Contents
Selecting CDs . . . . . . . . . . . . . . . . . 67
Selecting a track . . . . . . . . . . . . . . 68
Fast forward/reverse . . . . . . . . . . . 70
Playback options. . . . . . . . . . . . . . . 70
Audio AUX operation . . . . . . . . . . . . . . 72
Satellite radio*. . . . . . . . . . . . . . . . . . 73
General information . . . . . . . . . . . . . . . 74
Introduction to Satellite radio . . . . . 74
Satellite radio operation . . . . . . . . . . . . 75
Switching to Satellite radio mode . . 75
SAT main menu . . . . . . . . . . . . . . . . 75
Selecting a station . . . . . . . . . . . . . 76
Obtaining additional text
information . . . . . . . . . . . . . . . . . . . 79
Storing stations . . . . . . . . . . . . . . . 79
Calling the Sirius Service Center . . 80
Telephone*. . . . . . . . . . . . . . . . . . . . . 81
Important notes . . . . . . . . . . . . . . . . . . 82
Safety Instructions . . . . . . . . . . . . . 82
Tips on telephone operation . . . . . 83Telephone operation. . . . . . . . . . . . . . . 85
Switching the phone ON/OFF . . . . 85
911 emergency calls. . . . . . . . . . . . 86
Entering the PIN (only GSM) . . . . . 87
Entering the unlock code . . . . . . . . 88
Switching to telephone mode . . . . 89
Telephone main menu. . . . . . . . . . . 89
Answering an incoming call . . . . . . 90
Placing an outgoing call . . . . . . . . . 91
Accepted and missed calls . . . . . . . 92
Dialed calls . . . . . . . . . . . . . . . . . . . 94
Active call . . . . . . . . . . . . . . . . . . . . 96
Phone book . . . . . . . . . . . . . . . . . . . . . 98
Opening the phone book. . . . . . . . . 98
Selecting a phone book entry and
establishing a connection . . . . . . . 99
Adding spoken names to a phone
book entry. . . . . . . . . . . . . . . . . . . 100
Deleting a phone book entry . . . . 100
SMS (Mail) . . . . . . . . . . . . . . . . . . . . . 101
SMS inbox . . . . . . . . . . . . . . . . . . . 101
Reading a message . . . . . . . . . . . . 102
Deleting a message . . . . . . . . . . . 103
Exiting from the SMS menu . . . . . 103
Navigation*. . . . . . . . . . . . . . . . . . . . 105
Important notes . . . . . . . . . . . . . . . . . 106
Safety Instructions . . . . . . . . . . . . 106
Navigation DVD . . . . . . . . . . . . . . . 107
Loading/ejecting the DVD . . . . . . 107
Travelling abroad. . . . . . . . . . . . . . 108
Route guidance with GPS . . . . . . . 108
Route guidance after
vehicle transport . . . . . . . . . . . . . . 108
Trip interruption during
route guidance . . . . . . . . . . . . . . . 109
Selection lists . . . . . . . . . . . . . . . . 109
Navigation main menu . . . . . . . . . . . . 110
Calling up the
Navigation main menu . . . . . . . . . 110
Avoiding certain road types . . . . . 111
Adjusting the acoustics for
navigation announcements . . . . . . 111
Destination entry . . . . . . . . . . . . . . . . 114
Entering data. . . . . . . . . . . . . . . . . 114
Destination entry menu. . . . . . . . . 117
Entering a destination . . . . . . . . . . 117
Selecting the region . . . . . . . . . . . 117

21 At a glance
Telephone* operating elements
FunctionPage
1 
Telephone main menu
Switching the telephone
ON
Switching the telephone
OFF
89
85
85
2 Soft keys
(multifunction buttons)
FunctionPage
3 - 
Entering PIN
Entering unlock code
Entering phone number
Speed dial
87
88
92
95
4 , , , 
Selection buttons
5 
Confirmation
FunctionPage
6 
Answering calls
Redialing
91
92
7 
Ending or refusing a call
91
8 
Switching ON/OFF
30
9 
Volume adjustment
30

