Contents
Playback options. . . . . . . . . . . . . . . 70
Audio AUX operation . . . . . . . . . . . . . .
72
Satellite radio*. . . . . . . . . . . . . . . . . .
73
General information . . . . . . . . . . . . . . .
74
Introduction to Satellite radio . . . . .
74
Satellite radio operation . . . . . . . . . . . .
75
Switching to Satellite radio mode . .
75
SAT main menu . . . . . . . . . . . . . . . .
76
Selecting a station . . . . . . . . . . . . .
76
Obtaining additional text

information . . . . . . . . . . . . . . . . . . .
79
Storing stations . . . . . . . . . . . . . . .
80
Calling the Sirius Service Center . .
80
Telephone*. . . . . . . . . . . . . . . . . . . . .
81
Important notes . . . . . . . . . . . . . . . . . .
82
Safety Instructions . . . . . . . . . . . . .
82
Tips on telephone operation . . . . .
82
Telephone operation. . . . . . . . . . . . . . .
85
Switching the phone ON/OFF . . . .
85
911 emergency calls. . . . . . . . . . . .
85
Entering the PIN (only GSM) . . . . .
87
Entering the unlock code . . . . . . . .
88
Switching to telephone mode . . . .
88
Telephone main menu. . . . . . . . . . .
89
Answering an incoming call . . . . . .
90
Placing an outgoing call . . . . . . . . .
91
Accepted and missed calls . . . . . . .
92
Dialed calls . . . . . . . . . . . . . . . . . . .
94
Active call . . . . . . . . . . . . . . . . . . . .
95
Phone book . . . . . . . . . . . . . . . . . . . . .
97
Opening the phone book. . . . . . . . .
97
Selecting a phone book entry and es
-
tablishing a connection . . . . . . . . .
98
Adding spoken names to a phone book entry . . . . . . . . . . . . . . . . . . . . . . . .
99
Deleting a phone book entry . . . . .
99
SMS (Mail) . . . . . . . . . . . . . . . . . . . . .
100
SMS inbox . . . . . . . . . . . . . . . . . . .
100
Reading a message . . . . . . . . . . . .
101
Deleting a message . . . . . . . . . . .
102
Exiting from the SMS menu . . . . .
102
Navigation*. . . . . . . . . . . . . . . . . . . .
103
Important notes . . . . . . . . . . . . . . . . .
104
Safety Instructions . . . . . . . . . . . .
104
Navigation DVD. . . . . . . . . . . . . . .
105
Loading/ejecting the DVD . . . . . .
105
Travelling abroad. . . . . . . . . . . . . .
105
Route guidance with GPS . . . . . . .
106
Route guidance after

vehicle transport . . . . . . . . . . . . . .
106
Trip interruption during

route guidance . . . . . . . . . . . . . . .
106
Selection lists . . . . . . . . . . . . . . . .
107
Navigation main menu . . . . . . . . . . . .
108
Calling up the Navigation

main menu . . . . . . . . . . . . . . . . . .
108
Avoiding certain road types . . . . .
109
Adjusting the acoustics for

navigation announcements . . . . . .
109
Destination entry . . . . . . . . . . . . . . . .
112
Entering data. . . . . . . . . . . . . . . . .
112
Destination entry menu. . . . . . . . .
114
Entering a destination . . . . . . . . . .
115
Selecting the region . . . . . . . . . . .
115
Entering a city . . . . . . . . . . . . . . . .
116
Narrowing of the destination

after selecting city . . . . . . . . . . . .
117
Entering a city center . . . . . . . . . .
118
Entering a street in the

destination city . . . . . . . . . . . . . . .
119
Narrowing of the destination

after selecting street . . . . . . . . . . .
120

7
Where to find itIntroduction


Where to find it
This Operator's Manual is designed to pro
-
vide support for you, the COMAND opera
-
tor. Each chapter has its own guide color to
provide fast access to information.At a glanceHere you will find an overview of all
COMAND control elements and system
components. If you are operating
COMAND for the first time, or if you have
rented or borrowed the vehicle, this is the
chapter you should read first. AudioHere you will find all the information on
how to use the audio system and its radio
and CD components.
Satellite radio*This chapter contains all information relat
-
ed to the satellite radio system.Telephone*Here you can learn in detail about the
many functions of the telephone, SMS,
how to initiate an emergency call and use
service numbers. Navigation*This chapter provides detailed information
covering the following topics:
Destination entry

Route selection and calculation

Route guidance

Destination memory
ServiceThis chapter contains information con
-
cerning Tele Aid*.SystemThis chapter provides information on how
to adjust COMAND system settings.DirectoriesThe glossary explains the most important
technical terms.The table of contents and index directory
will help you quickly locate the information
you need.

