MERCEDES-BENZ E-Class 2008 W211 Comand Manual

121 Navigation*
Destination entry
After entering a street (
 page
119), a
street intersecting with this street can be
entered.
Press the
Intrsct.
soft key.
The Enter Intersection menu or a list of
all intersecting streets appears.
Enter Intersection menu
Proceed the same as when entering a
street
( page
119)
.
List of intersecting streets
Use

or

to select an intersec
-
tion. The
Page
soft keys allow scrolling
through the list page by page.

Press

.
The Start Route Guidance menu ( page
128)
appears.
Entering an intersectioniThe
Intrsct.
soft key is only available
if streets intersecting the destination
street are stored as intersections on
the navigation DVD.

122 Navigation*Destination entryA house number can be entered after en
-
tering the destination street
( page
119)
.

Press the
Hse.
no.
soft key.
The Enter House Number menu ap
-
pears
( page
122)
, or the house num
-
ber list appears. Now a house number
range can be selected
( page
123)
.
Enter House Number menu

Use

,
, , , (
or
+
to
select the numbers. Press

after
each selection.
or
Press
3
- "
to enter the numbers.

Press the
Delete
soft key if necessary.
The number last accepted by the sys
-
tem is deleted.

Press and hold

for approx. 2 sec
-
onds to confirm the input;
or
Entering a house numberiAn intersection instead of a house number can be entered (
 page
121).

Entry of both is not possible.
iThe
Hse.
no.
soft key is only available
when registered house numbers are
stored on the navigation DVD for the
selected street.
iSymbol “
” represents a space.
iDo not confuse the
Delete
soft key (de
-
letion of the last number) with the
Back

soft key (deletion of the complete en-
try).

123 Navigation*
Destination entry

Use

or

to select the
sym
-
bol and press

.
The house number list appears. Now a
house number range can be selected.
Selecting a house number range

Use

or

to select the desired
range of house numbers. The
Page
soft
keys allow scrolling through the list
page by page.

Press

.
The Start Route Guidance menu ( page
128)
appears.
Calling up the map display
Press
%
;
or
Press the
Map
soft key if it appears in a
menu.
The map appears in full-screen display.

If the soft key displays are hidden,
press any soft key.The soft key displays appear.
Selectable soft keys
Coord.
soft key

Allows entering a destination via geo
coordinates
( page
125)
.

Symbol
soft key

Provides access to setting the symbols
display
( page
143)
iThe
symbol can only be selected if
the system recognized the house num
-
ber.
ok
ok
Entering a destination using the map
iIf no soft key is selected within

approx. 8 seconds, the soft key dis
-
plays will disappear.


124 Navigation*Destination entry
Memory
soft key

The current map location is stored ( page
126)
.

Display
soft key

You can select which POIs will appear
as symbols on the map
( page
143)
.

soft key

The map scale will change to display a
more detailed map.

soft key

The map scale will change to display a
map that shows a wider area.
Moving the map and selecting a desti
-
nation
Move the cursor using

,
, ,
, (
or
+
to select the desired
destination.

Release the button.If the system finds a street name at the
location the cursor is pointing to, the
corresponding street name is shown in
the status bar. In this example:
WATER
ST
Start route guidance to the selected
destination
Press

.
The Start Route Guidance menu ap
-
pears if route guidance has not yet
been activated.
Press

.
Route calculation begins.
If route guidance is already active, you
will be prompted to confirm that you
wish to accept the new destination.
Press

to select
Yes
.

Press

.
Route calculation begins.
iThe soft keys
Coord.
, Memory
and
Dis
-
play
are visible only if the map has
been called up using
%
.
iThe destination selection will be lost
when pressing the
Back
soft key.

The system reverses to the details of
the previously entered destination.

125 Navigation*
Destination entry
Destination input via coordinates (longi
-
tude and latitude) will only be possible if
the map display is visible and if the
Coord.

soft key is displayed.

Press
%
.

Press any soft key if the soft key dis
-
plays are hidden.The soft key displays appear.

Press the
Coord.
soft key.
The menu for entering coordinates ap
-
pears. You can set the individual values
for the longitude and latitude in this
menu.
1“Hours” longitude value2“Minutes” longitude value3“Seconds” longitude value4“Seconds” latitude value5“Minutes” latitude value6“Hours” latitude value

Press

or

to select the value you
wish to set.

Select the desired value using

or

.

Keep repeating the last two steps until
you have set the required longitude and
latitude.

Press

.
If the coordinates entered are located
in the digital map range, the display will
switch to map display with cursor. The
center point of the cursor indicates the
position of the coordinates entered on
the map.
Entering a destination via geo coor
-
dinates


126 Navigation*Destination entry
Press

.
The Start Route Guidance menu ap
-
pears.

