31 At a glance
Quick reference COMAND
Setting balance/fader
Open the main menu of the appropriate
operating mode
( page
27)
.

Press the
Bal/Fad
soft key.
The Balance/Fader menu is displayed.
Now you can set the balance and the
fader
( page
31)
.
A cross-hair cursor appears. The verti
-
cal line indicates the balance setting.
The horizontal line indicates the fader
setting.

Press

or

:
The cursor moves horizontally, adjust
-
ing the desired balance,
or
Press

or

:
The cursor moves vertically, adjusting
the fader.Storing new settings:

Press

or the
Back
soft key,
or
wait until the display changes.
For the following operating modes, differ
-
ent settings for bass and treble can be se
-
lected:
Radio (FM waveband)

Radio (AM waveband)

Radio (Weather Band)

Single CD

MP3

CD changer*

AUX

Satellite radio*

Navigation*
Bass and treble settings for navigation an
-
nouncements are found under “Adjusting
the acoustics for navigation announce
-
ments”
( page
109)
.
i Using
+
and
(
, the cursor can be
moved simultaneously in vertical and
horizontal direction (diagonally).
Bass and treble

32 At a glanceQuick reference COMANDWhen adjusting bass or treble, the system
automatically stores the setting for the
currently active operating mode.Setting bass and treble
Open the main menu of the appropriate
operating mode
( page
27)
.

Press the
Bass
or
Treble
soft key.
The Bass or Treble menu appears.

Press

or

.
The cursor moves horizontally, adjust
-
ing bass or treble accordingly.
Storing new settings
Press

or the
Back
soft key,
or
wait until the display changes.
If the vehicle is equipped with a sound sys
-
tem*, the sound functions are available for
the following operating modes:
Radio

Single CD

MP3

CD changer*

AUX

Satellite radio*
The following sound functions are avail
-
able:
Default
Settings
:
Resets the sound functions to the fac
-
tory setting.

Standard
:
Normal stereo playback.

Speech
:
Playback optimized for speech compre
-
hension.

LOGIC7
Surround
:
7-channel-surround playback (not for
mono-sources like AM waveband or
Weather Band in radio mode).
Different sound functions can be activated
for each one of the operating modes listed
above.
Sound functions*

38 AudioRadio operation
The following options are available:
Tuning via station search
( page
38)
.

Tuning via station presets
( page
39)
.

Tuning via Autostore presets

( page
40)
.

Tuning via scan search
( page
40)
.

Manual tuning
( page
41)
.

Tuning via direct frequency input

( page
41)
.
Tuning via station search On COMAND control unit
Switch to the desired FM or AM wave
-
band
( page
37)
.

Press
-
or

:
The next receivable ascending frequen
-
cy is tuned in and begins to play,
or
Press
,
or

:
The next receivable descending fre
-
quency is tuned in and begins to play.
On multifunction steering wheel
Switch the multifunction display in the
instrument cluster to the Radio display ( page
25)
.

Press
j:
The next receivable ascending frequen
-
cy is tuned in and begins to play,
or
iThe wavebands cover different fre
-
quency ranges.FM broadcast band:
FM (VHF = very high frequency)

87.7 - 107.9 MHz

Tuning increments 0.2 MHz
AM broadcast band:
MW (medium wave)

530 - 1710 kHz

Tuning increments 10 kHz
WB waveband:
WB (Weather Band)

162.400 - 162.550 MHz

Tuning increments = 1 channel
Tuning to a FM/AM station
iAudio search function
Freq.
must be
set in the multifunction display
( page
26)
.

39 Audio
Radio operation

Press
k:
The next receivable descending fre
-
quency is tuned in and begins to play.
Tuning via station presets Ten presets each are available for FM and
AM. On COMAND control unitThe presets are accessed using the num
-
ber keypad, or via the Presets menu.Accessing via number keypad:
Switch to the desired waveband ( page
37)
.

Press one of the number keys

3
- "
:
The system tunes to the station stored
under this number.
Accessing via Presets menu:
Switch to the desired waveband ( page
37)
.

Press the
Presets
soft key.
The Presets menu appears.

Use

,
,
or

to choose a
preset and press

,
or
Press one of the number keys

3
- "
.
The system tunes to the station stored
under this number.
On multifunction steering wheel
Switch the multifunction display in the
instrument cluster to the Radio display ( page
25)
.

Press
j.
The system tunes to the next station
stored in the station presets;
or
Press
k.
The system tunes to the previous sta
-
tion stored in the station presets.iAudio search function
Memory
must be
set in the multifunction display
( page
26)
.

40 AudioRadio operationTuning via Autostore presets The Autostore function allows placing of
stations into the presets sorted by recep
-
tion quality
( page
43)
.
The system will store the station with the
strongest signal in preset
1.
Ten presets each are available for FM and
AM.
Switch to the desired waveband ( page
37)
.

Press the
Autost.
soft key.
The Autostore preset list appears. It
can take several seconds until all fre
-
quencies are displayed.

Use

,
,
or

to choose a
preset and press

.
or
Press one of the number keys

3
- "
.
The system tunes to the station stored
under this number.
Tuning via scan search Scan search is characterized as follows:
Scan search performs two runs.

During the first run, stations with ex
-
tremely good reception are played.

During the second run, stations with
weaker reception are played.

Scan search plays each receivable sta
-
tion for approx. 8 seconds.

Scan search can be ended manually.

Scan search automatically stops at the
station listened to before the scan
search was started.
Starting scan search
Switch to the desired waveband ( page
37)
.

Press the
Scan
soft key.
Scanning begins.

