127 Navigation
Destination input
Activating the street listStreet list21Street previously selected
22Display the previous page, if :
23Display the next page, if ;If the input menu “Street Entry” is display-
ed

Press the right-hand rotary/push-
button v longer than 2 seconds.
or

Turn the right-hand rotary/push-button
v to highlight menu field 20 with and
press to confirm.
The street list appears.
Here you can, as in the city list
(page 125), select another street or
display the previous/next page.

Press the right-hand rotary/push-
button v longer than 2 seconds.
This will confirm city/suburb and street
of the desired destination. The selec-
tion menu “Destination Entry” appears.
P82.85-9169-31
212223
iIf several options of a street are availab-
le, another menu will appear where you
must make and confirm your desired
selection.

128 NavigationDestination input“Destination Entry” selection menu1Adding an intersection
2Adding a house number
3Selecting a destination via the map
(
page 131)
4Saving a destination address in the
destination memory (
page 175)
5Confirming the destination and the cal-
culating route (
page 141)You have now selected the destination and
can define your destination address more
precisely in the following manner:


Adding an intersection


Adding a house number


Selecting it via the map (
page 131)


Selecting a city center, if you do not
want to select a street (
page 130)
or
Confirm the destination and calculate the
route (
page 141)

Press the right-hand rotary/push-
button v to confirm “OK” in the menu
“Destination Entry”.Adding an intersection
If the menu “Destination Entry” is display-
ed

Turn the right-hand rotary/push-button
v to highlight 1 and press to confirm.
A list of roads intersecting with the pre-
viously input street will appear.
Continue destination input
P82.85-9170-31
1
2
3
4
5
iIn order to do so, “House no.” must be
shown in black.

129 Navigation
Destination input

Turn the right-hand rotary/push-button
v to highlight the name of the inter-
section.

Press the right-hand rotary/push-
button v to confirm the selection.
The selection menu “Destination Entry”
will appear, indicating the intersection.

Press the right-hand rotary/push-
button v longer than 2 seconds to cal-
culate the route (
page 141).Adding a house number
Depending on the data stored on the navi-
gation CD, you can add a house number to
the destination address.
In order to do so, the menu field “House
no.” must be shown in black in the selec-
tion menu “Destination Entry”.

Turn the right-hand rotary/push-button
v to highlight 2 and press to confirm.
An input menu will appear.

Turn the right-hand rotary/push-button
v to highlight the desired numbers
one after the other and press to con-
firm.
The numbers will appear in the input
line.

Press the right-hand rotary/push-
button v longer than 2 seconds.
A list will appear.
iThe previous/next page can be display-
ed as described for the city list
(page 125).
P82.85-9172-31

136 NavigationDestination inputConfirming coordinate destination
Press the right-hand rotary/push-
button v longer than 2 seconds.
The above display appears.Starting the adjustment mode

Turn the right-hand rotary/push-button
v to highlight “OK” and press to con-
firm.
Store the coordinate destination in the
destination memory with a name

Turn the right-hand rotary/push-button
v to highlight “Save” and press to
confirm.
This will activate the destination me-
mory (
page 175).Activate the map with crosshairs

Turn the right-hand rotary/push-button
v to highlight “Map” and press to con-
firm.
This will activate the map
(page 132).
P82.85-9180-31

137 Navigation
Destination input
This function allows you to select Points of
Interest such as gas stations, parking faci-
lities or shopping centers.“Points of Interest” selection menuSelect a Point of Interest
1Around the current area of vehicle loca-
tion
2Around the previous destination area
3In the surrounding area of another city
4As regional destination, e.g. airport

Turn the right-hand rotary/push-button
v to highlight “Special destinations”
in the main destination input menu and
press to confirm.
The selection menu “Point of Interest”
will appear.

Turn the right-hand rotary/push-button
v to highlight 1 to 4 and press to con-
firm.
1, 2, 4 A Category list will appear
3 The input menu “City/Area”
will appear (
page 139)Around the current area of vehicle loca-
tion or previous destination area
Category list5Display previous page, if :
6Display next page, if ;
Entering Points of Interest
P82.85-9182-31
56

138 NavigationDestination input
Turn the right-hand rotary/push-button
v to highlight 1 or 2 and press to con-
firm.
The list “Select Category” will appear.

