MERCEDES-BENZ E-Class 2008 W211 Comand Manual

31 At a glance
Quick reference COMAND
Setting balance/fader
Open the main menu of the appropriate
operating mode
( page
27)
.

Press the
Bal/Fad
soft key.
The Balance/Fader menu is displayed.
Now you can set the balance and the
fader
( page
31)
.
A cross-hair cursor appears. The verti
-
cal line indicates the balance setting.
The horizontal line indicates the fader
setting.

Press

or

:
The cursor moves horizontally, adjust
-
ing the desired balance,
or
Press

or

:
The cursor moves vertically, adjusting
the fader.Storing new settings:

Press

or the
Back
soft key,
or
wait until the display changes.
For the following operating modes, differ
-
ent settings for bass and treble can be se
-
lected:
Radio (FM waveband)

Radio (AM waveband)

Radio (Weather Band)

Single CD

MP3

CD changer*

AUX

Satellite radio*

Navigation*
Bass and treble settings for navigation an
-
nouncements are found under “Adjusting
the acoustics for navigation announce
-
ments”
( page
109)
.
i Using
+
and
(
, the cursor can be
moved simultaneously in vertical and
horizontal direction (diagonally).
Bass and treble

32 At a glanceQuick reference COMANDWhen adjusting bass or treble, the system
automatically stores the setting for the
currently active operating mode.Setting bass and treble
Open the main menu of the appropriate
operating mode
( page
27)
.

Press the
Bass
or
Treble
soft key.
The Bass or Treble menu appears.

Press

or

.
The cursor moves horizontally, adjust
-
ing bass or treble accordingly.
Storing new settings
Press

or the
Back
soft key,
or
wait until the display changes.
If the vehicle is equipped with a sound sys
-
tem*, the sound functions are available for
the following operating modes:
Radio

Single CD

MP3

CD changer*

AUX

Satellite radio*
The following sound functions are avail
-
able:
Default
Settings
:
Resets the sound functions to the fac
-
tory setting.

Standard
:
Normal stereo playback.

Speech
:
Playback optimized for speech compre
-
hension.

LOGIC7
Surround
:
7-channel-surround playback (not for
mono-sources like AM waveband or
Weather Band in radio mode).
Different sound functions can be activated
for each one of the operating modes listed
above.
Sound functions*

33 At a glance
Quick reference COMAND
Example:

For CD mode: the
LOGIC7
Surround
func
-
tion,

for Satellite radio* mode: the
Speech
func
-
tion.Switching sound functions
Open the main menu of the appropriate
operating mode
( page
27)
.

Press the
Sound
soft key.
The Sound menu appears.

Use

or

to select the desired
function.

Press

.
The system switches to the selected
function.iYour harman/kardon
® audio system
features the innovative LOGIC7
® multi-
channel surround sound technology
developed for the professional record
-
ing industry.By selecting the “LOGIC7 Surround”
function, LOGIC7
® will be activated.
LOGIC7
® converts any 2-channel ma
-
terial into breathtaking multi-channel
surround sound and that without the
unnatural interpretation of many of to
-
day’s surround sound techniques.
iLOGIC7
® is not an artificial “effects”
button. It automatically adapts itself to
the incoming source material, adjust
-
ing the seven outputs based on the
original acoustic intent of the studio
master.harman/kardon LOGIC7
® creates a
true 360-degree “enveloping” sound
-
field with a maximum “audio sweet
-
spot” for all passengers. harman/kardon LOGIC7
® sets a new
benchmark in musical clarity and sepa
-
ration, giving the listener the impres
-
sion of actually “being there”.LOGIC7
® playback works with all con
-
ventional stereo audio sources (e.g.
stereo CD or stereo radio).

If the radio reception is poor, the sys
-
tem should be switched back to Stan
-
dard stereo playback. Switching back
to Standard stereo playback may im
-
prove reception quality.

34

35
Audio
Audio main menuRadio operation
Single CD operation
MP3 operation
CD changer* operation
Audio AUX operation

36 AudioAudio main menu
Press

.
The Audio main menu appears.If one of the Audio submenus appears:
Press the
Back
soft key as often as
necessary until the Audio main
menu appears,
or
Press

again.
Various audio sources can be selected in
the Audio main menu.