41 Audio
Radio operation
Ending Scan search manually
Press the
Scan
soft key again.
Manual tuning
Switch to the desired waveband ( page
37)
.

Press and hold
-
or
,
for at
least 2 seconds to tune up or down.
Manual tuning is activated.

Keep the button pressed or release it
and keep tapping
-
or
,
in
quick succession.
The frequency will change by the tuning
increments for the respective wave
-
band each time one of the buttons is
pressed or for as long as a button is
pressed and held.

Manual tuning is deactivated if no but
-
ton is pressed for approx. 3 seconds.
Tuning via direct frequency input Entry example:

98.5 MHz in FM waveband
Switch to the FM waveband ( page
37)
.

Press
2
.
The frequency input display appears.
The frequency range of the FM wave
-
band is shown.
iManual tuning is also possible in all
wavebands by pressing

or

.
The frequency will change by the tuning
increments for the respective wave
-
band each time one of the buttons is
pressed.Frequency increments for manual

tuning:
FM
0.2 MHz

AM
10 kHz


42 AudioRadio operation
Press the number buttons in
succession:
!
,
, and

.
Each number entered appears in the
display.

The system tunes to the frequency en
-
tered (in this example: 98.5 Mhz) and
switches back to the FM menu.
Tuning via station search Seven channels are available on the
Weather Band.On COMAND control unit
Switch to the WB waveband by press
-
ing the
WB soft key in the Radio main
menu
( page
37)
.
The system will tune to the strongest
receivable station.

Press
-
or
,
.
Search begins in ascending or

descending frequency.The search stops at the next receivable
station.
On multifunction steering wheel
Switch the multifunction display in the
instrument cluster to Radio display ( page
25)
.

Press
j or
k.
The search stops at the next receivable
station. Tuning via station presetsThe seven strongest channels are sorted in
prest 1 to 7 each time you press the
WB soft
key. They are accessed using the number
keypad.

Press one of the number keys

3
-
.
The system tunes to the station stored
under this number.
iEntries outside the frequency range are
not possible.Within the AM waveband, the input is
restricted to frequencies within the re
-
spective frequency increment, which
is10 kHz.The system will select the nearest valid
frequency if a frequency outside the
frequency increment is entered.
Tuning to a station on Weather Band

46 AudioSingle CD operation
The COMAND CD drive holds one CD. The
slot for inserting a CD is located above the
display
( page
15)
.

Insert a CD into the CD slot while
COMAND is switched ON. Insert the
CD face up.COMAND pulls in the CD. If the CD is
an audio CD, the system switches to
Single CD mode.

Press
7
.
COMAND ejects the CD.

Remove the CD from the slot.The CD will be pulled in again if it is not
removed from the slot within approx. 7
seconds.

Open the Audio main menu ( page
36)
.

Press the
CD soft key.
The system switches to Single CD
mode.
!Only use CDs, which bear the label
shown and that conform to the com
-
pact digital audio standard

(IEC 60908).Do not play single-CDs (80 mm) with an
adapter. Only use round, 12 cm diame
-
ter CDs.Your CD drive has been designed to
play CDs which correspond to the IEC
60908 standard. Therefore only CDs
not exceeding a thickness of 1.3 mm
can be used.

If you insert thicker data carriers, e.g.
ones that have data on both sides (one
side with DVD data, the other side with
audio data), they cannot be ejected
and will damage the drive.
iThe COMAND CD drive may not be able
to play audio CDs with copy protection.!If a CD is already loaded, it must be
ejected before inserting the new CD.

Inserting a second CD in the slot with
another CD still loaded will cause dam
-
age to the CD drive not covered by the
Mercedes-Benz Limited Warranty.
iIf the CD is an MP3 CD, the system
switches to MP3 mode
( page
54)
.
Ejecting a CD Single CD main menu

47 Audio
Single CD operation
The center of the status bar shows:
The track number and total number
of tracks

The elapsed playing time of the
track
1Track title or track number2Elapsed track playing time3Track number/total tracks The Single CD main menu shows the track
title in the center if the CD contains corre
-
sponding CD text data.If the CD does not contain any CD text da
-
ta, the track number is displayed instead of
the track title.
The following options are available:
Selecting via track skip


Selecting via track list

Selecting via manual entry of the track number
( page
48)

Selecting via scan search
( page
49)
Selecting via track skip On the COMAND control unit
Open the Single CD main menu ( page
46)
.

Press
-
for forward skipping.
or
Press
,
for backward skipping.
iThe
CD soft key is shaded out if no audio
CD is loaded. The system will not
switch to Single CD mode.

Load an audio CD into the
COMAND CD drive
( page
45)
.
The
MP3
soft key instead of the
CD soft
key is visible when a MP3 CD has been
loaded.
Selecting a track

48 AudioSingle CD operationOn the multifunction steering wheel
Switch the multifunction display in the
instrument cluster to the Single CD dis
-
play
( page
25)
.

Press
j for forward skipping.
or
Press
k for backward skipping.
Selecting via track list The track list contains all tracks of the cur
-
rent CD. Only one list entry is visible at a
time, it is the track currently playing.
Use

or

to select another track
from the list.

Press

, or wait approx. 3 seconds
without changing the selection.
The selected track is played.
Selecting via manual entry of the track
number
Open the Single CD main menu ( page
46)
.

Press
2
.
The Manual track input display ap
-
pears. The number of tracks on the CD
is displayed.
iForward skipping:

The next track is played.Backward skipping:

The system skips back to the beginning
of the track if more than approx. 10
seconds playing time of the track cur
-
rently playing have elapsed.

The system skips back to the beginning
of the previous track if less than 10
seconds playing time of the track cur
-
rently playing have elapsed.