84 Telephone*
Important notes
Close the windows and reduce all ex-
ternal noise as much as possible when
using hands-free operation.
Make sure that the air vents are not
pointed in the direction of the micro-
phones located in the overhead control
panel near the rear view mirror. Adjust
air vents and/or reduce blower speed
if necessary.
A brief disconnection from the cellular
network is not a malfunction, as this
can occur when the network switches
areas. The phone automatically at-
tempts to again sign on with a network.
If the message Enter unlock code is dis-
played, enter the unlock code
(
page 88). Only then will you be able
to use all the telephone functions.
You will still be able to make 911 emer-
gency calls (
page 86) if the tele-
phone is locked. The telephone cannot, or not yet, be used
in the following situations:
The telephone is already unlocked, but
it is not yet registered with the net-
work.
The message
NO SERV. appears in the
status bar. The telephone automatical-
ly attempts to register with a network.
If there is no network available, “911”
emergency calls can NOT be placed.
If you try to place an outgoing call, the
message
Call not possible is displayed
temporarily.
If the message Telephone being
activated, please wait
is displayed,
If the message Please insert phone is dis-
played.
Insert the cellular phone into the
telephone cradle.

86 Telephone*
Telephone operation
The following conditions must be met for a
“911” emergency call:
cellular phone readily inserted
telephone switched ON
available cellular phone network
The 911 emergency call will also function if
the telephone is locked.Placing an emergency call
An emergency call can be placed using the
cellular phone or the COMAND control
unit.
Using the cellular phone
(
Telephone Operation Guide).
Using the COMAND control unit during
PIN or unlock code entry
Press the 911 soft key.
The system opens an inquiry menu
prompting you if you want to dial a
911 call.
If necessary, press  to select Yes.
Press  to confirm Yes if you want to
place the 911 emergency call.
The telephone establishes the connec-
tion, a ringing tone is audible.
Wait until the emergency call center
answers, then describe the emergency.
If you do not want to place the emergency
call:
Press  to select No when the inquiry
menu appears.
Press  to confirm No.
911 emergency calls
WarningG
The “911” emergency call system is a
public service. Using it without due
cause is a criminal offense.
i
If you cannot make an emergeny call,
you will have to initiate rescue mea-
sures yourself.

87 Telephone*
Telephone operation
Using the COMAND control unit after
PIN and unlock code entry
Press repeatedly until the Tele-
phone main menu appears.
In succession, press the number keys
,  and .
Press.
The telephone establishes the connec-
tion, the ringing tone is audible.
Wait until the emergency call center
answers, then describe the emergency.
The PIN protects the telephone against un-
authorized use. Your PIN is found in the
telephone service provider's documenta-
tion.
Commit your PIN to memory.
Most telephone functions are not available
before entering the PIN.
Press the corresponding number key
 -  for each digit.
In case of erroneous entry, you can de-
lete the last or more digits:
Press the Delete soft key as often as
required.
Once all digits have been entered,
press the
OK soft key.
Entering the PIN (only GSM)
i
If a GSM cellular phone is used, a PIN
may also have to be entered.
The PIN may be entered on the cellular
phone itself (
Telephone Operation
Guide).


88 Telephone*
Telephone operation
If the input is correct, the telephone
will log itself into the network.
If the input is incorrect, message
Wrong PIN number will appear briefly.
Re-enter the PIN.
After three incorrect entries, the SIM
card is blocked. Message
SIM card
blocked
will appear briefly.
The PUK has to be entered.
(
Telephone Operation Guide)The unlock code protects the telephone
against unauthorized use. The unlock code
can be activated on the telephone
(
Telephone Operation Guide).
Commit your unlock code to memory.
The telephone functions are available only
after entering the unlock code.
Example: unlock code 2307
In sequence, press the number
keys, , and .
In case of erroneous entry, delete the
last or more digits:
Press the Delete soft key as often as
required.
i
The telephone cannot be used before it
is logged- in.
Entering the unlock code
i
The system switches back to last mode
if the unlock code is not entered within
8 seconds after you are prompted to do
so.

