ing point do not guarantee that the road sur-
face is free of ice. The road may still be icy,
especially in wooded areas or on bridges.

139 Controls in detail
Control system
Control system
The control system is activated as soon as
the SmartKey in the starter switch is
turned to position1 or as soon as the
KEYLESS-GO start/stop button* is in
position1. The control system enables you
to:

call up information about your vehicle

change vehicle settings
For example, you can use the control sys-
tem to find out when your vehicle is next
due for service, to set the language for
messages in the multifunction display, and
much more.
The control system relays information to
the multifunction display.
Multifunction display
1Outside temperature
2Trip odometer
3Automatic transmission program mode
4Main odometer
5Current gear selector lever position
Above illustration shows the standard
display.
For more information on menus displayed
in the multifunction display, see “Menus”
(
page 142).
iThe displays for the audio systems (radio,
CD player) will appear in English, regardless of
the language selected.
Warning!G
A driver’s attention to the road and traffic
conditions must always be his/her primary
focus when driving.
For your safety and the safety of others,
selecting features through the multifunction
steering wheel should only be done by the
driver when traffic and road conditions per-
mit it to be done safely.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.