Press

.
Route calculation begins.
You can store the current vehicle position
or a location selected via the map as an en
-
try in the
Last
Destinations
memory.
Therein such entries are marked with

( page
148)
.
If you wish to store such entries for later
retrieval or repeat usage, you can store
them in the standard destination memory ( page
149)
.
Storing current vehicle position
Press
%
.

Press any soft key if the soft key dis
-
plays are hidden.The soft key displays appear.
1Symbol
= current vehicle location

Press the
Memory
soft key.
The system stores the current vehicle
position.

While storage takes place, the
Memory

soft key display changes its color for a
short period of time.
iRoute guidance is only possible to co
-
ordinates within the digital map range.
Storing map location

127 Navigation*
Destination entry
Storing locations selected via the map
Press
%
.

Move the map and select a location ( page
124)
.

Press the
Memory
soft key.
The system stores the current cursor
position.

While storage takes place, the
Memory

soft key display changes its color for a
short period of time.

128 Navigation*Route guidanceYou can start route guidance when the
destination input is complete and Start
Route
Guidance
is displayed at the
bottom of the main area.
Besides starting route guidance following
soft keys are available:
Mode
soft key

Provides access to the route mode set
-
ting for certain road types to be avoid
-
ed
( page
109)
.

Save
soft key

Stores the entered destination in the
destination memory
( page
149)
.

To start route guidance, press

.
The route is calculated and route guid
-
ance begins.
Depending on the distance to the destina
-
tion, route calculation can take some time.
While the route is being calculated, Reading Navi DVD... Please Wait
and an
arrow pointing towards the destination are
displayed. Once route calculation is com
-
plete, route guidance begins.Because of changes in local traffic patterns
(e.g. road works) and/or incomplete data,
errors in calculation may occur.
As a result, the recommended route may
deviate from the ideal route. The data
stored on the DVD only reflects local con
-
ditions at the time of DVD production. DVD
maps may not cover all areas nor all routes
within an area.The system will calculate a new route dur
-
ing active route guidance if the driver fails
to follow the route guidance. During recalculation,
NEW
RTE
is displayed.
The arrow is not solid.
Start route guidance menu
Route calculation
Route re-calculation

129 Navigation*
Route guidance
After route calculation, the system assists
route guidance using pictorial displays and
navigation announcements.Current navigation announcementsIf a navigation announcement is not readily
understood, it can be repeated at any time.
Press
6
.
The current navigation announcement
is repeated.
Switching navigation announcements
ON/OFF Switching OFF
During a navigation announcement,
press
1
.
For a short period of time, the message Voice
announcements
muted
is dis
-
played. Now further route guidance takes
place using only the symbols in the dis
-
play. If a new route guidance cycle is
started, the announcements are auto
-
matically switched ON again.
Switching ON manually
Press
6
.
The navigation displays are visible only
with activated route guidance.
To switch to the navigation display
from another display, e.g. from CD
mode, press

or
%
.
Two display examples are shown below.Display example 1The road currently travelled on is indicated
in the status bar at the bottom, in this ex
-
ample
I-80 E
(Interstate 80 East).

The information 1.2 mi indicates the dis
-
tance to the next driving maneuver.
Navigation announcementsWarning
G
Navigation announcements are intended to
direct you while driving without diverting
your attention from the road and driving. Please always use this feature instead of
consulting the map display for directions.
Consulting the symbols or map display for
directions may cause you to divert your at
-
tention from driving and increase your risk
of an accident.
Navigation displays
iThe display unit can be changed to km
or miles using the control system (see
your vehicle Operator's Manual).


130 Navigation*Route guidanceThe circle
shows the current vehicle lo
-
cation. The arrow in the circle designates
the current driving direction.

The remaining route is highlighted in color.
Display example 2On the right-hand side of the display the
symbol for the next driving maneuver is in
-
dicated (here left turn).

On the very right is a distance bar. The
dark blue part of the bar and the informa
-
tion 700ft, in this example, indicate the
distance to the next driving maneuver.If available, the street following the driving
maneuver with its name is shown in the top
status bar (here
CHESTNUT
RIDGE
RD).
The destination is marked with a flag
on
the map, any stop-over destination is
marked with a flag

.
Changing map scaleThe currently selected map scale is shown
in the left-hand corner of the bottom status
bar
.
iWhen the display unit is set to miles,
the COMAND will indicate distances in
miles (mi) or feet (ft).

When the display unit is set to km, the
COMAND will indicate distances in kilo
-
meters (km) and meters (m). iThe colored highlight only appears
when the system has completed the
route calculation.
s
iThe display unit can be changed to km
or miles using the control system (see
your vehicle Operator's Manual).

When the display unit is set to miles,
COMAND will indicate distances in
miles (mi) or feet (ft).

When the display unit is set to km,
COMAND will indicate distances in kilo
-
meters (km) and meters (m).