89 Telephone*
Telephone operation
After entering all digits, press or the
OK soft key.
All telephone functions are available if
the correct number has been entered.
After registering, Information referring
to the telephone signal appears at the
right end of the status bar.
The unlock code has to be entered
again if the entry was incorrect.
When COMAND is switched ON, switching
to telephone mode from any other opera-
tion mode is made as follows.
On the COMAND control unit
Press.
The Telephone main menu opens
(
page 89).On the multifunction steering wheel
See (page 25)
1 Observe all legal requirements
Press.
The Telephone main menu appears.
Telephone status information is displayed
on the right end of the status bar.
The following displays are possible:
READY = telephone is logged into your
cellular phone home network and
ready for use,
Switching to telephone mode
Telephone main menu
WarningG
Some jurisdictions prohibit the driver from
using a cellular telephone while driving.
Whether or not prohibited by law, for safety
reasons, the driver should not use the cellu-
lar telephone while the vehicle is in motion.
Stop the vehicle in a safe location before
placing or answering a call.
If you nonetheless choose to use the cellular
phone while driving, please use the hands-
free device and be sure to pay attention to
the traffic situation at all times. Use the cel-
lular phone
1 only when road, weather and
traffic conditions permit.

90 Telephone*
Telephone operation
ROAMING = telephone is logged into a cel-
lular phone network outside your home
network,
NO SERV. = no network available,
 = telephone signal strength,
 = call active (page 96).
Other messages could also appear:
If the message
Please insert phone, Phone not installed or
Please insert SIM card appears, see chap-
ter “Switching the phone ON / OFF”
(
page 85)
If the message
Please Enter PIN: appears, see “Entering
the PIN” (
page 87)
If the message
Enter unlock code: appears, see “Enter-
ing unlock code” (
page 88)Selectable soft keys and options
 soft key
Opens the phone book (
page 98),
Recvd.# soft key
Opens the accepted and missed calls
list (
page 93),
Dialed # soft key
Opens dialed calls list (
page 94),
SMS soft key
Provides access to the SMS menu
(
page 101),
Entry of a phone number (page 91).The ringing tone is audible in the event of
an incoming call. The call screen pops up
on the current display.
If the multifunction display in the instru-
ment cluster is set to telephone mode, the
call screen also appears in the multifunc-
tion display.
i
If a list is empty, the corresponding soft
key is without function. This is indicat-
ed by the corresponding soft key dis-
play being shaded out.
Answering an incoming call

173 Glossary
Root directory
The uppermost directory on a storage
medium.
Scan rate (MP3)
Indicates the frequency at which volt-
age samples are taken during the con-
version of an analog signal into a digital
signal. The analog-to-digital converter
converts the samples into digital sig-
nals.
SCAN search
Plays receivable radio stations, or CD
tracks in succession, each for approx.
8 seconds.
SIM
(S
ubscriber Identity Module)
Card provided by the GSM telephone
service provider. Necessary for access-
ing a mobile communication network.
SMS
(S
hort Message Service)With this function, you can receive,
read and delete short text messages
(if SMS service is provided by your ser-
vice provider).
Soft keys
Keys to activate different functions,
depending on the selected operating
mode.
Tele Aid
(Tele
matic Alarm Identification on De-
mand)
The Tele Aid system consists of three
types of response: automatic and man-
ual emergency, roadside assistance
and information. Tele Aid is initially
activated by completing a subscriber
agreement and placing an acquain-
tance call.
The Tele Aid system is operational pro-
vided the vehicle's battery is charged,
properly connected, not damaged and
cellular and GPS coverage are avail-
able.Telematics
Compound word made up of the terms
Telecommunication and Informatics.
Unlock code
Your unlock code prevents unautho-
rized persons from using your tele-
phone. The unlock code is a number
string, which you have to enter when
switching on the telephone.
UTC
(U
niversal Time Coordinated)
The mean sun time associated with lon-
gitude zero (world time). It functions as
basis for the time zones.
WB
Weatherband

