MERCEDES-BENZ E-CLASS 2000 Owners Manual

308 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Spare parts service
All authorized Mercedes-Benz Centers maintain a stock
of original spare parts required for maintenance and
repair work. In addition, strategically located parts
distribution centers provide quick and reliable parts
service.
More than 300 000 different spare parts, for
Mercedes-Benz models, are available.
Mercedes-Benz original spare parts are subjected to
stringent quality inspections. Each part has been
specifically developed, manufactured or selected for and
adapted to Mercedes-Benz vehicles.
Therefore, Mercedes-Benz original spare parts should
be installed.
Important!
The use of non-genuine parts and accessories not
authorized by Mercedes-Benz could damage the vehicle
which damage is not covered by the Mercedes-Benz
Limited Warranty or compromise its durability or safety.Warranty coverage
Your vehicle is covered under the terms of the
“warranties” printed in the Service and Warranty
Information booklet and your authorized
Mercedes-Benz Center will exchange or repair any
defective parts originally installed on the vehicle in
accordance with the terms of the following warranties:
1. New vehicle limited warranty
2. Emission system warranty
3. Emission performance warranty
4. California, Massachusetts, and Vermont emission
control systems warranty
Replacement parts and accessories are covered by the
Mercedes-Benz Spare Parts and Accessories warranties,
copies of which are available at any Mercedes-Benz
Center.
Loss of Service and Warranty Information Booklet
Should you lose your Service and Warranty Information
booklet, have your authorized Mercedes-Benz Center
arrange for a replacement. It will be mailed to you.
ProCarManuals.com

309 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Identification labels
1Certification label2Vehicle Identification Number (VIN)
When ordering spare parts, please specify vehicle
identification and engine number.
P63.20-2368-26
ProCarManuals.com

310 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
E 320 shown3VIN, visible (lower edge of windshield)
4Engine number
5Body number and paintwork number
6Emission control label
7Information label, California version
Vacuum line routing for emission control system
6
7
4
3
5
ProCarManuals.com

311 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Layout of poly-V-belt drive 1Automatic belt tensioner
2Crankshaft
3Air conditioner compressor
4Generator (alternator)
5Idler pulley
6Power steering pump
7Coolant pump
6
5
1
2
3
7
4
ProCarManuals.com

312 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Technical data
Model E 320 ( 210. 0 65 )
1
E 320 AWD (210.082)
1
E 430 (210.070)
1
E 430 AWD ( 210. 2 7 0)
1
E 55 AMG ( 210 . 0 74 )
1
Engine11 2 113 113
Mode of operation 4-stroke engine,
gasoline injection4-stroke engine,
gasoline injection4-stroke engine,
gasoline injection
No. of cylinders 6 8 8
Bore 3.54 in (89.90 mm) 3.54 in (89.90 mm) 3.82 in (97.00 mm)
Stroke 3.30 in (84.00 mm) 3.31 in (84.00 mm) 3.60 in (92.00 mm)
Total piston displacement 195.2 cu.in. (3199 cm
3) 260.6 cu.in. (4265 cm
3) 332.0 cu.in (5439 cm
3)
Compression ratio 10:1 10:1 10.5:1
Output acc. to SAE J 1349 221 hp / 5600 rpm
(165 kW / 5600 rpm)275 hp / 5750 rpm
(205 kW / 5750 rpm)355 hp / 5500 rpm
(265 kW / 5500 rpm)
Maximum torque acc. to SAE J 1349 232 ft.lb / 3000 rpm
(315 Nm / 3000 rpm)295 ft.lb / 3200 rpm
(400 Nm / 3200 rpm)390 ft.lb / 3150 rpm
(530 Nm / 3150 rpm)
Maximum engine speed 6000 rpm 6000 rpm 6000 rpm
Firing order 1-4-3-6-2-5 1-5-4-2-6-3-7-8 1-5-4-2-6-3-7-8
Poly-V-belt 2390 mm 2390 mm 2390 mm
1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies
and special equipment.
ProCarManuals.com

313 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Rims – Tires
Model E 320
(without Sport Package)
Rims (light alloy)
Wheel offset7
1/2 J x 16 H 2
1.6 in (41 mm)
All season tires:
Radial-ply tires 215 / 55 R 16 93 H
Winter tires:
Radial-ply tires 215 / 55 R 16 93 H M+S
Spare wheel
Rim (steel)
Wheel offset7
1/2 J x 16 H 2
1.6 in (41 mm)
All season tire:
Radial-ply tire 215 / 55 R 16 93 H
ProCarManuals.com