9 Introduction
Operating safety


Operating safetyWarning
G
Any alterations made to electronic compo
-
nents and the software can cause malfunc
-
tions.The radio, amplifier, satellite radio*,
CD
changer*, navigation module*, tele
-
phone* and voice control system* are inter
-
connected. Therefore, when one of the
components is not operational or has not
been removed/ replaced properly, the func
-
tion of other components may be impaired.This condition might seriously impair the

operating safety of your vehicle.We recommend that you have any service
work on electronic components carried out
by an authorized Mercedes-Benz Center.
Warning
G
In order to avoid distraction which could
lead to an accident, the driver should enter
system settings with the vehicle at a stand
-
still and operate the system only when road,
weather and traffic conditions permit.Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate
-
ly 14 m) every second.COMAND supplies you with information to
help you select your route more easily and
guide you conveniently and safely to your
destination. For safety reasons, we encour
-
age the driver to stop the vehicle in a safe
place before answering or placing a call, or
consulting the COMAND screen to read nav
-
igational maps, instructions, or downloaded
information.
Warning
G
While the navigation system provides direc
-
tional assistance, the driver must remain

focused on safe driving behavior, including
attention to traffic and street signs, and
should utilize the system's audio cues while
driving.The navigation system does not supply any
information on stop signs, yield signs, traffic
regulations or traffic safety rules. This al
-
ways remains your personal responsibility
when you drive. DVD maps do not cover all
areas nor all routes within an area.

27 At a glance
Menu system


Menu system
The menu system allows for easy opera
-
tion of COMAND.Each of the following main functions has a
main menu:
Audio

(Radio, Single CD, CD changer* and
AUX mode)

Satellite radio*

Telephone*

Navigation*

Service
Opening main menus
Audio
( page
36)
:
Press

.

Satellite radio*
( page
73)
:
Press
5
.

Telephone*
( page
89)
:
Press

.

Navigation*
( page
108)
:
Press

.

Service
( page
159)
:
Press

.
Menu display A display can be composed of 3 sections.Example: Radio main menu1Soft key sections2Main area3Status barThe functions currently assigned to the
soft keys are displayed in the soft key sec
-
tions 1.
Messages or settings are displayed in the
main area 2.

The settings can be changed by operating
controls accordingly.The status bar 3 is divided into three ar
-
eas.Left side:

The selected operating mode is given. In
this example: RadioCenter:

Indication of the selected operating mode.In this example:

FM = selected waveband

1 = selected station is stored on
preset 1
iA maximum of five soft keys may be
displayed on each side of the main area
2.

29 At a glance
Quick reference COMAND


Quick reference COMAND
Switching ON
Turn the key in the steering lock to po
-
sition 1 or 2,
or

Press
.
.
COMAND switches on the last active
system and displays the corresponding
menu.
Switching OFF
Turn the key in the steering lock to po
-
sition 0 and remove it,
or
Press
.
.
Different volume settings are possible for
Navigation*, Telephone*, or Voice con
-
trol*.A common volume setting is provided for
Radio, Single CD, MP3, CD changer*, AUX
and Satellite radio* operating modes.When setting the volume, the system auto
-
matically stores the setting for the current
-
ly active operating mode. The volume of
navigation announcements can be
changed only during an actual announce
-
ment.
iThe system can be operated as follows:
from COMAND itself, or

from the multifunction steering
wheel
This operating manual describes oper
-
ation from COMAND and from the mul
-
tifunction steering wheel.

Unless otherwise specified, the de
-
scriptions and the displays illustrated
relate to the COMAND control unit.Switching ON/OFF
iWithout the key in position 1 or 2 of the
steering lock, the system automatically
switches OFF again after approx. 30
minutes of inactivity.
iIf a telephone call is in progress (hands
-
free) you cannot switch the COMAND
OFF,
.
is disabled.
Volume

30 At a glanceQuick reference COMANDSetting the volume
Turn the rotary control
4
located on
the COMAND control unit,
or
Press
æ or ç on the multifunc
-
tion steering wheelThe volume changes up or down, de
-
pending on the direction of rotation or
which button was pressed.The system stores the volume settings
when the device is switched OFF.

After switching the system back on again,
the volume may be lower than at the time
when the system was switched OFF.
This could be the case if:
the system was switched OFF for more
than 15 minutes, and

the volume had been set to a value in a
certain range at the time the device
was switched OFF.
Automatic volume control The automatic volume control adjusts the
volume depending on
the vehicle’s speed (only in vehicles
without Sound-system*),or onthe interior ambient noises of the vehi
-
cle (only in vehicles with Sound-sys
-
tem*)

other parameters (e.g. windows open
or closed)
A common balance and fader setting ap
-
plies to the following operating modes:
Radio

Single CD

MP3

CD changer*

AUX

Satellite radio*
When adjusting the balance or the fader,
the system automatically stores the set
-
ting for the currently active operating
mode.Balance and faderiFor Navigation* a different balance/
fader setting is possible. You find the
description under “Adjusting the
acoustics for navigation announce
-
ments”
( page
109)
.

31 At a glance
Quick reference COMAND
Setting balance/fader
Open the main menu of the appropriate
operating mode
( page
27)
.