176 Index
Controls
CD changer mode . . . . . . . . . . . . . . . 18
MP3 mode . . . . . . . . . . . . . . . . . . . . . 16
Multifunction steering wheel. . . . . . . 24
Navigation mode . . . . . . . . . . . . . . . . 22
Radio mode . . . . . . . . . . . . . . . . . . . . 12
Single CD mode . . . . . . . . . . . . . . . . 14
Telephone mode . . . . . . . . . . . . . . . . 20
Coordinates . . . . . . . . . . . . . . . . . . . 171
entering destination via . . . . . . . . . 127
Copy protection . . . . . . . . . . . . . . 45, 62
Copyright (MP3). . . . . . . . . . . . . . . . . 52
Current navigation announcement 131
cancelling . . . . . . . . . . . . . . . . . . . . 131
repeating . . . . . . . . . . . . . . . . . . . . . 131
D
Deleting
destination
from Destination memory . . . . . . 149
from Last destinations . . . . . . . . . 148
detour (navigation) . . . . . . . . . . . . . 138
phone book entry . . . . . . . . . . . . . . 100
SMS. . . . . . . . . . . . . . . . . . . . . . . . . 103
stop-over destination . . . . . . . . . . . 141Destination
deleting
from Destination memory . . . . . . 149
from Last destinations . . . . . . . . . 148
Last destinations . . . . . . . . . . . . . . . 147
special . . . . . . . . . . . . . . . . . . . . . . . 151
storing in Destination memory . . . . 149
Destination memory . . . . . . . . . . . . 148
calling up . . . . . . . . . . . . . . . . . . . . . 148
selecting destination . . . . . . . . . . . . 148
starting route guidance to a stored
destination . . . . . . . . . . . . . . . . . . . 149
storing destination . . . . . . . . . . . . . 149
Detour (navigation) . . . . . . . . . . . . . 137
changing . . . . . . . . . . . . . . . . . . . . . 138
deleting . . . . . . . . . . . . . . . . . . . . . . 138
setting . . . . . . . . . . . . . . . . . . . . . . . 137
Display
adjusting brightness . . . . . . . . . . . . 166
switching design . . . . . . . . . . . . . . . 166
Displaying route (navigation) . . . . . 136
DVD (navigation) . . . . . . . . . . 107, 171
E
Ejecting CD
in CD changer mode . . . . . . . . . . . . . 65
in MP3 mode . . . . . . . . . . . . . . . . . . . 53
in Single CD mode . . . . . . . . . . . . . . . 46
Ejecting navigation DVD . . . . . . . . . 107
Emergency call system . . . . . . . . . . 158
Emergency calls “911”. . . . . . . . . . . . 86
Ending
call (telephone) . . . . . . . . . . . . . . 91, 96
ENTER UNLOCK CODE . . . . . . . . . . . . 84
Entering
destination . . . . . . . . . . . . . . . . . . . 117
frequency (radio) . . . . . . . . . . . . . . . . 41
home address . . . . . . . . . . . . . . . . . 115
phone number . . . . . . . . . . . . . . . . . . 92
PIN. . . . . . . . . . . . . . . . . . . . . . . . . . . 87
unlock code . . . . . . . . . . . . . . . . . . . . 88
F
Fader . . . . . . . . . . . . . . . . . . . . . 31, 171
for navigation announcements . . . . 112
File structure (MP3 CD). . . . . . . . . . . 51