314 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
2 Must only be used with special MB authorized snow chains.
3 Also permissible 235 / 45 ZR 17.Model E 320
(Sport Package)E 430
(without Sport Package)E 430
(Sport Package)
Rims (light alloy)
Wheel offset8 J x 17 H2
1.46 in (37 mm)7
1/2 J x 17 H2
1.46 in (37 mm)8 J x 17 H2
1.46 in (37 mm)
Summer tires:
Radial-ply tires 235 / 45 R 17 93 W
2, 3
235 / 45 R 17 93 W
2, 3
235 / 45 R 17 93 W
2, 3
Winter tires:
Radial-ply tires 235 / 45 R 17 93 W M+S
2
235 / 45 R 17 93 H M+S
2
235 / 45 R 17 93 H M+S
2
Spare wheel
Rim (light alloy)
Wheel offset7
1/2 J x 17 H 2
1.46 in (37 mm)7
1/2 J x 17 H 2
1.46 in (37 mm)7
1/2 J x 17 H 2
1.46 in (37 mm)
Summer tire:
Radial-ply tire 235 / 45 R 17 93 W
2, 3
235 / 45 R 17 93 W
2, 3
235 / 45 R 17 93 W
2, 3
ProCarManuals.com

315 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
3 Also permissible 235 / 45 ZR 17.
4 Must not be used with snow chains.
Model E 55 AMG
Rims and summer tires
Rims front axle
(AMG light alloy)
Wheel offset8 J x 18 H 2
1.2 in (31 mm)
Rims rear axle
(AMG light alloy)
Wheel offset9 J x 18 H 2
1.4 in (35 mm)
Radial-ply tires, front axle
Radial-ply tires, rear axle245 / 40 ZR 18
4
275 / 35 ZR 18
4
Rims and winter tires
Rims
(AMG light alloy)
Wheel offset7
1/2 J x 17 H 2
1.4 in (35 mm)
Radial-ply tires 235 / 45 R 17 93 H M+SSpare wheel
Rim
(AMG light alloy)
Wheel offset7
1/2 J x 17 H 2
1.46 in (37 mm)
Summer tire:
Radial-ply tire 235 / 45 R 17 94 W
3
ProCarManuals.com

316 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Electrical system
We i g h t s
(see certification tag) Model E 320 E 430 E 55 AMG
Generator (alternator) 14 V / 115 A 14 V / 150 A 14 V / 150 A
S t a r te r m o to r 12 V / 1. 7 k W 12 V / 1. 7 k W 12V / 1.7 k W
Battery 12V / 100 Ah 12V / 100 Ah 12V / 100 Ah
Spark plugs
Electrode gap
Tightening torqueBosch F 8 DPER
Beru 14 FGH 8 DPUR X 2
NGK PFR 5 R-11
0.039 in (1.0 mm)
15 – 22 ft.lb (20 – 30 Nm)Bosch F 8 DPER
Beru 14 FGH 8 DPUR X 2
NGK PFR 5 R-11
0.039 in (1.0 mm)
15 – 22 ft.lb (20 – 30 Nm)Bosch F 8 DPER
0.039 in (1.0 mm)
15 – 22 ft.lb (20 – 30 Nm)
Roof load max. 220 lb (100 kg)
Trunk load max. 220 lb (100 kg)
ProCarManuals.com

317 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Main Dimensions
Model E 320
E 320 AWDE 430
E 430 AWD E 55 AMG
Overall vehicle length 189.4 in (4810 mm) 189.4 in (4810 mm) 190 in (4818 mm)
Overall vehicle width 70.8 in (1799 mm) 70.8 in (1799 mm) 70.8 in (1799 mm)
Overall height 56.7 in (1439 mm) 56.7 in (1439 mm) 56.9 in (1445 mm)
Wheel base 111.5 in (2833 mm) 111.5 in (2833 mm) 111.5 in (2833 mm)
Track, front 60.2 in (1529 mm) 60.2 in (1529 mm) 61.4 in (1560 mm)
Track, rear 59.9 in (1521 mm) 59.9 in (1521 mm) 60.7 in (1543 mm)
ProCarManuals.com