Radio
soft key

Station settings for WB, FM, and AM
wavebands appear
( page
37)

CD soft key or
MP3
soft key

The Single CD main menu
( page
46)

or the MP3 main menu
( page
55)
ap
-
pears

CDC
soft key

The CD changer main menu appears ( page
66)

AUX
soft key

Facilitates operation of an external au
-
dio source
( page
72)
Switching the mute function ON:
Press
1
.
The system is switched to mute.
Switching the mute function OFF:
Press
1
again,
or
Turn the rotary control
4
located on
the COMAND control unit,
or
Press
æ or ç on the multifunc
-
tion steering wheel.The audio source heard is the one se
-
lected before the mute function was
activated.
Opening the Audio main menu
Selectable soft keysiThe Satellite Radio menu is accessed
by pressing
5
( page
75)
.
Mute functioniThe mute function is still activated if
the system is switched off and then on
again.

37 Audio
Radio operation


Radio operation

Open the Audio main menu ( page
36)
.

Press the
Radio
soft key.
The Radio main menu appears. The sta
-
tion last tuned to will begin to play.
In this example:
Weather Band


Channel 1
= current station

Press the
FM/AM
soft key in the Radio
main menu.
Alternatingly the Radio main menu for
the FM or AM wavebands appears. The
station last tuned to will begin to play.
The waveband is indicated in the center
of the status bar.In this example:
FM = FM waveband

1 = selected station is stored on
preset 1
Safety InstructionsWarning
G
In order to avoid distraction which could
lead to an accident, the driver should enter
system settings with the vehicle at a stand
-
still and operate the audio system only when
road, weather and traffic conditions permit.Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate
-
ly 14 m) every second.Switching to radio mode
Switching wavebands

38 AudioRadio operation
The following options are available:
Tuning via station search
( page
38)
.

Tuning via station presets
( page
39)
.

Tuning via Autostore presets

( page
40)
.

Tuning via scan search
( page
40)
.

Manual tuning
( page
41)
.

Tuning via direct frequency input

( page
41)
.
Tuning via station search On COMAND control unit
Switch to the desired FM or AM wave
-
band
( page
37)
.

Press
-
or

:
The next receivable ascending frequen
-
cy is tuned in and begins to play,
or
Press
,
or

:
The next receivable descending fre
-
quency is tuned in and begins to play.
On multifunction steering wheel
Switch the multifunction display in the
instrument cluster to the Radio display ( page
25)
.

Press
j:
The next receivable ascending frequen
-
cy is tuned in and begins to play,
or
iThe wavebands cover different fre
-
quency ranges.FM broadcast band:
FM (VHF = very high frequency)

87.7 - 107.9 MHz

Tuning increments 0.2 MHz
AM broadcast band:
MW (medium wave)

530 - 1710 kHz

Tuning increments 10 kHz
WB waveband:
WB (Weather Band)

162.400 - 162.550 MHz

Tuning increments = 1 channel
Tuning to a FM/AM station
iAudio search function
Freq.
must be
set in the multifunction display
( page
26)
.

39 Audio
Radio operation

Press
k:
The next receivable descending fre
-
quency is tuned in and begins to play.
Tuning via station presets Ten presets each are available for FM and
AM. On COMAND control unitThe presets are accessed using the num
-
ber keypad, or via the Presets menu.Accessing via number keypad:
Switch to the desired waveband ( page
37)
.

Press one of the number keys

3
- "
:
The system tunes to the station stored
under this number.
Accessing via Presets menu:
Switch to the desired waveband ( page
37)
.

Press the
Presets
soft key.
The Presets menu appears.

Use

,
,
or

to choose a
preset and press

,
or
Press one of the number keys

3
- "
.
The system tunes to the station stored
under this number.
On multifunction steering wheel
Switch the multifunction display in the
instrument cluster to the Radio display ( page
25)
.

Press
j.
The system tunes to the next station
stored in the station presets;
or
Press
k.
The system tunes to the previous sta
-
tion stored in the station presets.iAudio search function
Memory
must be
set in the multifunction display
( page
26)
.

40 AudioRadio operationTuning via Autostore presets The Autostore function allows placing of
stations into the presets sorted by recep
-
tion quality
( page
43)
.
The system will store the station with the
strongest signal in preset
1.
Ten presets each are available for FM and
AM.
Switch to the desired waveband ( page
37)
.

Press the
Autost.
soft key.
The Autostore preset list appears. It
can take several seconds until all fre
-
quencies are displayed.

Use

,
,
or

to choose a
preset and press

.
or
Press one of the number keys

3
- "
.
The system tunes to the station stored
under this number.
Tuning via scan search Scan search is characterized as follows:
Scan search performs two runs.

During the first run, stations with ex
-
tremely good reception are played.

During the second run, stations with
weaker reception are played.

Scan search plays each receivable sta
-
tion for approx. 8 seconds.

Scan search can be ended manually.

Scan search automatically stops at the
station listened to before the scan
search was started.
Starting scan search
Switch to the desired waveband ( page
37)
.

Press the
Scan
soft key.
Scanning begins.