Press the
Bal/Fad
soft key.
The Balance/Fader menu is displayed.
Now you can set the balance and the
fader
( page
31)
.
A cross-hair cursor appears. The verti
-
cal line indicates the balance setting.
The horizontal line indicates the fader
setting.

Press

or

:
The cursor moves horizontally, adjust
-
ing the desired balance,
or
Press

or

:
The cursor moves vertically, adjusting
the fader.Storing new settings:

Press

or the
Back
soft key,
or
wait until the display changes.
For the following operating modes, differ
-
ent settings for bass and treble can be se
-
lected:
Radio (FM waveband)

Radio (AM waveband)

Radio (Weather Band)

Single CD

MP3

CD changer*

AUX

Satellite radio*

Navigation*
Bass and treble settings for navigation an
-
nouncements are found under “Adjusting
the acoustics for navigation announce
-
ments”
( page
109)
.
i Using
+
and
(
, the cursor can be
moved simultaneously in vertical and
horizontal direction (diagonally).
Bass and treble

74 Satellite radio*General informationSirius Satellite Radio provides 100 chan
-
nels, so called streams, of digital-quality
radio, among others music, sports, news,
and entertainment free of commercials.
Sirius Satellite Radio uses a fleet of high-
power satellites to broadcast 24 hours per
day, coast-to-coast, in the contiguous US.This diverse, satellite-delivered program
-
ming is available for a monthly subscrip
-
tion fee.

For more information and service availabil
-
ity call the Sirius Service Center ( page
80), or contact

www.siriusradio.comProgram categoriesThe channels are categorized. Categories
allow you to tune to stations broadcasting
a certain type of program (category mode) ( page
77)
.
Category selection
ALL
contains the sta
-
tion list of all receivable channels (channel
mode)
( page
77)
.
Introduction to Satellite radio
iAdditional optional satellite radio
equipment and a subscription to satel
-
lite radio service provider are required
for the satellite radio operation de
-
scribed in this chapter.

Contact your authorized Mercedes-
Benz Center for details and availability
for your vehicle.Note that categories and channels
shown in illustrations are dependent on
programming content delivered by the
service provider. Programming content
is subject to change. Therefore, chan
-
nel and categories shown in illustra
-
tions and descriptions contained in this
manual may differ from the channels
and categories delivered by the service
provider.
iSatellite radio service may be unavail
-
able or interrupted from time to time
for a variety of reasons, such as envi
-
ronmental or topographic conditions
and other things we can't control. Ser
-
vice might also not be available in cer
-
tain places (e.g., in tunnels, parking
garages, or within or next to buildings)
or near other technologies.

77 Satellite radio*
Satellite radio operation
Tuning via station presets Ten Satellite radio station presets are
available.

You can access the presets via number
keys or via the Presets menu.Accessing via number keys
Press one of the number keys

3
- "
.
The system will tune to the station
stored under this number.
Accessing via Presets menu.
Press the
Presets
soft key.
The Presets list appears.

Use

or

to choose a preset and
press

,
or
Press one of the number keys

3
- "
.
The system tunes to the station stored
under this number.
Tuning via manual channel inputExample: Tuning in channel 12
Press
2
.

Press
3
and

.
The system tunes to channel 12.
Tuning via the program category list The category list contains all currently re
-
ceivable categories of programs. It is sort
-
ed alphabetically.Only one entry is visible at a time. The en
-
try appears at the top of the main screen.Selecting a category Example 1: category
ALL

The station list of category
ALL
contains all
receivable channels (channel mode).

Use

or

to select the category
All
from the list.
iThe Presets memory is empty at first-
time activation of the system.
iIf an entry is made and such a channel
is not available, the message
Channel

unavailable
appears. The channel se
-
lected last continues playing.


145 Navigation*
During route guidance
You can set the following to be displayed in
the status bar:
Time of arrival/Dist. to Dest.

If the full-screen map display is activat
-
ed
( page
131)
, the estimated time of
arrival and the remaining distance to
the destination will be displayed. If you
have entered a stopover destination ( page
140)
, the corresponding data
will be displayed.

Current-Location display

If the full-screen map display is activat
-
ed
( page
131)
, the following data will
be displayed:
The current position as coordi
-
nates.

The number of satellites that can
currently be received.

The current elevation (ALT = alti
-
tude) above sea level.

No display

The name of the current road is dis
-
played.

In the Display menu
( page
143)
,
press the
Map
soft key.
The possible options appear.

Use

or

to select the desired
option.

Press

.
The map display is switched.

Finally, press the
Back
soft key or wait
for the screen to change.
iDuring route guidance, a symbol will
appear on the left-hand side of the bot
-
tom status bar if map display is
switched ON.
North symbol
:
Fixed map orientation, north is al
-
ways pointing up,

Compass symbol
:
Dynamic map orientation, driving
direction is always pointing up.
Map display menu
iThe COMAND uses GPS to calculate
the elevation above sea level. For rea
-
sons of tolerance, this value may devi
-
ate from the actual value.
iThe solid circle
shows the current
setting.
