70 Audio
CD changer* operation
Entry example: Track 12
Press and  in quick succession.
Wait approx. 3 seconds after entering
the number.
The selected track is played. The CD
main menu appears.
Selecting via scan search
Scan search is characterised as follows:
Scan search plays each track on the
current CD for approx. 8 seconds.
Scan search can be ended manually.
Scan search automatically stops at the
track listened to before the scan
search was started.Starting scan search
Press the Scan soft key.
Ending scan search manually
Press the Scan soft key.
The track playing at the time the scan
is ended remains playing.
Open the CD changer main menu
(
page 66).
Press and hold or .
To stop release or ..The following options are available:
Normal sequence
The tracks are played in the normal se-
quence (e.g. track 1, 2, 3 etc.).
If only one CD is loaded, the last track is
followed by again playing the first track.
If several CDs are loaded in the CD chang-
er, the last track on a CD in the changer
will be followed by the first track of the
next CD in the changer.
The CDs are changed in their normal se-
quence (e.g. CD 1, 2, 3 etc.).
Repeat track
The current track will be repeated until
this function is deactivated.
i
Entries beyond the number of available
tracks on the CD are not possible.
i
When you start the scan search, play-
back option
Normal sequence is activated
automatically. Therein scan search is
restricted to the current CD.
Fast forward/reverse
Playback options

71 Audio
CD changer* operation
Repeat CD
The current CD will be repeated until
this function is deactivated.
Random track
The tracks are played in random order
(e.g. track 3, 8, 5 etc.).
If several CDs are loaded in the CD
changer, the last track on a CD in the
changer will be followed by the first
track of the next CD in the changer.
The CDs are changed in their normal
sequence (e.g. CD 1, 2, 3, etc.).
Random CD
At least 4 tracks on one CD are played
in random order (e.g. track 5, 7, 3, 9).
Then, the next CD will be played.
The CDs are changed in random
order (e.g. CD 4, 1, 5, etc.).
Switching the playback option
In the CD changer main menu
(
page 66) press the Setting soft key.
The Setting menu appears.
The solid circle indicates which op-
tion is currently selected.
Use or  to select a different op-
tion.
Press.
The option is activated. A correspond-
ing display will appear in the status bar
for all options except
Normal sequence.
An option will remain activated even if
the COMAND is switched OFF and then
ON again.
i
It is only possible to select this function
if at least two audio CDs are loaded in
the CD changer.
i
This selection is only available if at
least two audio CDs are loaded.

72 Audio
Audio AUX operation
Open the Audio main menu
(
page 36).
Press the AUX soft key.
The AUX menu appears.
The external audio source is made au-
dible, provided it is connected and
switched to playback.In AUX mode, you can adjust the following:
Volume (page 30)
Fader and balance (page 31)
Bass and treble (page 32)
Sound functions (page 33)
i
An external audio source, for example a
tape player, can be connected to
COMAND.
For further information, please contact
your Mercedes-Benz Center.
Switching to AUX mode
i
Please refer to the appropriate operat-
ing manual for the operation of the ex-
ternal audio source.

73 Satellite radio*
General information
Satellite radio operation

74 Satellite radio*
General information
Sirius Satellite Radio provides 100 chan-
nels, so called streams, of digital-quality
radio, among others music, sports, news,
and entertainment free of commercials.
Sirius Satellite Radio uses a fleet of high-
power satellites to broadcast 24 hours per
day, coast-to-coast, in the contiguous US.
This diverse, satellite-delivered program-
ming is available for a monthly subscrip-
tion fee.
For more information and service availabil-
ity call the Sirius Service Center
(
page 80), or contact
www.siriusradio.com
Program categories
The channels are categorized. Categories
allow you to tune to stations broadcasting
a certain type of program (category mode)
(
page 77).Category selection
ALL contains the station
list of all receivable channels (channel
mode) (
page 77).
Introduction to Satellite radio
i
Additional optional satellite radio
equipment and a subscription to satel-
lite radio service provider are required
for the satellite radio operation de-
scribed in this chapter.
Contact your authorized Mercedes-
Benz Center for details and availability
for your vehicle.
i
Note that categories and channels
shown in illustrations are dependent on
programming content delivered by the
service provider. Programming content
is subject to change. Therefore, chan-
nel and categories shown in illustra-
tions and descriptions contained in this
manual may differ from the channels
and categories delivered by the service
provider.
Satellite radio service may be unavail-
able or interrupted from time to time
for a variety of reasons, such as envi-
ronmental or topographic conditions
and other things we can't control. Ser-
vice might also not be available in cer-
tain places (e.g., in tunnels, parking
garages, or within or next to buildings)
or near other technologies.