Turn the right-hand rotary/push-button
v to highlight the desired category
and press to confirm.
A corresponding list will appear.
7Point of Interest entry with distance to
destination in miles (as the crow flies)
8Symbol for long entry
9Complete entry in a windowDisplay the entry in full in a window 9

Press u.

Press u again to remove 9.
Selecting the desired destination

Turn the right-hand rotary/push-button
v to highlight the entry in the selec-
tion list and press to confirm.

Then calculate the route (
page 141).
iNot all Points of Interest may be listed
on the CD.
P82.85-9183-31
7
8
9

141 Navigation
Destination input
This function allows you to display up to 12
destinations you last selected.
1Destination selected last

Turn the right-hand rotary/push-button
v to highlight “Last destinations...” in
the main destination input menu and
press to confirm.
The list “Last destinations...” will ap-
pear.

Turn the right-hand rotary/push-button
v to highlight the desired destination
and press to confirm.

Then calculate the route.First select the calculation mode and then
calculate your route.
Selecting calculation mode
COMAND calculates the route either as
the Fast Route 1 or Short Route 2 whereby
traffic routes 3, 4 and 5 can be included or
avoided (with several selections).
Selecting the last destinations
P82.85-9190-31
1
Calculating a route

143 Navigation
Destination input
7Calculation method
8Destination
Cancel route calculation
Turn the right-hand rotary/push-button
v to highlight “Cancel” and press to
confirm.
The main destination input menu will
appear.During the calculation, the symbol display
will appear after a few seconds.
9Calculation of route
10Arrow indicating the direction to the
destination (as the crow flies)
11Distance to the destination (as the
crow flies)The route will be calculated. COMAND
identifies the road you are travelling on.
Position 12 now indicates the driving di-
rection.
You will e.g. hear the voice output “Please,
make the next right turn”.
P82.85-9192-31
78
P82.85-9194-31P82.85-9194-31
12

145 Navigation
Route guidance
Function
Page
1
Name of the street onto
which you should turn orDistance to destination orName of the route
(e.g. I-695) and direction
of travel to follow (e.g.
North)
154
155
155
2
Arrow indicating driving
direction or

Destination direction


Symbol for new cal-
culation of the route


Destination flag
154
168
170
3
Name of the street on
which you are travelling
149
4
Other display types

Distance bar to the
next maneuver


Distance to the next
maneuver in miles
154
155


“OFF MAP” - vehicle
is located outside of
the digitized map
area


“OFF ROAD” - vehicle
is located on a road
which is not digitized


“DEST AREA” - vehic-
le is approaching the
destination, the des-
tination area is not di-
gitized


“CALC. ROUTE” - a
route is being calcu-
lated
143


“NEW ROUTE” - an
existing route is
being recalculated


“NO ROUTE” - the
COMAND is unable
to calculate a route
170
Function
Page
5
Activating the map
Route guidance is active:
You can also press l.
156
6
Marking a way point
160
7
Mixture of map and sym-
bol display
157
8
Activating the symbol
display
Route guidance is active:
You can also press l.
156
9
Selecting
map orientation
159
10
Current map scale
158
11
Current vehicle location
with route (blue line)
151
12
Destination flagFunction
Page

146 NavigationRoute guidanceAfter the destination is selected and the
route is calculated, the navigation system
will guide you to the destination using both
pictorial displays and voice outputs.
During route guidance, you can select the
following 3 screen displays:

Symbol display
Always appears after a route has been
calculated


Map display
Activate the map with menu field 5,
switch back to symbol display with
menu field 8


Mix
Before the vehicle makes a turn,
COMAND switches automatically from
the map to the symbol display.
Once the turn has been completed, the
map is displayed again.
iIn the map display, menu fields 6, 8, 9
are removed after 6 seconds.
Turn the right-hand rotary/push-button
v to display the menu fields again.
iThe map appears automatically after 5
seconds if the vehicle is located on a
road which is not digitized (message
OFF ROAD).
If COMAND recognizes a stored road,
the symbol display is called up again.