75 Satellite radio*
Satellite radio operation

Satellite radio operation
Press.
Prior to activation of the Satellite radio
service (
page 75),
After Satellite radio service was acti-
vated (
page 75).
Prior to activation of the Satellite radio
service
The telephone number of the Sirius Service
Center and the twelve-digit electronic seri-
al number (ESN) of the particular receiver
are displayed.
This information is required to call the Siri-
us Service Center for an activation re-
quest.After activation of the Satellite radio
service
The SAT main menu appears.
The radio station selected last is audible,
provided it can be received.Station information is displayed on the
main screen and in the center of the status
bar.
Switching to Satellite radio mode
i
Credit card information is also required
for your application.
i
The activation process takes approxi-
mately 5 to 10 minutes after calling the
Sirius Service Center.
i
The system will tune to a default sta-
tion if no station had been selected
previously.
SAT main menu

76 Satellite radio*
Satellite radio operation
Main area, in this example:
ROCK = selected category (page 77)
Vault = name of the selected station
Status bar, in this example:
SAT (on the left) = the selected mode
SAT5 = location in the program
memory, if the current channel is pre-
stored
Ch16 = number of the current channel
Selectable soft keys
Presets
shows channels pre-stored in the pro-
gram memory (up to 10 channels). You
can store stations (
page 79) and re-
quest stored stations (
page 76).
Info
shows additional text information relat-
ed to the current channel.
Scan
is used to start and stop the scan
search (
page 79).
Service
displays a screen showing the tele-
phone number of the Sirius Service
Center and electronic serial number
(ESN) of the particular receiver.
You can also adjust the following:
Bass and treble (page 32)
Balance and fader (page 31)
Sound functions (page 33)
Volume (not on soft keys)
(
page 30)
The following options are available:
Tuning via station presets (page 76)
Tuning via manual channel input
(
page 77)
Tuning via the program category list
(
page 77)
Tuning a station within the selected
category (
page 78)
Tuning via scan search (page 79)
Tuning via station presets
Ten Satellite radio station presets are
available.
You can access the presets via number
keys or via the Presets menu.
Selecting a station
i
The Presets memory is empty at first-
time activation of the system.

77 Satellite radio*
Satellite radio operation
Accessing via number keys
Press one of the number keys
 - .
The system will tune to the station
stored under this number.
Accessing via Presets menu.
Press the Presets soft key.
The Presets list appears.
Use  or  to choose a preset and
press,
or
Press one of the number keys
 - .
The system tunes to the station stored
under this number.
Tuning via manual channel input
Example: Tuning in channel 12
Press.
Press  and .
The system tunes to channel 12.
Tuning via the program category list
The category list contains all currently re-
ceivable categories of programs. It is sort-
ed alphabetically.Only one entry is visible at a time. The en-
try appears at the top of the main screen.
Selecting a category
Example 1: category
ALL
The station list of category
ALL contains all
receivable channels (channel mode).
Use or  to select the category
All from the list.
The station listened to before remains
tuned.
i
If an entry is made and such a channel
is not available, the message
Channel
unavailable appears. The channel select-
ed last continues playing.

78 Satellite radio*
Satellite radio operation
Example 2: category POP
In the station list, only channels of catego-
ry
POP are available (category mode).
Use or  to select the category
POP from the list.
If the station listened to before was of
POP
category, the channel remains tuned.
Otherwise the system switches to the sta-
tion of
POP category that was selected last
in this category.The system will automatically switch to a
station of
POP category if the currently se-
lected station is not of the
POP category.
Otherwise, the currently selected station
remains tuned.
Tuning a station within the selected
category
The channels identified for the currently
selected category are sorted numerically
by channel number, which appear in the
status bar one at a time.
Tuning using COMAND control unit
Press or .
The search proceeds in ascending or-
der.
or
Press or .The search proceeds in descending or-
der and stops at the first receivable
station.
Tuning using the multifunction steering
wheel
Switch the multifunction display in the
instrument cluster to Satellite radio
display (
page 25).
Pressk.
The search proceeds in ascending or-
der.
or
i
Using oris followed by a short
delay before the change occurs. Using
 and changes the channel
immediately.

79 Satellite radio*
Satellite radio operation
Pressj.
The search proceeds in descending or-
der and stops at the first receivable
station.
Tuning via scan search
Scan search is characterized as follows:
Scan search plays a channel for
approx. 8 seconds and then skips to
the next channel within the current
category.
Scan search can be ended manually.
Scan search stops automatically at the
station that was playing when scan
search was started.
Press the Scan soft key.
The scan search starts.
Press the Scan soft key again.
The scan search ends.
Additional text information (artist and title)
related to the current broadcast can be
displayed.
Press the Info soft key.Two options are available:
Storing using the number keys
(
page 79).
Storing using the Presets menu
(
page 80).
Storing via number keys
Press and hold a number key between
 and  for more than 2 seconds.
The currently selected station is stored
in the corresponding preset location.
Obtaining additional text
information
Storing stations
i
When storing a station out of the cate-
gory
All, later selection of this channel
does not lead into the category mode.
